Model Characteristics And Practical Solvers In Nonlinear Programming

1
Model Characteristics And Practical Solvers
InNonlinear Programming

• Arne Stolbjerg Drud

2
General NLP Model

• Minimize f(x)
• Subject to
• g(x) b
• lb x ub
• Other forms can be useful for special cases, e.g.
  inequality formulations for convex models.
• We assume that all nonlinear functions are
  sufficiently smooth and differentiable.
• Notation n dim(x) and m dim(g)

3
Modeling Environment

• Models are formulated in a modeling system such
  as AMPL, AIMMS, GAMS, ...
• Function values, first and second derivatives and
  their sparsety patterns are easily available
  (without user intervention).
• Function and derivatives are fairly cheap.

4
Optimality Conditions

• Lagrange Function
• L(x,y) f(x) yT(g(x)-b)
• Optimality Conditions
• Primal g(x) b, lb x ub
• Dual df/dx yTdg/dx - 0, -8 y 8
• The orthogonality operator - is defined
  componentwise as
• if xi lbi then elseif xi ubi then
  else

5
Perturbed Optimality Conditions

• The Optimality Conditions are usually solved
  using some perturbation method related to Newtons
  Method.
• Evaluate all nonlinear terms and derivatives at a
  base point x0,y0 and solve for ?x,?y
• Primal g dg/dx?x b
• Dual df/dx d2f/dx2?x y0Td2g/dx2?x
  y0Tdg/dx ?yTdg/dx - 0

6
The KKT Matrix
7
Sources of Difficulty

• Combinatorics
• The Combinatorial nature of the orthogonality
  operator which bounds are active and which are
  not and therefore which dual constraints are
  active and which are not.
• Nonlinearity
• The Nonlinear nature of the objective and
  constraints local properties will in general not
  hold globally.

8
Nonlinearity
9
Handling Combinatorics

• Interior Point Methods
• Bounds are penalized using a log-barrier
  function.
• A large equality constrained problem is solved
  for a series of penalty values.
• Active Set Methods
• The set of active inequalities bounds is guessed.
• A small equality constrained sub-problem is
  solved to find an improving point.
• The guessed set of active inequalities is updated
  iteratively.

10
Handling Nonlinearity

• General Methods Iterate using Linear or
  Quadratic Approximations
• Special Methods Numerous methods tailored to
  take advantage of available information, special
  forms, etc, e.g.
• Sum of Square models can use special
  approximations (Gauss-Newton).
• Models without bounds can avoid combinatorics.
• Models without equality constraints can avoid
  projections.
• QPs are different from general NLPs

11
Interior Point Methods

• Lagrange Function
• L(x,y) f(x) yT(g(x)-b)
• µ?i(log(xi-lbi)log(ubi-xi))
• Optimality Conditions
• Primal g(x) b, lb x ub
• Dual df/dxi yTdg/dxi
• µ((xi-lbi)-1-(ubi-xi )-1) 0, -8 y 8

12
Interior Point KKT Matrix

• where Di µ((xi-lbi)-2(ubi-xi )-2) is a
  diagonal matrix with non-negative entries.

13
Degree of Nonlinearity
Nonconvex NLP
Convex NLP
Convex QP
LP
14
Interior Point LP

• Use diagonal matrix D as block-pivot and we get
  the usual interior point matrix AD-1AT in y-space

15
Interior Point Convex QP
16
Interior Point Convex QP

• A block-pivot on QD gives the reduced matrix M
  A(QD)-1AT in y-space.
• In practice Compute a Cholesky factorization of
  QD LLT (QD is positive definite) and
  compute M (A L-T) (A L-T)T.
• The ordering for sparse Cholesky factorization of
  both QD and M can be done once.
• The density of M will depend on the off-diagonal
  elements in Q

17
IP Separable Convex QP

• If the QP is convex and separable, e.g. sum of
  square models, then Q and (QD) are diagonal.
• All numerical work is equivalent to the numerical
  work in LP.
• Convergence is as fast as for LP.

18
Interior Point Convex NLP
19
Interior Point Convex NLP

• The usual block-pivot matrix HD is positive
  definite.
• A block-pivot on HD gives the reduced matrix M
  J(HD)-1JT in y-space.
• All work is exactly as in the convex QP case
  (except for repeated evaluation of J and H).
• All sparse ordering can be done once.
• Same convergence properties as for LP.

20
Interior Point Nonconvex NLP
21
Nonconvex NLP Technical Difficulties

• The block-pivot matrix HD is NOT necessarily
  positive definite and a Cholesky factorization
  may not exist.
• The factorization of the indefinite KKT system
  must be done as one system including both primal
  and dual parts
• The factorization result in an LD1LT
  factorization where D1 is block-diagonal with 1
  by 1 and 2 by 2 blocks.

