Mobile Calculi

1
Mobile Calculi
for Distributed Programming

• Catuscia Palamidessi, INRIA Futurs, France
• joint work with
• Mihaela Herescu, IBM, Austin

2
Mobile calculi

• The p calculus
• Milner, Parrow, Walker 89
• CCS Mobility of links
• Dynamic reconfiguration of the communication
  structure

3
Mobile Calculi

• The asynchonous p calc Honda-Tokoro92, Boudol
  91
• Action Calculi Milner, early 90
• The Fusion calculus Parrow, Victor, early 90
• Join Calculus Fournet, Gonthier, Levy, 96
• Related calculi
• Mobile Ambients Cardelli, Gordon 97
• The seal calculus Castagna, Vitek, mid 90
• Boxed Ambients Bugliesi, Castagna, Crafa, late
  90
• The spi calculus Abadi, Gordon, mid 90
• a calculus for specification and verification of
  security protocols
• based on the p calculus

4
The p calculus

• Basic constructs to expess parallelism,
  communication, choice, generation of new names
  (which can be communicated and in turn used as
  channels), scope
• Scope extrusion a name can be communicated and
  its scope extended to include the recipient

Q
z
z
x
y
R
P
z
5
Expressive Power of p

• link mobility
• network reconfiguration
• express HO (e.g. l calculus) in a natural way
• mixed choice
• solution to distributed problems involving
  distributed agreement

6
The expressive power of p

• Example of distributed agreement
• the leader election problem
• A symmetric and fully distributed solution in p
• x.Pwins y.Ploses y.Qwins x.Qloses

t? Ploses Qwins
t? Pwins Qloses
7
p the p calculus (w/ mixed choice)

• Syntax
• g x(y) xy t prefixes (input, output,
  silent)
• P Si gi . Pi mixed guarded choice
• P P parallel
• (x) P new name
• recA P recursion
• A procedure name

8
Operational semantics

• Transition system P -a? Q
• Rules
• Choice Si gi . Pi gi? Pi
• P -xy? P
• Open ___________________
• (y) P -x(y)? P

9
Operational semantics

• Rules (continued)
• P -x(y)? P Q
  -xz? Q
• Com ________________________
• P Q -t? P z/y Q
• P -x(y)? P
  Q -x(z)? Q
• Close _________________________
• P Q -t? (z) (P z/y
  Q)
• P -g? P
• Par _________________ f(Q) and
  b(g) disjoint
• Q P -g? Q P

10
Implementation issues

• It is well known that formalisms able to express
  distributed agreement are difficult to implement
  in a distributed fashion
• For this reason, the field has evolved towards
  asynchronous variants of p or other asynchronous
  formalisms
• for instance, the asynchronous p calculus
  Honda-Tokoro92, Boudol, 92

11
pa the Asynchonous p

• Syntax
• g x(y) t prefixes
• P Si gi . Pi input guarded choice
• xy output action
• P P parallel
• (x) P new name
• recA P recursion
• A procedure name

12
Operational semantics of pa

• Additional rule
• Out xy xy? 0
• Asynchronous communication
• we cant write a continuation after an output,
• i.e. no xy.P, but only xy P
• so P will proceed without waiting for the actual
  delivery of the message
• Note the original pa did not contain a choice
  construct. However the version presented here was
  shown expressively equivalent to the original pa
  by Nestmann and Pierce, 96

13
p vs. pa

• pa is suitable for distributed implementation,
• in contrast to p
• However, despite the difficulties regarding
  implementation, the p calculus is still very
  appealing, because of its superior expressive
  power
• Examples of problems that can be solved in p and
  not in pa
• dining philosophers ( following Francez and
  Rodeh, 82 )
• the symmetric leader election problem , for any
  ring of processes
• The solution uses name mobility to fully connect
  the graph, and then mixed choice to break the
  symmetry.
• This problem cannot be solved in pa , nor in CCS
  Palamidessi 97

