Mango

1
Mango

• A General Purpose Programming Language

2
Have Mercy

• First time talking about Mango
• Not good on my feet
• Not a good public speaker
• Never had any feedback
• Im an idiot savant
• Dont stump the chump

3
My Background

• Early experience on Apple II
• University of Illinois Champaign Urbana.
• Bachelor's degree in computer engineering
• Three years at Neoglyphics software
• Three years at Alpha hardware

4
How Mango Got Started

• Frustrated with C/C/Java
• There had to be a better way
• Foolishly began designing my own language
• Foolishness can be a virtue
• Its been a seven year voyage

5
The Problem

• Common computing infrastructure is written in
  C/C
• C/C is inadequate
• Lack of higher level abstractions
• Programmers must use low level constructs
• Unsafe/unstable software
• Slower development times

6
A lack of alternatives

• Java, Python, Pascal, Ada, Modula, C
• Not viable replacements
• Lack Cs virtues in performance and flexibility
• Dependent on C for core tasks
• Lack of widespread appeal (clumsy, i.e. Ada?)
• Not sufficiently different to switch

7
The Solution Core Goals

• Provide higher level abstractions
• Avoid low level constructs when not needed
• Make programming easier, more enjoyable
• Retain performance and flexibility
• Allow unrestricted operations as necessary
• Low overhead
• Overall make a better experience for programmers

8
Overview

• High level design goals and decisions
• Feature walk through
• Future directions

9
Design Goals
10
Design goals

• Syntax
• Static Typing vs. Dynamic Typing
• How Vs. What
• Large Languages Vs. Small Languages
• Object Orientation Yes or No

11
Goal 1 A Good Syntax

• Syntax is key
• Its underrated (focus on semantics)
• Makes the language easier to learn
• Makes it accessible to non-programmers
• Makes the language self-documenting
• Marketing versus engineering
• Bad marketing of a good product will fail
• Bad syntax around good semantics will have a
  harder time gaining acceptance

12
Static versus Dynamic Typing

• Mango is statically typed
• Critical for performance
• Offers compiler hints for optimization
• Types act as documentation
• They catch many errors at compile time
• Types allows overloading of names

13
How versus What

• CS fantasy to forget how and focus on what
• How is a hard problem
• Distinguish features that are theoretically
  equivalent but practically different
• Rich set of primitive and aggregate types
• Everything can be a list, but itll be slow
• Side effects to use memory more effectively
• Reduce copying
• Manual memory management
• GC is not possible for some applications
• Done right beats a garbage collector

14
Large Vs. Small Languages

• Small language
• Secondary features are in a standard library
• Advantages easier to learn core features, make a
  compiler
• Large language
• First class treatment of secondary features
• Allows specialized operations, makes programs
  more readable
• Advantage a smoother user experience
• Ease of learning is dependent on more than
  language size
• You still have to learn library APIs
• Intangible quality how the language corresponds
  to human cognition
• Open source makes compilers easier to write
• Open front end acts as the spec

15
Object-Orientation Yes or No?

• Stepanovs criticism
• programming data structures algorithms
• multi-sorted algebras
• Object orientation has shown itself useful in
  certain circumstances
• Offer OO as an option
• Leave inheritance behind
• Inheritance hierarchies are difficult to follow
• Fragile base class problem requires reanalysis of
  class behavior

16
Mango walk through

• Influences
• Syntax plus some basic examples
• Module system incremental compilation (Include
  requires clause, parameter and options) (platform
  and foundation files)
• Naming and overloading
• Literals (include string format)
• Primitive Types
• Memory model (include pointer/reference syntax)
• Records and Abstracts
• Procedures, functions, constants (pure
  functions?)
• Statements Control flow
• Statements I/O
• Abstract Data Type (objects)
• Iterators and iteration operators
• Mutexes
• Exception Handling
• Strings, arrays, buffers
• Collection Types
• Global variables/External symbols/Module
  Constructors
• Calling convention part of the type system

17

• SETL - set operations
• ALGOL - imperative block structure and syntax
• C - low level ops, low overhead
• ML - type inference, type syntax
• ADA - fine grained control over primitives
• PYTHON - indentation based syntax
• JAVA - interfaces
• C - STL, operator overloading, IO syntax
• CLU - iterators
• PASCAL - sets (bit masks)
• PERL - richness of expressibility
• COBOL - readable syntax
• SIMULA - objects

18
Syntax
19
Mangos Syntax

• Mango looks like pseudo code
• Indentation based syntax
• Reduces clutter and typing
• Allows more code to be shown on the screen
• Blocks can be enclosed with begin/end delimiters
  if desired
• All directives, definitions, statements begin
  with a keyword
• Simple style that is easy to remember
• Users symbolic names cannot conflict with
  reserved words
• This makes the language easy to extend
• There are no exclusively reserved keywords
• Legacy of lex?

