OPTIMAL FSMD PARTITIONING FOR LOW POWER

1
OPTIMAL FSMD PARTITIONING FOR LOW POWER

• Nainesh Agarwal and Nikitas Dimopoulos
• Electrical and Computer Engineering
• University of Victoria

2
Summary

• Power and energy
• Power gating
• Partitioning as means to achieve optimal power
  gating
• What next

3
Computation Power and Energy

• What is the minimum energy a computation can
  expend?
• Are we there yet?

4
Computation Power and Energy contd

• Feynman gives a relation between free energy and
  computation rate for reversible computation
• E kTlogr
• Where r is the computation rate.
• This means that at the limit, we may expend zero
  energy (when r 1) but then the computation will
  take infinitely long.

5
Computation Power and Energy contd

• For irreversible computation,
• ?EkTblog2
• Where b is the number of bits involved in the
  computation (entropy)

6
Computation Power and Energy contd

• In both cases, these quantities are wxceptionally
  small.
• k 1.380650410-23 J/K
• At T300ºK, kT 4.14x10-21J
• A 50W 3GHz processor, in one cycle, consumes
  1.65x10-8J

7
Computation Power and Energy contd

• DSPstone benchmarks synthesized in 180 nm and 90
  nm technologies

8
DSPstone dynamic energy
9
DSPstone total energy
10
Computation Power and Energy contd

• Computational energy is far above the theoretical
  minimum (by more than 10 orders of magnitude)
• Technological drive reduces total energy (an
  order of magnitude per generation)
• Leakage power has become an issue
• Power gating may provide efficiencies to further
  scale the technology

11
Partitioning

• Controller and datapath are considered together
• Problem is formulated as
• Integer Linear Programming
• Non-linear programming solved using simulated
  annealing

12
Notation

• si represents a state of a FSMD
• vk represents a variable associated with one
  or more states
• A variable vk is considered to be shared between
  two states si and sj if the variable is read
  and/or written at both states
• Tij Is the total number of bits of all variables
  shared by states si and sj
• Eij is 1 if there is a transition between states
  si and sj, otherwise it is 0.

13
ILP formulation

• Minimizes the number of bits that are shared
  between the partitions and the number of times
  that control could between the partitions
• sij is 1 if both states si and sj are in the
  same partition. Otherwise, it is 0.

14
ILP formulation - complete
15
Simulated Annealing formulation

• xi is -1 if state si is in the left partition,
  and it is 1 if si is in the right partition
• These quantities count the number of variable
  bits and transition edges shared between the two
  partitions

16
Simulated Annealing formulation

• simplification steps
• Observe that is constant (the total
  number of variable-bits)

17
Simulated Annealing formulation

• Minimizes both the shared bits and the transition
  edges.

18
Evaluation

• Implemented four integer algorithms
• 8-bit counter
• 5/3 wavelet transform using lifting
• multiplierless approximation to the eight-point
  Discrete Cosine Transform (DCT)
• Integer transform from the H.264 standard
• Used CoDeL to implement the designs.
• Trace data were obtained from simulations using
  Synopsys
• The ILP model was solved using the CPLEX solver
  included in the AIMMS modeling environment
• The simulated annealing used MATLAB

19
Evaluation contd

• Power savings were estimated (no partitioned
  design implementation yet)
• The static power savings depends on the size of
  the sequential logic and the portion of time
  spent in each partition.
• The dynamic power savings depends on the number
  of bits that are not clocked while the partition
  is not powered mediated by the overhead due to
  data communication when the active partition
  changes.

20
Evaluation (Static Power savings)
21
Evaluation (Dynamic Power Savings)
22
Results (ILP)
23
Results (Simulated Annealing)
24
Discussion

• Results show that partitioning the control and
  datapaths could potentially save up to 50 of
  power (static power)
• Some circuits could not partition (DWT includes
  one tight loop where it spends more than 90 of
  the time)
• Simulated annealing and ILP (for the partitioned
  circuits) give identical results.
• Simulated annealing is much faster.

25
Future

• Extend methodology to more than 2 partitions
• Implement the partitioned FSMD machines and
  confirm the realized power savings
• Lower energy!
