The Biggest Unknowns in Functional MRI

1
The Biggest Unknowns in Functional MRI

• Peter A. Bandettini, Ph.D
• bandettini_at_nih.gov
• Unit on Functional Imaging Methods
• Functional MRI Facility
• Laboratory of Brain and Cognition
• National Institute of Mental Health

2
Functional Neuroimaging Techniques
Non-invasive
Log Size (mm)
Invasive
Log Time (sec)
3
(No Transcript)
4
Uses
Understanding normal brain organization and
changes -networks involved with specific tasks
(low to high level processing) -changes over
time (seconds to years) -correlates of behavior
(response accuracy, performance
changes) Clinical research -correlates of
specifically activated networks to clinical
populations -presurgical mapping
Future Uses
Complementary use for clinical diagnosis -utiliza
tion of clinical research results -prediction of
pathology Clinical treatment and
assessment -drug, therapy, rehabilitation,
biofeedback -epileptic foci mapping -drug
effects Non clinical uses -complementary use
with behavioral, anatomical, other modality
results -lie detection -prediction of behavior
tendencies -brain/computer interface
5
(No Transcript)
6
Type of fMRI research performed
Motor (black) Primary Sensory (red) Integrative
Sensory (violet) Basic Cognition
(green) High-Order Cognition (yellow) Emotion
(blue)
J. Illes, M. P. Kirschen, J. D. E. Gabrielli,
Nature Neuroscience, 6 (3) p.205, 2001
7
Methodology
Technology
Neuroscience
Interpretation
Applications
8
The Biggest Unknowns in Functional MRI

1. Relationship between neuronal activity and fMRI.
2. Sources of fMRI dynamic characteristics.
3. Sources of spatial and temporal variability.
4. Whats really in the noise?
5. Whats resting state?
6. Other sources of functional contrast?
7. Ultimate temporal resolution?
8. Ultimate spatial resolution?
9. Ultimate clinical utility?
10. Best processing and display methods?
11. Optimal field strength?

9
The Biggest Unknowns in Functional MRI

1. Relationship between neuronal activity and fMRI.
2. Sources of fMRI dynamic characteristics.
3. Sources of spatial and temporal variability.
4. Whats really in the noise?
5. Whats resting state?
6. Other sources of functional contrast?
7. Ultimate temporal resolution?
8. Ultimate spatial resolution?
9. Ultimate clinical utility?
10. Best processing and display methods?
11. Optimal field strength?

10
Motor Cortex
Auditory Cortex
S. M. Rao et al, (1996) Relationship between
finger movement rate and functional magnetic
resonance signal change in human primary motor
cortex. J. Cereb. Blood Flow and Met. 16,
1250-1254.
J. R. Binder, et al, (1994). Effects of stimulus
rate on signal response during functional
magnetic resonance imaging of auditory cortex.
Cogn. Brain Res. 2, 31-38
11
Flow modulation is not necessarily the same as
BOLD modulation
12
(No Transcript)
13
fMRI responses in human V1 are proportional to
average firing rates in monkey V1?
Heeger, D. J., Huk, A. C., Geisler, W. S., and
Albrecht, D. G. 2000.Spikes versus BOLD What
does neuroimaging tell us about neuronal
activity? Nat. Neurosci. 3 631633.
0.4 spikes/sec -gt 1 BOLD
Rees, G., Friston, K., and Koch, C. 2000. A
direct quantitative relationship between the
functional properties of human and macaque V5.
Nat. Neurosci. 3 716723.
9 spikes/sec -gt 1 BOLD
14
Magnitude
Jesmanowicz, P. A. Bandettini, J. S. Hyde, (1998)
Single shot half k-space high resolution EPI
for fMRI at 3T. Magn. Reson. Med. 40, 754-762.
15
Relationship between neuronal activity and BOLD.
Magnitude
16
Relationship between neuronal activity and BOLD.
Location
17
T1 - weighted
Flow weighted
T2 weighted
BOLD weighted
P. A. Bandettini, E. C. Wong, Echo - planar
magnetic resonance imaging of human brain
activation, in "Echo Planar Imaging Theory,
Technique, and Application" (F. Schmitt, M.
Stehling, R. Turner, Eds.), p.493-530, Springer -
Verlag, Berlin, 1997
T1 and T2 weighted
Flow and BOLD weighted
18
Anatomy
BOLD
Perfusion
P. A. Bandettini, E. C. Wong, Magnetic resonance
imaging of human brain function principles,
practicalities, and possibilities, in
"Neurosurgery Clinics of North America
Functional Imaging" (M. Haglund, Ed.), p.345-371,
W. B. Saunders Co., 1997.
19
NeuroImage, 19 132-144, (2003).
20
(No Transcript)
21
(No Transcript)
22
Relationship between neuronal activity and BOLD.
23
The Biggest Unknowns in Functional MRI

1. Relationship between neuronal activity and fMRI.
2. Sources of fMRI dynamic characteristics.
3. Sources of spatial and temporal variability.
4. Whats really in the noise?
5. Whats resting state?
6. Other sources of functional contrast?
7. Ultimate temporal resolution?
8. Ultimate spatial resolution?
9. Ultimate clinical utility?
10. Best processing and display methods?
11. Optimal field strength?