20
program hello with args of args_string is
print "hello world", eol print " args ",
args size, eol foreach a in args over i do
print "args", i, " '", a, "'", eol
21
import std/io program sort is declare list
of integer list repeat read x of
integer from stdin exit when x 0
add x into list repeat begin
declare x of logical/boolean foreach i in
1 to list size - 1 where listi gt listi1 do
swap listi with listi1
set x exit when x false end
foreach x in list do print x, eol
22
module primes import std/program, ascii/utils
procedure find_primes n of integer, primes of
(integer list) do exit when n 0 add
2 into primes declare z of integer where z
3 while primes size lt n do while
some x in primes where z x 0 do
incr z add z into primes program
primes with args of args_string is eval
args1 with ascii_to_integer into n when args
size 2 else 1000 declare primes of
integer list call find_primes with n,
primes foreach i in primes do print
i, " " print eol
23
module ackermann import ascii/parse
function ack with m of integer, n of integer
yielding integer is n 1
when m 0, ack(m - 1, 1)
when n 0, ack(m - 1, ack(m, n -
1)) otherwise program ackermann with args of
args_string is declare n of integer where n
1 eval args1 with parse into n when args
size gt 0 call ack with 3, n into result
print "Ack(3,", n, ") ", result", eol
24
module spell_check import ascii/parse
literal dict_hash_size is 1079 program
spell_check with args of args_string is
declare dict of ltascii stringgt set
dict_hash_size open file of ascii text
where path "dictionary.txt" foreach word
of ascii string in file do add word into
dict close file foreach word of
ascii string in stdin do print word, eol
when word not_in dict
25
literal z is 43.234iprogram complex is
declare x of number/32 complex assign
1 z into p 1.0 3.3i into x
print p, , x, eol
26
program set_example is declare s1 of ltascii
string, integergt set declare s2 of integer
set declare s3 of setltintegergt add
1 at one into s1 2 at two into
s2 fill s2 with x in 1 to 30 where x 3
0 yielding x extract z from x in s2 where x
9 yielding x print z, eol print
s1, eol
27
Modules and Naming
28
Modules

• Module is a set of symbols
• Each file is a module
• Module name must correspond to pathname
• A modules symbols can be public or private
• Public symbols are visible to other modules
• Private symbols are invisible to other modules
• Modules may import and include other modules
• Import foreign symbols are localized (private)
• Include foreign symbols are exported (public)

29
Incremental Compilation

• Mango supports incremental compilation
• Module has changed
• A dependency has changed
• Major or minor revision?
• Compares syntax trees
• Major revision public change
• Minor revision private change
• Comparing syntax
• Advantage Eases implementation
• Disadvantage Set of major revisions is obviously
  larger

30
Naming

• Naming is not hierarchical, but geometric
• Symbol names exist within a four-d grid
• Namespace, keyword, extension, auxiliary
• Only namespace and keyword are mandatory
• Each module is part of a namespace
• Public symbols use declared namespace
• Private symbols use special namespace local
• Format
• namespacekeyword_at_extensionauxiliary

31
module test in system enum color is red, blue,
green procedure do_it object tst_obj is
state a of integer b of
integer method ppp of integer yielding
integer program test is print
systemcolor_at_red print systemcolor_at_blue
call systemdo_it declare record of
systemtst_objrecord declare method of
ltinteger gt integer, systemtst_objgt method
assign systemtst_obj_at_ppp into method
32
Shallow Overloading

• Overloading occurs for every imported or included
  module
• 4d namespace is collapsed into 1d namespace
• Utilizing keyword or extension
• Other partial namespaces as well
• Symbol can be access using proper name or alias
• Ensures all overloaded symbols have a unique name
• As a result, all overloading is superficial or
  shallow
• Operator overloading is also supported

