NETWORKS 2: 090920201

1
CHAPTER 14

• NETWORKS 2 0909202-01
• 16 November 2005 Lecture 7
• ROWAN UNIVERSITY
• College of Engineering
• Dr Peter Mark Jansson, PP PE
• DEPARTMENT OF ELECTRICAL COMPUTER ENGINEERING
• Autumn Semester 2005 Quarter Two

2
Chapter 14 key concepts

• Todays learning objectives
• Review HW problems section 11.4 (1,24)
• information society
• review the Laplace L transform method
• applicability, benefits, properties
• impulse function, time delay, freq. shift
• inverse Laplace transform L-1
• solution of diff. eqns. with Laplace
• transfer function

3
Information Society Electrical Communication
4
Figure 14.3-1 The transform method.
5
Laplace applicability

• first we learned methods that worked for
• dc circuits
• sinusoidal sources
• now we consider a method that works for sources
  of many more forms
• step functions (dc and other), and/or
• exponentials (dc and other), and/or
• sinusoidal sources
• the Laplace transform applies for all signals
  that are zero when t lt 0.
• i.e, where Lf(t) f(t) 0 when t lt 0

6
Benefits of Laplace

• all functions of time f(t) that are physically
  possible always have a Laplace transform
• the Laplace transform is unique for every unique
  f(t) function
• the Laplace transform is linear
• the Laplace has an inverse transform
• all calculations can become algebra for solution
  in the frequency - F(s) - domain
• Laplace tables simplify our calculations
• clear applicability in the information age

7
example 1

• Find the Laplace transform L of the following
  f(t) e-2t sin t

Write LC1 for equation above
8
impulse and time delay

• an impulse is a pulse of infinite amplitude for
  an infinitesimal time whose area is finite
• the Laplace transform L of an impulse function
  is 1

9
impulse and time delay

• the Laplace of a time delay ?
• f(t- ?) is L f(t- ?)u(t- ? ) e-s? F(s)
• Where F(s) L u(t) 1/s

10
example 2

• Find the Laplace transform of the following
  product of a step function and time delay f(t)
  Au(t- ?)

If the time delay was 5 seconds and amplitude of
the step function was 3, write the Laplace as
LC2
11
frequency shift property

• the Laplace of e-at f(t) yields another very
  helpful formula
• L e-at f(t) F (s a)
• An example is where f(t) sin ?t
• Since L sin ?t ? /(s2 ?2 )
• L e-at sin ?t ? /((sa)2 ?2 )

12
example 3

• Find the Laplace transform of the following
  product of an exponential function and time
  delay
• g(t) e-4t u(t-3)

13
example 3
First from the time delay property we find
And from the frequency shift property we find
Simplify this expression and write the Laplace as
LC3
14
Learning Check 4

• using the linearity property and the frequency
  shift property find
• L 6u(t) 5e-8tu(t)

15
Inverse Laplace Transform

• critical to the LaPlace method is the existence
  of an inverse transform.
• it is remarkably straight-forward
• f(t) L -1 F(s)
• If F(s) 8/s 4/(s5) 12/(s216)
• what is f(t)?

16
Inverse Laplace Transform

• it is remarkably straight-forward
• f(t) L -1 F(s)
• L -1 8/s 4/(s5) 12/(s216)
• L -18/s L 14/(s5) L -1 12/(s216)
• 8 4e-5t LC5

17
Do you remember Partial Fraction Expansion?
To find A, multiply through by its denominator
18
Partial Fraction Expansion explained
Choose a value of s so the denominator goes to
zero (in our case 1), consequently A 2
19
Partial Fraction Expansion explained

• Solve for B
• Multiply all terms by Bs denominator
• Choose a value of s so that Bs denominator goes
  to zero,
• Solve for B LC6

20
Another useful relationship explained transforms
with complex poles
21
Lets solve an example of an inverse transform
with complex poles
f(t) L -1 F(s)
Any idea how we can get it in this form?
22
Lets go its quite easy really
Now can you see it in this form?
What is a? what is c? what is ?? Solve for d as
LC7
23
And now the final step - the inverse transform
f(t) L -1 F(s)
Solve for f(t) as LC8
24
Solutions of circuit problems with diff eqs via
Laplace
General method

• Identify the circuit variables
• Write the diff eqs and i.d. initial conditions
• Obtain Laplace Transform for all terms
• Solve for unknown variables in s-domain
• Obtain the inverse Laplace for solution in the
  time domain

25
example 4
v1 -
i1(t) 7 e6t A for t gt 0, i(0) 0
26
midterm examination review

• 30 of final Net II grade
• covers Chapters 10 and 11
• through section 11.8
• study helps Lectures 1-7 sample problems and
  learning checks
• homework problems in assn. 1 - 3

27
midterm examination review - continued

• key concepts
• history of electric power (10.2, 11.2)
• sinusoidal sources (10.3 10.7)
• developing/interpreting the equations phase
  angle
• complex forcing functions
• phasors (frequency time domains)
• complex numbers (apps. B C)
• rectangular, exponential and polar notation
• trigonometric identities
• impedance and admittance (10.8)
• KCL, KVL, etc. (10.9 10.11)
• phasor diagrams (10.12)

28
midterm examination review - continued

• key concepts
• instantaneous power (11.3)
• real (average) power (11.3, 11.5)
• effective value of periodic waveforms (11.4)
• root-mean-square
• complex power (11.5)
• complex, apparent, real, and imaginary power
• more detail on frequency and time domain
• power factor (11.6)
• leading and lagging power factor, pf phase angle
• maximum power transfer (11.8)

29
midterm examination review sample problems

• key concepts
• LaPlace Transform
• Why Use LaPlace?
• How to use LaPlace
