S2DB A Novel Simulation-Based Debugger for
Sensor Network Applications

• Ye Wen, Rich Wolski, Selim Gürün
• Department of Computer Science
• UC Santa Barbara
• EMSOFT2006

2
Sensor Networks

• Sensor networks
• An ad-hoc community of thousands of
  heterogeneous, resource
  constrained, tiny devices

Deployed in remote locations under extreme
conditions
Src Matt Welsh
Src Culler01
How can we debug an application on hundreds of
sensor nodes concurrently and realistically
without installing them in the field?
3
Outline

• Overview
• Other debugging methods
• Our approach S2DB
• Building blocks
• Debugging points
• Virtual instrumentation
• Coordinated break
• Time traveling
• Evaluation
• Summary and conclusion

4
Other Debugging Approaches

• JTAG
• Set breakpoints, step-execute program and query
  hardware
• Not possible to synchronize I/O and program
  execution
• Visualization tools
• Sympathy, SpyGlass, Surge Network Viewer,
  MoteView
• Display network topology and analyze the data
  flow
• Require a data collection agent on sensor node
• Simulation-based debuggers
• TOSSIM debugs the emulated code event-based
• ATEMU, Avrora, Emstar have similar concepts that
  we built on and extend in various ways

5
Simulation-based Sensor network debugger (S2DB)

• Base a scalable distributed sensor network
  simulator
• Fidelity cycle-accurate full-system simulation
  of sensor network applications
• Performance real-time speed for hundreds of
  sensor nodes
• Scalability simulate thousands of sensor nodes
  using cluster computer
• Novel debugging facilities for sensor network
• For single device debugging points for device
  state inspection virtual debugging hardware for
  software-controlled debugging
• For multiple devices coordinated break condition
  for parallel debugging
• For network time traveling for trace analysis

6
Internal Distributed Simulator Design

• Correct, faithful execution of AVR binaries
• Rich, complete hardware simulation
• Simple, effective radio synchronization protocol
• Automatic node partitioning

7
Debugging Points

• Conventional debuggers expose register, PC and
  memory
• S2DB operates on debugging points The access
  point to one of the internal states of the
  simulated machine
• The conventional debug points in S2DB

8
New Debugging Points

• Further debugging points for exposing the full
  system states
• Software defined events based on virtual
  debugging hardware
• Synthetic high-level system events, derived from
  the combination of simple events/states

9
Debug Points Setting and Executing

• Print a variable X
• gtprint mem( X )
• Break execution on erasing first page of flash

10
Debug Points Setting and Executing

• Print a variable X
• gtprint mem( X )
• Break execution on erasing first page of flash
• gtbreak when flash access( erase, 0x1 )

11
Debug Points Setting and Executing

• Print a variable X
• gtprint mem( X )
• Break execution on erasing first page of flash
• gtbreak when flash access( erase, 0x1 )
• Break execution when pc matches foo and a program
  variable Y is larger than 1

12
Debug Points Setting and Executing

• Print a variable X
• gtprint mem( X )
• Break execution on erasing first page of flash
• gtbreak when flash access( erase, 0x1 )
• Break execution when pc matches foo and a program
  variable Y is larger than 1
• gtbreak when pc() foo mem(Y)gt1

13
Debug Points Setting and Executing

• Print a variable X
• gtprint mem( X )
• Break execution on erasing first page of flash
• gtbreak when flash access( erase, 0x1 )
• Break execution when pc matches foo and a program
  variable Y is larger than 1
• gtbreak when pc() foo mem(Y)gt1

High Overhead
Lower Overhead
In a complex expression, we evaluate lower
overhead debug functions first to optimize
condition evaluation
14
Virtual Hardware Based Code Instrumentation

• Three virtual registers in reserved AVR address
  space Command, input, output
• Useful for injecting a print command into
  source code without going through serial port
• Allows custom debugging points e.g. To monitor
  nth execution of a function
• User sets debugger to monitor ID,VALUE
• User command writes ltid, valuegt to output
  register
• The debugger interrupts execution if id ID and
  value VALUE
• 3 register accesses total

15
Parallel Debugging

• Debugging single nodes is useful but not enough
  for distributed applications
• Many bugs emerge from the interactions between
  nodes
• E.g. packet delivery failures in network
  protocols and race conditions in distributed
  applications
• Goals
• Display the status of multiple devices in
  parallel
• Break the execution on multiple nodes
  simultaneously
• Step execute multiple devices at same pace
• These require clock synchronization
• Should be efficient and scalable