33
module test in system enum color is blue,
green procedure test -------------------------
--------------------------------------------------
----------------------------------- module io
part of namespace io import test enum
color is red, green, blue procedure test
program doit is call test
this will cause a unresolvable symbol name
conflict call systemtest this will
work just fine print red
this will print the word 'red' print
color_at_red this will print the word
'red' print blue this
will an unresolvable symbol name conflict
print iocolor_at_blue this will work
34
module test in mango Operator
overloading (, add, mangoadd) procedure
add with a of integer, b of integer yielding
integer Prefix overloading (parse,
parseinteger, mangoparse, mangoparseinteger)
procedure parseinteger with ascii string
yielding integer Package
overloading package ops is procedure add
(, add, _at_add, ops_at_add,
mangoops_at_add) procedure div /
(/, div, _at_div, ops_at_div, mangoops_at_div)
procedure mul (, mul, _at_mul,
ops_at_mul, mangoops_at_mul) procedure sub -
(-, sub, _at_sub, ops_at_sub, mangoops_at_sub)
35
Memory Model
36
Mangos Memory Model

• Value semantics
• Put stuff on the stack, particularly primitives
• Key for performance
• Offers more flexibility
• Three types of memory
• Static
• Compiled data, global variables
• Heap items that are never deleted
• Arbitrary
• Heap items that are eventually deleted
• Local
• Items that live on the stack

37
Safe manual memory management

• Static datums
• Always safe to use
• Arbitrary datums
• Need to be guarded to avoid dangling pointer
  references
• Local datums
• Compiler must enforce restrictions to avoid
  dangling pointer references

38
Sentries

• Pointer guards are called sentries
• Pointers to arbitrary datums are fat
• One address to the datum on the heap
• One address to the datums sentry
• Sentries live on the heap too
• Have a static lifetime (i.e. never deallocated)
• They are very small 5 bytes

39
Sentry Performance

• When sentries is small
• Good performance on modern hardware
• Sentries stay in the cache
• Half of the processors time is spent waiting on
  memory
• As sentries increases
• cache starts to overflow
• We need to reduce the number of sentries

40
Arenas and Recycling

• Method 1 Allocate in pools
• A group of datums share a sentry
• Allocated arbitrarily, but deallocated at once
• Method 2 Recycling
• Use static datums instead
• When static datums are deleted
• Initialized to zero
• Stay on the heap until datum of the same type is
  requested
• Incorrect results are possible, catastrophic
  failures are not
• The program cannot break the type system

41
variable x of integer g1 of integer
arbitrary g2 of integer static
program test is assign x into g1 legal
assign x into g2 legal assign new
integer into g1 legal declare z
of integer p1 of integer
arbitrary p2 of (integer) local
p3 of integer static assign z
into p1 illegal assign z into p2
legal assign new integer into p2
legal new integer into p3 illegal
get integer into p3 legal
42
Literals
43
Literals

• Definition
• A value which is known at compile time
• Types
• Immediate values
• Numeric primitives and text
• Literal expressions
• Interpreted during compilation
• Parameters
• Values used to configure the compiler
• Options
• User supplied values to customize a build
• Literals can be named

44
Numeric Literals

• Six types
• Integer, Decimal, Hex, Address, Binary, Signal
• Integers and decimals also include complex plane
  signifiers
• Can be anonymous
• Anonymous literals are stored as untyped strings
• Converted to a real value when type is known
• There are no constraints on range
• Can be typed
• Type is specified with value
• Converted immediately to the desire type value
• There are no constraints on range

45
literal int_scalar is 100_000 literal int_real
is 100_000_000_000_000_000_000_000_000_000_000r
Literal int_imag is 100_000i Literal
dec_scalar is 1.00E5 Literal dec_real is
3.14r Literal imag_imag is 123_456.56i Literal
hex is ffff_ef1d Literal addr1 is
ffee.0 Literal addr2 is ffee.7 Literal
binary is 1000_1001_0101 Literal signal is
\10xz_xxzz_0101 Literal crdnl_100 is lt100,
cardinal/32gt Literal intgr_100 is lt-100,
integer/32gt Literal pi is lt3.14, number/32gt
46
Text Literals

• Two types
• Characters and Strings
• Stored as untyped strings until desired type is
  known
• Characters enclosed with the back tick
• Text string enclosed with the double quote
• Literals can be inserted into characters and text
  strings
• Named literals
• Parameters
• Options
• Character codes
• Character aliases

