LHC IRQ Interconnect Engineering Design
ReviewJanuary 29, 2002T. Page - Fermilab
2
Topics

• Interconnect Kit
• Automatic Welding Clearances
• Shield Line Bellows Pressure Test

3
Interconnects
4
IC Q1-Q2
5
IC Q2-Q3
6
Interconnect Kit

• Absorber (T.Nicol).
• Pipes with integrated bellows.
• Pipe supports.
• Bellows protectors.
• Weld rings.
• Shield bridge.
• MLI blanket.
• Outer vacuum sleeve.

7
Interconnect pipe with integrated bellows
8
Hx Outer Bellows

• Added Hx Outer Bellows

9
Helium Pipe Layout
10
Pipe Supports
11
Bellows Protector
12
Interconnect - Welded Joint
13
Shield Bridge IC Q1-Q2
14
Shield Bridge
Fixed End
Free End
15
Shield Bridge
16
Outer Vacuum Sleeve
CERN Bellows LHCQBB_A0030
17
Vacuum Vessel Bellows

• IC Q1-Q2 and IC Q2-Q3 will use the CERN Bellows.
• Drawing No. LHCQBB_A0030
• Bellows length 1130 mm
• A special bellows is needed for the Q3 to Feedbox
  Interconnect.
• Interconnect Length 510 mm
• Bellows Length 540 mm
• Modify CERN Bellows

18

• Weld Clearances

19
Automatic Welding Clearances

• (2) Locations where automatic welder will be
  difficult.
• Cold mass pipe flanges around BPM.
• Hx inner corrugated pipe flange.

20
Automatic Welding Clearances - BPM
21
Automatic Welding Clearances - BPM
22
Automatic Welding Clearances Hx Inner
23
Automatic Welding Clearances Hx Inner
24
Shield Line Pressure Test

• Full Scale Test
• Bellows Internal Sleeves
• Test Pressure 400 psi (hydrostatic)

25
Shield Line Bellows Cross Section
26
Test Setup
27
Test Pressure
28
Bellows Squirm
