A Proposal for a Video Modeling for Composing Multimedia Document

1
A Proposal for a Video Modeling for Composing
Multimedia Document

• Cécile ROISIN - Tien TRAN_THUONG - Lionel VILLARD
• Presented by Tien TRAN THUONG
• Project OPERA - INRIA
• Grenoble - France

2
Work Context

• Theme Multimedia Document (Madeus)
• Authoring system for multimedia structured
  documents
• Basic media sound, video, text, image, etc.
• Document composed by relations

• Need composition of semantic video fragments
  with other basic media elements (image, text,
  sound, ...)

3
Temporal Synchronization ExampleINRIAs
positions document
Pictures Titles synchronized with video parts
Video Presentation
4
Logical organization of document
InriaIntroduction
Buildings
Overview
Video Presentation
Video Frames
5
Time line view of the document
Rocquencourt Title Picture
Texts grow up
Rennes Title Picture
Sophia-Antipolis Title Picture
Lorraine Title Picture
Rhône-Alpes Title Picture
Raw video
Time
Video fragments
6
Spatial Synchronization examples
7
Spatial layout of text follow video object
document
Document Region (Left, Top, Width, Height)
Text Region (Width, Height)
Video Region (Left, Top, Width, Height)

• Location of the video object region that is
  moving region in the video region

8
Objective and plan of that work

• Research and development on the video modeling
  for the description of the video content relevant
  to multimedia applications
• Video modeling video description for multimedia
  composition,
• Multimedia application our VideoMadeus is an
  editing and presentation system.

9
Video Description

• Dublin core the semantic indexing schema for
  video content description.
• MPEG-7 the future standard tools will enable to
  define the semantic schemas for description of
  the audiovisual information.

• Our video modeling for composing multimedia
  document.

10
Methodology

• Specification of a modeling for the description
  of video content
• Multi-level structuration,
• temporal and spatial relations,
• actions interactive on the video elements.
• Specification in XML
• Experimentation in Madeus (VideoMadeus)

11
Multi-level Structuration
lt!--XML schema for the description of
VideoContent--gt lt!ELEMENT VideoContent
(MetaInfo, MediaInfo, Summary, Structure,
Semantic, Thesaurus)gt lt!ELEMENT Structure
(Sequence, Relation?)gt lt!ELEMENT Semantic
(VideoObject, EventSemantics)gt lt!ELEMEN
T Thesaurus
(ReferenceDictionary, UserDictionary)gt
12
Video Structure Description

• Motivation for composition, the basis is to have
  the Structure description level.
• Semantic and Thesaurus are more necessary for
  retrieval applications or as a support for
  structuration level.
• First step is Structure description

13
High Level Description

• Video Structure

lt!--XML schema for the description high level
structure --gt lt!ELEMENT Structure (Sequence,
Relation?)gt lt!ELEMENT Sequence
(Scene,Relation?)gt lt!ELEMENT Scene
(Shot,Event, Relation?)gt lt!ELEMENT Shot
(Transition?,Event,Occurrence,

Background?, Relation?)gt
14
Shot Content Description
lt!-- XML Shot Description --gt lt!ELEMENT
Shot (Transition?,Event,Occurrence,
Background?, Relation?) gt lt!ELEMENT
Transition EMPTY gt lt!ELEMENT Event
EMPTYgt lt!ELEMENT Background (Region)gt lt!ELEME
NT Occurrence (Region, Trajectory?,
Occurrence) gt lt!ELEMENT SpatialLayout
(2DBStringDS) gt lt!ELEMENT CameraWork
(CameraMotion?) gt

• Shot Content

Semantic

• Transition

• Event

Shot

• SpatialLayout

• Background

Trans.
CameraWork

• Occurrence

Event
Occurrence
SpatialLayout
Background

• Camerawork

Reference
15
Occurrence Content Description

• Occurrence Content

lt!-- XML Occurrence description --gt lt!ELEMENT
Occurrence (Trajectory, Region,
Occurrence)gt lt!ELEMENT Trajectory
gt lt!ELEMENT Region (Contour, Color, Texture,
Centroid, Region)gt lt!ELEMENT Contour
gt lt!ELEMENT Color gt lt!ELEMENT Texture
gt lt!ELEMENT Centroid gt lt!ELEMENT Region gt
Occurrence
16
Model summary

• The model focuses on the description of video
  elements useful for composing a multimedia
  document (shot, scene, occurrence, event,
  relation, etc.)
• It has a XML specification that makes it
  independent and easy to apply to multimedia
  applications (ex. our VideoMadeus).

