OGF HPC-Basic Profile Application Interoperability Demonstration

1
OGF HPC-Basic Profile Application
Interoperability Demonstration

• GIN-CG

2
Overview

• Application
• Standards
• Implementations
• Demo
• Future

3
Scientific Application
4
Plasma Charge Minimization

• Undergraduate project
• Total system energy minimization of point charges
  around the surface of a sphere
• Three different applications
• Pre processing generate input files
• Main processing parallel distributed processing
• Post-processing choose optimal solution

5
Participation

• DEISA UNICORE, SuSE, AMD 64-bit, 1 core
• NorduGrid ARC, Debian Linux, i686, 16 core
• UK NGS/OMII-UK GridSAM, Scientific Linux 4.7,
  AMD 64-bit, 256 core
• University of Virginia Campus Grid GENESIS2,
  Ubuntu Linux, i686, 8 core
• Platform - BES Client

6
ARC features

• Standards compliant WS interfaces.
• Modular architecture.
• Core components for job execution (AREX),
  information exchange (ISIS), data storage
  (Chelonia), and security.
• Broad range of supported platforms.
• Straightforward user interfaces.
• Developer friendliness, supports services in
  Java, Python and C.
• Supports IPv6.

Thanks to Peter Stefan
7
Job Execution Client and Server

• The client
• Modular library CLI tools.
• Allows grid users accessing different middleware
  operated grid services gLite CREAM2, Unicore,
  pre-WS ARC.
• Available on MS Windows, MacOS X, Solaris and
  Linux.

• The server
• Implements a CE.
• Supports BES/JSDL/GLUE2 with ARC extensions.
• Conforms to numerous LRMSes.

Thanks to Peter Stefan
8
Genesis II Standards Based Grid Implementation

• Users FIRST!
• Design the system from the ground up with the
  overriding mantra that users come first!
• Users dont want to know about grids
• Provide a secure, cohesive system in a production
  system available to users today!
• Provide an open source, reference implementation
  of the OGSA and OGSA-related specifications
• Use standards and proto-standards available from
  the OGF and OGSA to provide feedback into the OGF
  process on various standards based on
  implementation experience

Thanks to Mark Morgan
9
(Most) everything is a file or directory

• Files and directories can be accessed without
  knowing anything about Grids, Web Services, or
  anything thanks to FUSE/IFS
• FUSE/IFS map the Grid into the file system
• BES resources, queues are directories
• ls to list the jobs, cat a job to see its
  state
• cp a JSDL file into the directory -gt start the
  job up
• A shell script can start jobs by copying
• Genesis II containers are directories
• ls to see the services and porttypes
• IDP are files/directories
• ISs are directories
• cp a query file to IS, creates result
• RDBMSs will be directories
• The user can access all of these services without
  dealing with Web Services!!

Thanks to Mark Morgan
10
GridSAM Use Characteristics

• Currently deployed and used (amongst others)
• On UK National Grid Service (NGS)
• University College London and Imperial College
  London (numerous projects)
• Open Geospatial Consortium (OGC)
• 2 deployments within Chinese automotive industry
• Chinese Drug Discovery project
• Southampton University
• Characteristics
• Easily installed and configured
• Client install on Windows, Mac OS X and Linux
• Server install on many popular Linux variants
• Supports PBS, DRMAA, Sun GridEngine, Condor,
  Globus, LSF batch systems
• Standards-based HPC Basic Profile v1.0, OGSA-BES
  v1.0, JSDL v1.0, HPC File Staging Profile
  (partial)
• Supports FTP, SFTP, HTTP, HTTPs, GridFTP, WebDav
  data protocols
• User-focused development and Open Source

Thanks to Steve Crouch
11
Open Community Development

• GridSAM is Open Source, Open Community
  Development
• GridSAM SourceForge project
• 99.03 activity, 1 release/month
• SVN source code repository
• Developer discuss mailing lists
• Contribute!

http//sourceforge.net/projects/gridsam/
Thanks to Steve Crouch
12
Availability and Future Developments

• Availability
• SourceForge gridsam project
• With bundled Apache Tomcat/Axis/WSS4j
  (WS-Security)
• OMII-UK Campus Grid Toolkit (CGT) automated
  client or server install
• OMII-UK Development Kit heavily assisted client
  or server installation
• Future Developments
• For end-users
• Refactored documentation (with improved OGF
  standards coverage)
• Full support for HPC File Staging Profile across
  PBS, Condor Fork DRMs
• Full support for JSDL Resource selection across
  PBS, Condor Fork DRMs
• JSDL Parameter Sweep Extension
• Support for SRB and iRODS
• For resource owners
• Packaging as standalone, manually configurable
  web archive (WAR) file
• Job submission through multiple remote SSH
  accounts

Thanks to Steve Crouch
13
Grid driving High Performance Computing (HPC)

