Title: Introduction to MPI


1
Introduction to MPI
  • Eric Aubanel
  • Advanced Computational Research Laboratory
  • Faculty of Computer Science, UNB
  • Fredericton, New Brunswick

2
(No Transcript)
3

4
Goals
  • How to decompose your problem to solve it in
    parallel?
  • What patterns of communication arise in solving
    problems?
  • What is a minimal subset of commands necessary to
    do parallel computing?
  • What is the MPI syntax?
  • Hello world example
  • What is collective communication?
  • Matrix multiply example
  • How to distribute the work evenly among the
    processors
  • Static dynamic load balancing with fractals

5
Is Parallelism For You?
The nature of the problem is the key contributor
to ultimate success or failure in parallel
programming
6
Problem Architectures
  • Type of decomposition dictated by the problems
    architecture
  • Perfect Parallelism
  • wholly independent calculations
  • Seismic Imaging, fractals (see later)
  • Pipeline Parallelism
  • overlap work that would be done sequentially
  • simulation followed by image rendering
  • Fully Synchronous Parallelism
  • future computations or decisions depend on the
    results of all preceding data calculations
  • weather forecasting
  • Loosely Synchronous Parallelism
  • Processors each do parts of the problem,
    exchanging information intermittently.
  • contaminant flow

easier
harder
7
Perfect Parallelism
Site A data
Site B data
Site C data
Site A image
Site B image
Site C image
8
Pipeline Parallelism
Seismic Imaging Application
9
Synchronous Parallelism
10
Three steps to a successful parallel program
  • 1. Choose a decomposition and map to the
    processors
  • perfectly parallel, pipeline, etc.
  • ignore topology of the system interconnect and
    use the natural topology of the problem
  • 2. Define the inter-process communication
    protocol
  • specify the different types of messages which
    need to be sent
  • see if standard libraries efficiently support the
    proposed message patterns.
  • 3. Tune alter the application to improve
    performance
  • balance the load among processors
  • minimize the communication-to-computation ratio
  • eliminate or minimize sequential bottlenecks (Is
    one processor doing all the work while the others
    wait for some event to happen?)
  • minimize synchronization. All processors should
    work independently where possible. Synchronize
    only where necessary

11
Domain Decomposition
  • In the scientific world (esp. in the world of
    simulation and modelling) this is the most common
    solution
  • The solution space (which often corresponds to
    real space) is divided up among the processors.
    Each processor solves its own little piece
  • Finite-difference methods and finite-element
    methods lend themselves well to this approach
  • The method of solution often leads naturally to a
    set of simultaneous equations that can be solved
    by parallel matrix solvers

12
Domain Decomposition Pictured
13
Finite Element Decomposition
  • Cover the whole domain with finite elements, then
    break up the car in various places depending on
    how many processors you are likely to have
  • Each subdomain proceeds independently except on
    the boundaries between processors
  • Challenging for dynamic codes (e.g. crash
    simulations) since the shape of the car changes.
    Elements that were not close together at the
    beginning may come into close proximity
  • Decomposition may have to change as the
    calculation proceeds

14
Gravitational N-Body Problem
Given a box containing N particles that interact
with each other only through gravitational
attraction, describe the trajectory of the
particles as a function of time.
15
Solution to Gravitational N-Body Problem
  • Calculate the force and acceleration on each
    particle
  • Update each particles velocity and position
  • One parallel solution spatial decomposition

16
Spatial Decomposition of N-Body Problem
What happens when all the particles start
condensing in one of the small boxes?
17
Particle Decomposition of N-Body Problem
18
Message Passing Model
  • We have an ensemble of processors and memory they
    can access
  • Each processor executes its own program
  • All processors are interconnected by a network
    (or a hierarchy of networks)
  • Processors communicate by passing messages
  • Contrast with OpenMP implicit communication

19
The Process basic unit of the application
  • Characteristics of a process
  • A running executable of a (compiled and linked)
    program written in a standard sequential language
    (e.g. Fortran or C) with library calls to
    implement the message passing
  • A process executes on a processor
  • all processes are assigned to processors in a
    one-to-one mapping (in the simplest model of
    parallel programming)
  • other processes may execute on other processors
  • A process communicates and synchronizes with
    other processes via messages.

