CS 9633 Machine Learning

1
CS 9633Machine Learning

• Computational Learning Theory

Adapted from notes by Tom Mitchell http//www-2.cs
.cmu.edu/tom/mlbook-chapter-slides.html
2
Theoretical Characterization of Learning Problems

• Under what conditions is successful learning
  possible and impossible?
• Under what conditions is a particular learning
  algorithm assured of learning successfully?

3
Two Frameworks

• PAC (Probably Approximately Correct) Learning
  Framework Identify classes of hypotheses that
  can and cannot be learned from a polynomial
  number of training examples
• Define a natural measure of complexity for
  hypothesis spaces that allows bounding the number
  of training examples needed
• Mistake Bound Framework

4
Theoretical Questions of Interest

• Is it possible to identify classes of learning
  problems that are inherently difficult or easy,
  independent of the learning algorithm?
• Can one characterize the number of training
  examples necessary or sufficient to assure
  successful learning?
• How is the number of examples affected
• If observing a random sample of training data?
• if the learner is allowed to pose queries to the
  trainer?
• Can one characterize the number of mistakes that
  a learner will make before learning the target
  function?
• Can one characterize the inherent computational
  complexity of a class of learning algorithms?

5
Computational Learning Theory

• Relatively recent field
• Area of intense research
• Partial answers to some questions on previous
  page is yes.
• Will generally focus on certain types of learning
  problems.

6
Inductive Learning of Target Function

• What we are given
• Hypothesis space
• Training examples
• What we want to know
• How many training examples are sufficient to
  successfully learn the target function?
• How many mistakes will the learner make before
  succeeding?

7
Questions for Broad Classes of Learning Algorithms

• Sample complexity
• How many training examples do we need to
  converge to a successful hypothesis with a high
  probability?
• Computational complexity
• How much computational effort is needed to
  converge to a successful hypothesis with a high
  probability?
• Mistake Bound
• How many training examples will the learner
  misclassify before converging to a successful
  hypothesis?

8
PAC Learning

• Probably Approximately Correct Learning Model
• Will restrict discussion to learning
  boolean-valued concepts in noise-free data.

9
Problem SettingInstances and Concepts

• X is set of all possible instances over which
  target function may be defined
• C is set of target concepts learner is to learn
• Each target concept c in C is a subset of X
• Each target concept c in C is a boolean function
• c X?0,1
• c(x) 1 if x is positive example of concept
• c(x) 0 otherwise

10
Problem Setting Distribution

• Instances generated at random using some
  probability distribution D
• D may be any distribution
• D is generally not known to the learner
• D is required to be stationary (does not change
  over time)
• Training examples x are drawn at random from X
  according to D and presented with target value
  c(x) to the learner.

11
Problem Setting Hypotheses

• Learner L considers set of hypotheses H
• After observing a sequence of training examples
  of the target concept c, L must output some
  hypothesis h from H which is its estimate of c

12
Example Problem(Classifying Executables)

• Three Classes (Malicious, Boring, Funny)
• Features
• a1 GUI present (yes/no)
• a2 Deletes files (yes/no)
• a3 Allocates memory (yes/no)
• a4 Creates new thread (yes/no)
• Distribution?
• Hypotheses?

13
Instance a1 a2 a3 a4 Class
1 Yes No No Yes B
2 Yes No No No B
3 No Yes Yes No F
4 No No Yes Yes M
5 Yes No No Yes B
6 Yes No No No F
7 Yes Yes Yes No M
8 Yes Yes No Yes M
9 No No No Yes B
10 No No Yes No M
14
True Error

• Definition The true error (denoted errorD(h))
  of hypothesis h with respect to target concept c
  and distribution D , is the probability that h
  will misclassify an instance drawn at random
  according to D.

15
Error of h with respect to c
Instance space X
-
-
-
c


h

-
16
Key Points

• True error defined over entire instance space,
  not just training data
• Error depends strongly on the unknown probability
  distribution D
• The error of h with respect to c is not directly
  observable to the learner Lcan only observe
  performance with respect to training data
  (training error)
• Question How probable is it that the observed
  training error for h gives a misleading estimate
  of the true error?

