Title: Heart of Brazos FutureGen Site


1
Heart of Brazos FutureGen Site
2
Overview of Heart of Brazos Site
Honorable Michael L. Williams Chairman,
FutureGen Texas Advisory Board Scott
Tinker FutureGen Texas Coordinating Team Jay
Kipper FutureGen Texas Coordinating Team Tom
Wilkinson Heart of Brazos Partnership Ken Simons
Heart of Brazos Partnership
3
9 Regional Councils of Governments Submitted a
Proposal
January 9, 2006
4
Regional Councils of Governments Two Sites
Selected
Heart of Texas
Permian Basin
Brazos
March 14, 2006
5
FutureGen
Proposed Jewett FutureGen Site
6
  • The proposed site rests just north of the town
    of Jewett, extending into Leon, Limestone, and
    Freestone counties. The site partially consists
    of the reclaimed mining areas of the Texas
    Westmoreland
  • Mine Co.
  • Injection sites exist primarily within Freestone
    and Anderson counties.

7
The Converging ForcesBringing FutureGen to Texas
  • Energy
  • Demand increasing for clean energy/power,
    hydrogen, national security.
  • Environment
  • Benefits of capturing and storing CO2 a major
    greenhouse gas.
  • Economy
  • Wellhead value, taxes, natural gas prices,
    infrastructure development, jobs.

8
Energy
  • Texas is 1 consumer of coal
  • Texas is 5 producer of coal
  • Texas has a 200 year supply of coal
  • Texas is 1 consumer of Hydrogen
  • Texas is 1 overall consumer and producer of
    electricity

9
Environmental Facts
  • Texas emits 700 million metric tons of CO2
    annually.
  • The U.S. emits 5,700 million metric tons
    annually.
  • About 220 billion tons of CO2 could be stored by
    filling just one percent of brine volume in
    sandstones from Alabama to Mexico border
    potentially offering a global solution for CO2
    emissions through carbon sequestration.

10
Economy
  • Affordable energy is necessary for economic
    development and job creation
  • Texas has been doing CO2 Enhanced Oil Recovery
    for over thirty (30) years, and has expertise and
    experience in the transportation and handling of
    CO2
  • A CO2 pipeline network is already in place in
    parts of Texas

11
Combustion Turbine
FutureGen IGCC w/ CO2 Capture
Steam
Syngas
Electricity
SteamTurbine
Steam
Hydrogen
H
Shift Reactor
CO2
CO2
Particulate Removal
Sulfur
Sulfur
Solids and Co-products
12
Geologic Storage
CO2 capture is a cornerstone of FutureGen. CO2
could be used for EOR to offset development cost
and speed implementation.
Oil
Very large volume Of CO2 storage potential in
brine formations beneath reservoir footprints
Brine
Gulf Coast Carbon Center
13
Site Attributes
14
Road Access
The site is bordered by Farm Road 39, which
intersects U.S. Highway 79, 10 miles (16
kilometers) from the site boundary and State
Highway 164, 8 miles (13 kilometers) from the
boundary. It is also conveniently situated near
Interstate 45.
15
Rail Lines
The Burlington Northern Santa Fe Railway line
runs along the northern border of the proposed
Heart of Brazos (HOB) site.
16
Existing Land Use
The FutureGen facility will be compatible with
existing land use.
17
Water Sources.
The primary water source available to this site
is a proposed groundwater well field developed
on-site and immediately adjoining the site.
18
Transmission Lines
A dual circuit 345-kV transmission line forms the
northwest boundary of the proposed site. The
interconnection will require only the
construction of a substation on the property.
19
Natural Gas Pipelines
The required start-up fuel for the
coal-gasification facilities to be utilized by
the FutureGen plant at the proposed Heart of
Brazos (HOB) site will be supplied by an existing
natural gas pipeline owned and operated by Energy
Transfer Corporation that enters the site at its
northwest corner.
20
Proposed Primary Injection Target
The proposed injection site is underlain by a
deep saline formation with four main injection
zones the Travis Peak Sands, The Rodessa and
Pettet lime grainstones, and the Woodbine sands
all beneath a primary seal, the Eagle Ford Shale.
21
Community Participation and Support
22
Community Participation
  • State of Texas has authorized 20 million direct
    contribution to FutureGen Alliance upon execution
    of contract
  • Workforce development funding from national,
    state, and local levels
  • TX Capital Fund Up to 500,000 to help pay for
    water lines to site or rail spur to site

23
NRG Energy donates 400-acre site adjacent to
Westmoreland mine to FutureGen Alliance. NRG
Energy offering FutureGen Alliance access to a
heliport site at their plant, adjacent to the
proposed site.
24
  • Texas Westmoreland contracts to provide ample
    supply of lignite coal as FutureGen fuel source.
  • Westmoreland, working with the surrounding
    counties to provide equipment to prep the site
    for construction

25
Community Support
  • Proposed Jewett site enjoys widespread support
    from elected officials in Limestone, Freestone,
    Anderson, and Leon counties
  • County Judges Byron Ryder (Leon), Daniel Burkeen
    (Limestone), and Linda Grant (Freestone), and
    Linda Ray (Anderson) have directed regional
    efforts to educate the community and build public
    support
  • Local news media has done an excellent job of
    educating area citizens on all aspects of
    proposed FutureGen site
  • More than 250 area residents attended the
    FutureGen Texas community briefing on June 29,
    2006 in Buffalo, Texas

26
Employment Opportunities
27
Estimations
  • 1300 skilled craftsman during peak construction
  • 50-75 permanent scientific researchers
  • 150 permanent workforce

28
Additional Benefits
  • The service field will be deeply effected by the
    arrival of FutureGen. Expansion will be
    necessary, which could create more jobs and
    revenue for the region.
  • Emergency Services
  • Fire
  • Law enforcement
  • EMS
  • Visitor Accommodations
  • Food Services
  • Health Care Services
  • Shopping

29
