Controlling concurrency

1
Controlling concurrency

• A look at some techniques for process
  synchronization in the Linux environmemt

2
What is a race condition ?

• Without any synchronization mechanism,
  multiprogramming is vulnerable to races in
  which programs produce unpredictable and
  erroneous results, due to the relative timing of
  instruction-execution in separate threads or
  processes
• An example program demonstrates this phenomenon
  (see our racedemo.cpp)

3
Two tasks write to one terminal

• A parent-process forks a child-process, and both
  write messages to the screen, but without
  coordinating their efforts
• The operating systems task-scheduler repeatedly
  preempts each of them
• The result is incomprehensible gibberish!
• Programs like this one are said to contain a
  race condition

4
The cure is communication

• Whats needed is some way for the tasks to be
  made aware of each others actions
• Various mechanisms for this exist in Linux
• One of the simplest ways is by signaling (i.e.,
  one task can wait for an all clear signal to be
  sent to it by the other task)
• But busy-waiting needs to be avoided, since it
  wastes CPU time and degrades the overall
  efficiency of the system

5
The signal mask

• Each process has a signal mask that can be used
  to block certain specific signals
• The signal mask for each process is kept in its
  process control block (in the kernel)
• But a process can inspect and modify its signal
  mask by using special system-calls

6
The sigset_t type
struct task_struct
Process Control Block
The signal mask is a collection of flag-bits that
indicates which signals are to be blocked
sigset_t
blocked
7
How to inspect signal mask

• 1. Include the ltsignal.hgt header-file
• include ltsignal.hgt
• 2. Declare a sigset_t object
• sigset_t sigmask
• 3. Call the sigprocmask() library-function
  sigprocmask( 0, NULL, sigmask )

8
How to modify signal mask

• 1. Declare two sigset_t objects
• sigset_t nset, oset
• 2. Initialize the new signal-set
• sigemptyset( nset )
• sigaddset( nset, SIGUSR1 )
• sigaddset( nset, SIGUSR2 )
• 3. Call the sigprocmask() library-function
• sigprocmask( SIG_BLOCK, nset, oset )

9
How to wait for a signal

• 1. Declare and initialize a global variable
• int done 0
• 2 Define your signal-handling function
• void upon_signal( int signum ) done 1 .
• 3. Install your signal-handler function
• signal( SIGUSR1, upon_signal )
• signal( SIGUSR2, upon_signal )
• 4. Declare and initialize a sigset_t object
• sigset_t zeromask
• sigemptyset( zeromask )
• 5. Then use sigsuspend() to wait for your
  signal
• while ( done 0 ) sigsuspend( zeromask )

10
Our racecure.cpp demo

• These signal-handling library-functions are used
  by this demo-program to remove the race
  condition without doing busy-waiting
• Its based on ideas of W. Richard Stevens from
  his classic Advanced Programming in the UNIX
  Environment (1993).

11
How it works
parent-process
child-process
done
done
signal-handler
signal-handler
write-message TELL_CHILD WAIT_CHILD
WAIT_PARENT write-message TELL_PARENT
SIGUSR1
SIGUSR2
user
kernel
signal-mask
signal-mask
12
In-class exercises

• Modify racedemo so that the parent forks twice
  (i.e., two child-processes), with three processes
  all writing to the stdout stream
• Then add synchronization functions which will
  eliminate the race conditions and allow the
  parent-process to finish writing before either of
  the child-processes begins
