Component-Level Dataflow Analysis

1
Component-Level Dataflow Analysis
Atanas (Nasko) Rountev Ohio State University
2
Outline

• Interprocedural dataflow analysis
• Whole-program analysis limitations
• Problem making dataflow analysis usable and
  useful for component-based software
• Technical challenges
• Ongoing and future work

3
Uses of Dataflow Analysis

• Software understanding tools
• e.g. dependence analysis for program slicing,
  change impact analysis, refactoring, etc.
• Software testing
• e.g. dataflow-based testing testing of object
  interactions in OO software
• Software checking
• e.g. object protocols open(readwrite)close
• Performance optimizations in compilers

4
Model for Whole-Program Analysis
code for C1
Whole Program Dataflow Analysis
dataflow solution for C1 C2 Cn
code for C2

code for Cn

• C1 C2 Cn constitute a complete program
• Implicit assumption it is possible and desirable
  to analyze the source code of the entire program
  as a single unit

5
Limitations of Whole-Program Analysis

• What if some of the components are only available
  in binary form?
• What if we are building a library?
• What if we are using large libraries that need to
  be re-analyzed from scratch?
• e.g. the standard Java libraries contain a few
  thousand classes
• What if one part of program changes?
• may have to re-analyze the entire program

6
Outline

• Interprocedural dataflow analysis
• Whole-program analysis limitations
• Problem making dataflow analysis usable and
  useful for component-based software
• Dozens of existing analyses could potentially
  become useful for component-based software
• In tools for software understanding, testing,
  checking, and optimization
• Technical challenges

7
A Simple Case Main Lib
Component Level Dataflow Analysis
dataflow solution for Lib
code for Lib
summary for Lib
Component Level Dataflow Analysis
code for Main
dataflow solution for Main
summary for Lib

• Goal the solution for Main should be as good as
  the solution that would have been computed by a
  whole-program analysis (no loss of precision)

8
Component Model and Summary Info

• Component set of related procedures or classes
• Component interactions synchronous calls, shared
  variables
• Challenge more sophisticated component models
• Summary information is computed based only on the
  source code of Lib
• Challenge use info from component specifications

9
Summary Functions
Main calls procedure Q
Main
Q
Summary function for Q fQ f1 ? f2 computed
by the analysis of Lib
Lib
path p1 dataflow function f1
path p2 dataflow function f2
10
Open Questions

• Challenge compact representation of dataflow
  functions and their transitive composition and
  meet
• Existing work solves this problem for some
  analysis categories need generalizations
• Challenge callbacks
• e.g., function pointers in C
• e.g., virtual dispatch in C and Java
• Fundamental problem, not addressed adequately by
  existing work

11
Callbacks
Main calls procedure Q during the call, Lib
calls R
Main
R
Q
Lib
The function for p2 cannot be computed until Main
is analyzed
Solution summary functions for
subpaths, computed during the analysis of
Lib Later, compose them with the functions from
Main
12
Ongoing Work

• Goal 1 (achieved) theoretical model for
  computing and using summary functions in the
  presence of callbacks
• Goal 2 (ongoing) instantiate the model to common
  categories of analyses
• dependence analysis, pointer analysis, etc.
• Goal 3 experimental evaluation
• e.g. how large are the summaries?
• Eclipse plug-in for call graph construction
  needs summary info for all Java 1.4 libraries

13
Future Work

• Beyond the traditional restrictions
• Use not only code, but also component
  specifications e.g., sharpen the summary
  functions based on preconditions
• Higher-level of abstraction for component
  interfaces and interactions
• Right now low-level mechanisms such as procedure
  calls and shared variables
• Extensive experimental evaluation on real-world
  software systems
