Transductive Support Vector Classification for RNA Related Biological Abstracts

1
Transductive Support Vector Classification for
RNA Related Biological Abstracts

• Blake Adams
• Graduate Student
• Department of Computer Science
• Advisor Dr. Muhammad A. Rahman

2
Overview

• Statistical Learning Theory
• Support Vector Machines
• Linear Separability
• Project Motivation/Concept
• Expectations
• Program Design / Algorithm Implementation
• Results
• Demonstration
• Acknowledgements
• Questions Answers

3
Statistical Learning Theory

• Introduced by Vladimir Vapnik and Alexey
  Chervonenkis
• 4 major areas
• Theory of consistency of learning processes
• What are the necessary conditions for consistency
  of a learning process?
• Nonasymptotic theory of the rate of convergence
  of learning processes
• How fast is the rate of convergence of the
  learning process?
• Theory of controlling the generalization ability
  of learning processes
• How can one control the rate of convergence
  (generalization) of the learning process?
• Theory of constructing learning machines
• How can one construct algorithms that can control
  the generalization ability?
• This concept introduced the support vector
  machine.

4
Support Vector Machines

• The Support Vector Machine is a classification
  technique that is receiving heavy attention due
  to its precision classification.
• It has been especially in successful in text
  categorization
• Also showing good results in image recognition
  such as face and fingerprint identification.

5
Precision Through SVM

• Support Vector Machines express machine learning
  through supervised statistical learning theory.
  The technique works with high-dimensional data
  and avoids the pitfalls of local minima. It
  represents decision boundaries using a subset of
  training examples known as support vectors

6
Structural Risk Minimization

• Support vector machines are based on the
  Structural Risk Minimization principle. The idea
  of structural risk minimization is to find a
  hypothesis h for which we can guarantee the
  lowest true error.
• The true error of h is the probability that h
  will make an error on an unseen and randomly
  selected test example.

7
How does SVM work?

• Uses training data to create a set of plot points
  that can be mapped out and used to predict the
  status of future information.
• Finds a hyperspace surface H, which separates
  positive and negative examples with the maximum
  distance.

8
Linearly Separable Data

• Linearly Separable Datasets ? and ?
• Hyper-plane of separation
• Decision boundaries

9
Consequences of hyper-plane selection

• Maximizing decision boundary margins for best
  success.

10
Research Motivation

• Keyword searches have become the norm for finding
  information in large bodies of documents but such
  searches often prove to be highly Imprecise.
• Example
• PubMed is a service of the National Library of
  Medicine that includes over 15 million citations
  from MEDLINE and other life science journals for
  biomedical articles back to the 1950s. PubMed
  includes links to full text articles and other
  related resources. This site adds new citations
  on a daily basis.
• http//www.ncbi.nlm.nih.gov/entrez/query.fcgi?CMD
  searchDBpubmedtermmRNA
• A search on the expressions RNA and Ribosomal
  Nucleic Acid at Pubmed earlier in the semester
  (geared towards finding articles SPECIFICALLY
  about RNA research) yielded a success rate of 38
  based on a review of the first 50 abstracts.
• What can be done to improve the precision of
  searches in such large bodies of documents?

11
Expectations

• It is resonable to presume that Support Vector
  Machines yield statistically significant
  improvements over this success rate at a minimal
  cost to the user.
• If a user was able to request a body of documents
  on a keyword from such a database, and then read
  a small subset of abstracts, identifying positive
  and negative examples, then a Support Vector
  Machine could be used to key on they articles the
  user is interested in reading.

12
Learning Technique

• One of the short comings of traditional SVM is
  its implementation of Inductive Learning. (the
  process of reaching a general conclusion from
  specific examples). While this method is highly
  effective when applied properly, it often
  requires SEVERAL examples (at least hundreds,
  preferably thousands) in order for it to return
  good results.

13
Learning Technique

• Transductive Learning
• Implemented by Thorsten Joachims Author of
  SVM-Light
• Well known for his work with Support Vector
  Machines and Text-Categorization and highly
  regarded as one of the foremost authorities on
  the subject.
• Transductive Learning takes into account a
  specific set of data and attempts to minimize
  error for that specific set based on a minimal
  number of training examples.