47
literal hello_word is hello world! literal
char_a is a literal newline is \n literal
version is (major_version).(minor_version).(re
vision) literal abc is lt64gtlt65gtlt66gt lite
ral char_b is lt64gt literal path_seperator is
(path_seperator) literal home_path is
(base_path)(path_seperator)home
48
Literal Expressions

• Two forms of literal expressions
• Normal literals immediate evaluation
• Macro literals deferred evaluation
• Macros are evaluated over arguments
• Result value is optionally typed
• Expressions can include
• Condition construct
• Conversion construct
• Local aliasing

49
literal page_width is 80 literal seperator is
(' ', page_width) creates a string of 80
spaces literal name is "joebob briggs" macro
pick with a, b, c is min(a,b) max(b,c)
literal test is pick(10,30,50) literal
file_seperator is operating_system
such_that "linux_x86" yields '/',
"windows_95 yields '\\', "solaris"
yields '/', "windows_xp" yields
'/', else '?' literal version_string is
major_version "." minor_version "."
program_revision
50
literal max_int of integer/32 is 232 -
1 literal seperator is (' ', page_width)
creates a string of 80 spaces literal name of
char/ascii() is "joebob briggs" macro pick
with a, b, c is min(a,b) max(b,c) literal
test is pick(10,30,50) literal file_seperator
is operating_system such_that
"linux_x86" yields '/', "windows_95" yields
'\\', "solaris" yields '/',
"windows_xp" yields '/', else '?' literal
version_string is major "." minor "."
revision where major
major_version, minor minor_version,
revision program_revision
51
Parameters and Options

• Changes cause recompilation of module
• Part of the public interface of the module
• Checked when comparing syntax
• Only options that are used included in dependency
  analysis
• Parameters included in dependency analysis
• Specified by user
• Have a major impact on compilation

52
Core Types
53
Core Types

• Primitives
• Tuples and Unions
• Addresses, Pointers, References
• Polymorphic Types
• Strings, Arrays and Buffers
• Collections
• Records and Abstracts

54
Primitives

• Logicals
• 2 state binary on/off
• 3 state boolean true/false/unknown
• 4 state signals 1/0/x/z)
• Ordinals
• Unsigned base (264-1 max)
• Range from 0 to N
• Characters
• ASCII, UTF8, UTF16, UTF32, etc
• Base 2 registers
• User specified size in bits
• Signal buses
• 4 state logic
• User specified range in bits
• Included for hardware modeling/simulations

55
Primitives (contd)

• Cardinal numbers
• 1 bit to 64 bits
• Fractional precision
• Subranges
• Signed base (-262 to 262)
• upper bound, lower bound, and default are user
  specified
• Integer numbers
• 8 bits to 64 bits unlimited precision
• Fractional precision
• Rational numbers
• ratio of 2 integers
• Fixed point decimals
• Floating point numbers

56
Primitives (contd)

• Complex numbers
• Primitives qualified with units
• Enumerations
• Matrices
• Coordinates

57
Primitive Modifiers

• Conversion
• Automatic, manual, none, universal
• Evaluation
• None, Fixed, Fluid
• Approximation
• Round, Truncate, Conserve
• Overflow
• Check, Limit, Wrap
• Byte Order
• Big, Little, Host, Network

58
type boolean of logical/boolean type addr of
address 1 type index of ordinal 1024
having overflow wrapped type ascii of char/ascii
having overflow checked type reg_16 of
register 150 type upper_32 of signal
6332 type count of cardinal/32 having
overflow checked, endian network type fahrenheit
of subrange -100, 32, 212 having overflow
limited type int32 of integer/32 4 a
fixed point integer with 4 bits of fractional
precision type rat360 of rational 360
rational number with base 360 type float_32 of
number/32 type dollar of decimal 102 type
cmplx32 of number/32 complex type speed of
number/32 units miles per seconds type point of
integer/32 coordinate x,y type matrix_2_2 is
integer matrix 22
59
Tuples and Unions

• Anonymous type products
• Fields can be labeled
• Unions
• Each term of product is overlapped
• Unsafe
• Elaborate types decompose into tuples

60
Addresses, Pointers, References

• Addresses have bitwise resolution
• Address is 2 product tuple
• Upper value byte count
• Lower value bit count
• Addresses still optimal
• types with byte-wise alignment will drop bit
  count
• Pointers
• Address of type where address is significant
• References
• Address of type where type is significant

