Statistical decisionmaking with two or more means

1
Statistical decision-making with two or more means
2
Hypothesis testing with two or more means

• Why a new statistical test?
• Analysis of variance theory
• F ratio
• Breakdown of sums of squares and degrees of
  freedom
• Hypothesis testing with ANOVA
• Independent samples ANOVA table
• Dependent samples ANOVA table
• Which means are different from which Tukeys
  HSD.

3
Testing two or more means why a new test?

• Why test more than two means?
• Efficiently test multiple levels of one IV (dose
  effects, etc)
• Examine the effects of more than one IV
• Why not use lots of t-tests?
• With every single t-test, p(Type I error) lt .05
• With two t-tests, you risk a Type I error on one
  or the other.
• Multiple t-tests cause the p(Type I error) to go
  over .05!
• Need a test that can compare all means in a study
  while holding p(Type I error) to lt .05 ANOVA and
  the F test!

4
A preliminary look at ANOVA and the F ratio

• ANOVA Analysis of variance.
• Used for testing the differences between 2 or
  more (up to k) means.
• H0 m1 m2 m3 mk
• HA m1 m2 m3 mk
• Statistic is the F ratio made up of two separate
  estimates of s
• Variance between the sample means numerator
• (between groups variance).
• Mean of the sample variances denominator.
• (within groups variance)
• When H0 is true, F ratio is close to 1 (because
  BGvar WGvar)
• When HA is true F ratio gets bigger than 1
  (because BGvar gt WGvar)

5
A preliminary look at ANOVA and the F ratio

• ANOVA Analysis of variance.
• Used for testing the differences between 2 or
  more (k) means.
• H0 m1 m2 m3 mk
• HA m1 m2 m3 mk
• Statistic is the F ratio made up of two separate
  estimates of s
• Variance between the sample means numerator
• (between groups variance).
• Mean of the sample variances denominator.
• (within groups variance)
• When H0 is true, F ratio is between 0 and 1
  (because BGvar WGvar)
• When HA is true F ratio gets bigger than 1
  (because BGvar gt WGvar)

6
ANOVA for independent samples example and theory

• Consider the following example You have a
  medication that you think adds points to peoples
  IQ scores. You ask 9 people to agree to
  participate in an experiment where 3 will get
  placebo, 3 will get one dose of the medication
  and 3 will get a double dose of the medication.
  You reason that, if the medication has no effect
  on IQ (H0 is true) the means of the three groups
  IQ scores should be equal (m1 m2 m3) but if
  the medication does have an effect on IQ scores
  (HA is true), the means of the three groups IQ
  scores for the should not be equal (m1 m2
  m3).
• Lets look at some possible data that you might
  expect under the two hypotheses, H0 and HA.
• Please note This example uses a small sample
  size for pedagogical purposes the sample size
  described above for is way too low to be
  realistic (i.e., it is an underpowered experiment
  as described)!

7
Sample data if H0 is true.
8
Sample data if H0 is true.
Variance of means ?
Mean of variances ?
Variance of means n Between group
variance F or Mean of variances
Within group variance
9
Sample data if H0 is true.
Variance of means 0
Mean of variances (1 1 1)/3
Variance of means n Between group
variance 0 F or or 0
Mean of variances Within group variance
1
10
Small values of F are a dime a dozen, big values
are rare!
Rejection Region (actual critical value based on
degrees of freedom)
11
Sample data if HA is true.
12
Sample data if H0 is true.
Variance of means ?
Mean of variances ?
Variance of means n Between group
variance F or Mean of variances
Within group variance
13
Sample data if H0 is true.
Variance of means 25
Mean of variances (1 1 1)/3
Variance of means n Between group
variance 75 F or or 75
Mean of variances Within group
variance 1
14
Small values of F are a dime a dozen, big values
are rare!
Rejection Region (actual critical value based on
degrees of freedom)
15
So . . .

• Statistic is the F ratio made up of two separate
  estimates of s
• Variance between the sample means numerator
• (between groups variance).
• Mean of the sample variances denominator.
• (within groups variance)
• When H0 is true, F ratio is between 0 and 1
  (because BGvar WGvar)
• When HA is true F ratio gets bigger than 1
  (because BGvar gt WGvar)

16
Hypothesis testing with two or more means

• Why a new statistical test? To maintain p(Type I
  error) lt .05 when testing more than two means?
• Analysis of variance theory
• F ratio BGvar/WGvar when HA is true, numerator
  goes up, denominator stays the same.
• Breakdown of sums of squares and degrees of
  freedom
• Hypothesis testing with ANOVA
• Independent samples ANOVA table
• Dependent samples ANOVA table
• Which means are different from which Tukeys
  HSD.