20
SPMD vs. MPMD
21
SPMD for performance
Not just for MPI even OpenMP programmers should
use SPMD model for high performance, scalable
applications
22
Programmers View of the Application
  • The characteristics of the problem and the way it
    has been implemented in code affect the process
    structure of an application

23
Characteristics of the Programming Model
  • Computations are performed by a set of parallel
    processes
  • Data accessed by one process is private from all
    other processes
  • memory and variables are not shared.
  • When sharing of data is required, processes send
    messages to each other

24
Message Passing Interface
  • MPI 1.0 standard in 1994
  • MPI 1.1 in 1995
  • MPI 2.0 in 1997
  • Includes 1.1 but adds new features
  • MPI-IO
  • One-sided communication
  • Dynamic processes

25
Advantages of MPI
  • Universality
  • Expressivity
  • Well suited to formulating a parallel algorithm
  • Ease of debugging
  • Memory is local
  • Performance
  • Explicit association of data with process allows
    good use of cache

26
Disadvantages of MPI
  • Harder to learn than shared memory programming
    (OpenMP)
  • Does not allow incremental parallelization all
    or nothing!

27
MPI Functionality
  • Several modes of point-to-point message passing
  • blocking (e.g. MPI_SEND)
  • non-blocking (e.g. MPI_ISEND)
  • synchronous (e.g. MPI_SSEND)
  • buffered (e.g. MPI_BSEND)
  • Collective communication and synchronization
  • e.g. MPI_BCAST, MPI_BARRIER
  • User-defined datatypes
  • Logically distinct communicator spaces
  • Application-level or virtual topologies

28
What System Calls Enable Parallel Computing?
  • A simple subset
  • send send a message to another process
  • receive receive a message from another process
  • size_the_system how many processes am I using to
    run this code
  • who_am_i What is my process number within the
    parallel application

29
Message Passing Model
  • Processes communicate and synchronize with each
    other by sending and receiving messages
  • no global variables and no shared memory
  • All remote memory references must be explicitly
    coordinated with the process that controls the
    memory location being referenced.
  • two-sided communication
  • Processes execute independently and
    asynchronously
  • no global synchronizing clock
  • Processes may be unique and work on own data set
  • supports MIMD processing
  • Any process may communicate with any other
    process
  • there are no a priori limitations on message
    passing. However, although one process can talk,
    the other is not required to listen!

30
Starting and Stopping MPI
  • Every MPI code needs to have the following form
  • program my_mpi_application
  • include mpif.h
  • ...
  • call mpi_init (ierror) / ierror is where
    mpi_init puts the error code
  • describing the success or failure of the
    subroutine call. /
  • ...
  • lt the program goes here!gt
  • ...
  • call mpi_finalize (ierror) / Again, make sure
    ierror is present! /
  • stop
  • end
  • Although, strictly speaking, executable
    statements can come before MPI_INIT and after
    MPI_FINALIZE, they should have nothing to do with
    MPI.
  • Best practice is to bracket your code completely
    by these statements.

31
Finding out about the application
  • How many processors are in the application?
  • call MPI_COMM_SIZE ( comm, num_procs )
  • returns the number of processors in the
    communicator.
  • if comm MPI_COMM_WORLD, the number of
    processors in the application is returned in
    num_procs.
  • Who am I?
  • call MPI_COMM_RANK ( comm, my_id )
  • returns the rank of the calling process in the
    communicator.
  • if comm MPI_COMM_WORLD, the identity of the
    calling process is returned in my_id.
  • my_id will be a whole number between 0 and the
    num_procs - 1.

