Title: Oppenheimer Technologies


1
Oppenheimer Technologies
  • Rick King
  • Jonathan Creekmore

2
Problem
  • Current programming solutions for the Ubicom SX
    microcontroller are expensive.
  • Typical costs range from 150-240.

3
Requirements
  • Our product must
  • Program all Ubicom SX microcontrollers
  • Cost less than current solutions
  • Be manufacturable using equipment at Mississippi
    State University

4
The ProgrammingSpecification
  • 17 Frames Per Word
  • 4 Cycles Per Frame
  • Application of 12V DC Required to Program Flash
    Memory

5
Hardware Design
Ubicom SX-18
Flash Programming Voltage
In-System Programming Interface
PC
Target System
6
RS-232 Interface
Ubicom SX-18
PC
7
RS-232The Concept
  • Most Commonly Available Serial Communications
    Protocol for Computer.
  • Transceiver Necessary to Translate Between RS-232
    Voltage Levels and CMOS Levels.

8
The Hardware
2
2
MAX233
SX18
DB9
9
Wheres the UART?
  • A UART Converts Between Asynchronous Serial Data
    and Parallel Data
  • This Function is Performed in Firmware by the
    SX-18 using Ubicoms Virtual Peripheral UART.

10
Flash ProgrammingVoltage
Ubicom SX-18
Flash Programming Voltage
Target System
11
Where, Oh Where?
  • Where can 12V DC be generated from?
  • An op-amp?
  • Derive it from the RS-232 lines?
  • An IC whose single purpose is to generate a 12V
    signal from a 5V signal?

12
In-System Programming Interface
Ubicom SX-18
In-System Programming Interface
Target System
13
Firmware
  • UART Virtual Peripheral
  • HandleCycle and HandleFrame
  • System Control Code

14
The ProgrammingSpecification (again)
  • 17 Frames Per Word
  • 4 Cycles Per Frame
  • Application of 12V DC Required to Program Flash
    Memory

15
Waveform
The Data Word is 0x1FCE.
16
Hardware Costs
  • Current Parts Cost 30.00
  • Possible Cost Reductions
  • Reduce PCB Cost from 10 to 0.70
  • Potential Cost (1000 quantity) 15.00

17
Software Design
PC Programming Software
Data Link Layer
ISP Protocol Interface
Programmer
18
RS-232 Interface
PC Programming Software
Data Link Layer
Programmer
19
RS-232 Interface
  • Implements a raw serial interface to the embedded
    device.
  • Contains commands to send and receive arbitrary
    length strings of binary data.
  • Test Bench
  • Send text and binary strings across serial
    connection to a software implemented loop-back.
  • Status Passed

20
DLL Interface
PC Programming Software
Data Link Layer
Programmer
21
DLL Interface
  • Contains a single command to send binary data and
    block until the receipt of a binary response.
  • Implements a simple checksum algorithm to aid in
    debugging of the communications channel.

22
DLL Interface
  • Test Bench
  • Send text and binary strings across serial
    connection.
  • Interject errors in the payload data and check
    for data consistency in the response.
  • Status Passed

23
ISP Protocol Interface
PC Programming Software
ISP Protocol Interface
24
ISP Protocol Interface
  • Contains the following commands
  • Start Session
  • End Session
  • Erase Device
  • Read Device Word
  • Read FuseX Word
  • Program FuseX Word
  • Load Data Word
  • Program Data Word
  • Read Data Word
  • Increment Address

25
ISP Protocol Interface
  • Each command is followed by a repeat count to
    increase the throughput of the serial
    communications channel.
  • Test Bench
  • Commands are sent through a test program and the
    responses are analyzed to determine if the
    correct action was taken.
  • Status Passed

26
File Format Interface
PC Programming Software
27
File Format Interface
  • Contains functionality to read and interpret the
    Intel 8-bit Merged file format.
  • Contains functionality to interpret out-of-band
    information such as the Fuse and FuseX bits.
  • Test Bench
  • Compare output of the filter with the data used
    to generate the file.
  • Status Passed

28
Screenshot
29
Future Directions
  • All SMT Design
  • USB Serial Interface
  • In-System Debugging
  • Integrated Assembler and Simulator

30
Demo
  • Create sample program that has output noticeable
    to the audience.
  • Such as a blinking LED?
  • Modify program based on audience interaction.
  • Such as changing the blink rate?
  • Program test microcontroller and demonstrate with
    the new code.