17
Breakdown of SS and df for independent ANOVA

• Quick review variance of any group of scores is
  SS/df
• or S(X-X)2/N-1
• In ANOVA, there are multiple variance estimates,
  so there are multiple SS and df
• There is the total SS (SST), when all scores are
  treated as one big group of numbers, and a
  corresponding total df (N-1)
• There is the between groups SS (SSB), concerned
  only with the means of each group, it also has a
  df (k-1)
• There is the within groups SS (SSW), concerned
  with data within each group, it also has a df
  (N-k).

18
Sample data if HA is true.
SST (104-110)2 (105-110)2 (106-110)2
(109-110)2 (110-110)2 (111-110)2
(114-110)2 (115-110)2 (116-110)2
156
SST The sum of the square of each score
subtracted from the grand mean dfT N-1 Total
variance is then SST/dfT 156/8 19.5
19
Breakdown of SS and df for independent ANOVA
Generally
SST
dfT N-1
SSB
SSW
dfB k-1
dfW N-k
Observed F ratio BGvar/WGvar
(SSB/dfB)/(SSW/dfW)
Different subjects in different groups.
20
Breakdown of SS and df for independent ANOVA
Generally
SST
dfT
SSB
SSW
dfB
dfW
Observed F ratio BGvar/WGvar
(SSB/dfB)/(SSW/dfW)
For our example
SST 156
dfT 8
SSB 150
SSW 6
dfB 2
dfW 6
F ratio BGvar/WGvar (150/2)/(6/6) 75/1 75.0
21
All that information can be put into a table
Typical one-factor, independent groups ANOVA
table
Aka Mean Squared or MS
Source SS df s2 Fobt Between
Groups 150.0 2 75.0 75.0 Within groups
6.0 6 1.0 Total 156.0 8
Is the probability of obtaining an F of 75 lt
.05? As with t test, need to use degrees of
freedom and a table (Table F)
22
All that information can be put into a table
Typical one-factor, independent groups ANOVA
table
Source SS df s2 Fobt p Between
Groups 150.0 2 75.0 75.0 lt .01 Within groups
6.0 6 1.0 Total 156.0 8
Plt.05
Plt.01
Is the probability of obtaining an F of 75 lt .05?
Yes Fobt(2,6) 75, which is greater than
Fcrit (2,6) 5.14 or 10.92 Therefore, reject
H0!
23
Sample test problem independent ANOVA

• An educational psychologist was interested in the
  spelling performance of children at different
  grade levels in her school district. She
  randomly selects a sample of 6 children from each
  of grades 2, 4, 6, and 8 in her school district.
  She gives the 24 children a 20-word spelling test
  and counts the number of spelling errors made.
  Using the information below, help her determine
  if spelling ability is or is not equal among the
  grade levels.

Source SS df s2 Fobt p Between Groups
82.83 Within groups
Total 157.83
X2 12.17, X4 10.00, X6 7.33, X8 8.17
24
Decision-making steps

• 1. Define problem Is spelling ability related to
  grade level?
• 2. Define hypotheses
• H0 m2 m4 m6 m8
• HA m2 m4 m6 m8
• 3. Define experiment 24 kids, 6 in each of 4
  grades, given spelling test.
• 4. Define statistic F test One factor,
  independent samples ANOVA
• 5. Define acceptable probability of Type I error
  a lt .05.
• 6. Define value of statistic upon which decision
  hinges F(?,?) ?
• 7. Collect data X2 12.17, X4 10.00, X6
  7.33, X8 8.17
• 8. Compare observed statistic to critical value.

Source SS df s2 Fobt p Between Groups
82.83 Within groups
Total 157.83
25
Decision-making steps

• 1. Define problem Is spelling ability related to
  grade level?
• 2. Define hypotheses
• H0 m2 m4 m6 m8
• HA m2 m4 m6 m8
• 3. Define experiment 24 kids, 6 in each of 4
  grades, given spelling test.
• 4. Define statistic F test One factor,
  independent samples ANOVA
• 5. Define acceptable probability of Type I error
  a lt .05.
• 6. Define value of statistic upon which decision
  hinges F(?,?) ?
• 7. Collect data X2 12.17, X4 10.00, X6
  7.33, X8 8.17
• 8. Compare observed statistic to critical value.