16
Partially Ordered Synchronization

• Partially ordered synchronization for the
  evaluation of coordinated break condition in
  distributed simulation
• One node acts as master
• Other nodes always follow the master, i.e. clocki
  lt clockmaster

17
Coordinated Break Condition

• Coordinated Break
• Simple breaks execution when all nodes clocks
  reach time T
• gt break when clock() T
• Conjunction of atomic conditions
• gt break when node1.cond1 nodeX.condY

18
Coordinated Break Condition

• Coordinated Break
• Simple breaks execution when all nodes clocks
  reach time T
• gt break when clock() T
• Conjunction of atomic conditions
• gt break when node1.cond1 nodeX.condY

• Limitation Arbitrary conditions (e.g.
  disjunction of atomic conditions)
• Constraints from distributed simulation structure
• Sacrifice generality for scalability and
  performance

19
Time Traveling

• Analyze anomaly using trace logs
• Replay events before and at the time of anomaly
• Periodic check-pointing saves simulated network
  state
• Snapshots of CPU, memory and hardware components
• Also Radio packet queue, receive/send queue,
  power status
• Small footprint 5KB size
• Flash is too large log-based snapshot
• Other mechanisms can be used to trigger a
  checkpoint
• Debugging points
• Break points

20
Debug Point Cost
Comparison of Debugging Point Cost
21
Coordinated Break Points
Coordinated break point condition with multiple
devices
Y-axis is the ratio to execution speed on real
device without condition monitoring
22
Checkpointing Overhead
Each curve represents a configuration. i.e, 4x1
running 1 host and 4 nodes per host
23
Conclusion and Summary

• S2DB contributions
• Debugging points
• Virtual debugging hardware
• Coordinated break condition for parallel
  debugging
• Time traveling for sensor network debugging
• The debugger overhead to simulation is less than
  10
• Ongoing work
• User interface
• Plug-in for Eclipse IDE
• We expect feedback from sensor network community
  to add new debugging features

24
Questions?
25
Stargate Simulation

• Xscale processor
• Arm v5TE instruction set with Xscale DSP
  extensions
• No thumb instruction set support yet
• MMU, GPIO, interrupt controller, real-time clock
• Flash memory
• Memory-mapped I/O
• State machine based on Intel Verilog model
• Estimate Flash latency using empirical data
• 802.11 Wireless card
• Serial interface
• Boots and runs Familiar Linux

26
Related Work

• Sensor Network Simulation
• ATEMU, Avrora
• Full system, multi-simulation, lock-step
  synchronization
• No sensor network gateway support
• EmTos
• A wrapper library for TOSSIM and EmStar
• All applications must be recompiled to host
  machine code and linked to EmTos
• Other Simulation
• Skyeye
• Full system ARM emulator including LCD and
  debugger
• Not intended for sensor networks and
  multi-simulation

27
Partially Ordered Synchronization
Peer Synchronization
Partially Ordered Synchronization
Y
Y
B
D
B
D
UPDATE
WAIT
UPDATE
master
A
X
C
A
X
E
C
WAIT
UPDATE
WAIT

• Peer synchronization used in the base simulator
• Synchronize only before a radio read, no order is
  enforced
• Partially ordered synchronization for the
  evaluation of coordinated break condition in
  distributed simulation
• One node acts as master
• Other nodes always follow the master, i.e. clocki
  lt clockmaster

28
Ensemble Synchronization

• Clock synchronization
• Execution rates of simulators should be
  proportional to real devices
• Lock-step method synchronize clocks on each
  serial byte transfer period
• Serial transfer rate 57.6 Kbits/seconds (128
  Mote cycles)
• Ensemble simulation requires clock
  synchronization to slowest simulation thread
• Stargate simulator is the bottleneck (most
  complex)
• Communication
• Packets assembled using receivers local clock
• Packet rate 19.2 Kbits/seconds

29
Debugging over Simulation

• Sensor network research requires substantial
  engineering, investment, and learning curve
• Configuring/installing network devices a hassle
• Many bugs not detected until run-time
• HW lacks user-interface, debugging requires HW
  modification
• Analyzing erroneous behavior not easy
• Hard to distinguish hardware faults from software
  bugs
• Simulation has significant advantages
• Provides a controlled environment
• Cost-effective solution
• - Not the same as real-life execution

30
S2DB Building Blocks

• S2DB spreads simulation into a computation
  cluster for scalability

Separate operating system threads on possibly
different machines
Clock synchronization only on network read from
another node
