MPEG-7 Visual part of eXperimentation Model

1
MPEG-7 Visual part of eXperimentation Model

• Presented by Moustafa A. Hammad.

2
Introduction

• MPEG-7 Multimedia content description
  interface.
• A Quick review
• Feature, Descriptor, Descriptor value,
  Description Scheme, Description Definition
  Language (DDL)
• Visual Elements ( Color, Spatial Structure,
  Shape, Motion)
• Representation of descriptors using DDL ( MPEG-7
  DDL has been approved, October 99 )

3
Topics of Discussion

• Visual Elements Descriptors
• Color
• Color Space
• Dominant Color
• Color Histogram
• Spatial Structure
• Grid Layout
• Shape
• Object Bounding Box
• Motion
• Camera Motion
• Object Motion Trajectory

4
Color

• Color Space
• Like
• RGB, YCrCb, HSV, linear transformation matrix
  with reference to RGB
• Syntax
• Color_Space_Descriptor
• Enum description_color_space rgb, ycrcb, hsv,
  linear_matrix
• If (description_color_space linear_matrix)
• Int color_trans_mat33

5
Color (Cont.)

• Dominant Color (DC)
• To specify set of DC in a shaped region.
• Syntax
• Dominant_Color_D
• int Dominant_Colors_Number
• struct Dominant_Color
  DCsDominant_Colors_Number
• Int Confidence_Measure
• struct Dominant_Color
• int Color_ValueColor_Space_Dimension
• Int Percentage
• Use color histogram (to get dominant colors (non
  normative part)
• Content-based retrieval.

6
Color (Cont.)

• Color Histogram
• Denotes percent of each color in image object.
• Syntax
• Color_Histogram_Descriptor
• int histogram_norm_factor
• int number_histogram_bins
• int histogram_valuenumber_histogram_bins

Histogram_value
Histogram_bin
7
Spatial Structure

• Grid Layout
• Grid_Layout
• int PartNumberH
• int PartNumberV

8
Shape

• Object Bounding Box
• Bounding_Box
• Enum LengthUnits //Picture height, meters.
• double BoxHeight
• double BoxWidth
• double BoxDepth
• double FractionalOccupancy
• boolean Is3D
• If (HasCompositionInfo0
• double BoxCentreH
• double BoxCentreV
• double ?
• If (Is3D)
• double BoxCentreD
• double ?

DAR h/w
9
Shape (Cont.)

• Extraction for 2D objects (non normative part)
• Matching/Query process (non normative part)
• Find the 2D objects whose aspect ratio (,gt,lt) a
  certain value or within a certain range.
• Find the 2D or 3D objects whose sizes are similar
  to the one in this object or (,gt,lt) a certain
  vale or within a certain range.
• Find the object that are positioned near (x,y) or
  (x,y,z) location in the picture/3D world.
• Find the object whose height/width/depth are
  (,gt,lt) a certain value or within a certain
  range.

ObjectID of interest
Identifying samples belonging to object of
interest
Bounding Box Estimation
Segmentation map
Bitmap of the object Of interest
Segmentation
Aspect Ratio
10
Motion

• Camera Motion
• Camera operations
• (8 well known operation) The operations in the
  figures
• (zooming, change of the focal length) and Fixed
• Extract
• (camera motion parameter information)
• Sub shots
• - (frames characterized by type (s) of camera
  motion)
• - mixture or non-mixture
• Sub shots are the building blocks of this
  descriptor

11
Motion (Cont.)

• Fractional_Presence
• float TRACK_LEFT
• float TRACK_RIGHT
• float BOOM_DOWN
• float BOOM_UP
• float DOLLY_FORWARD
• float DOLLY_BACKWARD
• float PAN_LEFT
• float PAN_RIGHT
• float TILT_UP
• float TILT_DOWN
• float ROLL_CLOCKWISE
• float ROLL_ANTICLOCKWISE
• float ZOOM_IN
• float ZOOM_OUT
• float FIXED

• Syntax
• Camera_Motion_Descriptor
• Int
  Num_Segment_Description
• Int
  Description_Mode
• Segmented_Camera_Motion InfoNum_Segment_Descrip
  tion
• Segmented_Camera_Motion
• TimeStamp start_time
• float duration
• Fractional_Presence presence
• Amount_of_Motion speeds
• float
  FOE_FOC_Horizontal_Position
• float
  FOE_FOC_Vertical_Position
•

Amount_of_Motion float TRACK_LEFT float
TRACK_RIGHT float BOOM_DOWN float
BOOM_UP float DOLLY_FORWARD float
DOLLY_BACKWARD float PAN_LEFT float
PAN_RIGHT float TILT_UP float TILT_DOWN floa
t ROLL_CLOCKWISE float ROLL_ANTICLOCKWISE float
ZOOM_IN float ZOOM_OUT
Example A shot represented as mixture mode of
duration 40 time unit
Shot
Num_Segment_Description 1 Description_Mode
1 // mixture mode Segmented_Camera_Motion
Info1
Start_time 0 Duration 40 Presence
0.25-0.25 0.32 - - - 0.25 - - - - 0.2 0.2
ltrest of attributesgt
12
Motion (Cont.)

