Eastern Brook trout: Joint venture

1
Eastern Brook trout Joint venture

• Editors
• M. Hudy, USDA Forest Service
• T.M. Thieling, USDA Forest Service, James Madison
  University
• N. Gnat Gillespie, Trout Unlimited
• Eric P. Smith , Virginia Tech

2
and a cast of thousands

• New York
• D. Bishop
• J. Robins
• B. Hammers
• F. Angold
• W. Pearsall
• C. Guthrie
• D. Zielinski
• F. Linhart
• D. Cornwell
• W. Elliot
• L. Suprenant
• B. Angyal
• R. Pierce
• M. Flaherty
• F. Flack
• R. Preall
• J. Daley

• Virginia
• Larry Mohn
• Paul Bugas
• Steve Reeser
• Maine
• Merry Gallagher
• Paul Johnson
• Gregory Burr
• Rick Jordan
• Ron Brokaw
• Forrest Bonney
• David Howard
• James Pellern
• Francis Brautigan
• Timothy Obrey
• Nels Kramer
• David Basley
• North Carolina
• Doug Bestler

3
The Big Picture Through the eyes of a brook
trout!
4

• Study Area
• 25 of native range
• 70 of native range in the U.S.

5
Assessment goals

• Assess the loss of reproducing brook trout
  habitat as it relates to historic
  (pre-settlement) levels.
• Assess watershed perturbations by expert opinion

• Assess watershed level metrics using GIS
• Make an interactive database on the web (ArcIMS)

6
What the assessment is not

• Classification of wild trout
• Classification of recreational fishing quality or
  potential
• A value judgment on past or current management
  practices
• A viability assessment

7
Methods
8
What scale?
9
Appropriate Scale

• 5th level too big
• Stream reach too small (too many)
• 6th level just right

• How big is a 6th level watershed?
• 41-163 sq. km
• 1 quadrangle map

10
6th Level watersheds classifications (n gt 10,000)

• Preliminary classification with GIS layers
• Validation of Classifications with experts

11
Brook trout population status classifications by
6th level watershed

• Present Reduced
• (50 to 90 of historic habitat occupied)
• Present Greatly reduced ( lt 50 of historic
  habitat occupied)

• Unknown (no data)
• AbsentUnknown history (no brook trout today, not
  known if extirpated or never occurred)
• Never occurred
• Extirpated
• Present Qualitative
• (no quantitative data in watershed or gt 10
  years old)
• Present Intact
• (gt 90 of historic habitat)

12
Reducing subjectivity

• Consistency rules
• Data standards (quality age)
• Broad classification categories
• No brainers
• high repeatability
• Standard validation procedures with experts for
  each subwatershed (N gt 11,000)

13
Consistency Rules for reduction

• Documented loss of reproducing populations by
  current or historical data
• Only exotic coldwater species reproducing (within
  MacCrimmon and Campbell range)
• Exotics greater than 75 of coldwater fish
  biomass or numbers
• Brook trout carrying capacity reduced by greater
  than 90 from historic or reference data within
  the watershed
• Reproducing brook trout stream inundated by dam
  and converted to warm water
• Acid mine drainage, acid rain, etc eliminated
  habitat
• Severe channelization (stream paved)
• Watershed changed from coldwater to warmwater by
  riparian changes (documented water temp)

14
Results
15
Study Area 6th level watersheds

• Unknown no data 14
• Absent unknown history 5
• Extirpated 21
• PresentQualitative
• 19
• Present Intact 5
• Present Reduced 9
• Present Greatly reduced 27

16
Final Classifications

• Extirpated
• Predicted Extirpated from Unknown and Present
  qualitative
• Reduced gt 50
• Predicted Reduced gt 50 from Unknown and Present
  qualitative
• Intact gt 50
• Predicted Intact gt 50 from Unknown and Present
  qualitative

17
Study Area 6th level watersheds

• Extirpated 21
• Predicated extirpated 8
• Reduced gt50
• 28
• Predicated Reduced gt50 7
• Intact gt50 14
• Predicated Intact gt50 17
• Absent Unknown History 5

18
Limiting factors by watershed(expert opinion)
19
Limiting factors by watershed(mark all that
apply)

• 1 high impact loss of life cycle component
• 2 medium impact life cycle component reduced
  but not lost
• 3 low impact potential future impact on life
  cycle component reduction or loss