• UNICORE used in
• DEISA (European Distributed Supercomputing
  Infrastructure)
• National German Supercomputing Center NIC
• Gauss Center for Supercomputing (Alliance of the
  three German HPC centers official National Grid
  Initiative for Germany in the context of EGI)
• SKIF-Grid (Russion-Belarus HPC Infrastructure)
• PRACE (European PetaFlop HPC Infrastructure)
  starting-up
• Traditionally taking up major requirements from
  i.e.
• HPC users (i.e. MPI, OpenMP)
• HPC user support teams
• HPC operations teams
• and via SourceForge Platform

Thanks to Morris Riedel
14
Guiding Principles, Implementation Strategies

• Open source under BSD license with software
  hosted on SourceForge
• Standards-based OGSA-conform, WS-RF 1.2
  compliant, adoption and driving of various Open
  Grid Forum (OGF) standards
• Open, extensible Service-Oriented Architecture
  (SOA)
• Interoperable with other Grid technologies
• Seamless, secure and intuitive following a
  vertical end-to-end approach
• Mature Security X.509, proxy and VO support
• Workflow support tightly integrated while being
  extensible for different workflow languages and
  engines for domain-specific usage
• Application integration mechanisms on the client,
  services and resource level
• Variety of clients graphical, command-line, API,
  portal, etc.
• Quick and simple installation and configuration
• Support for many operating systems (Windows,
  MacOS, Linux, UNIX) and batch systems
  (LoadLeveler, Torque, SLURM, LSF, OpenCCS)
• Implemented in Java to achieve platform-independen
  ce

Thanks to Morris Riedel
15
scientific clientsand applications
UCCcommand-line client
URCEclipse-based Rich client
HiLAProgrammingAPI
Portal e.g. GridSphere
X.509, Proxies, SOAP, WS-RF, WS-I, JSDL
web service stack
Gateway
central services running in WS-RF hosting
environments
ServiceRegistry
WorkflowEngine
OGSA-RUS, UR,GLUE 2.0
ServiceOrchestrator
CISInfoService
Gateway Site 1
Gateway Site 2
authentication
UNICOREWS-RFhostingenvironment
OGSA-ByteIO, OGSA-BES, JSDL, HPC-BP, OGSA-RUS, UR
UNICOREWS-RFhostingenvironment
UNICORE Atomic Services
OGSA-
UVOSVO Service
UNICORE Atomic Services
OGSA-
Grid services hosting
XNJS Site 1
XNJS Site 2
IDB
IDB
job incarnation
X.509, XACML, SAML, Proxies
XACML entity
XACML entity
XUUDB
XUUDB
authorization
Target System Interface Site 1
Target System Interface Site 2
DRMAA
ExternalStorage
GridFTP, Proxies
USpace
USpace
data transfer to external storages
http//www.unicore.eu
Thanks to Morris Riedel
16
Challenges

• Time - 4 days to do core work
• Learning curve middlewares, demo requirements
• Impacted many decisions, compromise!
• Select best time/benefit approach
• Good team coordination, high communication
  critical
• Exploitation of standards support for each
  middleware probably not complete!
• Compatibility of BES client and middleware
• Client has some limitations e.g. no delegation
  support (ARC), no support for full EPRs (Genesis
  II)
• Middleware support for standards and data
  differs how to support?
• Approach was hybrid of highest common
  denominator of support, and customisation
• JSDL generate middleware-oriented rendering
  based on template
• Data use what we could get working for each
  middleware
• Support for full EPRs was blocker for Genesis II

17
Standards/Data Protocols/Security Supported in
Demo (at the moment!)

• Standards
• HPC Basic Profile v1.0
• OGSA BES (Basic Execution Service) v1.0
• JSDL (Job Submission Description Language) v1.0
• HPC Profile Application Extension v1.0 ARC,
  GridSAM
• HPC File Staging Profile UNICORE only
• Data protocols
• UNICORE, ARC ftp
• GridSAM GridFTP
• Security
• Direct middleware -gt certificate CA trust (just
  import CAs)