22
Nonconvex NLP Mathematical Problems

• The model may have several locally optimal
  solutions.
• The constraints may have infeasible points with
  local minima for various measures of
  infeasibility, even if the model is feasible.
• The direction derived from the KKT system may not
  be a descend direction.
• No reason to expect fast convergence for interior
  point methods.

23
More Technical Difficulties

• Extra proximity-terms can be added to D to
  make approximation model more convex and force
  descend directions.
• Interia-methods can be used to test if HD
  projected on the constraints is positive
  definite.
• Changes in D require re-factorization.
• Sparse ordering cannot be done a priori.
  Re-factorization is expensive.

24
Software based on IP Methods

• For General NLP
• LOQO Shanno, Vanderbei, Benson, ...
• IPOPT Weachter, Biegler.
• KNITRO Byrd, Nocedal, Waltz, ...
• For Convex NLP
• Mosek
• For Convex QP and Convex Quadratic Constraints
• Cplex with barrier and QP option

25
IP Software LOQO

• Adds a proximity term to the constraints giving
  the KKT matrix an extra nonzero block in lower
  right hand corner. Should improve stability.
• Factorization uses only 1 by 1 pivots (positive
  and negative).
• User can select ordering as primal-first or
  dual-first. Standard ordering methods are used
  within each group.

26
IP Software IPOPT

• Freely available via COIN-OR.
• Based on 3rd party factorization software
  (Harwell Subroutine Library).

27
IP Software KNITRO

• Based on 3rd party factorization software
  (Harwell Subroutine Library).
• Commercially available from Ziena Optimization.
• Available with AMPL, GAMS, and stand-alone.
• Has alternative active set methods based on LP
  methods for guessing active constraints and
  equality constrained QPs for search directions.
• Can use Conjugate Gradients instead of
  factorization for solving KKT system.

28
Comparison of IP Software

• LOCO, IPOPT, and KNITRO are mostly used with
  AMPL.
• Published comparisons based on the CUTE-R set of
  models show solvers to be similar ratings
  changes frequently.
• Difficulties are related to
• Slow Analyze/Factorize for the KKT matrix.
• Newton steps are not good gt very many iterations
  with short steps on some non-convex models.
• Several CUTE-R models seem to be constructed to
  hurt the competition.

29
Active Set Methods

• The variables are partitioned into 3 sets
• At Lower Bound (LB), At Upper Bound (UB), and
  Between Bounds (BB).
• The dual constraints are as a consequence
  partitioned into
• Binding as , Binding as , Binding as
• Fixed variables and non-binding constraints are
  temporarily ignored, a smaller model is used to
  determine a search direction, and the sets are
  updated.

30
Active Set Methods
31
Active Set Methods
32
Active Set Methods
33
Active Set Methods
34
Active Set Methods

• The Active Set Optimality Conditions
• Have Fewer Variables
• Have Fewer Dual Constraints and only Equalities
• Are Symmetric
• A direction ?x, ?y is computed based on the
  smaller system and a step is made.
• The sets BB, LB, and UB are updated if necessary.

35
Active Set Strategies

• Dual Equalities with Accurate or Approximate H?
• Many active set methods date to a period when 2nd
  derivatives were not easily available.
• Reduced Hessians (see later) may be cheaper to
  work with than complete Hessians.
• How are the Active Set Optimality Conditions
  solved?
• Direct factorization or partitioning methods.
• Updating or Refactorization.

36
Active Set Strategies

• How is the step ?x, ?y used?
• Minor iterations using the same linearized KKT
  system.
• Major iterations using accumulated ?x, ?y from
  minor iterations.
• Step at Major iterations use some Merit Function
  (usually based on primal information only).
• When are the sets BB, LB, and UB updated?
• Variables must be moved from BB to LB or UB when
  they reach a bound.
• Variables can be moved from LB or UB to BB when
  dual inequalities are violated. Number of
  variables to move and test frequency vary.

37
Active Set Optimality Conditions

• Direct Factorization
• The Symmetric Indefinite system is factorized as
  LDLT where D is block triangular with 1 by 1
  and 2 by 2 blocks and L is lower triangular.
• Updates when LB, BB, and UB changes.

38
Active Set Optimality Conditions

• Partitioning
• J is partitioned in B, a non-singular Basis, and
  S Superbasis.
• B and BT are used as Block Pivots.
• The B-parts of H are eliminated.

39
Active Set Optimality Conditions

• B-1S not formed explicitly.
• The Reduced Hessian, RHSS, is complicated,
  symmetric, and dense.
• RHSS can be approximated using Quasi-Newton
  methods.
• Simplex-like updates used for B-1, projection
  updates used for RHSS.