24
Sources of BOLD dynamic characteristics.
Yacoub E, Le TH, Ugurbil K, Hu X (1999) Magn Res
Med 41(3)436-41
Courtesy of Arno Villringer
25
Sources of BOLD dynamic characteristics.
Pre-undershoot
26
Post-undershoot
27
Sources of BOLD dynamic characteristics.
Lu, et al (2004), ISMRM 271
28
Different stimulus ON periods
Dynamic Nonlinearity Assessment
measured
linear
BOLD Response
Signal
Stimulus timing
0.25 s
0.5 s
1 s
2 s
20 s
Brief stimuli produce larger responses than
expected
R. M. Birn, Z. Saad, P. A. Bandettini, (2001)
Spatial heterogeneity of the nonlinear dynamics
in the fMRI BOLD response. NeuroImage, 14
817-826.
29
BOLD response is nonlinear
Observed response
Linear response
Short duration stimuli produce larger responses
than expected
30
Spatial Heterogeneity of BOLD Nonlinearity
R. M. Birn, Z. Saad, P. A. Bandettini, (2001)
Spatial heterogeneity of the nonlinear dynamics
in the fMRI BOLD response. NeuroImage, 14
817-826.
31
Results visual task
Nonlinearity
Magnitude
Latency
R. M. Birn, Z. Saad, P. A. Bandettini, (2001)
Spatial heterogeneity of the nonlinear dynamics
in the fMRI BOLD response. NeuroImage, 14
817-826.
32
Results motor task
8
f (SD)
6
4
2
0
1
2
3
4
5
Stimulus Duration
33
Results motor task
Nonlinearity
Magnitude
Latency
34
Reproducibility
Visual task
Motor task
Nonlinearity1
Nonlinearity1
Nonlinearity2
Nonlinearity2
Experiment 1
Experiment 2
Experiment 1
Experiment 2
35
Different stimulus OFF periods
measured
BOLD Response
Signal
linear
Stimulus timing
2 s
3 s
4 s
8 s
16 s
Brief stimulus OFF periods produce smaller
decreases than expected
36
Sources of this Nonlinearity
37
BOLD Correlation with Neuronal Activity
Logothetis et al. (2001) Neurophysiological
investigation of the basis of the fMRI signal
Nature, 412, 150-157.
P. A. Bandettini and L. G. Ungerleider, (2001)
From neuron to BOLD new connections. Nature
Neuroscience, 4 864-866.
38
The Biggest Unknowns in Functional MRI

1. Relationship between neuronal activity and fMRI.
2. Sources of fMRI dynamic characteristics.
3. Sources of spatial and temporal variability.
4. Whats really in the noise?
5. Whats resting state?
6. Other sources of functional contrast?
7. Ultimate temporal resolution?
8. Ultimate spatial resolution?
9. Ultimate clinical utility?
10. Best processing and display methods?
11. Optimal field strength?

39
Sources of spatial and temporal variability.
Latency and Magnitude From Subject to Voxel.
40

• Rapid event-related design with varying ISI

8 ON
25 ON
50 ON
75 ON
R. Birn, et al (2001), OHBM 971
41
Estimated Impulse Response
Predicted Responses to 20 s stimulation
R. Birn, et al (2001), OHBM 971
42
Sources of spatial and temporal variability.
Spatial Variation
43
The Biggest Unknowns in Functional MRI

1. Relationship between neuronal activity and fMRI.
2. Sources of fMRI dynamic characteristics.
3. Sources of spatial and temporal variability.
4. Whats really in the noise?
5. Whats resting state?
6. Other sources of functional contrast?
7. Ultimate temporal resolution?
8. Ultimate spatial resolution?
9. Ultimate clinical utility?
10. Best processing and display methods?
11. Optimal field strength?

