Body Impedance Analysis

1
Body Impedance Analysis

• David Fu
• 7-Jan-03

2
Content

• Introduction
• Theory of BIA
• Application
• Designation of BIA Equipment
• Problem and Discussion
• Conclusion

3
Introduction

• A newer method
• Simplicity
• Safety
• Non-invasive

4
Theory of BIA

• A very small current through the body
• 800 mA at 50 kHz
• Measuring its resistance
• Lean tissue offers less resistance
• more water
• electrolytes
• Adipose tissue(Fatty tissue).

5
Theory of BIA
6
Application
7
Application
8
Application Testing Procedure

• Do not have exercised or taken a sauna within 8
  hours
• Refrain from alcohol intake for 12 hours prior .
• The height and weight should be accurately
  measured and recorded.
• Quietly during the entire test.

9
Application

• The arms 30 degrees from the body and legs not
  touching.
• The electrode sites may need to be cleaned with
  alcohol
• if the skin is dry or covered with lotion.
• Attach the electrodes and patient cables.
• Name, age, gender, height and weight

10
Application
11
Application
12
Designation of BIA Equipment

• Principle
• Measuring the Value of Resistance
• Small current for safety consideration

13
Designation of BIA Equipment
Vref
Vout Rf/(RhRf)Vref Rh(Vref-Vout)/VoutRf
????
Rh
Vout
R 1M
Rf
14
Designation of BIA Equipment
Vout Zf/(ZhZf)Vref Zh(Vref-Vout)/VoutZf
Vref
AC 50KHz signal gen.
Probe
Zh
Z 1.5K
Vout
Zf
15
Problems and Disscussion
Zi Signal Generator inner impedance The Zi will
change by different device component
Vref
AC 50KHz signal gen.
Probe
Zh
Vout
Zf
16
Problems and Disscussion

• Solutions
• AC signal generator
• AC constant current source
• AC voltmeter
• Ideal diode circuit
• Peak value detector

17
Problems and Disscussion
AC signal gen.
Constant Current
Body Tissue
Ideal Diode
Peak Value Detector
ADC / Algorithm
Body Fat
18
Conclusion

• Need more knowledge of both Bio-system and
  Mechatronic system.
• Problems of integration between Bio-system and
  Mechatronic system.
• Safety consideration