32
Timing
  • When analysing performance, it is often useful to
    get timing information about how sections of the
    code are performing.
  • MPI_WTIME ()
  • returns a double-precision number that represents
    the number of seconds from some fixed point in
    the past.
  • That fixed point will stay fixed for the duration
    of the application, but will change from run to
    run.
  • MPI assumes no synchronization between processes.
  • Every processor will return its own value on a
    call to MPI_WTIME.
  • can be inefficient

33
MPI_WTIME
  • The importance of MPI_WTIME is in timing segments
    of code running on a given processor
  • start_time MPI_WTIME ()
  • do (a lot of work)
  • elapsed_time MPI_WTIME() - start_time
  • It is wall-clock time, so if a process sits idle,
    time still accumulates.

34
Basis Set of MPI Message-Passing Subroutines
  • MPI_SEND (buf, count, datatype, dest, tag, comm,
    ierror)
  • send a message to another process in this MPI
    application
  • MPI_RECV (buf, count, datatype, source, tag,
    comm, status, ierror)
  • receive a message from another process in this
    MPI application
  • MPI_COMM_SIZE (comm, numprocs, ierror)
  • total number of processes allocated to this MPI
    application
  • MPI_COMM_RANK (comm, myid, ierror)
  • logical process number of this (the calling)
    process within this MPI application

35
MPI in Fortran and C
  • Important Fortran and C difference
  • In Fortran the MPI library is implemented as a
    collection of subroutines.
  • In C, it is a collection of functions.
  • In Fortran, any error return code must appear as
    the last argument of the subroutine.
  • In C, the error code is the value the function
    returns.

36
MPI supports several forms of SENDs and RECVs
  • Which form of the send and receive is best is
    problem dependent
  • Here are the different types
  • Complete (aka blocking) MPI_SEND, MPI_RECV
  • Incomplete (aka non-blocking or asynchronous)
    MPI_ISEND, MPI_IRECV
  • Combined MPI_SENDRECV
  • Buffered MPI_BSEND
  • Fully synchronous MPI_SSEND
  • and there are more!
  • We will focus on the simplest MPI_SEND and
    MPI_RECV.

37
MPI Datatypes
  • MPI defines its own datatypes
  • important for heterogeneous applications
  • implemented so that the MPI datatype is the same
    as the corresponding elementary datatype on the
    host machine
  • e.g. MPI_REAL is a four-byte floating-point
    number on an IBM SP is an eight-byte
    floating-point number on a Cray T90.
  • designed so that if one system sends 100
    MPI_REALs to a system having a different
    architecture, the receiving system will still
    receive 100 MPI_REALs in its native format

38
Elementary MPI Datatypes - Fortran
  • MPI Datatype
  • MPI_BYTE
  • MPI_CHARACTER
  • MPI_COMPLEX
  • MPI_DOUBLE_PRECISION
  • MPI_INTEGER
  • MPI_LOGICAL
  • MPI_PACKED
  • MPI_REAL
  • Fortran Datatype
  • CHARACTER
  • COMPLEX
  • DOUBLE PRECISION (REAL8)
  • INTEGER
  • LOGICAL
  • REAL (REAL4)

39
Elementary MPI Datatypes - C
  • MPI Datatype
  • MPI_BYTE
  • MPI_CHAR
  • MPI_DOUBLE
  • MPI_FLOAT
  • MPI_INT
  • MPI_LONG
  • MPI_LONG_LONG_INT
  • MPI_LONG_DOUBLE
  • MPI_PACKED
  • MPI_SHORT
  • MPI_UNSIGNED_CHAR
  • MPI_UNSIGNED
  • MPI_UNSIGNED_LONG
  • MPI_UNSIGNED_SHORT
  • C Datatype
  • signed char
  • double
  • float
  • int
  • long
  • long long
  • long double
  • short
  • unsigned char
  • unsigned int
  • unsigned long
  • unsigned short

