Scanning Probe Microscopy (SPM) Study of Surface
Modification of InP(111) Due to MeV Sb
Implantation.
  • Dipak Paramanik
  • Institute of Physics, Bhubaneswar

Research Advisor Dr. S . Varma
3
Experimental Techniques
  • SPM with Nanoscope III from Digital
    Instruments(Veeco).

4
Atomic Force Microscope(AFM)
Multimode AFM
5
Atomic Force Microscope
Diff-Amp.
Light Deflection System
L.D.
P.S.D.
Monitor
Cantilever
Computer
Z Axis Servo System
Sample
Z Control
PZT Scanner
X,Y-Scanning System
X,Y Control
6
Scanning Probe Microscopy (SPM)
A Family of Microscopy forms where a sharp probe
is scanned across a surface and some tip/sample
interaction are monitored.
  • Scanning Tunneling Microscope (STM).
  • Atomic Force Microscope(AFM)
  • Contact Mode
  • Non-Contact Mode
  • Tapping Mode
  • Lateral Force
  • Force Modulation
  • Magnetic or Electric Force
  • Phase imaging

3. Other forms of SPM
7
  • General AFMBeam Deflection Detection
  • Used for Contact Mode, Non-contact and
    TappingMode AFM
  • Laser light from a solid state diode is reflected
    off the back of the cantilever and collected by a
    position sensitive detector (PSD). This consists
    of two closely spaced photodiodes. The output is
    then collected by a differential amplifier.
  • Angular displacement of the cantilever results in
    one photodiode collecting more light than the
    other. The resulting output signal is
    proportional to the deflection of the cantilever.
  • Detects cantilever deflection lt1A0 .

8
  • Piezoelectric Scanners
  • Whether they expand or contract depends upon the
    polarity of the applied voltage. Digital
    Instruments scanners have AC voltage ranges of
    220 to -220V.
  • SPM scanners are made from a piezoelectric
    material that expands and contracts
    proportionally to an applied voltage.

V
- V
0 V
  • In some versions, the piezo tube moves the sample
    relative to the tip. In other models, the sample
    is stationary while the scanner moves the tip.
  • AC signals applied to conductive areas of the
    tube create piezo movement along the three major
    axes.

9
Contact Mode AFM
  • A tip is scanned across the sample while a
    feedback loop maintains a constant cantilever
    deflection (and force) .
  • The tip contacts the surface through the adsorbed
    fluid layer.
  • Forces range from nano to micro N in ambient
    conditions and even lower (0.1 nN or less) in
    liquids.

10
Tapping Mode AFM
  • A cantilever with attached tip is oscillated at
    its resonant frequency and scanned across the
    sample surface.
  • A constant oscillation amplitude (and thus a
    constant tip-sample interaction) are maintained
    during scanning. Typical amplitudes are 20-100nm.
  • Forces can be 200 pN or less
  • The amplitude of the oscillations changes when
    the tip scans over bumps or depressions on a
    surface.

11
Lateral force Microscopy
  • The probe is scanned sideways. The degree of
    torsion of the cantilever is used as a relative
    measure of surface friction caused by the lateral
    force exerted on the probe.
  • Identify transitions between different components
    in a polymer blend, in composites or other
    mixtures.
  • This mode can also be used to reveal fine
    structural details in the sample.

12
Phase Imaging
  • Accessible via TappingMode
  • Oscillate the cantilever at its resonant
    frequency. The amplitude is used as a feedback
    signal. The phase lag is dependent on several
    things, including composition, adhesion, friction
    and viscoelastic properties
  • than lateral Identify two-phase structure of
    polymer blends
  • Identify surface contaminants that are not seen
    in height images
  • Less damaging to soft samples force microscopy

13
Magnetic Force Microscopy
  • Special probes are used for MFM. These are
    magnetically sensitized by sputter coating with a
    ferromagnetic material.
  • The cantilever is oscillated near its resonant
    frequency (around 100 kHz).
  • The tip is oscillated 10s to 100s of nm above
    the surface.
  • Gradients in the magnetic forces on the tip shift
    the resonant frequency of the cantilever .
  • Monitoring this shift, or related changes in
    oscillation amplitude or phase, produces a
    magnetic force image.
  • Many applications for data storage technology.

14
Cantilever And Tips for AFM
10 nm
Cantilever with the tip on its end is the main
sensing component ultimately responsible for
quality of AFM imaging.
15
Different Kind of AFM Probes
Tapping mode Probe
16
Different Kind of AFM Probes
Contact mode Probe
17
Motivation
  • InP is a key material for fibre optics and high
    speed electronics.
  • Sb is an important dopant in the development of
    Field Effect Transistor and Infrared Detectors.
  • MeV implantation important for producing devices
    with thick buried layers.
  • Ion implantation causes morphological changes in
    surface.
  • Surface properties can crucially effect device
    performance and its reliability.

18
Experimental Sb Implantation in InP(111)
Beam 51Sb2 Energy 1.5 MeV Average Flux 20
nA/cm2 (dE/dx)e Se 84.99 eV/Ao (dE/dx)n Sn
158.7 eV/Ao
7o off implantation Projected Range 4977
Ao Long. Stragling 1680 Ao Lat. Stragling
1221 Ao
19
Modification InP(111) Surface due to Sb
implantion
Interface
  • All the imges are of scan size 10 um and Z heihgt
    75 nm.

Dose 1x1011 ions/cm2
Virgin
20
Higher Doses
Dose 1x1012 ions/cm2
Dose 1x1013 ions/cm2
21
More higher Doses
Dose 1x1014 ions/cm2
Dose 5x1014
ions/cm2
22
Very high Dose
Dose 1x1015
Dose 5x1015
ions/cm2
ions/cm2
23
Roughness Study
  • Roughness increases as dose increases .
  • Dose 1x1014 ions/cm2 ,maximum roughness, beyond
    that roughness slowly decreases
  • Surface Roughness NOT a continuous phenomena .

24
Raman Analysis
  • Peaks disappear at dose 5x1013 ions/cm2

TO
LO
  • This indicates sample becomes completely
    amorphised at dose 5x1013 ions/cm2 .
  • Surface roughness influenced by the lattice
    damage.

25
Summary
  • Evoluation of Surface Roughness Studied with
    Increasing Dose.
  • Surface Roughness influenced by the lattice
    damage .

26
Future Plan
  • Roughness study for various length scales.
  • Variation of defect size with Dose.
  • RBS/C and Transmission Electron Study of this
    sample.