14
Implementing Support Vector Machines

• Fortunately, Joachims SVM-Light already
  successfully implements Transductive Learning,
  thus in this project it was not my task to
  reinvent the wheel of Support Vector Machines,
  but to develop a set of software tools to convert
  sets of articles into training and testing data
  that can be read and learned by svm-light.
• http//svmlight.joachims.org/

15
Using SVM Light

• Requires specific formatted input.
• Things needed by SVM Light user
• Feature Set
• Scoring method
• Training data file
• Testing data file
• Things SVM-Light Generates
• Model file
• Predictions file.

16
Feature Set

• Features can be defined in many ways
• Single words
• ANY word that appears in more than one document
  relating to a particular subject (Bag of words
  approach).
• Terms
• Topic specific ribosomal nucleic acid,
  translation, interference, genetic.
• Combination
• Any method including both concepts such as a
  weighing scheme that allows more weight to
  words that also classify as terms.

17
Scoring Method

• Every feature needs a corresponding value that
  represents that particular features impact in
  the given example.
• A popular method of feature scoring (and the one
  implemented in this project) is Term Frequency
  Inverse Document Frequency
• TF X Log(N/ DF)
• TF Total number of times the term occurs in the
  document
• N Total number of documents in the corpus
• DF Total number of documents in the corpus that
  contain the term.

18
Generating Training Sets for Transductive Learning

• File Format
• ltexpected outcomegt ltfeaturegtltvaluegt
  ltfeaturegtltvaluegt ltfeaturegtltvaluegt
• Feature values must also be organized from lowest
  to highest
• Thus a completed train file might look something
  like
• 1 12.8473 23.8324 95.423 191.003
• 1 41.11 95.423 110.012
• 1 12.84734 1510.9213 219.343 447.7231
• -1 18.8473 23.8324 95.423 191.003
• -1 45.135.423 110.012 2819.6548
• -1 12.84734 1510.9213 219.343 447.7231
• 0 10.8473 93.84 195.423 291.00
• 0 41.11 95.423 110.012
• 0 22.84734 1510.9213 219.343 227.7231
• 0 14.5473 26.7324 95.42
• 0 41.11 95.423 110.012
• 0 12.84734 1510.9213 219.343 447.7231
• 0 195.1864 247.215 2812.123

19
Generating Test Sets for Transductive Learning

• Since Transductive Learning works with a
  pre-established set, the test file has the exact
  same format. The only difference being that the
  expected outcomes originally set to 0 are
  now set to their actual value so that the system
  can test how well it predicted the outcomes.

20
Key Experiments

• How well can SVM Light transductively
• Distinguish between abstracts that ARE and ARE
  NOT about RNA
• Distinguish between abstracts that ARE and ARE
  NOT about each of the following types of RNA
• messenger RNA
• ribosomal RNA
• transfer RNA
• small nuclear RNA
• Glean abstracts about a specific type of RNA from
  a body abstracts that are all RNA-centric.

21
Implementation

• In order to implement this project two key
  elements were collected
• A corpus of abstracts was collected and
  categorized manually from the Pubmed database.
  These articles fell into the following
  categories
• 40 abstracts specific to RNA research AND
  containing the term RNA.
• 40 abstracts not specific to RNA research AND
  containing the term RNA.
• 40 abstracts specific to messenger RNA research
  AND containing the term mRNA.
• 40 abstracts not specific to messenger RNA
  research AND containing the term mRNA.
• 40 abstracts specific to transfer RNA research
  AND containing the term tRNA.
• 40 abstracts not specific to transfer RNA
  research AND containing the term tRNA.
• 40 abstracts specific to ribosomal RNA research
  AND containing the term rRNA.
• 40 abstracts not specific to ribosomal RNA
  research AND containing the term rRNA.
• 40 abstracts specific to small nuclear RNA
  research AND containing the term snRNA.
• 40 abstracts not specific to small nuclear RNA
  research AND containing the term snRNA.
• This resulted in a GRAND TOTAL corpus of 400
  abstracts.

22
Implementation

• Term Dictionary
• A dictionary of terms specific to each topic was
  developed based on these terms relevance to the
  particular set of abstracts (ex messenger RNA
  abstracts would correspond to a dictionary that
  contained the term messenger but small Nuclear
  RNA abstracts would not).