18
Compute Related Standards
Architecture OGSA EMS Scenarios (GFD 106)
Use Cases Grid Scheduling Use Cases (GFD 64)
Education ISV Primer (GFD 141)
Agreement WS-Agreement (GFD 107)
Programming Interface SAGA (GFD 90)
Uses
Programming Interface DRMAA (GFD 22/133)
Accounting Usage Record (GFD 98)
Supports
Produces
Job Management OGSA-BES (GFD 108)
Information GLUE Schema 2.0 (GFD. 147)
Describes
Profiles
HPC Domain Specific Profile HPC Basic
Profile (GFD 114)
19
Compute Related Standards
Architecture OGSA EMS Scenarios (GFD 106)
Use Cases Grid Scheduling Use Cases (GFD 64)
Education ISV Primer (GFD 141)
Agreement WS-Agreement (GFD 107)
Job Definition
Programming Interface SAGA (GFD 90)
Job Description JSDL (GFD 56/136)
Uses
Programming Interface DRMAA (GFD 22/133)
Accounting Usage Record (GFD 98)
Application Description HPC Application (GFD 111)
Supports
Produces
Application Description SPMD Application (GFD
115)
Extend
Job Management OGSA-BES (GFD 108)
Job Parameterization Parameter Sweep (GFD. 149)
Information GLUE Schema 2.0 (GFD. 147)
Describes
Profiles
File Transfer HPC File Staging (GFD 135)
HPC Domain Specific Profile HPC Basic
Profile (GFD 114)
20
JSDL Template
ltJobDefinition xmlns"http//schemas.ggf.org/jsdl/
2005/11/jsdl"gt ltJobDescriptiongt
ltApplicationgt lt_at_APPLICATION_TYPE_at_
xmlns"_at_APPLICATION_TYPE_NAMESPACE_at_"gt
ltExecutablegt_at_MINEM_INSTALL_LOCATION_at_/update_fi
lelt/Executablegt
ltArgumentgtinput.txtlt/Argumentgt
ltArgumentgtoutput.txtlt/Argumentgt
ltOutputgtstdout.txtlt/Outputgt
ltErrorgtstderr.txtlt/Errorgt
_at_OPTIONAL_WORKING_DIR_ELEMENT_at_
lt/_at_APPLICATION_TYPE_at_gt lt/Applicationgt
ltDataStaginggt ltFileNamegtinput.txtlt
/FileNamegt ltCreationFlaggtoverwritelt/Cr
eationFlaggt ltSourcegt
ltURIgt_at_INPUT_FILE_URI_at_lt/URIgt
lt/Sourcegt _at_OPTIONAL_HPCFSP_CREDENTIAL_at_
lt/DataStaginggt ltDataStaginggt
ltFileNamegtoutput.txtlt/FileNamegt
ltCreationFlaggtoverwritelt/CreationFlaggt
ltDeleteOnTerminationgtfalselt/DeleteOnTermination
gt ltTargetgt
ltURIgt_at_OUTPUT_FILE_URI_at_lt/URIgt
lt/Targetgt _at_OPTIONAL_HPCFSP_CREDENTIAL_at_
lt/DataStaginggt
ltDataStaginggt ltFileNamegtstdout.txtlt/F
ileNamegt ltCreationFlaggtoverwritelt/Crea
tionFlaggt ltDeleteOnTerminationgtfalselt/
DeleteOnTerminationgt ltTargetgt
ltURIgt_at_STDOUT_FILE_URI_at_lt/URIgt
lt/Targetgt _at_OPTIONAL_HPCFSP_CREDENTIAL_at_
lt/DataStaginggt ltDataStaginggt
ltFileNamegtstderr.txtlt/FileNamegt
ltCreationFlaggtoverwritelt/CreationFlaggt
ltDeleteOnTerminationgtfalselt/DeleteOnTermination
gt ltTargetgt
ltURIgt_at_STDERR_FILE_URI_at_lt/URIgt
lt/Targetgt _at_OPTIONAL_HPCFSP_CREDENTIAL_at_
lt/DataStaginggt lt/JobDescriptiongt
_at_OPTIONAL_MYPROXY_ELEMENT_at_ lt/JobDefinitiongt
21
How it Fits Together
Minem
UNICORE
Minem
minem-interop.pl
FTP
MyProxy
BES Client
GridSAM
Minem
GridFTP
FTP
ARC
Minem
22
Future

• Support full EPRs for Genesis II
• Include CREAM-BES within interop demo
• Harmonise standards support across all
  middlewares
• HPC Basic Profile Application Extension
  (currently supported by GridSAM, ARC)
• HPC File Staging Profile (currently supported by
  UNICORE)
• This would need middleware development!
• Support for single data protocol across all
  middlewares?
• HPC File Staging Profile only mandates support
  for one protocol from ftp, http, scp (does not
  mandate a specific one, or all three)
• Issues with each e.g. GridFTP would need support
  in Genesis II, production-level support in
  UNICORE, and delegation support in BES client
  for ARC
• Again, middleware development required!
• We already know data is a next big Grid
  challenge protocol support a key part of this
  challenge

23
Thanks

• Demo development Steve Crouch, OMII-UK
• Core Interop assistance
• ARC
• Peter Stefan - NorduGrid
• Genesis 2
• Mark Morgan - UVa
• GridSAM
• Justin Bradley OMII-UK
• Richard Boardman OMII-UK
• UNICORE
• Shahbaz Memon Juelich
• BES
• Chris Smith - Platform
• Resource provision
• Andrew Grimshaw - UVa
• Balazs Konya - NorduGrid
• Matteo Turilli UK NGS
• Morris Riedel Juelich
