On Grid Performance Evaluation using Synthetic Workloads

1

• On Grid Performance Evaluation using Synthetic
  Workloads

Carsten Franke, Alexander Papaspyrou, Lars
Schley, Baiyi Song, and Ramin Yahyapour
Alexandru Iosup, Dick Epema
PDS Group, ST/EWI, TU Delft
PDS Group, ST/EWI, TU Delft
JSSPP 2006
2
Outline

• A Short Introduction to Grid Computing
• On Grid Performance Evaluation
• Experimental Environments
• Performance Indicators
• General Workload Modeling
• Grid-Specific Workload Modeling
• The GrenchMark Framework
• Future Work
• Conclusions

3
A Short Introduction to Grid Computing

• Typical grid environment
• Applications !
• Unitary, composite
• Data
• Resources
• Compute (Clusters)
• Storage
• (Dedicated) Network
• Virtual Organizations, Projects
• Groups, Users

• Grids vs. parallel production environments
• Dynamic
• Heterogeneous
• Very large-scale (world)
• No central administration
• ? Most resource management problems are NP-hard

4
Experimental Environments Real-World Testbeds

• Real-World Testbed
• DAS, NorduGrid, Grid3/OSG, Grid5000
• Pros
• True performance, also shows it works!
• Infrastructure in place
• Cons
• Time-intensive
• Exclusive access (repeatability)
• Controlled environment problem (limited
  scenarios)
• Workload structure (little or no realistic data)
• What to measure (new environment)

5
Experimental Environments Simulated and Emulated
Testbeds

• Simulated and Emulated Testbeds
• GridSim, SimGrid, GangSim, MicroGrid
• Essentially trade-off precision vs. speed
• Pros
• Exclusive access (repeatability)
• Controlled environment (unlimited scenarios)
• Cons
• Synthetic Grids What to generate? How to
  generate? Clusters, Disks, Network, VOs, Groups,
  Users, Applications, etc.
• Workload structure (little or no realistic data)
• What to measure (new environment)
• Validity of results (accuracy vs. time)

6
Grid Performance Evaluation Current Practice

• Performance Indicators
• Define my own metrics, or use U and AWT/ART, or
  both
• Workload Structure
• Run my own workload, or use traces that are not
  validated by peer researchers do not make
  comparisons!
• Run benchmarks from typical parallel production
  environments
• Mostly all users are created equal assumption

Need a common performance evaluation framework
for Grid
7
Grid Performance Evaluation Current Issues

• Performance Indicators
• What are the metrics for the new environment?
• Workload Structure
• Which general aspects are important?
• Which Grid-specific aspects need to be addressed?

Need a common performance evaluation framework
for Grid
8
Performance Indicators

• Time-, Resource-, and System-Related Metrics
• Traditional utilization, A(W)RT, A(W)WT, A(W)SD
• New waste, fairness (or service quality
  reliability)
• Workload Completion and Failure Metrics
• In Grids, functionality may be even more
  important than performance
• Workload Completion (WC)
• Task and Enabled Task Completion (TC, ETC)
• System Failure Factor (SFF)

9
General Aspects for Workload Modeling

• User/Group/VO model
• Detailed modeling for top-5/10 users, then
  clustering (Use squash area to group)
• Submission patterns
• Yearly, monthly, weekly, daily
• Do daily patterns exist? (Are Grids truly
  global?)
• Temporal patterns
• Repeated submission (batches of jobs)
• Job dependencies (composite applications common
  in Grid(?))
• Feedback
• Empiric rules (dont submit jobs when system
  busy). But, reactive submission tools,
  co-allocators, evolving applications, etc.