40
Software based on Active Sets

• MINOS and SNOPT, Saunders, Gill, ...
• CONOPT, Drud
• Many others, especially based on dense linear
  algebra for small-scale models

41
SNOPT

• How are the Active Set Optimality Conditions
  solved?
• Partitioning Primal constraints are satisfied
  accurately using Basis and Simplex technology.
  Phase-1 procedure.
• Overall Hessian is not used -- Reduced Hessian is
  approximated using Quasi-Newton methods with
  updates between Major iterations.
• Reduced Hessian stored as dense lower triangular
  matrix gt space can be a problem.
• Minor/Major iterations.

42
SNOPT

• How is the step ?x, ?y used?
• Standard minor/major iteration approach.
• Merit function needs accurate solution to primal
  constraints to guarantie descend.
• How are the sets BB, LB, and UB updated?
• Standard use of Basis Superbasis.
• B is updated as in Simplex when basis changes.
• RH is projected when basis changes.
• Diagonal added when RH is increased.

43
CONOPT

• How are the Reduced Optimality Conditions solved?
• Partitioning Primal constraints are satisfied
  accurately using Basis and Simplex technology (as
  SNOPT).
• Special fast SLP phase with H 0 is used when
  it is considered acceptable, i.e. bounds are
  more important than curvature.
• Uses either one Hessian evaluation per major
  iteration or one Hessian-vector evaluation per
  minor iteration. Selection based on
  availability and expected work.

44
CONOPT

• How are the Reduced Optimality Conditions solved
  (continued)?
• Reduced Hessian approximated using Quasi-Newton
  methods (as SNOPT), but updated at appropriate
  minor iterations.
• Conjugate Gradients are used in the xs space when
  Reduced Hessian becomes too large. Diagonal
  preconditioning is used if available.
• Dual equalities are solved using minor
  iterations stop when expected change in
  objective is good.

45
CONOPT

• How is ?x, ?y used?
• ?x and ?y are accumulated over minor iterations
  (as SNOPT).
• ?xS is used directly. ?xB is used as initial
  point in a Newton process with B-1 to ensure
  feasibility of the actual Primal constraints (as
  opposed to the linearized Primal constraints).
• Newton Process requires many primal function
  evaluations.
• Step is determined using actual objective
  function (Primal feasibility means that Merit
  function is not needed).

46
SNOPT
Merit function
Initial point
Tangent plane
Final Point
Constraint
47
CONOPT
Initial point
Tangent plane
Newton process restores feasibility
Constraint
True objective tested in linesearch
48
CONOPT

• How are the sets BB, LB, and UB updated?
• Similar to SNOPT but details are different.
• More aggressive movement of variables from LB/UB
  to BB, motivated by cheaper and more frequent
  updates of Reduced Hessian (every minor
  iteration).

49
Comparison SNOPT/CONOPT

• Models with fairly linear constraints are good
  for SNOPT.
• CONOPTs SLP procedure good for Easy models.
• The Newton process in CONOPT is costly but useful
  for very nonlinear models gt CONOPT more
  reliable.
• Many superbasics cannot be handled by SNOPT
  (space).
• Large unpredictable variation in relative
  solution time.

50
Comparison IP/Active Set

• Active Set Methods usually good for models with
  few degrees of freedom, Interior Point for models
  with many degrees of freedom.
• Relative solution times can vary by more than a
  factor 100 both ways.
• Our ability to predict which solver will be best
  is fairly limited.

51
GAMS/Globallib Performance profile ignoring
objective value
52
GAMS/Globallib Performance profile - best
objective only
53
Limitations for NLP models

• Models with over 100,000 variables equations
  have been solved, but models with 10,000 can be
  unsolvable.
• Most models below 1000 varequ should be solvable
  unless poorly formulated.
• We can usually iterate or move on vary large
  models (500,000 VarEqu), at least for Active Set
  methods. Convergence is the problem.
• We have no way to predict if a model can be
  solved or not.

54
Personal Favorites

• Do easy things with cheap algorithms.
• Recognize when in trouble and switch algorithm.
• Change from Active Set to Interior Point.
• Easy use of Multi-Processor Run two different
  solvers in parallel.

55
Conclusions

• We can solve many fairly large NLP models.
• Solution times are often over 10 times larger
  than for comparable LPs.
• Reliability is considerably lower than for LP.
• Good model formulation is very important for
  reliability and speed.
• Large variation between solvers. No good
  automatic solver selection.
• Future Linear Algebra, Numerical Analysis,
  Pre-processing, and better model formulation.