23
Implementation

• Pre-processing
• Prior to conversion from abstract to
  feature/value sets, a limited amount of
  pre-processing was implemented
• All special characters were removed from the
  abstracts including parentheses, commas, periods,
  apostrophes, colons, semicolons, dashes, etc.
• Articles were sorted into an arrangement of all
  positive abstracts followed by all negative
  abstracts. This was done to facilitate
  identification of positive and negative abstracts
  by the software tools during generation of
  training and testing sets. It should be
  mentioned that the order of feature sets has no
  bearing on learing.

24
Implementation

• Software Development Package Java
• 2 Major Data Structures
• TreeMap Containing Term objects that
  represent every term feature in every document in
  the corpus of documents.
• Term object Actual Term, Unique Term Id,
  Document Id, term frequency score, document
  frequency score. Objects are keyed by an id that
  combines the term Id with the document Id.
• TreeMap Containing TermDF objects that
  represent individual features as they enter the
  program.
• TermDF objects contain the actual term, the
  document frequency score and the last document id
  that contained the term as a placeholder.
• Once each Map is constructed, the TermDF map is
  cross-referenced with the Term map to set the DF
  score to the appropriate value in each term.

25
Algorithm/Implementation

• The set of tools for this project were developed
  in Java. Programmatic implementation included
  the following steps
• Read a set of abstracts and a term dictionary
  from file.
• Tokenize abstracts and test every tokenized word
  against the term dictionary.
• If the token exists in term dictionary it must be
  search for in the current corpus set of terms
  to see if it has been added.
• If the feature is not found in the current set,
  it is added, id-ed, and the TF and DF are
  initialized to 1
• If the feature is found in the current set, the
  current document count is checked to determine
  whether the term is an initial occurrence in a
  new document or a subsequent occurrence in the
  current document
• If it is an initial occurance in a new document,
  DF is incremented, and TF for the term in the
  current article is set to one.
• If it is a subsequent occurrence, the DF remains
  unchanged and the TF for the current article is
  incremented by one.
• Once EVERY term for EVERY abstract is accounted
  for, the TF/IDF for each term can be calculated.
• Finally, the data structure is reorganized to
  arrange feature VALUES from lowest to highest for
  each feature set.

26
Mapping a Feature
Tokenized Word
Is it in the Term Map?
No
Yes
Is it in the keyword list?
Is word in current document?
Yes
Increment termFreq
No
Yes
No
Assign id, docID, set termFreq to 1
Increment docFreq
Is it in the TermDocFreqMap?
Do Nothing
Yes
Assign featureId, set docFreq to 1, assign
lastDocId
Yes
No
Is word in current document?
Increment docFreq
Discard
No
27
Implementation

• So THIS
• All organisms sense and respond to conditions
  that stress their homeostatic mechanisms Here we
  review current studies showing that the nucleolus
  long regarded as a mere ribosome producing
  factory plays a key role in monitoring and
  responding to cellular stress After exposure to
  extra or intracellular stress cells rapidly down
  regulate the synthesis of ribosomal RNA
• Becomes THIS
• 1 25.619650483261998 50.17733401528291545
  61.869439496743316 120.7184649885442351
  133.0441924140622225 252.772588722239781
  503.283414346005772 516.566828692011544

28
Implementation

• All experiments were conducted in sets of 80
  abstracts, with 5 positive and 5 negative
  training examples. Additionally, 35 positive and
  35 negative examples were included but unlabeled
  during the training phase to allow to program to
  make a decision on where the feature set should
  fall in order to minimize error.

29
Results and Conclusions

• The outcome for every experiment far outpaced the
  highest expectations of the researchers.
• Following examination of misclassified abstracts
  from the first set of results, some abstracts
  were found to have been misclassified by the
  manual classifiers. Correcting these errors led
  to even better results.
• It is the belief of the researchers that
  incorporating such a system into a database like
  pubmed would allow users to query a term on a
  keyword, and then use the support vector machine
  to narrow the results into the specific
  information the user is looking for, allowing the
  user to maximize the use research time.

30
Demonstration
31
Future Work

• Future work in this project will address
• Precision in feature selection
• Web Interface to tie application to real results

32
Acknowledgements

• Dr Muhammand A Rahman Assistant Professor,
  University of West Georgia
• Dr Goran Nenadic Assistant Professor,
  University of Manchester
• Thorsten Joachims Assistant Professor, Cornell
  University
• The Department of Computer Science University
  of West Georgia

33

• Questions
• ?