61
Polymorphic Types

• Sums
• Superposition of multiple types
• Qualified with type tag to ensure safety
• Handle
• Anonymous pointer (points to anything)
• Anything
• Stores any type value

62
type three_integers of integer, integer,
integer type three_names_integers of a
integer, b integer, c integer type the_union
of i integer/32, c cardinal/64, b
logical/boolean union type bit_address of
address 1 type bit_address of address
8 type integer_pointer of integer
equiv to address 8 type bit_pointer of
logical/bit equiv to address1 type
integer_reference of integer program test is
declare the_sum of integer cardinal
logical/boolean rational/32 declare h of
handle declare a of anything declare p
of integer declare i1, i2 of integer
delcare c1 of cardinal assign i1 into
the_sum assign the_sum into i2 assign
p into h the handle absorbs the pointer
assign i1 into a a can hold anything
assign c1 into a
63
Strings, Arrays, Buffers

• Arrays
• Dimension type can be customized
• Slices of arrays preserve range information
• Strings
• Array of items from 1 to x
• Dimension type can be customized
• Slices of strings begin at 1
• Buffers
• Fixed length string that wraps around itself
• Varying start and end positions
• Dimension type can be customized

64
type string_fixed of char/ascii(10) type
string_variable of ltchar/ascii,cardinal/64gt
string type array_fixed of ltchar/ascii, integer
coordinate x,ygt0,0 to 30,30 type
array_variable of ltchar/ascii, integer coordinate
x,ygt array type buffer_fixed of (byte,
10) type buffer_variable of ltchar/ascii,
cardinal/8gt buffer
65
Collections

• Entry
• a node of a linked list
• Segment
• a combination of string and pointer
• List
• appends new data at the end
• elements allocated in pages
• Stack
• FIFO
• Can be prioritized
• Sequence
• inserts new data
• elements allocated in pages
• Queue
• LIFO
• Can be prioritized

66
Collections (contd)

• Mask
• A bit mask
• Range
• A numeric range with upper and lower bounds
• Set
• A hashed set
• Doubles as a one-to-one map
• Table
• A hashed one-to-many mapping
• Group
• A special collected used for comparisons
• Graph
• Used for frequency tables

67
type entry of integer entry type segment of
ascii segment 100 type list of user_record
list 256 type stack of ltuser_record,
cardinalgt stack type sequence of user_record
sequence 32 type queue of user_record queue
type mask of ascii mask type range of number
range type set of ascii string set 19 type
table of ltascii string, cardinalgt table 89
type group of integer range group type graph
of ltascii string, numbergt graph
68
Type Qualifiers

• Immutable, Volatile

69
Records

• Three visibility states
• Public accessible anywhere
• Protected accessible by modules that declare
  access
• Private accessible within the module
• Two layout types
• Fixed in order of declaration
• Packed ordered to reduce record size
• Fields can be qualified to remove them from the
  build

70
Abstracts

• Interface to multiple record types
• Records mapped to abstracts using link directive
• Gives more flexibility in mapping abstracts
• Mappings can occur after declaration
• i.e. library types can still be mapped to
  abstracts
• Simplifies remapping of fields
• Fields can be qualified to remove them from the
  build
• Medley combines abstract with a group of records

71
record user_data is name, surname of ascii
string address, town of ascii string
zip_code of ordinal 10_000 when
enable_zip record payment_data having
visibility protected is name, last_name of
ascii string code of ascii(3) abstract
named_record is name of ascii string
surname of ascii string link user_data to
named_record link payment_data to named_record
is last_name gt surname record
register_f1having layout fixed is count of
register 30 enable_1 of logical/bit
enable_2 of logical/bit delay of register
50 hold of regsiter 30
72
medley Expression with unary, binary, ternary,
postfix, literal is target of expression
for unary, postfix, ternary left, right of
expression for binary, ternary string of
ascii string for literal value of integer
for postfix, literal procedure print_it with e
of Expression is program test is let
e1 new Expression_at_unary let e2 new
Expression_at_binary call print_it with e1
call print_it with e2
73
Abstract Data Types

• Mango can bind any type to a class
• Objects Classes Record
• Properties
• getter/setter methods
• Parameters
• Properties that can only be set at instantiation
• Delegates
• Multiple dispatch for aspects and aggregates
• Normal classes do not support inheritence