17
PAC Learnability

• Goal characterize classes of target concepts
  that can be reliably learned
• from a reasonable number of randomly drawn
  training examples and
• using a reasonable amount of computation
• Unreasonable to expect perfect learning where
  errorD(h) 0
• Would need to provide training examples
  corresponding to every possible instance
• With random sample of training examples, there is
  always a non-zero probability that the training
  examples will be misleading

18
Weaken Demand on Learner

• Hypothesis error (Approximately)
• Will not require a zero error hypothesis
• Require that error is bounded by some constant ?,
  that can be made arbitrarily small
• ? is the error parameter
• Error on training data (Probably)
• Will not require that the learner succeed on
  every sequence of randomly drawn training
  examples
• Require that its probability of failure is
  bounded by a constant, ?, that can be made
  arbitrarily small
• ? is the confidence parameter

19
Definition of PAC-Learnability

• Definition Consider a concept class C defined
  over a set of instances X of length n and a
  learner L using hypothesis space H. C is
  PAC-learnable by L using H if all c ? C,
  distributions D over X, ? such that 0 lt ? lt ½ ,
  and ? such that 0 lt ? lt ½, learner L will with
  probability at least (1 - ?) output a hypothesis
  h? H such that errorD(h) ? ?, in time that is
  polynomial in 1/?, 1/?, n, and size(c).

20
Requirements of Definition

• L must with arbitrarily high probability (1-?),
  out put a hypothesis having arbitrarily low error
  (?).
• Ls learning must be efficientgrows polynomially
  in terms of
• Strengths of output hypothesis (1/?, 1/?)
• Inherent complexity of instance space (n) and
  concept class C (size(c)).

21
Block Diagram of PAC Learning Model
Control Parameters ?, ?
Training sample
Hypothesis h
Learning algorithm L
22
Examples of second requirement

• Consider executables problem where instances are
  conjunctions of boolean features
• a1yes ? a2no ? a3yes ? a4no
• Concepts are conjunctions of a subset of the
  features
• a1yes ? a3yes ? a4yes

23
Using the Concept of PAC Learning in Practice

• We often want to know how many training instances
  we need in order to achieve a certain level of
  accuracy with a specified probability.
• If L requires some minimum processing time per
  training example, then for C to be PAC-learnable
  by L, L must learn from a polynomial number of
  training examples.

24
Sample Complexity

• Sample complexity of a learning problem is the
  growth in the required training examples with
  problem size.
• Will determine the sample complexity for
  consistent learners.
• A learner is consistent if it outputs hypotheses
  which perfectly fit the training data whenever
  possible.
• All algorithms in Chapter 2 are consistent
  learners.

25
Recall definition of VS

• The version space, denoted VSH,D, with respect to
  hypothesis space H and training examples D, is
  the subset of hypotheses from H consistent with
  the training examples in D

26
VS and PAC learning by consistent learners

• Every consistent learner outputs a hypothesis
  belonging to the version space, regardless of the
  instance space X, hypothesis space H, or training
  data D.
• To bound the number of examples needed by any
  consistent learner, we need only to bound the
  number of examples needed to assure that the
  version space contains no unacceptable hypotheses.

27
?-exhausted

• Definition Consider a hypothesis space H,
  target concept c, instance distribution D, and
  set of training examples D of c. The version
  space VSH,D is said to be ?-exhausted with
  respect to c and D, if every hypothesis h in VH,D
  has error less than ? with respect to c and D.

