Using Problem Structure for Efficient Clause Learning

1
Using Problem Structure for Efficient Clause
Learning

• Ashish Sabharwal, Paul Beame, Henry Kautz
• University of Washington, Seattle
• April 23, 2003

2
The SAT Approach
CNF encoding f
SAT solver
Input p 2 D
p Instance D Domain graph problem,
AI planning, model checking
f ? SAT
f ? SAT
p bad
p good
3
Key Facts

• Problem instances typically have structure
• Graphs, precedence relations, cause and effects
• Translation to CNF flattens this structure
• Best complete SAT solvers are
• DPLL based clause learners branch and backtrack
• Critical Variable order used for branching

4
Natural Questions

• Can we extract structure efficiently?
• In translation to CNF formula itself
• From CNF formula
• From higher level description
• How can we exploit this auxiliary information?
• Tweak SAT solver for each domain
• Tweak SAT solver to use general guidance

5
Our Approach
CNF encoding f
Branching sequence
SAT solver
Input p 2 D
f ? SAT
f ? SAT
Encode structure as branching sequence
p bad
p good
6
Related Work

• Exploiting structure in CNF formula
• GMT02 Dependent variables
• OGMS02 LSAT (blocked/redundant clauses)
• B01 Binary clauses
• AM00 Partition-based reasoning
• Exploiting domain knowledge
• S00 Model checking
• KS96 Planning (cause vars / effect vars)

7
Our Result, Informally
Given a pebbling graph G, can efficiently
generate a branching sequence BG that
dramatically improves the performance of current
best SAT solvers on fG.

• Structure can be efficiently retrieved from
  highlevel description (pebbling graph)
• Branching sequence as auxiliary information can
  be easily exploited

8
Preliminaries CNF Formula
Conjunction of clauses
f (x1 OR x2 OR x9) AND (x3 OR x9)
AND (x1 OR x4 OR x5 OR x6)
9
Preliminaries DPLL

• DPLL(CNF formula f)
• Simplify(f)
• If (conflict) return UNSAT
• If (all-vars-assigned) return SAT
  assignment exit
• Pick unassigned variable x
• Try DPLL(f x0), DPLL(f x1)

10
Prelim Clause Learning

• DPLL Change if (conflict) return
  UNSATto if (conflict)
  learn conflict clause return UNSAT

x2 1, x3 0, x6 0 ) conflict
Learn (x2 OR x3 OR x6)
11
Prelim Branching Sequence

• B (x1, x4, x3, x1, x8, x2, x4, x7, x1, x2)
• DPLL Change Pick unassigned var
  xto Pick next literal x from B
  delete it from B if x already assigned,
  repeat
• How good is B?
• Depends on backtracking process, learning scheme

Different from branching order
12
Prelim Pebbling Formulas
Node E is pebbled if(e1 OR e2) 1
fG Pebbling(G) Source axioms A, B, C are
pebbled Pebbling axioms A and B are pebbled
) E is pebbled Target axioms T is not
pebbled
Target(s)
(t1 OR t2)
T
(e1 OR e2)
E
F
(f1)
A
B
C
(c1 OR c2 OR c3)
(a1 OR a2)
(b1 OR b2)
Sources
13
Prelim Pebbling Formulas

• Can have
• Multiple targets
• Unbounded fanin
• Large clause labels
• Pebbling(G) is unsatisfiable
• Removing any clause from subgraph of each target
  makes it satisfiable

14
Grid vs. Randomized Pebbling
(n1 ? n2)
m1
(t1 ? t2)
l1
(h1 ? h2)
(h1 ? h2)
(i1 ? i2)
(i1 ? i2 ? i3 ? i4)
e1
f1
(e1 ? e2)
(g1 ? g2)
(f1 ? f2)
(d1 ? d2 ? d3)
(g1 ? g2)
(a1 ? a2)
(b1 ? b2)
(c1 ? c2)
(d1 ? d2)
(a1 ? a2)
b1
(c1 ? c2 ? c3)
15
Why Pebbling?

• Practically useful
• precedence relations in tasks, fault propagation
  in circuits, restricted planning problems
• Theoretically interesting
• Used earlier for separating proof complexity
  classes
• Easy to analyze
• Hard for current best SAT solvers like zChaff
• Shown by our experiments

16
Our Result, Again
Given a pebbling graph G, can efficiently
generate a branching sequence BG such that
zChaff(fG, BG) is empirically exponentially
faster than zChaff(fG).

• Efficient Q(fG)
• zChaff One of the current best SAT solvers

17
The Algorithm

• Input
• Pebbling graph G
• Output
• Branching sequence BG, BG Q(fG), that
  works well for 1UIP learning scheme and fast
  backtrackingfG CNF encoding of pebbling(G)

18
The Algorithm GenSeq(G)

• Compute node heights
• Foreach u 2 unit clause labeled nodes bottom up
• Add u to G.sources
• GenSubseq(u)
• Foreach t 2 targets bottom up
• GenSubseq(t)

19
The Algorithm GenSubseq(v)

• // trivial wrapper
• If (v.preds gt 0)
• GenSubseq(v, v.preds)

20
The Algorithm GenSubseq(v, i)

• u v.predsi // by increasing
  height
• if i1 // lowest pred
• GenSubseq(u) if unvisited non-source
• return
• Output u.labels // higher pred
• GenSubseq(u) if unvisitedHigh non-source
• GenSubseq(v, i-1) // recurse on i-1
• GenPattern(u, v, i-1) // repetitive pattern

21
Results Grid Pebbling

• Pure DPLL upto 60 variables
• DPLL upto 60 variablesbranching seq
• Clause learning upto 4,000 variables(original
  zChaff)
• Clause learning upto 2,000,000 variables
  branching seq

22
Results Randomized Pebl.

• Pure DPLL upto 35 variables
• DPLL upto 50 variablesbranching seq
• Clause learning upto 350 variables(original
  zChaff)
• Clause learning upto 1,000,000 variables
  branching seq

23
Summary

• High level problem description is useful
• Domain knowledge can help SAT solvers
• Branching sequence
• One good way to encode structure
• Pebbling problems Proof of concept
• Can efficiently generate good branching sequence
• Structure use improves performance dramatically

24
Open Problems

• Other domains?
• STRIPS planning problems (layered structure)
• Bounded model checking
• Variable ordering strategies from BDDs?
• Other ways of exploiting structure?
• branching order
• something to guide learning?
• Domain-based tweaking of SAT algorithms
