Enhancements to NFS

1
Enhancements to NFS

• ??? R88725039
• 2000/11/6

2
Introduction

• File system modules
• Directory module
• File module
• Access control module
• File access module
• Block module

3
Introduction

• Distributed file system requirements
• Transparency
• Access transparency
• location transparency
• Scaling transparency
• Consistency
• Security

4
Sun NFS architecture
5
Andrew file system architecture
6
Mobility enhancement

• Mobile file system (MFS)

7
Mobile file system (MFS)

• Client modules

8
Mobile file system (MFS)

• Proxy modules
• Source Maria-Teresa Segarra IRISA Research
  Institute Campus de Beaulieu

9
Mobility enhancement cont.

• NFS/M
• Enable the mobile user to access the information
  regardless of
• the location of the user
• the state of the communication channel
• the state of the data server

10
NFS/M architecture
11
NFS/M modules
12
NFS/M modules

• Cache Manager (CM)
• All the file system operations to any cached
  objects in the local disk cache are managed by
  the CM
• It functions only in the connected phase

13
NFS/M modules

• Proxy Server (PS)
• Emulates the functionalities of the remote NFS
  server by using the cached file system objects in
  the local disk cache
• It functions in the disconnected phase

14
NFS/M modules

• Reintegrator (RI)
• Propagates the changes of the data objects in the
  local disk cache performed during the
  disconnected period back to the NFS server
• Three tasks for the RI
• Conflict detection
• Update propagation
• Conflict resolutions

15
NFS/M modules

• Data Prefetcher (DP)
• Improving data access performance
• Data prefetching techniques can be classified
  into two categories
• Informed prefetching
• Predictive prefecting

16
NFS/M modules
17
Phase of the NFS/M

• NFS/M client maintains an internal state which
  terms as phase, which is used to indicate how
  file system service provided under different
  conditions of network connectivity
• Three phases
• Connected phase
• Disconnected phase
• Reintegration

18
Phase of the NFS/M

• John C.S. Lui , Oldfield K.Y. So , T.S. Tam,
  Department of Computer Science Engineering

19
Case wireless andrew

• It builds on the universitys wired network
  infrastructure,which currently provides
  10/100Mb/s Ethernet service
• To supply high-speed wireless service to the
  campus, lucent WaveLAN equipments have installed
• For wireless access off campus or otherwise out
  of the range of the WaveLAN network, using
  cellular digital packet data

20
Case wireless andrew

• Wireless Andrew mobile computing for university
  campus 1999 IEEE

21
Reference URL

• http//csep1.phy.ornl.gov/nw/node3.html
• http//www.dqc.org/chris/tcpip_ill/nfs_netw.htm
• http//www.coda.cs.cmu.edu/
• http//www.uwsg.iu.edu/usail/network/nfs/overview.
  html
• http//www.netapp.com/tech_library/nfsbook.html

22
Scalibility about NFS

• ????? R88725032
• 2000/11/6

23

• NFS - Scalability
• AFS - Scalability
• NFS Enhancement -Spritely NFS, NQNFS, WebNFS, NFS
  Version4
• AFS Enhancement - RAID, LSF, xFS
• Frangipani

24
NFS - Scalability

• The performance of a single server can be
  increased by the addition of processors, disks
  and controllers.
• When the limits of that process are reached,
  additional servers must be installed and the
  filesystems must be reallocated between them.

25
NFS - Scalability (contd)

• The effectiveness of that strategy is limited by
  the existence of hot spot files.
• When loads exceed the maximum performance, a
  distributed file system that supports replication
  of updatable files, or one that reduces the
  protocol traffic by the caching of whole files,
  may offer a better solution.

26
AFS - Scalability

• The differences between AFS and NFS are
  attributable to the identification of scalability
  as the most important design goal.
• The key strategy is the caching of whole file in
  client nodes.

27
AFS - Scalability (contd)

• Whole-file serving The entire contents of
  directories and files are transmitted to client
  computers by AFS servers.
• Whole-file caching Once a copy of a file has
  been transferred to a client computer, it is
  stored in a cache on the local disk.
• The cache is permanent, surviving reboots of the
  client computer.

28
NFS enhancement - Spritely NFS

• is an implementation of the NFS protocol with the
  addition of open and close calls.
• The parameters of the Sprite open operation
  specify a mode and include counts of the number
  of local processes that currently have the file
  open for reading and for writing.
• Spritely NFS implements a recovery protocol that
  interrogates a list of clients to recover the
  full open files table.

29
NFS enhancement - NQNFS

• maintains similar client-related state concerning
  open files, but it uses leases to aid recovery
  after a server crash.
• Callbacks are used in a similar manner to
  Spritely NFS to request clients to flush their
  caches when a write request occurs.

30
NFS enhancement - WebNFS

• makes it possible for application programs to
  become clients of NFS servers anywhere in the
  Internet (using the NFS protocol directly)
• implementing Internet applcations that share data
  directly, such as multi-user games or clients of
  large dynamics databases.

31
NFS enhancement - NFS version 4

• will include the features of WebNFS
• the use of callback or leases to maintain
  consistency
• on-the-fly recovery
• Scalability will be improved by using proxy
  servers in a manner analogous to their use in the
  Web.