28
Exhausting the version space
Hypothesis Space H
error 0.2 r0
error 0.1 r0.2
error 0.3 r0.4
VSH,D
error 0.1 r0
error 0.2 r0.3
error 0.3 r0.2
29
Exhausting the Version Space

• Only an observer who knows the identify of the
  target concept can determine with certainty
  whether the version space is ?-exhausted.
• But, we can bound the probability that the
  version space will be ?-exhausted after a given
  number of training examples
• Without knowing the identity of the target
  concept
• Without knowing the distribution from which
  training examples were drawn

30
Theorem 7.1

• Theorem 7.1 ?-exhausting the version space. If
  the hypothesis space H is finite, D is a sequence
  of m ? 1 independent randomly drawn examples of
  some target concept c, then for any 0???1, the
  probability that the version space VSH,D is not
  ?-exhausted (with respect to c) is less than or
  equal to
• He-?m

31
Proof of theorem

• See text

32
Number of Training Examples (Eq. 7.2)
33
Summary of Result

• Inequality on previous slide provides a general
  bound on the number of trianing examples
  sufficient for any consistent learner to
  successfully learn any target concept in H, for
  any desired values of ? and ?.
• This number m of training examples is sufficient
  to assure that any consistent hypothesis will be
• probably (with probability 1-?)
• approximately (within error ?) correct.
• The value of m grows
• linearly with 1/?
• logarithmically with 1/?
• logarithmically with H
• The bound can be a substantial overestimate.

34
Problem

• Suppose we have the instance space described for
  the EnjoySports problem
• Sky (Sunny, Cloudy, Rainy)
• AirTemp (Warm, Cold)
• Humidity (Normal, High)
• Wind (Strong, Weak)
• Water (Warm, Cold)
• Forecast (Same, Change)
• Hypotheses can be as before
• (?, Warm, Normal, ?, ?, Same) (0, 0, 0, 0, 0,
  0)
• How many training examples do we need to have an
  error rate of less than 10 with a probability of
  95?

35
Limits of Equation 7.2

• Equation 7.2 tell us how many training examples
  suffice to ensure (with probability (1-?) that
  every hypothesis having 0 training error, will
  have a true error of at most ?.
• Problem there may be no hypothesis that is
  consistent with if the concept is not in H. In
  this case, we want the minimum error hypothesis.

36
Agnostic Learning and Inconsistent Hypotheses

• An Agnostic Learner does not make the assumption
  that the concept is contained in the hypothesis
  space.
• We may want to consider the hypothesis with the
  minimum error
• Can derive a bound similar to the previous one

37
Concepts that are PAC-Learnable

• Proofs that a type of concept is PAC-Learnable
  usually consist of two steps
• Show that each target concept in C can be learned
  from a polynomial number of training examples
• Show that the processing time per training
  example is also polynomially bounded

38
PAC Learnability of Conjunctions of Boolean
Literals

• Class C of target concepts described by
  conjunctions of boolean literals
• GUI_Present ? ?Opens_files
• Is C PAC learnable? Yes.
• Will prove by
• Showing that a polynomial of training examples
  is needed to learn each concept
• Demonstrate an algorithm that uses polynomial
  time per training example

39
Examples Needed to Learn Each Concept

• Consider a consistent learner that uses
  hypothesis space H C
• Compute number m of random training examples
  sufficient to ensure that L will, with
  probability (1 - ?), output a hypothesis with
  maximum error ?.
• We will use m ?(1/?)(lnHln(1/?))
• What is the size of the hypothesis space?

40
Complexity Per Example

• We just need to show that for some algorithm, we
  can spend a polynomial amount of time per
  training example.
• One way to do this is to give an algorithm.
• In this case, we can use Find-S as the learning
  algorithm.
• Find-S incrementally computes the most specific
  hypothesis consistent with each training example.
• Old ? Tired
• Old ? Happy
• Tired
• Old ? ?Tired -
• Rich ? Happy
• What is a bound on the time per example?

41
Theorem 7.2

• PAC-learnability of boolean conjunctions. The
  class C of conjunctions of boolean literals is
  PAC-learnable by the FIND-S algorithm using HC

42
Proof of Theorem 7.2

• Equation 7.4 shows that the sample complexity for
  this concept class id polynomial in n, 1/?, and
  1/?, and independent of size(c). To incrematally
  process each training example, the FIND-S
  algorithm requires effort linear in n and
  independent of 1/?, 1/?, and size(c). Therefore,
  this concept class is PAC-learnable by the FIND-S
  algorithm.