10
Grid-Specific Workload ModelingComputation
Management

• Processor co-allocation
• Fixed, non-fixed, semi-fixed jobs
• Job flexibility
• Moldable, evolvable, flexible, -ble
• Other aspects
• Background load define top jobs (by
  consumption), model the rest as background load
• Project stage

11
Grid-Specific Workload ModelingData Management

• Clearly Defined I/O Requirements
• Files, streams,
• Data location and size
• Replicas
• Replica location
• Other aspects

12
Grid-Specific Workload ModelingNetwork Management

• Clearly Defined Network Requirements
• Bandwidth, latency,
• Communication pattern
• Special Situations
• Dedicated paths, other QoS
• Other aspects
• Background load

13
Grid-Specific Workload ModelingLocality/Origin
Management

• Job issuer and execution site
• Not all VOs are created equal !
• Two-level view Which VO generates the next job?
  Within a VO, which user generates the next job?
• Three-level view, Multi-level view (Project, VO,
  Group, User)
• (Usage) Service Level Agreements
• Use my system 50 for 7 days, or 20 for 30 days
• Dedicated paths, other QoS
• Other aspects
• Background load pertaining to same (u)SLA

14
Grid-Specific Workload ModelingFailure Modeling

• Error level
• Infrastructure
• Middleware
• Application
• User
• Fault tolerance scheme for submitted jobs
• Catch the system feedback into the model
• Other aspects

15
Grid-Specific Workload ModelingEconomic Models

• Pricing
• Application cost
• Application utility
• Other aspects

16
GrenchMark a Framework for Analyzing, Testing,
and Comparing grids

• Whats in a name?grid benchmark ? working
  towards a generic tool for the whole community
  help standardizing the testing procedures,
  but benchmarks are
  too early we use
  synthetic grid workloads instead
• Whats it about?A systematic approach to
  analyzing, testing, and comparing grid settings,
  based on synthetic workloads
• A set of metrics for analyzing grid settings
• A set of representative grid applications
• Both real and synthetic
• Easy-to-use tools to create synthetic grid
  workloads
• Flexible, extensible framework

17
GrenchMark Overview Easy to Generate and Run
Synthetic Workloads
18
but More Complicated Than You Think

• Workload structure
• User-defined and statistical models
• Dynamic jobs arrival
• Burstiness and self-similarity
• Feedback, background load
• Machine usage assumptions
• Users, VOs
• Metrics
• A(W) Run/Wait/Resp. Time
• Efficiency, MakeSpan
• Failure rate !
• (Grid) notions
• Co-allocation, interactive jobs, malleable,
  moldable,

• Measurement methods
• Long workloads
• Saturated / non-saturated system
• Start-up, production, and cool-down scenarios
• Scaling workload to system
• Applications
• Synthetic
• Real
• Workload definition language
• Base language layer
• Extended language layer
• Other
• Can use the same workload for both simulations
  and real environments

19
GrenchMark Iterative Research Roadmap
20
GrenchMark Iterative Research Roadmap
Simple functional system A.Iosup, J.Maassen,
R.V.van Nieuwpoort, D.H.J.Epema, Synthetic Grid
Workloads with Ibis, KOALA, and GrenchMark,
CoreGRID IW, Nov 2005.
21
GrenchMark Iterative Research Roadmap
Open- GrenchMark CommunityEffort
Complex extensible system A.Iosup, D.H.J.Epema,
GrenchMark A Framework for Analyzing, Testing,
and Comparing Grids, IEEE CCGrid'06, May 2006.
22
Take home message

• Performance Evaluation of Grid Systems - need a
  common performance evaluation framework for grids
  - need real grid traces (scheduling,
  accounting, monitoring, etc.) - need more
  research on workload modeling and performance
  indicators
• Performance indicators - failure metrics as
  important as traditional performance metrics
• Workload modeling - generic workload modeling
  needs validation based on real grid traces -
  computation/data/network management -
  locality/origin management - failure modeling -
  economic models
• GrenchMark - generic tool for the whole
  community - generates diverse grid workloads -
  easy-to-use, flexible, portable, extensible,

23
Thank you!

• Questions? Remarks? Observations? All welcome!
• GrenchMark http//grenchmark.st.ewi.tudelft.nl/

http//grenchmark.st.ewi.tudelft.nl/
24
(No Transcript)
25
Representative Grid applications (3/4)Composite
DAG-based

• DAG-based applications
• Real DAG
• Chain of tools
• Try to model real or predicted (use) cases
