Bran Selic Rational Software Canada [e-mail]

1
Physical Programming Beyond Mere Logic

• Bran SelicRational Software Canadabselic_at_rationa
  l.com

2
What I am Hoping For
E THEORY AND PRACTICE OF
SOFTWARE
3
The Ideal and the Real

• By focussing on the imperfect world of physical
  reality we may miss the essence

• Software seems much closer to the ideal world

4
The Software World

• Fundamental design principle separate program
  logic from the underlying implementation
  technology
• separation of concerns
• software portability

Program Logic
HL ProgrammingLanguages
Computing Environment Technology
5
The Real-Time Software World

• Key question How long will it take?
• The quantitative characteristics of the computing
  environment encroach upon the purity of the logic
• software design involves engineering tradeoffs

6
A Simple Programming Application

• Traverse a transactions log database and print
  all transactions pertaining to a specific account

open (DB) for i 1 to DB.size do record
read (DB) if (record.acctNo
myAccount)then print (record) enddo close
(DB)
7
Porting to a Distributed Environment

• Can it really be this simple?

Network
open (DB)for i 1 to DB.size do record
read (DB) if (record.acctNo
myAccount)then print (record) enddoclose
(DB)
RPC_open (DB)for i 1 to DB.size do record
RPC_read (DB) if (record.acctNo
myAccount)then print (record) enddoRPC_close
(DB)
8
Some (Unstated!) Assumptions

• The CPU and database are fast enough for the
  needs of the application
• e.g. random access database hardware
• The CPU and database fail as a unit
• i.e., no need to contend with failures of the
  database
• Communications is reliable
• order preserving
• exactly once semantics
• A system never has anything more important to do
  than what it is doing at the moment

9
Partial Failures

• Distributed systems can exhibit partial failures
• fault tolerance ability to recover from partial
  failures
• Issue failure recovery strategy
• fault detection
• failure recovery
• fault diagnosis
• Issue how do other sites detect that a site has
  failed?
• (apparent) lack of activity/response
• how do we distinguish between a failed site and a
  lost message?
• Timeout is the only general mechanism available
• how long do we wait?
• Tradeoff between responsiveness vs. degree of
  certainty

10
A More Realistic Distribution Scenario

• Dealing with partial failures

DB locate_database (Network)exception abort
RPC_open (DB)exception do DB
locate_database (Network)exception abort
enddo for i 1 to DB.size do record
RPC_read (DB)exception do DB
locate_database (Network)exception abort for
j 1 to (i-1) do RPC_read (DB)
exception abort retry enddo if
(record.acctNo myAccount)then print
(record) enddo RPC_close (DB)
Most of the code is in the exception handlers!
11
Asynchronous Events and Fault Tolerance

• Partial system failures are only one kind of
  event that may need to be handled in the course
  of execution of a distributed program
• Others
• high-priority situations (e.g., imminent
  deadlines)
• aborts
• These events are often unpredictable
• may occur at any point in the execution of a
  program
• fault tolerance requires that whenever they occur
  and whatever they are, we need to deal with them

12
Revisiting An Old Assumption

• Is the traditional main path focussed
  programming style appropriate when exceptions are
  the rule?

13
Asynchronous Event Handling

• This is nicely captured by the state-event matrix
  of finite state machines

Event A
etc.
Event S
Handler AN
Handler AN1
Handler AN2
14
A Conclusion

• In an event-driven and deadline-based
  application, a state machine-based programming
  model may be more appropriate than the
  traditional algorithmic (main path) programming
  model
• The environment strikes back
• the program logic is strongly affected by the
  environment

15
Communication Media Failures

• Message loss
• due to hardware failures
• due to software failures (e.g., buffer overflow)
• Message reordering
• due to different paths
• due to variable delays (e.g., due to variable
  message lengths)
• retransmission due to fault-tolerant protocols
• Message duplication
• due to faulty hardware
• retransmission due to fault-tolerant protocols

16
Transmission Delays

• Possibility of out of date status information

17
Relativistic Effects

• Relativistic effects
• different observers see different event orderings
  (due to different and variable transmission
  delays)

18
Distribution Transparencies

• Providing supporting layers of functionality that
  shield the application from the undesirable
  effects of distribution
• e.g., reliable communication protocols

client
server
19
Impossibility Result No.1

• It is not possible to guarantee that agreement
  can be reached in finite time over an
  asynchronous communication medium, if the medium
  is lossy or one of the distributed sites can fail
• Fischer, M., N. Lynch, and M. Paterson,
  Impossibility of Distributed Consensus with One
  Faulty Process Journal of the ACM, (32, 2) April
  1985.

20
Impossibility Result No.2

• Even when communication is fully reliable, it is
  not possible to guarantee common knowledge if
  communication delays are unbounded
• Halpern, J.Y, and Moses, Y., Knowledge and
  common knowledge in a distributed environment
  Journal of the ACM, (37, 3) 1990.

21
The End-To-End Argument

• Transparency mechanisms are intended to protect
  the application from observing the undesirable
  effects of distribution
• Most transparency types require distributed
  agreement!
• The end-to-end argument Saltzer et al.
• if transparency cannot be guaranteed, the
  application is not really shielded from the
  effects of distribution
• the overhead of introducing transparency
  mechanisms may not be justified

22
Stepping Back...

• Most distribution problems are a consequence of
  the encroachment of the physical world into the
  pliable and limitless logical world of software
• the problem is fundamental (e.g., the end-to-end
  argument)
• Traditional Programming Logic
• Physical Programming Logic Physics
• like traditional engineers, software designers
  must take into account the raw material out of
  which they spin their logic
• finite resources, finite delays, finite
  reliability...