40
Simple MPI Example
My_Id, numb_of_procs
0, 3
1, 3
2, 3
This is from MPI process number 0
This is from MPI processes other than 0
This is from MPI processes other than 0
41
Simple MPI Example
  • Program Trivial
  • implicit none
  • include "mpif.h" ! MPI header file
  • integer My_Id, Numb_of_Procs, Ierr
  • call MPI_INIT ( ierr )
  • call MPI_COMM_RANK ( MPI_COMM_WORLD, My_Id, ierr
    )
  • call MPI_COMM_SIZE ( MPI_COMM_WORLD,
    Numb_of_Procs, ierr )
  • print , ' My_id, numb_of_procs ', My_Id,
    Numb_of_Procs
  • if ( My_Id .eq. 0 ) then
  • print , ' This is from MPI process number
    ',My_Id
  • else
  • print , ' This is from MPI processes other than
    0 ', My_Id
  • end if
  • call MPI_FINALIZE ( ierr ) ! bad things happen if
    you forget ierr
  • stop
  • end

42
Simple MPI C Example
  • include ltstdio.hgt
  • include ltmpi.hgt
  • int main(int argc, char argv)
  • int taskid, ntasks
  • MPI_Init(argc, argv)
  • MPI_Comm_rank(MPI_COMM_WORLD, taskid)
  • MPI_Comm_size(MPI_COMM_WORLD, ntasks)
  • printf("Hello from task d.\n", taskid)
  • MPI_Finalize()
  • return(0)

43
Matrix Multiply Example
A
B
C
X

44
Matrix Multiply Example
  • Intialize matrices A B
  • time1timef()/1000
  • call jikloop
  • time2timef()/1000
  • print , time2-time1
  • subroutine jikloop
  • integer matdim, ncols
  • real(8), dimension (, ) a, b, c
  • real(8) cc
  • do j 1, matdim
  • do i 1, matdim
  • cc 0.0d0
  • do k 1, matdim
  • cc cc a(i,k)b(k,j)
  • end do
  • c(i,j) cc
  • end do
  • end do
  • end subroutine jikloop

45
Matrix multiply over 4 processes
A
B
C
X

All processes
0 1 2 3
0 1 2 3
  • Process 0
  • initially has A and B
  • broadcasts A to all processes
  • scatters columns of B among all processes
  • All processes calculate CA x B for appropriate
    columns of C
  • Columns of C gathered into process 0

C
process 0
46
MPI Matrix Multiply
  • real a(dim,dim), b(dim,dim), c(dim,dim)
  • ncols dim/numprocs
  • if( myid .eq. master ) then
  • ! Intialize matrices A B
  • time1timef()/1000
  • call Broadcast(a to all)
  • do i1,numprocs-1
  • call Send(ncols columns of b to i)
  • end do
  • call jikloop ! c(1st ncols) a x b(1st ncols)
  • do i1,numprocs-1
  • call Receive(ncols columns of c from i)
  • end do
  • time2timef()/1000
  • print , time2-time1
  • else ! Processors other than master
  • allocate ( blocal(dim,ncols), clocal(dim,ncols)
    )
  • call Broadcast(a to all)
  • call Receive(blocal from master)
  • call jikloop ! clocalablocal
  • call Send(clocal to master)
  • endif

47
MPI Send
  • call Send(ncols columns of b to i)
  • call MPI_SEND( b(1,incols1), ncolsmatdim,
    MPI_DOUBLE_PRECISION, i,
    tag MPI_COMM_WORLD, ierr
    )
  • b(1,incols1 ) address where the data start.
  • ncolsmatdim The number of elements (items) of
    data in the message
  • MPI_DOUBLE_PRECISION type of data to be
    transmitted
  • i message is sent to process i
  • tag message tag, an integer to help distinguish
    among messages

48
MPI Receive
  • call Receive(ncols columns of c from i)
  • call MPI_RECV( c(1,incols1), ncolsmatdim,
    MPI_DOUBLE_PRECISION, i, tag
    MPI_COMM_WORLD, status, ierr)
  • status integer array of size MPI_STATUS_SIZE of
    information that is returned. For example, if you
    specify a wildcard (MPI_ANY_SOUCE or MPI_ANY_TAG)
    for source or tag, status will tell you the
    actual rank (status(MPI_SOURCE)) or tag
    (status(MPI_TAG)) for the message received.

