Introducing

1
Introducing
Enhancing Crystallinity and molecular weight for
semi-crystalline thermoplastics
2
Company Profile
Privately owned by Diefenthal Investments in the
USABrother Sister entity relationship with
PETUSCorporate RD and Mini-Melt plant in
Cleveland OhioRegistered in Scotland as an
overseas trading CompanyLicensed by SEPA
,essentially a green operationAudited by
Lloyds Register to ISO 90012 2000 (Sept
2003)Entry to Europe May 1996Company focus on
polymer Development UpratingOperated as an
autonomous facility to service the European
markets
Enhancing Crystallinity and molecular weight for
semi-crystalline thermoplastics
3
Site view 2003
Enhancing Crystallinity and molecular weight for
semi-crystalline thermoplastics
4
PETUK The Formative Years

• August 1995 PETUK Company Registered in UK

• October 1995 Soil cutting on Green Field Site

• May 1996 First Commercial Production of SSP
  Polymer

• September 1996 Second Stage Reactor Expansion

• September 1997 Awarded BS EN ISO 9002 by Lloyds
  Register

• November 1999 Third Stage Reactor Expansion

• May 2001, Introduce Vacuum Eggs High Vacuum
  to
• enhance Productivity

• September 2003 certified to ISO 9001/2000

• December 2003 Fourth Stage Reactor Site
  Expansion

Enhancing Crystallinity and molecular weight for
semi-crystalline thermoplastics
5
The Solid Phase Polymerisation (SPP) technique is
widely applied in industrial manufacture of
certain polymers to achieve improved processing
and/or finished product features. Finished
products can include food/drink containers, wide
temperature range usage speciality films and
superior industrial fibres, monofilaments and
sheet. Solid Phase Polymerisation (SPP) is a
chemical process in which the polymer chain
length is increased by the controlled application
of heat in the absence of oxygen and water by
means of either a vacuum or by purging, with an
inert gas, to drive off the by-products of the
reaction. The reactivity is a function of polymer
type, applied temperature and pressure and the
diffusion of the by-products from the pellet
centre to the outer surface. SPP is an important
step frequently employed after melt
polymerisation for the purpose of improving the
mechanical and rheological properties of the
polymers. The batch process and systems employed
by PETUK enables extremely high accuracy of the
product measured molecular weight (IV) and
repeatability between batches.
Enhancing Crystallinity and molecular weight for
semi-crystalline thermoplastics
6
Range of Materials processed
PET poly ethylene terephthalate
PEN poly ethylene napthalate
PBT poly butylene terephthalate
PBTE poly butylene terephthalate elastomers
PTT poly trimethylene terephthalate
PPS poly phenylene sulphide
PA polyamides 6, 66 and derivatives
CXG Customer experimental grades (customer
specific)
LCP liquid crystal polymers
All in amorphous, semi crystalline, fully
crystalline state and recycled and pre-consumer
reworked variants
Enhancing Crystallinity and molecular weight for
semi-crystalline thermoplastics
7
Process Logic Flow
Material reception
Analysis pre-testing
Define Processing parameters
Reaction Testing
Post- Treatment
Pre-treatment
Logistics
Final Test Issue Certificate Of Conformance
Customer
ISO 9001/2000 compliant
8
Rotary Vacuum Reactor
Enhancing Crystallinity and molecular weight for
semi-crystalline thermoplastics
9
Plant Laboratory Melt Viscometers
Enhancing Crystallinity and molecular weight for
semi-crystalline thermoplastics
10
IV Uprating Range
MONOFILAMENT
TYRE CORD
INDUSTRIAL FIBRE
PEN FILM
PET FILM
SHEET
BxSSP CSSP
RESIN
BxSSP
STRAPPING
EBM
INJECTION MOULDING
TEXTILES
ROD STOCK
ENGINEERING SPECIALS
0.50 0.55 0.60 0.65 0.70 0.75
0.80 0.85 0.90 0.95 1.00 1.05
1.10 1.15 1.20 1.25
PETUK IV VALUES
Enhancing Crystallinity and molecular weight for
semi-crystalline thermoplastics
11
Year 2003 Analysis by Market Activity
Enhancing Crystallinity and molecular weight for
semi-crystalline thermoplastics
12
Typical Market Applications

• Medical sterile containers

• High Profile appealing cosmetic containers

• Rigid wide temperature range food containers

• High impact strength car components

• Thick film for electric motor rotor insulation

• Long shelf life Beer Bottles

• High Tenacity Strapping Tape monofilaments

• Fibre optic cabling

• Pachenco Gaming cards (Japan)

• Semi flexible membranes

• Rigid and semi rigid foams

Enhancing Crystallinity and molecular weight for
semi-crystalline thermoplastics
13
Development ProjectsJVProduct Development
Electronics
Profiles Sheet
Monofilaments Strapping
High Tenacity Fibres
Engineering Construction
Beer Bottles PEN
Automotive
Hot Fill Food PET PEN
Medical Cosmetic
?
Rigid and Relaxed Foam
Thick Profiles Blocks
Enhancing Crystallinity and molecular weight for
semi-crystalline thermoplastics
14
New Developments

• Masterbatch Developments for complex
  processing
• Blending technology with liquid additives to
  de-pigment RPET
• Integrated pelletisation
• Access to micro polymerisation plant for RD
• Availability of spherical pellets for
  uniform SSP
• Access to new high productivity SSP reactors
• Customised polymer formulations
• New Polymer testing facilities and bespoke
  correlations

Enhancing Crystallinity and molecular weight for
semi-crystalline thermoplastics
15
Phillip GibbManaging Director
44 (0)1387 247947 44 7802 1277041(mobile) phi
llip.gibb_at_petuk.com Dr Mick ONeill Technical
Manager 44 (0) 1387 247924 mick.oneill_at_petuk.com
European Offices 44 (0) 1387247965, fax 44(0)
1387 247963 USA Offices Fred Current
President 001 440 345 4321 fred_current
_at_petus.com Internet Information www. petuk.com
www.petus.com