44
0.25 Hz Breathing at 3T
3ms
26ms
Power Spectra
Respiration map
49ms
0 0.25
0.5 Hz
45
0.68 Hz Cardiac rate at 3T
3ms
26ms
Power Spectra
Cardiac map
49ms
0 0.68 (aliased) 0.5 Hz
46
Temporal S/N vs. Image S/N
PHANTOMS
SUBJECTS
1400 1200 1000 800 600 400 200
Temporal S/N
Temporal S/N
0 200 400 600 800
1000 1200 1400
Image S/N
Image S/N
N. Petridou
47
Signal / Thermal Noise
Signal / Physiologic Noise
Signal to Noise Ratio
Optimal for fMRI
Resolution, Speed, Surface Coils, Field Strength,
etc..
48
(No Transcript)
49
(No Transcript)
50
Whats really in the noise?
Spontaneous Fluctuation Correlation
0.3 Hz
51
Whats really in the noise?
Correlation with External Measures
52
The Biggest Unknowns in Functional MRI

1. Relationship between neuronal activity and fMRI.
2. Sources of fMRI dynamic characteristics.
3. Sources of spatial and temporal variability.
4. Whats really in the noise?
5. Whats resting state?
6. Other sources of functional contrast?
7. Ultimate temporal resolution?
8. Ultimate spatial resolution?
9. Ultimate clinical utility?
10. Best processing and display methods?
11. Optimal field strength?

53
What is resting state?
Decreases during activation
54
Are decreases related to resting correlations?
What is resting state?
55
What is resting state?
Clinical applications?
56
The Biggest Unknowns in Functional MRI

1. Relationship between neuronal activity and fMRI.
2. Sources of fMRI dynamic characteristics.
3. Sources of spatial and temporal variability.
4. Whats really in the noise?
5. Whats resting state?
6. Other sources of functional contrast?
7. Ultimate temporal resolution?
8. Ultimate spatial resolution?
9. Ultimate clinical utility?
10. Best processing and display methods?
11. Optimal field strength?

57
Other sources of functional contrast?
Blood Volume
58
Other sources of functional contrast?
59
CBF
BOLD
Simultaneous Perfusion and BOLD imaging during
graded visual activation and hypercapnia
N12
60
Computed CMRO2 Changes
40
30
20
10
0


-10
-20
-30
-40
Subject 2
Subject 1
R. Hoge et al.
61
Other sources of functional contrast?
Direct Neuronal Current Imaging
62
Other sources of functional contrast?
In Vitro Results
Active condition black line Inactive condition
red line
A 0.15 Hz activity, on/off frequency B
activity C scanner noise (cooling-pump)
Petridou, et al (2003), HBM
63
Other sources of functional contrast?
Temperature
Yablonskiy, D. A., J. J. H. Ackerman, et al.
(2000). "Coupling between changes in human brain
temperature and oxidative metabolism during
prolonged visual stimulation." Proceedings of the
National Academy of Sciences of the United States
of America 97(13) 7603-7608.
64
The Biggest Unknowns in Functional MRI

1. Relationship between neuronal activity and fMRI.
2. Sources of fMRI dynamic characteristics.
3. Sources of spatial and temporal variability.
4. Whats really in the noise?
5. Whats resting state?
6. Other sources of functional contrast?
7. Ultimate temporal resolution?
8. Ultimate spatial resolution?
9. Ultimate clinical utility?
10. Best processing and display methods?
11. Optimal field strength?

65
First Event-related fMRI Results
Blamire, A. M., et al. (1992). Dynamic mapping
of the human visual cortex by high-speed magnetic
resonance imaging. Proc. Natl. Acad. Sci. USA
89 11069-11073.
66
R. L. Savoy, et al., Pushing the temporal
resolution of fMRI studies of very brief visual
stimuli, onset variability and asynchrony, and
stimulus-correlated changes in noise oral, 3'rd
Proc. Soc. Magn. Reson., Nice, p. 450. (1995).
67
P. A. Bandettini, Functional MRI temporal
resolution in "Functional MRI" (C. Moonen, and
P. Bandettini., Eds.), p. 205-220, Springer -
Verlag,. 1999.
68
Ultimate temporal resolution?
Voxel-wise hemodynamic variation
Magnitude
69
Relative dynamics obtained by precise activation
timing modulation
Preliminary results (with Savoy et al. 1995)
Hemi-Field Experiment
Right Hemisphere
Left Hemisphere
70
500 ms
500 ms
Right Hemifield
Left Hemifield
2.5 s

-
0 s
- 2.5 s
71
Ultimate temporal resolution?
Task Timing Modulation
72
Ultimate temporal resolution?
In an ideal worldno hemodynamic variation over
space.
73
Ultimate temporal resolution?
Neuronal Communication Timing
74
The Biggest Unknowns in Functional MRI

1. Relationship between neuronal activity and fMRI.
2. Sources of fMRI dynamic characteristics.
3. Sources of spatial and temporal variability.
4. Whats really in the noise?
5. Whats resting state?
6. Other sources of functional contrast?
7. Ultimate temporal resolution?
8. Ultimate spatial resolution?
9. Ultimate clinical utility?
10. Best processing and display methods?
11. Optimal field strength?