49
Collective Communications
  • allows many nodes to communicate with each other
  • MPI defines subroutines/functions that implement
    common collective modes of communication.
  • relieves the user of having to develop his/her
    own out of send/recv primitives.
  • Good MPI implementations should have these
    collective operations already optimized for the
    target hardware.

50
Some Fundamental Modes of Collective Communication
  • broadcast Send something from one processor to
    everybody
  • reduce Send something from everybody and combine
    it together on one processor
  • barrier Pause until everybody has encountered
    this barrier
  • scatter Take multiple pieces of data from one
    process and send individual pieces of it to
    individual processes
  • gather Gather individual pieces of data from
    individual processes and create multiple
    pieces of data on a single process.

51
The Broadcast Operation MPI_BCAST
Useful when one processor has data that is needed
by everyone.
52
Using MPI_BCAST
  • Processor 0
  • pi 3.14159
  • pi 3.14159
  • pi 3.14159
  • C This runs on processor 0.
  • real8 pi
  • integer ierr
  • if (my_rank .eq. 0) pi 3.14159
  • call mpi_bcast(pi,
  • 1,
  • MPI_DOUBLE_PRECISION,
  • 0,
  • MPI_COMM_WORLD,
  • ierr)
  • Processors 1, 2, 3,...,n
  • pi uninitialized
  • pi uninitialized
  • pi 3.14159
  • C This runs on processor 1, 2, 3,...,n
  • C It's the same code that runs on proc 0!
  • real8 pi
  • integer ierr
  • if (my_rank .eq. 0) pi 3.14159
  • call mpi_bcast(pi,
  • 1,
  • MPI_DOUBLE_PRECISION,
  • 0,
  • MPI_COMM_WORLD,
  • ierr)

MPI_BCAST
MPI_BCAST
53
MPI Broadcast
  • call Broadcast(a to all)
  • call MPI_BCAST( a, matdimsq, MPI_DOUBLE_PRECISION,
    master,
    MPI_COMM_WORLD, ierr )
  • master message is broadcast from master process
    (myid0)

54
Better MPI Matrix Multiply
  • if( myid .eq. master ) then
  • ! Intialize matrices A B
  • time1timef()/1000
  • endif
  • call Broadcast ( a, enveloppe)
  • call Scatter (b, blocal, enveloppe)
  • call jikloop ! clocal a blocal
  • call Gather (clocal, c, enveloppe)
  • if( myid .eq. Master) then
  • time2timef()/1000
  • print , time2-time1
  • endif

55
MPI_SCATTER
The diagram is a little deceptive. Why?
56
MPI_GATHER
57
MPI Scatter
100
100
100
All processes
blocal
100
100
100
Master
b
call MPI_SCATTER( b, 100, MPI_DOUBLE_PRECISION,
blocal, 100, MPI_DOUBLE_PRECISION, master,
MPI_COMM_WORLD, ierr)
58
MPI Gather
100
100
100
All processes
clocal
100
100
100
Master
c
call MPI_GATHER( clocal, 100, MPI_DOUBLE_PRECISIO
N, c, 100, MPI_DOUBLE_PRECISION, master,
MPI_COMM_WORLD, ierr)
59
Matrix Multiply timing Results on IBM SP
60
Measuring Performance
  • Assume we time only parallelized region
  • Ideally

61
Matrix Multiply Speedup Results on IBM SP
62
A Closer look at MPI Send/Recv
  • MPI_SEND
  • MPI_SEND returns after the user send buffer has
    been copied by the system.
  • After MPI_SEND returns, the user is free to
    change the contents of the buffer without
    affecting the message being sent (i.e. it is
    guaranteed to already be in some stage of its
    journey -- and can't be recalled!)
  • MPI_SEND blocks until the system is finished
    copying the user buffer.
  • MPI_RECV
  • MPI_RECV returns after the message has been
    received and has been copied into the user buffer
    at the destination.
  • MPI_RECV blocks until this has happened.