20
Streams
21
Top Ten Threats Streams Cumulative Categories 1
2n 4,484

• Agriculture 36
• High Water Temperature 35
• Sediment-Roads 27
• All Exotics 26
• Urbanization 25
• Riparian Habitat 22.
• Brown trout 19
• Stream Fragmentation - Roads Culverts 17
• Dams 15
• Forestry 15

22

• Number 1 perturbation
• Agriculture

23

• Number 2 perturbation
• water temperature

24

• Number 3 perturbation
• urbanization

25

• Number 4 perturbation
• Exotics

26

• Number 12 perturbation
• Acid mine drainage

27
Lakes
28
Top Ten Threats Lakes Cumulative Categories 1
2n 1,294

• All Exotics 25
• Smallmouth bass 14
• Other cool/warm exotics 13
• Largemouth bass 10
• Dissolved oxygen 4
• Eutrophication 4
• Forestry 3
• Water temp 3
• Brown trout 3
• Northern pike 3

29
GIS Analysis
30
10,838 6th level subwatersheds
31
Candidate Metrics
Subwatershed and Subwatershed Corridor Scale

• Road Density
• Dams/area
• Road/Stream Crossings
• Population Density
• NO3 and SO4 Deposition
• Exotics
• Elevation
• Latitude/Longitude
• Land Use (21 land use classes)

Over 60 Metrics
32
National Land Cover Data (30m)
Human Uses
Natural Cover

• Low Intensity Residential
• High Intensity Residential
• Commercial/Industrial/ Transportation
• Quarries/Strip Mines/Gravel Pits
• Transitional
• Orchards/Vineyards
• Pasture/Hay
• Row Crops
• Small Grains
• Fallow
• Urban/Recreational Grasses

• Woody Wetlands
• Emergent Herbaceous Wetlands
• Open Water
• Perennial Ice/Snow
• Bare Rock/Sand/Clay
• Deciduous Forest
• Evergreen Forest
• Mixed Forest
• Shrubland
• Grasslands/Herbaceous

Derived Cover

• Total Forested
• Agriculture
• Residential
• Human Use

33
Metric testing screening

• Completeness
• Correct for watershed size
• Range
• Redundancy
• Responsiveness to classification categories

34
Model Development

• We tried
• Single metric logistic regression
• Multi metric logistic regression
• CART Classification Trees
• Discriminate
• Nearest neighbor

35
We picked CART classification trees
Because

• Higher of correct predictions
• Easier interpretation than logistic (especially
  trinomial) multi metric
• Helps in development of thresholds for land
  managers

36
What CART classification trees do

• Look at all possible combination of metrics and
  metric values to most efficiently divide the
  dataset
• Sets up a decision tree using different metric
  values as splitting criteria (20 80 couplets)
• Predicts the probability of correct
  classifications at terminal nodes

37
Final Core Metrics for CART Analysis

• Forested land
• Agricultural land
• Combined N03 SO4 deposition (kg/ha)
• Road density (km/km2)
• Mixed forested land in corridor
• Latitude (decimal degrees)

38
(No Transcript)
39
(No Transcript)
40
Model Development CART

• M1 Presence Extirpated
• 5 core metrics
• M2 Presence Extirpated
• 5 core metrics latitude
• M3 Extirpated Reduced gt 50 Intact gt50
• 5 core metrics
• M4 Extirpated Reduced gt 50 Intact gt50
• 5 core metrics latitude

41
M1 Presence Extirpated79 correct overall80
Extirpated78 Present

• Forest lt 68
• Deposition lt 23 kg/ha
• Road Density lt 1.19 km/km2
• Riparian Mixed Forest lt12
• Deposition lt 23 kg/ha
• Deposition lt 28 kg/ha

42
(No Transcript)
43
(No Transcript)
44
M3 Extirpated Reduced gt 50 Intact gt 5071
correct overall76 Extirpated64 Reduced79
Intact

• Forest lt68
• Deposition lt 28 kg/ha
• Deposition lt 19 kg/ha
• Agriculture lt 27
• Road Density lt 1.67 km/km2
• Deposition lt 18 kg/ha