32
AFS enhancement

• RAID
• Log-structured file storage
• xFS
• implements a software RAID storage system,
  striping file data across disks on multiple
  computers together with a log-structuring
  technique.

33
Frangipani

• A highly scalable distributed file system
  developed and deployed at the Digital Systems
  Research Center.

34
Frangipani (contd)

• The responsibility for managing files and
  associated tasks is assigned to hosts
  dynamically.
• All machines see a unified file name space with
  coherent access to shared updatable files.

35
Frangipani - System Structure

• Two totally independent layers -
• 1. Petal distributed virtual disk system
• - Data is stored in a log-structured and striped
  format in the virtual disk store.
• - Providing a storage repository
• - Providing highly available storage that can
  scale in throughput and capacity as resources are
  added to it
• - Petal implements data replication for high
  availability, obviating the need for Frangipani
  to do so.

36
Frangipani - System Structure (contd)

• 2. Frangipani server modules.
• - Providing names, directories, and files
• - Providing a file system layer that makes Petal
  useful to applications while retaining and
  extending its good properties.

37
Frangipani
38
Frangipani
39
Frangipani
40
Frangipani
41
Frangipani - Logging and Recovery

• uses write-ahead redo logging of metadata to
  simplify failure recovery and improve
  performance.
• User data is not logged.
• Each Frangipani has its own private log in Petal.
• As long as the underlying Petal volume remains
  available, the system tolerates an unlimited
  number of Frangipani failures.

42
Frangipani - Logging and Recovery

• Frangipanis locking protocol ensures that
  updates requested to the same data by different
  servers are serialized.
• Frangipani ensures that recovery applies only
  updates that were logged since the server
  acquired the locks that cover them, and for which
  it still holds the locks.

43
Frangipani - Logging and Recovery

• Recovery never replays a log describing an update
  that has already been completed.
• For each block that a log record updates, the
  record contains a description of the changes and
  the new version number.
• During recovery, the changes to a block are
  applied only if the block version number is less
  than the record version number.

44
Frangipani - Logging and Recovery

• Frangipani reuses freed metadata blocks only to
  hold new metadata.
• At any time, only one recovery demon is trying to
  replay the log region of a specific server.
• If a sector is damaged such that reading it
  returns a CRC error, Petals built-in replication
  can recover it.

45
Frangipani - Logging and Recovery

• In both local UNIX and Frangipani, a user can get
  better consistency semantics by calling fsync at
  suitable checkpoint.

46
Frangipani - Synchronization and Cache Coherence

• Frangipani uses multiple-reader/single-writer
  locks to implement the necessary synchronization.
• When the lock service detects conflicting lock
  requests, the current holder of the lock is asked
  to release or downgrade it to remove the conflict.

47
Frangipani - Synchronization and Cache Coherence

• When a Frangipani crashes, the locks that it owns
  cannot be released until appropriate recovery
  actions have been performed.
• When a Frangipanis lease expires, the lock
  service will ask the clerk on another machine to
  perform recovery and release all locks belonging
  to the crashed Frangipani.

48
Frangipani - Synchronization and Cache Coherence

• Petal can continue operation in the face of
  network partitions, as long as a majority of the
  Petal remain up and in communication.
• The lock service continues operation as long as a
  majority of lock servers are up and in
  communication.

49
Frangipani - Synchronization and Cache Coherence

• If a Frangipani server is partitioned away from
  the lock service, it will be unable to renew its
  lease.
• If a Frangipani server is partitioned away from
  Petal, it will be unable to read or write the
  virtual disk.

50
Frangipani - Adding Servers

• The new server need be told which Petal virtual
  disk to use and where to find the lock service.
• The new server contacts the lock service to
  obtain a lease, determines which portion of the
  log space to use from the lease identifier.

51
Frangipani - Removing Servers

• Simply shut the server off.
• Preferable for the server to flush all its dirty
  data and release its locks before halting, but
  not strictly be needed

52
Frangipani - Servers halts abruptly

• Recovery will run on its log the next time one of
  its locks is needed, birnging the shared disk
  into a consistent state.
• Petal can also be added and removed
  transparently. Lock servers are added and removed
  in a similar manner.

53
Frangipani - Scaling

• Operational latencies are unchanged and
  throughput scales linearly as servers are added.

54
Frangipani - Scaling
55
Frangipani - Scaling
56
Frangipani - Scaling
57
Frangipani - Scaling

• The performance is seen to scale well because of
  no contention until the ATM links to the Petal
  are saturated.
• Since the virtual disk is replicated, each write
  from a Frangipani server turns into two writes to
  the Petal.

58
Frangipani - Conclusions

• Providing its users with coherent, shared access
  to the same set of files, yet is scalable to
  providing more storage space, higher performance,
  and load balancing
• It was feasible to build because of its two-layer
  structure, consisting of multiple file servers
  running the same file system code on top of a
  shared Petal.

59
Reference Source

• Timothy Mann and Edward K. Lee,. Frangipani A
  Scalable Distributed File System