63
What Will Happen?
  • / Processor 0 /
  • ...
  • MPI_Send(sendbuf,
  • bufsize,
  • MPI_CHAR,
  • partner,
  • tag,
  • MPI_COMM_WORLD)
  • printf("Posting receive now ...\n")
  • MPI_Recv(recvbuf,
  • bufsize,
  • MPI_CHAR,
  • partner,
  • tag,
  • MPI_COMM_WORLD,
  • status)
  • / Processor 1 /
  • ...
  • MPI_Send(sendbuf,
  • bufsize,
  • MPI_CHAR,
  • partner,
  • tag,
  • MPI_COMM_WORLD)
  • printf("Posting receive now ...\n")
  • MPI_Recv(recvbuf,
  • bufsize,
  • MPI_CHAR,
  • partner,
  • tag,
  • MPI_COMM_WORLD,
  • status)

64
Deadlock?
include ltstdio.hgt include ltmpi.hgt define DIM
2000 int main(int argc, char argv) int
i,taskid, otherid, ntasks float
aDIM,bDIM MPI_Status status
MPI_Init(argc, argv) MPI_Comm_rank(MPI_COMM_
WORLD, taskid) MPI_Comm_size(MPI_COMM_WORLD,
ntasks) for(i0 iltDIM i) aitaskid
otherid(taskid1)2 MPI_Send( a, DIM,
MPI_REAL, otherid, taskid,
MPI_COMM_WORLD) MPI_Recv( b, DIM, MPI_REAL,
otherid, otherid, MPI_COMM_WORLD,
status) printf("Process d received array
from process d.\n", taskid, otherid)
MPI_Finalize() return(0)
65
No Deadlock
include ltstdio.hgt include ltmpi.hgt define DIM
2000 int main(int argc, char argv) int
i,taskid, otherid, ntasks float
aDIM,bDIM MPI_Status status
MPI_Request request MPI_Init(argc, argv)
MPI_Comm_rank(MPI_COMM_WORLD, taskid)
MPI_Comm_size(MPI_COMM_WORLD, ntasks)
for(i0 iltDIM i) aitaskid
otherid(taskid1)2 MPI_Isend( a, DIM,
MPI_REAL, otherid, taskid,
MPI_COMM_WORLD, request) MPI_Recv( b, DIM,
MPI_REAL, otherid, otherid,
MPI_COMM_WORLD, status) printf("Process d
received array from process d.\n", taskid,
otherid) MPI_Finalize() return(0)
66
MPI_ISEND
  • call MPI_ISEND ( buf, count, datatype, dest, tag,
    comm, request, ierror)
  • request is a handle returned by the subroutines
    so that MPI_WAIT knows what to wait for
  • type integer in Fortran and MPI_REQUEST in C
  • MPI_ISEND returns immediately.
  • send buffer can be reused once MPI_WAIT returns
  • unlike, MPI_WAIT, the subroutine MPI_TEST is
    non-blocking and can be used to determine
    (repeatedly, if desired) whether the send
    completed.

67
Use of non-blocking communication
  • Where possible, use MPI's features to help
    overlap computation and communication.
  • don't wait for a message if there is something
    else useful to do!
  • it is always possible to improve performance by
    overlapping computation and the waiting for a
    message

68
? -6
69
? -6 (detail)
70
? 6
71
  • ? 2 gives mandelbrot set
  • Colours represent points c in the complex plane,
    and are mapped to the number of iterations
    required to diverge
  • Points that don't diverge are black

72
Fractal Example
  • do i0, pic-1
  • cxaxixmin
  • do j0, pic-1
  • cyymax-axj
  • cdcmplx(cx,cy)
  • ! Initialize z to (0,0) or (1,1)
  • do k1,niter
  • if(abs(z).lt.lim) then ! Z hasnt
    diverged yet
  • zzalphac
  • kount(j,i)k
  • else
  • exit
  • endif
  • end do
  • end do
  • end do