74
Object Construction

• Constructor (prelude)
• Destructor (finale)
• New style constructor
• Parameters and properties can be set before the
  constructor is called
• Only one constructor per class no overloading
• Constructor spans entire object.
• Variable initialization at declaration

75
class abc of integer is property value
of integer is update
assign operand into target query
assign target into result
method print is print value, target,
eol prelude assign 0 into
target finale call print with

76
object user_obj with cnt of integer, nm of ascii
string is state count of integer where
count cnt name of ascii string where
name nm letters of ascii mask
path, type of ascii string request
allocates at initialization request buffer of
ascii buffer upto cnt prelude fill
.letters with x in name yielding x finale
print Destroying object , name, eol
property path automatically does getter and
setter method parameter type of ascii string
is update assign operand
into .type query return
.type
77
Object Interfaces

• Interfaces (mixins)
• Separates sub typing concerns from implementation
• Interfaces are purely abstract. No associated
  code
• Uses link directive like record abstracts
• Bind operator links types to interfaces
  automatically

78
Interface printable with method write with
s of stream attribute default_format of
io_format attribute type_info of
type class print_integer of integer is
method write with s of stream property
default_format of io_format attribute type
of type link print_integer to printable where
type gt type_info program test is declare x
of integer where x 100 write log with x
, x, eol write (log) takes
printable interface only
79
Aggregates

• Composition instead of hierarchical inheritance
• Flattens the hierarchy easier to understand and
  maintain
• Overriding of methods is explicit
• Compiler can statically check for problems
• All publicly accessible methods must explicitly
  exported

80
aspect general_motors method ghi method
abc method def aspect truck is method
abc virtual method def aggregate
general_motors_truck is inherit
general_motors inherit truck override
abc in truck with ghi in general_motors
export abc in truck export ghi in
general_motors export def in
general_motors
81
aspect general_motors method ghi method
abc method def aspect truck with a of
integer, b of integer is method abc
virtual method def prelude
. aggregate general_motors_truck with a of
integer is inherit general_motors
inherit truck with a, 100 override abc in
truck with ghi in general_motors export abc
in truck export ghi in general_motors
export def in general_motors
82
Built in I/O Devices

• Mangos built in I/O devices are typed
• Six types of I/O devices
• file an operating system file
• text a line oriented text file
• stream an I/O stream
• port a connection listener
• database a database
• document a document (XML)

83
program test is open tx of ascii text where
path "test.txt" foreach line in tx over
i do print width5 -gt i, "", line
close tx
84
Procedures and Functions
85
Procedures

• Multiple inputs and output
• Call by localized reference
• Compiler makes a duplicate of a value on the
  stack if necessary
• Nested procedures
• Can reference variables within parents scope
• Return values are held in a named variable
• Possible to return values with assignment

86
Functions and Constants

• Real functions
• Essentially a single expression
• Extended with two case constructs
• Condition and conversion
• Constants
• Similar format to functions
• Evaluated only once, result is cached
• AKA Eiffel once function
• Clean way to instantiate global variables

87
Procedures and Functions (contd)

• Mango supports function/procedure pointers
• Both global and local procedures
• Invokation through expressions or statements
• Statement invokations automatically infer return
  types
• Labeled arguments possible

88
procedure test with a of integer, b of integer
yielding c of integer, d of integer is assign
a / b into c assign a b into
d Procedure yo_baby with a of integer, b of
integer yielding integer is procedure assign
of c of integer yielding integer is
assign c into result procedure compute with
d of integer, e of integer yielding integer is
return d / e call assign
with a b into d call compute with a, b
into e call compute with a d, b e into
result Function qvc with a of integer, b of
integer yielding integer is a / b when b
ltgt 0, a when b 0 and a ltgt 0,
b when b ltgt 0, 1 otherwise
89
Function fact with integer yielding integer is
1
when operand lt 1, operand fact(operand
1) when operand gt 1 Function qvc with a of
integer, b of integer yielding ascii string is
a / b when b ltgt 0, a when b
0 and a ltgt 0, b when b ltgt 0, 1
otherwise such_that 1
yields one, -1 yields minus
one, 2 to 50 yields fiftey,
51 to 100 yields one hundred,
else unknown constant total of
integer is 1 constant arena of arena is new
general_arena
90
function test with ascii string string,
integer/32 yielding logical/boolean is sx
when x gt 0, sy when y gt 0, "x"
otherwise of_type ascii string such_that
"true" yields true, "false yields
false else unknown where s
operand.1, x operand.2, y x
100 constant global_arena of arena is get
arena
91
procedure call_back_global with v of integer, p
of integer -gt void is call p with
v procedure call_back_local with v of integer,
p of integer -gtgt void is call p with
v procedure dump_global with v of integer is
print value , v, eol procedure doit with v
of integer is procedure dump_local with v of
integer is print value , v, eol
call call_back_local with v, dump_local
compiles call call_back_local with v,
dump_global compiles call
call_back_global with v, dump_local
fails call call_back_global with v,
dump_global compiles
92
Method Pointers