75
Magnitude
Jesmanowicz, P. A. Bandettini, J. S. Hyde, (1998)
Single shot half k-space high resolution EPI
for fMRI at 3T. Magn. Reson. Med. 40, 754-762.
76
Ocular Dominance Column Mapping using fMRI
Menon, R. S., S. Ogawa, et al. (1997). Ocular
dominance in human V1 demonstrated by functional
magnetic resonance imaging. J Neurophysiol
77(5) 2780-7.
Optical Imaging
R. D. Frostig et. al, PNAS 87 6082-6086, (1990).
77
(No Transcript)
78
Parallel acquisition (16 radio frequency
channels)
Custom-built Radio-frequency (RF) coil
Nova Medical, Inc.
79
Parallel acquisition (16 radio frequency
channels)
Receiver Hardware
80
Individual coil images
Single combined image
81
Parallel acquisition (16 radio frequency
channels)
Large improvement in signal-to-noise ratio (SNR)

• Increased resolution
• Increased imaging speed
• Increased sensitivity

82
Single Shot EPI
T2 decay
EPI Readout Window
20 to 40 ms
83
Multishot Imaging
T2 decay
EPI Window 2
84
Partial k-space imaging
85
SENSE Imaging
5 to 30 ms
Pruessmann, et al.
86
Ultimate spatial resolution?
Resolving columns with single shot EPI is a goal..
using SENSE, 32 channels, 7T, and perhaps
partial k-space we might get to 0.5 mm3
87
The Biggest Unknowns in Functional MRI

1. Relationship between neuronal activity and fMRI.
2. Sources of fMRI dynamic characteristics.
3. Sources of spatial and temporal variability.
4. Whats really in the noise?
5. Whats resting state?
6. Other sources of functional contrast?
7. Ultimate temporal resolution?
8. Ultimate spatial resolution?
9. Ultimate clinical utility?
10. Best processing and display methods?
11. Optimal field strength?

88
Ultimate clinical utility?
Needs Real time feedback Characterization of
confounding effects Robust yet incisive set of
probe tasks Baseline information?
89
The Biggest Unknowns in Functional MRI

1. Relationship between neuronal activity and fMRI.
2. Sources of fMRI dynamic characteristics.
3. Sources of spatial and temporal variability.
4. Whats really in the noise?
5. Whats resting state?
6. Other sources of functional contrast?
7. Ultimate temporal resolution?
8. Ultimate spatial resolution?
9. Ultimate clinical utility?
10. Best processing and display methods?
11. Optimal field strength?

90
Best processing and display methods?
Processing
fMRI data, and noise is time and space varying in
predictable and unpredictable ways over several
temporal and spatial scales
Signal and noise models Model free, open ended,
methods?
Classification methods? Multivariate
methods? Connectivity (across time and space
scales?)
91
Best processing and display methods?
Display
To convey -collapsed multidimensional
data -sense of data quality
Surface Glass brain ROI Time courses Example
slices Connectivity maps? Quality index?
92
The Biggest Unknowns in Functional MRI

1. Relationship between neuronal activity and fMRI.
2. Sources of fMRI dynamic characteristics.
3. Sources of spatial and temporal variability.
4. Whats really in the noise?
5. Whats resting state?
6. Other sources of functional contrast?
7. Ultimate temporal resolution?
8. Ultimate spatial resolution?
9. Ultimate clinical utility?
10. Best processing and display methods?
11. Optimal field strength?

93
Optimal Field Strength?
Utility vs. Difficulty
Difficulty Shimming (generally lower T2 and
T2) RF penetration effects Stability Utility
Higher SNR Better susceptibility contrast Better
ASL perfusion contrast (longer T1)
94
Functional Imaging Methods Unit Functional MRI
Facility
Post Docs Hauke Heekeren David Knight Anthony
Boemio Niko Kriegeskorte
Staff Scientists Sean Marrett Jerzy
Bodurka Frank Ye Wen-Ming Luh Rasmus Birn
Computer Specialist Adam Thomas
Scanning Technologists Karen Bove-Bettis Paula
Rowser Alda Ottley Ellen Condon
Graduate Student Natalia Petridou
Program Assistant Kay Kuhns
95
Unit on Functional Imaging FMRI Core Facility
http//sodium.nimh.nih.gov/upload T165.ppt