73
Master-Slave Parallelization static balancing
74
MPI Fractal static balancing
  • lblockpic/(numprocs-1)
  • allocate( kount(0pic-1,0lblock) )
  • if( myid .eq. master ) then
  • read(,) alpha
  • time1timef()/1000
  • call Broadcast(alpha to all)
  • do i1,numprocs-1
  • call Receive(kount from i)
  • print , kount
  • end do
  • time2timef()/1000
  • print , time2-time1
  • else ! slaves
  • call Broadcast(alpha to all)
  • call DECOMP_SLAVE(ia, ib)
  • do iia,ib
  • ..
  • kount(j,i-ia)k
  • ..
  • end do
  • call Send(kount to master)
  • endif

75
(No Transcript)
76
Master-Slave Parallelization dynamic balancing
77
MPI Fractal dynamic balancing
  • nb40
  • allocate( kount(0pic-1,0nb-1),
    kountal(0pic-1,0pic-1) )
  • if( myid .eq. master ) then
  • read(,) alpha time1timef()/1000
  • call Broadcast(alpha to all)
  • blocks_done0 nblockspic/nb
  • col_start(numprocs-1)nb-nb1
  • do while (blocks_done.lt.nblocks)
  • call Receive(kount, any slave)
  • islavesource_of_message
  • call Store_kount_in_kountall
  • blocks_done blocks_done 1
  • col_startcol_startnb
  • call Send(col_start to islave)
  • end do
  • time2timef()/1000
  • print , time2-time1
  • else ! slaves
  • call Broadcast(alpha to all)
  • col_startnbmyid-nb1
  • cols_lastpic-nb1
  • do while (col_start.le.cols_last)
  • do i0,nb-1
  • cxax(icol_start-1)xmin
  • .. Calculate fractal
  • end do
  • call Send(kount to master)
  • call Receive(col_start from master)
  • end do
  • endif

78
Dynamic Balancing Detail
  • Master
  • do while (numdone.lt.nbsize)
  • call MPI_RECV(kount,lkount,MPI_INTEGER,MP
    I_ANY_SOURCE,
  • MPI_ANY_TAG,MPI_COMM_WORLD,
    status,ierr)
  • ncolumnstatus(MPI_TAG)-1
  • islavestatus(MPI_SOURCE)
  • Slaves
  • call MPI_SEND(kount,lkount,MPI_INTEGER,master,col_
    start,
  • MPI_COMM_WORLD,ierr)

79
(No Transcript)
80
Common Errors and Misconceptions
  • 1. Forgetting ierr in Fortran (compiler won't
    always catch this for you)
  • especially MPI_FINALIZE(ierr)
  • 2. Misdeclaring status in Fortran (must be an
    array of integers of size MPI_STATUS_SIZE)
  • 3. (For C programmers) Expecting argv and argc to
    be propagated to all processes.
  • May or may not happen on all MPI implementations
  • 4. Doing things before MPI_INIT or after
    MPI_FINALIZE.
  • 5. Matching MPI_BCAST with MPI_Recv

81
Conclusions
  • Some general principles for good parallel
    performance
  • Balance the computational load
  • Make the program scalable so that adding nodes
    makes the program run faster in a predictable way
  • Parallelize the whole problem
  • How a problem is decomposed up for parallel
    execution should depend on the nature of the
    problem, not the nature of the computer on which
    it is running
  • Choice of decomposition determines success of
    your effort
  • As in single-processor applications, tuning can
    yield significant performance gains
  • Dont forget single-processor optimization!

82
Amdahls law revisited
Horoi Enbody, J. HPC Applications, 15, no. 1
(2001), p. 75
83
References
  • Is Parallelism for You?, by Sheri Pancake,
    Computational Science and Engineering, Vol. 3,
    No. 2 (Summer, 1996), pp. 18-37
  • Using MPI, by Gropp, Lusk, and Skjellum (MIT)
  • Using MPI-2, by same
  • MPI Website
  • www-unix.mcs.anl.gov/mpi/
  • Matrix multiply programs www.cs.unb.ca/acrl/acrl_
    workshop/
  • Parallel programming with generalized fractals
    www.cs.unb.ca/staff/aubanel/aubanel_fractals.html
Write a Comment
User Comments (0)
About PowerShow.com