• Object Motion Trajectory
• Spatio-temporal localization of one
  representative point of the object (such as a
  centroid).

Object_Motion_Trajectory int
Camera_follows_object enum Coord_system
local, world I (Coord_system
world) Boolean local_to_world_parameters_known
if ( local_to_world_parameters_known) world_coo
rd_info world_params enum spatial_units
picture_height, meters boolean
Coords_are_3D int N_key_points double
Key_point_tN_key_points double
Key_point_xN_key_points double
Key_point_yN_key_points If ( Coords_are_3D) do
uble Key_point_zN_key_points boolean
Object_Always_Visible If ( ! Object_Always_Visible
) Object_is_visibleN_key_points 1
boolean Use_default_interp_only
If( ! Use_default_interp_only) If (
Coords_are_3D) Interval_3D_info
Intervals_3DN_key_points 1 else Interva
l_2D_info Intervals_3DN_key_points
1 Interval_3D_info interpolation_functi
on_info x_function interpolation_function_info
y_function interpolation_function_info
z_function Interval_2D_info interpolation_func
tion_info x_function interpolation_function_in
fo y_function Interpolation_function_info i
nt Function_ID if ( Function_ID gt 0) list of
parameters_values
f(t) fa va ( t ta ) f(t) fa va ( t
ta ) ½ aa (tb ta)
13
Motion (Cont.)

• Extraction (non-normative part)
• Input object binary segmentation mask sequence.
• Output global motion information.
• Process
• Instantiate key points time instants in
  description ( one per frame)
• Calculate the mass center of the mask at each
  frame.
• Calculate speed and acceleration (z information
  may be deduced by from the size variation)
• Choose interpolation function
• If the object is moving eventually subtract the
  global motion from the object motion if you want
  the trajectory in the scene reference and not in
  the camera reference.
• We define object followed by the camera as
• Unmoving object at a position near from the
  image center
• Object having irregular displacement of little
  amplitude around a position near the image
  center
• Matching
• The distance between two trajectory descriptors
  D, D is
• d(D, D) ?i ? ( (xi - x i )2 (yi - y i
  )2 (zi - z i )2 ) / (?t i )
• ? ( (Vxi - Vxi )2 (Vyi - Vyi )2
  (Vzi - Vzi)2 ) / (?t i )
• ? ( (axi - a xi )2 (ayi - ayi )2 (azi
  - azi)2 ) / (?t i )

14
Motion (Cont.)

• Example query
• Find the video frames in which object k is moving
  to the right (left, up, down)
• Soln
• For all pairs of frames contained within the
  existance interval for object k compute the
  motion vector
• v(t2) pos(t2) - pos(t1)
• Where, pos(t) is the object spatial coordinate at
  time t.

15
Descriptor representation using MPEG-7 proposed
DDL

• ltDType name'speeds'gt
• ltattribute name'TRACK_LEFT' type'real'/gt
• ltattribute name'TRACK_RIGHT' type'real'/gt
• ltattribute name'BOOM_DOWN' type'real'/gt
• ltattribute name'BOOM_UP' type'real'/gt
• ltattribute name'DOLLY_FORWARD' type'real'/gt
• ltattribute name'DOLLY_BACKWARD' type'real'/gt
• ltattribute name'PAN_LEFT' type'real'/gt
• ltattribute name'PAN_RIGHT' type'real'/gt
• ltattribute name'TILT_UP' type'real'/gt
• ltattribute name'TILT_DOWN' type'real'/gt
• ltattribute name'ROLL_CLOCKWISE' type'real'/gt
• ltattribute name'ROLL_ANTICLOCKWISE'
  type'real'/gt
• ltattribute name'ZOOM_IN' type'real'/gt
• ltattribute name'ZOOM_OUT' type'real'/gt
• lt/DTypegt
•
• ltDType name'presence'gt
• ltsubDOf name'speeds/gt

• Camera motion descriptor
• ltDType name'CameraMotionD'gt
• ltattribute name'NumSegmentDescription'
  typeinteger/gt
• ltattribute name'DescriptionMode'
  typeboolean/gt
• ltseq minOccurs'0' maxOccursPar'NumSegmentDes
  cription'gt
• ltDTypeRef name'SegmentedCameraMotionD'/gt
• lt/seqgt
• lt/DTypegt
•  ltDType name'SegmentedCameraMotionD'gt
• ltDType name'start_time' type'time'/gt
• ltDType name'duration' type'timeDuration'/gt
• ltDTypeRef name'presence'/gt
• ltDTypeRef name'speeds'/gt
• ltDType name'FOE_FOC_HorizontalPosition'
  typereal/gt
• ltDType name'FOE_FOC_VerticalPosition'
  type'real'gt
• lt/DTypegt
