Design Patterns

• References Xiaoping Jia, Object-Oriented
  Software Development Using JavaDouglas
  C.Schmidt, Design Pattern Case Studies with C

2
Design Patterns

• Generic (reusable) solutions to a recurring
  problem
• Evolved from Christopher Alexanders patterns for
  architecture.
• Each pattern describes a problem which occurs
  over and over again in our environment, and then
  describes the core of the solution to that
  problem, in such a way that you can use this
  solution a million times over, without ever doing
  it the same way twice. Alexander et. al., A
  Pattern Language (Oxford U.Press,1977)

3
Design Patternsa Hot Topic

• OOPSLA Workshops 17
• Patterns for Software Architecture
• Killer Examples for Design Patterns Objects
  First
• Patterns in Distributed Real Time Embedded
  Systems
• Patterns for Customer Interaction Expectation
  Management
• Software Development Process Patterns

4
Design Patternsa Hot Topic

• OOPSLA Tutorials 20
• Pattern-oriented Software Architectures for
  Networked and Concurrent Applications
• Patterns of Enterprise Application Architecture
• Patterns at Work
• Patterns for Writing Effective Use Cases
• Dungeons and Patterns!
• Patterns and Application Experiences for
  Real-time Object Request Brokers
• Refactoring to Patterns
• Object-oriented Reengineering Patterns
  Techniques
• Patterns for EJB Development
• How to Use Design Patterns in Java and .NET

5
Design Patterns

• Categories of Software Design Patterns
• Creational deal with process of creation
• Structural deal with static composition and
  structure of classes and objects
• Behavioral deal with dynamic interaction among
  classes and objects

6
Design Patterns

• Each pattern is described as follows
• Pattern name
• Category creational, structural or behavioral
• Intent short description of problem addressed
• AKA other names for the pattern
• Applicability where pattern can be applied
• Structure diagram that describes participants
  in the pattern relationships among them
• Participants list of classes and/or objects
  that participate in the pattern

7
Singleton Pattern

• Category creational
• Intent ensure that a class has only one instance
  and provide global point of access to it
• Applicability use where there must be exactly
  one instance of a class and it must be accessible
  to clients from a well-known access point (e.g.
  database)

8
Singleton Pattern

• Structure

Singleton static getInstance() operation() getData
() static Singleton theInstance data
return theInstance
9
Singleton Pattern

• Participants only one
• Singleton declares the unique instance of the
  class as a static variable and defines a static
  method getInstance() for clients to access the
  unique instance.

10
Singleton Pattern

• public class Singleton
• public static Singleton getInstance()
• return theInstance
• private Singleton()
• //initialize instance fields
• //.
• private static Singleton theInstance new
  Singleton()

11
Strategy Pattern

• Category behavioral
• Intent define a family of algorithms,
  encapsulate each one and make them
  interchangeable

12
Strategy Pattern

• Applicability use when
• many related classes differ only in behavior
• plotting different functions
• different variations of algorithm are needed
• sorts
• an algorithm uses data that clients should not
  know about
• LayoutManager in the AWT
• a class defines many behaviors which appear as
  multiple conditional statements in its methods

13
Structure of Strategy Pattern
STRATEGY
Context contextInterface()
Strategy algorithmInterface()
Concrete Strategy A algorithmInterface()
Concrete Strategy C algorithmInterface()
Concrete Strategy B algorithmInterface()
Note arrowheads should be unfilled
14
Using the Strategy Pattern
Pivot Strategy getPivot()
quicksort
pivotStrategy.getPivot(array,lo,hi)
Random
Median of Three
Select First
Concrete Strategies
Strategy pattern resolves how to extend policies
for selecting a pivot value without modifying
main quicksort algorithm
15
Dungeons Patterns
A tutorial presented by Steve Metsker and William
Wake At OOPSLA 2001
16
Why Design Patterns?

• Patterns record previous successes in a reusable
  form
• Design patterns are well-worn solutions to
  problems at about a class level

17
How the Game Works

• Each table has a pattern master who has a map of
  a dungeon
• You must adventure through the dungeon to reclaim
  pearls of wisdom from a dragon
• Your primary helper is an Ahobbit
• With capricious magical abilities

18
Ahobbits

• Your Ahobbit has a magical ring that
• Cannot be removed
• You can activate by getting him/her to say Aha
• Ahobbits are enlightened only when they
  understand a design pattern
• Ahobbits learn from real-world examples in the
  dungeon

19
Adventuring

• Find a room in the dungeon
• When you enter
• Examine the device or contents therein
• Determine which pattern it shows
• Use the device to explain to your Ahobbit the
  intent of the pattern (2 guesses)
• When the Ahobbit says Aha, something magical
  will occur

20
Beginning

• We shall begin as one huge exploration party
• Before breaking into one party per table or group
• You stand before a door that leads to the dungeon
• What do you do?