14
Towards a fully distributed implementation of p

• The results of previous pages show that a fully
  distributed implementation of p must necessarily
  be randomized
• A two-steps approach

p
Advantages the correctness proof is easier
since (which is the difficult part of the
implementation) is between two similar languages

probabilistic asynchronous p
ltlt gtgt
distributed machine
15
ppa the Probabilistic Asynchonous p

• Syntax
• g x(y) t prefixes
• P Si pi gi . Pi pr. inp. guard. choice
  Si pi 1
• xy output action
• P P parallel
• (x) P new name
• recA P recursion
• A procedure name

16
The operational semantics of ppa

• Based on the Probabilistic Automata of Segala and
  Lynch
• Distinction between
• nondeterministic behavior (choice of the
  scheduler) and
• probabilistic behavior (choice of the process)

Scheduling Policy The scheduler chooses the
group of transitions
Execution The process chooses probabilistically
the transition within the group
17
The operational semantics of ppa

• Representation of a group of transition
• P --gi-gt pi Pi i
• Rules
• Choice Si pi gi . Pi --gi-gt pi Pi i
• P --gi-gt piPi i
• Par ____________________
• Q P --gi-gt piQ Pi i

18
The operational semantics of ppa

• Rules (continued)
• P --xi(yi)-gt piPi i Q --xz-gt 1 Q
  i
• Com ____________________________________
• P Q --t-gt piPiz/yi Q xix U
  --xi(yi)-gt pi Pi Q xi/x
• P --xi(yi)-gt piPi i
• Res ___________________ qi renormalized
• (x) P --xi(yi)-gt qi (x) Pi xi / x

19
Implementation of ppa

• Compilation in Java ltlt gtgt ppa ? Java
• Distributed
• ltlt P Q gtgt ltlt P gtgt.start() ltlt Q gtgt.start()

• Compositional
• ltlt P op Q gtgt ltlt P gtgt jop ltlt Q gtgt for all
  op
• Channels are one-position buffers with
  test-and-set (synchronized) methods for input and
  output
• The probabilistic input guarded construct is
  implemented as a while loop in which channels to
  be tried are selected according to their
  probability. The loop repeats until an input is
  successful

20
Encoding p into ppa

• p ? ppa
• Fully distributed
• P Q P Q
• Uniform
• P s P s
• Correct wrt a notion of probabilistic testing
  semantics
• P must O iff P must O with
  prob 1

21
Encoding p into ppa

• Idea
• Every mixed choice is translated into a parallel
  comp. of processes corresponding to the branches,
  plus a lock f
• The input processes compete for acquiring both
  its own lock and the lock of the partner
• The input process which succeeds first,
  establishes the communication. The other
  alternatives are discarded

f
Pi
P
R
f
Ri
Qi
Ri
Q
S
f
Si
f
The problem is reduced to a generalized dining
philosophers problem where each fork (lock) can
be adjacent to more than two philosophers Further,
we can reduce the generalized DP to the classic
case, and then apply the algorithm of Lehmann and
Rabin
22
Dining Philosophers classic case

• Each fork is shared by exactly two philosophers

23
Dining Philosophers, classic case

• The requirements on the encoding p ? ppa imply
  symmetry and full distribution
• There are many solution to the DP problem, but in
  order to be symmetric and fully distributed a
  solution has necessarily to be randomized.
• Proved by Lehmann and Rabin 81 - They also
  provided a randomized algorithm (for the classic
  case)
• Note that the DP problem can be solved in p in a
  fully distributed, symmetric way. Hence the need
  for randomization is not a characteristic of our
  approach it would arise in any encoding of p
  into an asynchronous language.