17
Experimentation of the model in Madeus -
VideoMadeus
18
Madeus Architecture
Editor/Presentation Tools
EXECUTION View
TIME LINE View
HIERARCHICAL View
VIDEO STRUCTURED View
. . .
MODEL MANAGEMENT
PARSERS
LOGIC STRUCTURATION
EVENT MANAGEMENT
TEMPORAL STRUCTURATION
SAVE
Madeus document
SPATIAL STRUCTURATION
MADEUS
OUTILS

• To extend Madeus to VideoMadeus, video content
  description is handled both in composition and in
  presentation parts.

19
Madeus Document Model

• Structured document organized according to the
  dimensions Logical, temporal, spatial.

Internal Document
Madeus Document
Logical
Content
Actor
Temporal
Spatial
20
Relations

• Temporal relations (Allen extension)
• meets, starts, equals, during, overlaps,
  parmin,etc.
• Spatial relations
• left_align, right_align, center_v, center_h,
  top_align, bottom_align, etc.

ltTemporalgt ltRelationsgt
ltstart Interval1 a Interval2 b  /gt
ltmeet Interval1 b Interval2 d  /gt
ltRelationsgt lt/Temporalgt ltSpatialgt
ltRelationsgt ltleft-align
Region1 b Region2 d  /gt
ltRelationsgt lt/Spatialgt
d
21
Overview of VideoMadeus
Editing and Presentation Tools
Video edition View
Execution View
SynchronizationManagement
Behavior Management

• Structure View
• Semantic View
• Thesaurus View

Element Management
Synchronization

• Hyperlink
• Follow-up
• Erase
• Display, etc...

• Temporal
• Spatial

• Edit
• Play
• Search

Requested descriptions
Requested descriptions
Modified description
Data Management
XML Description of video content
Internal Structure (MODEL)
Modify
Parser
Index on video
22
VideoMadeus document
ltMadeusgt ltContentgt . . .
ltVideoContentDSgt . . . ltScene ID
 MyScene  ... gt . . . lt/Scenegt
lt/VideoContentDSgt
lt/Contentgt ltActorgt . . .
ltVideoElement IDSceneVideo Content
MyScene  . . . gt . . .lt/VideoElementgt
lt/Actorgt ltTemporalgt
ltInterval IDScenceInt ActorSceneVideo
Duration... /gt ltRelationsgt . . .
lt/Relationsgt lt/Temporalgt
ltSpatialgt ltRegion
IDScenceReg ActorSceneVideo Height 288
Width352 /gt ltRelationsgt . . .
lt/Relationsgt
lt/Spatialgt lt/Madeusgt
23
Editing features

• Editing of the video description
• shot detection (automatic or manual)
• extract manually video objects, events,
  spatialLayout, etc.
• Creating of semantic groups (manual)
• group shots in a scene, group scenes in a
  sequence
• detection occurrences of a character (group
  occurrences in objects)
• creation of the other semantic indexing
• classifying of the video elements (thesaurus)
• scenario editing (composing)
• Set temporal and spatial relations between video
  element and other media
• Set actions on the video elements

24
Conclusion

• Provide support for deeper access into video data
  in the multimedia authoring system
• temporal/spatial synchronization with the other
  media elements (image, text, sound, etc.),
• actions on the video elements (hyperlink,
  follow-up, erasing, etc.)
• Develop experimentally the video editing view to
  help the user create and modify descriptions of
  video data in accordance with our video model.

25
Perspectives

• More experimentation for spatial synchronization,
• Extension and experimentation of the semantic
  parts (Semantic and Thesaurus) -gt semantic
  queries,
• Use the MPEG-7 tools to specify our video model,
• Develop the video content description editing
  tool
• Integration and adaptation of the video analyzing
  algorithms for generating more automatically
  possible the video elements,
• Timeline editing view for video structure, etc.
• Semantic queries for playing a part of video
  through network.