• Method pointers
• combine class state with class method
• When a method is selected from a class
• Result is a method pointer
• Special attribute and receptor pointers
• Automatically evaluated
• Method pointers are a supertype of function
  pointers
• Will absorb function pointers

93
class abc is method test1 with integer
yielding boolean parameter p1 of integer
attribute a1 of integer receptor r1 of
integer procedure p1 with integer yielding
boolean procedure test with a of abc is
declare m1 of integer gt boolean declare m2
of integer gt void declare m3 of void gt
integer assign a.test1 into m1 assign
p1 into m1 assign a.r1 into m2 assign
a.a1 into m3
94
Expressions
95
Operator Precedence
96
Arithmetic
97
Comparison/Logical
98
Casting
99
Membership

• in, not_in
• is, is_not
• like, not_like

100
Array

• , / for string comparisons

101
Production
102
Sequence Operators

• Generate sequence pick, every
• Test sequence some, all
• Compute sequence product, sum

103
Statements
104
Basic Blocks
105
Production
106
Placement
107
Arithmetic
108
Invokations
109
Control Flow
110
Iteration
111
Collection

• Add, replace, remove, take, trim, filter
• Find, extract, fill, compute, copy, modify

112
Program test is declare s1, s2, s3 of
integer set assign 1,2,3,4,5 into s1
add 9 into s1 add 10 into s1
replace 5 with 6 within s1 remove 1,2,3
from s1 filter s1 with 2, 4, 6 if
3 in s1 then print 3 is in the set
fill s2 with x in 1 to 100 where x
3 0 yielding x assign every x in 1 to
100 where x 3 0 yielding x into s2
find i of integer with x in s2 where x 33
yielding x extract I of integer with x in
s2 where x 66
113
I/O
114
Development
115
Iterators
116
Iterators

• Procedures to iterate through through collections

117
Exceptions
118
Exception Handling
119
Global variables
120
Variables
121
Global Constructors
122
Misc
123
Mutexes
124
Packets
125
Devices
126
Genericity
127
Genericity
128
Builds
129
Builds

• Assemblies, Platforms, and Prologues

130
Module Suffixes

• Runtime type identification
• Requests types that are used
• Therefore not all types need to be instantiated

131
Future Directions
132
Future Directions

• Finish the compiler
• Mango is the first in a family of languages
• Sharing type system and syntax
• Targeting a virtual machine

133
Application Language

• In the spirit of C or Java
• Reference semantics
• i.e. no user defined pointers
• Automated memory management
• With user intervention
• Less complicated type system
• More accessible language

134
Functional Language

• Functional/Dataflow semantics
• Strong focus on doing distributed computations
• Gateway to bring functional programming to the
  masses
• Accessible because of shared syntax and types

135
Record Processing Language

• Basically a replacement for COBOL
• The use of COBOL cripples the mind
• working within the limitations of the original
  COBOL programming model can make for robust and
  maintainable code
• Overlooked area by language designers

136
Command Language

• Cross between TCL and LISP
• Can be used as OS shell
• Eliza MIT LL4 conference
• Classification of Functions into 4 TypesltGgt
  GeneratorltCgt ConcentratorltTgt TransformerltFgt
  Filter
• Connected with pipes (aka unix shells)

137
Miscellaneous

• Standard Development Environment
• Text Editor, Debugger, Static Analysis, Etc.
• Programming is about community
• Programmers Organization
• Builds community
• Standards body
• Funds open source projects
• Earns revenue by supplying directory services

138
The End

• Thanks for listening