24
The algorithm of Lehmann and Rabin

1. Think
2. choose first_fork in left,right commit
3. if taken(first_fork) then goto 3
4. take(first_fork)
5. if taken(first_fork) then goto 2
6. take(second_fork)
7. eat
8. release(second_fork)
9. release(first_fork)
10. goto 1

25
Dining Phils generalized case
Each fork can be shared by more than two
philosophers
Reduction to the classic case each fork is
initially associated with a token. Each phil
needs to acquire a token in order to participate
to the competition. The competing phils determine
a set of subgraphs in which each subgraph
contains at most one cycle
26
Generalized philosophers

• Another problem we had to face the solution of
  Lehmann and Rabin works only for fair
  schedulers, while ppa does not provide any
  guarantee of fairness
• Fortunately, it turns out that the fairness is
  required only in order to avoid a busy-waiting
  livelock at instruction 3. If we replace
  busy-waiting with suspension, then the algorithm
  works for any scheduler
• This result was achieved independently also by
  Fribourg et al, TCS 2002

27
The algorithm of Lehmann and Rabin
The algorithm of Lehmann and RabinModified so to
avoid the need for fairness

1. Think
2. choose first_fork in left,right commit
3. if taken(first_fork) then wait
4. take(first_fork)
5. if taken(first_fork) then goto 2
6. take(second_fork)
7. eat
8. release(second_fork)
9. release(first_fork)
10. goto 1

1. Think
2. choose first_fork in left,right commit
3. if taken(first_fork) then goto 3
4. take(first_fork)
5. if taken(first_fork) then goto 2
6. take(second_fork)
7. eat
8. release(second_fork)
9. release(first_fork)
10. goto 1

28
Conclusion

• We have provided an encoding of the
• p calculus into its asynchronous fragment,
  enriched with probabilities
• fully distributed
• compositional
• correct wrt a notion of testing semantics
• Advantages
• high-level solutions to distributed algorithms
• Easier to prove correct (no reasoning about
  randomization required)

29
Future work Application of ppa to Security
protocols

• Propis a small language based on ppa to express
  and verify security protocols and their
  properties, like
• Secrecy
• messages, keys, etc. remain secret
• Authentication
• guarantees about the parties involved in the
  protocol
• Non-repudiation
• evidence of the involvement of the other party
• Anonymity
• protecting the identity of agents wrt particular
  events
• Formal tools for automatic verification

30
Features of PROPIS

• PRObabilistic PI for Security
• ppa enriched with cryptographic primitives
  similar to those of the spi-calculus Abadi and
  Gordon
• The probability features will allow to analyse
  security protocols at a finer level
  (cryptographic level), i.e. beyond the Dolew-Yao
  assumptions In our approach an attacker can
  guess a key. The point is to prove that the
  probability that it actually guess the right key
  is negligible.
• The probability features will also allow to
  express protocols that require randomization.

31
Example The dining cryptographers
An example of achieving anonymity
Crypt(0)
pays0
notpays0
Master
Crypt(1)
Crypt(2)
32
The dining cryptographers

• The Problem
• Three cryptographers share a meal
• The meal is paid either by the organization
  (master) or by one of them. The master decides
  who pays
• Each of the cryptographers is informed by the
  master whether or not he is paying
• GOAL
• The cryptographers would like to know whether the
  meal is being paid by the master or by one of
  them, but without knowing who is paying (if it is
  one of them).

33
The dining cryptographers Solution

• Solution Each cryptographer tosses a coin
  (probabilistic choice). Each coin is in between
  two cryptographers.
• The result of each coin-tossing is visible to the
  adjacent cryptographers, and only to them.
• Each cryptographer examines the two adjacent
  coins
• If he is paying, he announces agree if the
  results are the same, and disagree otherwise.
• If he is not paying, he says the opposite
• Claim 1 if the number of disagree is even,
  then the master is paying. Otherwise, one of them
  is paying.
• Claim 2 In the latter case, if the coin is fair
  the non paying cryptographers will not be able to
  deduce whom exactly is paying

34
The dining cryptographers Solution
Crypt(0)
pays0
notpays0
Coin(0)
Coin(1)
look20
Master
out1
Crypt(1)
Crypt(2)
Coin(2)