26
Thanks for your attention
27
Video content description in Madeus document

• lt?xml version"1.0"?gt
• ltMadeus Name"DocMadeus" Version"2.0"
  Width"800" Height"600"gt
• ltContentgt
• ltVideoContent ID"InriaInfoco" gt
• ltStructure ID"InriaInfocoStruc" gt
• ltSequence ID"Seq" Start_Time "0"
  Stop_Time "76.69" gt
• ltScene ID"Scene1" Start_Time "0"
  Stop_Time "4.91" gt lt/Scenegt
• ltScene ID"Scene2" Start_Time
  "4.91" Stop_Time "11.09" gt
• ltShot ID"Shoti" Start_Time
  "4.91" Stop_Time "8.71" /gt
• ltShot ID"Shotii" Start_Time
  "8.71" Stop_Time "11.09" /gt
• lt/Scenegt
• ltScene ID"Scene3" Start_Time
  "11.09" Stop_Time "29.07" gt lt/Scenegt
• lt/Sequencegt
• lt/Structuregt
• lt/VideoContent gt
• ltVideoContent ID"InriaGen" gt
  lt/VideoContentgt

28
Video element definition
lt?xml version"1.0"?gt ltMadeus Name"DocMadeus"
Version"2.0" Width"800" Height"600"gt
ltContentgt . . . lt/Contentgt ltActorgt
ltVideoElement IDWesternScene
ContentWesternDS.Seq.Scene1 TypeRendere
rLightWeight. . . gt ltVideoObject
IDVO1 Object Shot2.ActorOcc1
ActionsFollow-upHyrperlink...
HRef file///C/Users/ttran/Multimedia/Madeus/op
era.html /gt . . . lt/VideoElementgt . .
. lt/Actorgt ltTemporalgt . . . lt/Temporalgt
ltSpatialgt . . . lt/Spatialgt lt/Madeusgt

• The operations can be defined in the instance of
  the described video Hyperlink, Tracking,
  Erasing, Jumping, etc.

29
Temporal part of Inria introduction document

• lt?xml version"1.0"?gt
• ltMadeus Name"DocMadeus" Version"2.0"
  Width"800" Height"600"gt ...
• ltTemporalgt
• ltT-Group ID"Temporal" Duration"pref20s
  min15s max22s"gt
• lt!-- Interval of three hypertexts --gt
• ltInterval ID"ControlOperaInterval"
  Actor"ControlOperaInfo" Duration"pref20s
  min15s max22s"/gt
• lt!-- Interval of the video element --gt
• ltInterval ID"MovieInriaURScene4" Actor
  "InriaURScene4" Fill"freeze" Duration"pref20s
  min15s max22s"/gt
• lt!-- Interval of the texts --gt
• ltInterval ID"txtInriaURScene4Shotii"
  Actor "TxtInriaURScene4" Duration"pref20s
  min15s max22s" /gt
• ...
• ltInterval ID"txtInriaURScene4Shotvi"
  Actor "TxtInriaURScene4Shotvi"
  Duration"pref20s min15s max22s" /gt
• lt!-- Interval of the images --gt
• ltInterval ID"ImgInriaURScene4Shotii"
  Actor "ImgRoc" Duration"pref20s min15s
  max22s" /gt
• ...
• ltInterval ID"ImgInriaURScene4Shotvi"
  Actor "ImgRA" Duration"pref20s min15s
  max22s"/gt
• ltRelationsgt
• lt!-- Equals relations of the texts with the
  video elements --gt

30
Spatial part of Spatio-Temporal Relation Demo
document

• lt?xml version"1.0"?gt
• ltMadeus Name"DocMadeus" Version"2.0"
  Width"800" Height"600"gt
• ...
• ltSpatialgt
• ltS-Group ID"TOTOSpatial"gt
• lt!-- Video region --gt
• ltRegion ID  "WesternVideoRegion"
  Actor"WesternVideo" Left"206" Top"140"
  Height"288" Width"352" Depth"1"/gt
• lt!-- Three hypertext regions--gt
• ltRegion ID " LinkOperaInfoRegion"
  Actor "ControlOperaInfo" Left"236.0"
  Top"492.0" Width"210.0" Depth"2.0"/gt
• ltRegion ID"LinkAutoCitroenRegion"
  Actor "ControlAutoCitroen" Left"36.0"
  Top"492.0" Width"210.0" Depth"2.0"/gt
• ltRegion ID"LinkSTRST" Actor
  "ControlSpatioTemp" Left"472.0" Top"492.0"
  Width"236.0" Depth"2.0"/gt
• ltRegion ID"TxtOperaIntroRegion" Actor
  "TxtOperaIntro" Left"168" Top"46" Height"42"
  Width"429" Depth"2.0"/gt
• lt!-- Regions of the text following the
  video object--gt
• ltRegion ID"TxtMotionRegion" Actor
  "TxtMotion" Height"16.0" Width"69"
  Depth"2.0"/gt
• ltRelationsgt
• ltTop_align Region1"WesternVideoR
  egion.Shot1.Obj" Region2"TxtMotionRegion" /gt
• lt/Relationsgt