45
(No Transcript)
46
(No Transcript)
47
Study Area 6th level watersheds

• Extirpated 21
• Predicated extirpated 8
• Reduced gt50
• 28
• Predicated Reduced gt50 7
• Intact gt50 14
• Predicated Intact gt50 17
• Absent Unknown History 5

48
(No Transcript)
49
(No Transcript)
50
(No Transcript)
51
(No Transcript)
52
(No Transcript)
53
(No Transcript)
54
(No Transcript)
55
Model Analysis
56
Areas of misclassification
1. Extirpated subwatersheds misclassified as
presentExotic species?
57
Areas of misclassification
2. Reduced and Intact subwatersheds predicted as
Extirpated Low Total Forest and High
Deposition. Watershed size??
58
Key findings
59
Trouts there be good store in every brook,
ordinarily two and twenty inches

• John Josselyn New England 1674

60
Brook trout are extirpated from 29 of the
subwatersheds and reduced gt 50 in another 35

• The majority of large riverine habitats are gone

61
Presence does not equal persistence
62
Even with no further degradation many of the
Reduced gt 50 populations could become Extirpated.

• No connectivity or redundancy to reestablish
  populations after stochastic events
• Exotics fill in
• 330 subwatersheds highly vulnerable to extirpation

63
I have given the matter considerable thought,
and frankly I can think of not one stream that I
would classify as predominately brook trout. This
state and neighboring states have spent most of
their time and money stocking brown trout in what
were good brook trout waters

• All about Brook Trout from Maine to California
  Bob Elliot 1950

64
Exotics, Exotics, Exotics!!!

• Biggest non land use threat
• Rainbow trout in south east
• Brown trout in New York, New England
• Smallmouth bass in lakes
• Metric ??

65
If you dont know where you are going any road
will get you there !
66
Important quantitative data gaps exist for many
stream habitats (33 ) in large portions of
Maine, New Hampshire, New York with smaller gaps
in portions of Vermont, Massachusetts and West
Virginia.

• Need to validate the predictive models
• Quantitative needed for monitoring land use
  changes and exotics

67
very large and nice trout were formerly caught
here but since the introduction of pickerel about
the year 1820 but very few trout have been
taken
68
Lake populations have all but been eliminated
except for a few strong holds in Maine

• Vulnerable to exotics
• Vulnerable to land ownership changes

69
While many extirpations and losses occurred at
the turn of the century, many documented losses
have occurred in the last ten years.

• 75,000 dams
• 2 million miles road
• 90 million people

70
Land use metrics at the subwatershed level are
useful predictors of brook trout for land managers
71
Core Metric Total Forest

• Land managers should be concerned as Total
  Forested in the subwatershed drops below 68
• Only 6 of Intact gt 50 subwatersheds have less
  than 68 Total Forest.
• 85 of Extirpated subwatersheds have less than
  68 Total Forest

72
Core Metric Agriculture

• Land managers should be concerned if the
  Agriculture in the subwatershed is in the 12-19
  range or greater
• Only 17 of Intact gt 50 subwatersheds have
  greater than 19 Agriculture
• 74 of Extirpated subwatersheds have greater than
  12 Agriculture

73
Core Metric NO3 SO4 Deposition (kg/ha)

• Land managers should be concerned if the
  Deposition in the subwatershed is in the 24 - 33
  kg/ha range or greater
• Only 23 of Intact gt 50 subwatersheds have a
  Deposition greater than 33 kg/ha
• 94 of Extirpated subwatersheds have a Deposition
  greater than 24 kg/ha

74
Core Metric Riparian Mixed Forest

• Land managers should be concerned if the
  Riparian Mixed Forest in the subwatershed
  corridor is less than the 17-20 range
• Only 35 of Intact gt 50 subwatersheds have a
  Riparian Mixed Forest less than 17
• 81 of Extirpated subwatersheds have a Riparian
  Mixed Forest less than 20

75
Core Metric Road Density (km/km2)

• Land managers should be concerned if the Road
  Density in the subwatershed is in the 1.8-2.0
  km/km2 range or greater
• Only 17 of Intact gt 50 subwatersheds have a
  Road Density greater than 1.8 km/km2
• 72 of Extirpated subwatersheds have a Road
  Density greater than 2.0 km/km2

76
Next steps Brook trout populations 2015 ?
77
Brook trout Life Histories
78
(No Transcript)
79
(No Transcript)