43
Interesting Results

• Unbiased learners are not PAC learnable because
  they require an exponential number of examples.
• K-term Disjunctive Normal Form is not PAC
  learnable
• K-term Conjunctive Normal Form is a superset of
  k-DNF, but it is PAC learnable

44
Sample Complexity with Infinite Hypothesis Spaces

• Two drawbacks to previous result
• It often does not give a very tight bound on the
  sample complexity
• It only applies to finite hypothesis spaces
• Vapnik-Chervonekis dimension of H (VC dimension)
• Will give tighter bounds
• Applies to many infinite hypothesis spaces.

45
Shattering a Set of Instances

• Consider a subset of instances S from the
  instance space X.
• Every hypothesis imposes dichotomies on S
• x?S h(x) 1
• x?S h(x) 0
• Given some instance space S, there are 2S
  possible dichotomies.
• The ability of H to shatter a set of concepts is
  a measure of its capacity to represent target
  concepts defined over these instances.

46
Shattering a Hypothesis Space

• Definition A set of instances S is shattered by
  hypothesis space H if and only if for every
  dichotomy of S there exists some hypothesis in H
  consistent with this dichotomy.

47
Vapnik-Chervonenkis Dimension

• Ability to shatter a set of instances is closely
  related to the inductive bias of the hypothesis
  space.
• An unbiased hypothesis space is one that shatters
  the instance space X.
• Sometimes H cannot be shattered, but a large
  subset of it can.

48
Vapnik-Chervonenkis Dimension

• Definition The Vapnik-Chervonenkis dimension,
  VC(H) of hypothesis space H defined over instance
  space X, is the size of the largest finite subset
  of X shattered by H. If arbitrarily large finite
  sets of X can be shattered by H, then VC(H) ?.

49
Shattered Instance Space
50
Example 1 of VC Dimension

• Instance space X is the set of real numbers X
  R.
• H is the set of intervals on the real number
  line. Form of H is
• a lt x lt b
• What is VC(H)?

51
Shattering the real number line
-1.2
3.4
6.7
What is VC(H)? What is H?
52
Example 2 of VC Dimension

• Set X of instances corresponding to numbers on
  the x,y plane
• H is the set of all linear decision surfaces
• What is VC(H)?

53
Shattering the x-y plane
2 instances
3 instances
VC(H) ? H ?
54
Proving limits on VC dimension

• If we find any set of instances of size d that
  can be shattered, then VC(H) ? d.
• To show that VC(H) lt d, we must show that no set
  of size d can be shattered.

55
General result for r dimensional space

• The VC dimension of linear decision surfaces in
  an r dimensional space is r1.

56
Example 3 of VC dimension

• Set X of instances are conjunctions of exactly
  three boolean literals
• young ? happy ? single
• H is the set of hypothesis described by a
  conjunction of up to 3 boolean literals.
• What is VC(H)?

57
Shattering conjunctions of literals

• Approach construct a set of instances of size 3
  that can be shattered. Let instance i have
  positive literal li and all other literals
  negative. Representation of instances that are
  conjunctions of literals l1, l2 and l3 as bit
  strings
• Instance1 100
• Instance2 010
• Instance3 001
• Construction of dichotomy To exclude an
  instance, add appropriate ?li to the hypothesis.
• Extend the argument to n literals.
• Can VC(H) be greater than n (number of literals)?

58
Sample Complexity and the VC dimension

• Can derive a new bound for the number of randomly
  drawn training examples that suffice to probably
  approximately learn a target concept (how many
  examples do we need to ?-exhaust the version
  space with probability (1-?)?)

59
Comparing the Bounds
60
Lower Bound on Sample Complexity

• Theorem 7.3 Lower bound on sample complexity.
  Consider any concept class C such that VC(C) ? 2,
  any learner L, and any 0 lt ? lt 1/8, and 0 lt ? lt
  1/100. Then there exists a distribution D and
  target concept in C such that if L observes fewer
  examples than
• Then with probability at least ?, L outputs a
  hypothesis h having errorD(h) gt ?.