23
Quality of Service Concepts

• The physical characteristics of software can be
  specified using the general notion of Quality of
  Service (QoS)
• a specification of how well a service is (to be)
  performed
• e.g. throughput, capacity, response time
• usually a quantitative measure
• QoS specifications are two sided
• offered QoS the QoS that is offered to clients
• required QoS the QoS required by a client

24
Resources and Quality of Service

• Resource an element whose functional capacity is
  limited, directly or indirectly, by the finite
  capacities of the underlying physical computing
  environment
• The services of a resource are characterized by
  one or more QoS attributes
• capacity, reliability, availability, response
  time, etc.

Client
Resource
Resource Demand
OfferedQoS
RequiredQoS
RequiredQoS ? OfferedQoS
25
Simple Example

• Concurrent tasks accessing a monitor with known
  response time characteristics

Required QoS
Deadline 3 ms
MaxExecutionTime 4 ms
Offered QoS
26
Types and Physical Types

• The purpose of types is to tell us about the
  externally relevant properties of software
  components so that we can validate whether they
  are being used appropriately
• Physical types type specifications that
  incorporate QoS characteristics
• Answer two key engineering questions
• can this component support the load intended
  for it?
• what does this component require to support its
  offered QoS?

27
Physical Type Example

• A semaphore type
• class Semaphore
• heap 10 bytes -- required QoS
• CPU? 5 MIPS -- required QoS
• get()proc? 0.4CPU usstack4 bytes
• rel()proc? 0.4CPU usstack4 bytes
• Usage
• mySema Semaphore
• mySema.get() proc? 3 us -- req. QoS

28
Violation of Encapsulation?

• Arent the offered QoS characteristics a
  consequence of the implementation?
• Not necessarily...
• The offered QoS characteristics can and should be
  defined independently of the implementation
• the worst-case numbers of traditional
  engineering
• The contractual obligations that the component
  designer is willing to assume

29
Physical Type Checking

• Can physical types be statically checked?
• The good news Yes, they can (in most cases)
• The bad news typically requires complex analysis
  methods (queueing network analysis,
  schedulability analysis, etc.)
• but then, model checking and theorem proving is
  not simple either
• Some issues
• Typically, QoS-based analyses cannot be done
  incrementally -- the full system context is
  required
• but then, the same holds for many formal
  verification methods
• Each type of QoS (e.g., bandwidth, CPU
  performance) combines differently

30
Required QoS

• Like all guarantees, the offered QoS is
  contingent on the component getting what it needs
  to do its job
• There are two distinct dimensions to this
• the peer dimension
• the layering dimension

31
Logical Viewpoint

• Example logical view of aircraft simulator
  software

INSTRUCTOR STATION
AIRFRAME
ATMOSPHEREMODEL
PILOT CONTROLS
CONTROLSURFACES
GROUNDMODEL
ENGINES
32
Engineering (Realization) Viewpoint

• The realization of a specific set of logical
  components using facilities of the run-time
  environment

33
Viewpoints and Mappings
Realizationmappings
34
The Engineering Viewpoint

• The engineering viewpoint represents the raw
  material out of which we construct the logical
  viewpoint
• the quality of the outcome is only as good as the
  quality of the ingredients that are put in
• as in all true engineering, the quantitative
  aspects of the logical model are often crucial
  (How long will it take? How much will be
  required?)

35
Distributed Systems Dilemma

• Dilemma How can we account for the engineering
  characteristics of the system without prematurely
  and possibly unnecessarily committing to a
  specific technology?
• Proposed solution Include in the logical model a
  generic (technology-neutral) specification of the
  required/expected characteristics of the
  engineering environment

36
Viewpoint Separation

• Required Environment a technology-neutral
  environment specification required by the logical
  elements of a model

Logical Viewpoint
37
Required Environment Specifications

• What a logical component needs in order to
  perform its function according to spec

realization mapping
38
Required Environment Partitions

• Logical elements often share common QoS
  requirements

QoS domain (e.g.,failure unit, uniform comm
properties)
39
QoS Domains

• Specify a domain in which certain QoS values
  apply throughout
• failure characteristics (failure modes,
  availability, reliability)
• CPU speeds
• communications characteristics (delay,
  throughput, capacity)
• etc.
• The QoS values of a domain can be compared
  against those of a concrete engineering
  environment to see if a given environment is
  adequate for a specific model

40
Physical Programming

• The notions of QoS and QoS domains enable the
  design of distributed systems that properly
  account for the effects of distribution and other
  non-transparent physical phenomena, while
  allowing for a high degree of portability and
  technology independence
• They are also the basis for formal verification
  of realization mappings
• required QoS ? QoS of the proposed engineering
  environment
• May also be used to automatically synthesize
  engineering environments that satisfy a given QoS
  specification of a logical model

41
Conclusions and an Appeal...

• The physical aspects of software will not go away

• ignoring them can be perilous especially when
  working with distributed systems
• most interesting software systems of the future
  will be distributed and will have stringent
  dependability requirements (cannot reboot the
  Internet)
• What is needed is a proper theoretical framework
  for dealing with physical types
• The QoS framework described here is currently
  being incorporated into a profile of UML for
  real-time applications