Source SS df s2 Fobt p Between Groups
82.83 3 Within groups
75.00 20 Total 157.83 23
26
Decision-making steps

• 1. Define problem Is spelling ability related to
  grade level?
• 2. Define hypotheses
• H0 m2 m4 m6 m8
• HA m2 m4 m6 m8
• 3. Define experiment 24 kids, 6 in each of 4
  grades, given spelling test.
• 4. Define statistic F test One factor,
  independent samples ANOVA
• 5. Define acceptable probability of Type I error
  a lt .05.
• 6. Define value of statistic upon which decision
  hinges F(?,?) ?
• 7. Collect data X2 12.17, X4 10.00, X6
  7.33, X8 8.17
• 8. Compare observed statistic to critical value.

Source SS df s2 Fobt p Between Groups
82.83 3 27.61 Within groups
75.00 20 3.75 Total 157.83 23
27
Decision-making steps

• 1. Define problem Is spelling ability related to
  grade level?
• 2. Define hypotheses
• H0 m2 m4 m6 m8
• HA m2 m4 m6 m8
• 3. Define experiment 24 kids, 6 in each of 4
  grades, given spelling test.
• 4. Define statistic F test One factor,
  independent samples ANOVA
• 5. Define acceptable probability of Type I error
  a lt .05.
• 6. Define value of statistic upon which decision
  hinges F(3,20) ?
• 7. Collect data X2 12.17, X4 10.00, X6
  7.33, X8 8.17
• 8. Compare observed statistic to critical value.

Source SS df s2 Fobt p Between Groups
82.83 3 27.61 7.36 Within groups
75.00 20 3.75 Total 157.83 23
28
Decision-making steps

• 1. Define problem Is spelling ability related to
  grade level?
• 2. Define hypotheses
• H0 m2 m4 m6 m8
• HA m2 m4 m6 m8
• 3. Define experiment 24 kids, 6 in each of 4
  grades, given spelling test.
• 4. Define statistic F test One factor,
  independent samples ANOVA
• 5. Define acceptable probability of Type I error
  a lt .05.
• 6. Define value of statistic upon which decision
  hingesF(3,20)3.10 4.94
• 7. Collect data X2 12.17, X4 10.00, X6
  7.33, X8 8.17
• 8. Compare observed statistic to critical value.

Source SS df s2 Fobt p Between Groups
82.83 3 27.61 7.36 Within groups
75.00 20 3.75 Total 157.83 23
29
Decision-making steps

• 1. Define problem Is spelling ability related to
  grade level?
• 2. Define hypotheses
• H0 m2 m4 m6 m8
• HA m2 m4 m6 m8
• 3. Define experiment 24 kids, 6 in each of 4
  grades, given spelling test.
• 4. Define statistic F test One factor,
  independent samples ANOVA
• 5. Define acceptable probability of Type I error
  a lt .05.
• 6. Define value of statistic upon which decision
  hingesF(3,20)3.10 4.94
• 7. Collect data X2 12.17, X4 10.00, X6
  7.33, X8 8.17
• 8. Compare observed statistic to critical value.

Source SS df s2 Fobt p Between Groups
82.83 3 27.61 7.36 lt.01 Within
groups 75.00 20 3.75 Total 157.83 2
3
30
Decision-making steps

• 1. Define problem Is spelling ability related to
  grade level?
• 2. Define hypotheses
• H0 m2 m4 m6 m8
• HA m2 m4 m6 m8
• 3. Define experiment 24 kids, 6 in each of 4
  grades, given spelling test.
• 4. Define statistic F test One factor,
  independent samples ANOVA
• 5. Define acceptable probability of Type I error
  a lt .05.
• 6. Define value of statistic upon which decision
  hingesF(3,20)3.10 4.94
• 7. Collect data X2 12.17, X4 10.00, X6
  7.33, X8 8.17
• 8. Compare observed to critical value Fobs gt
  Fcrit at p lt .05 and p lt.01
• 9. Decide Reject H0
• 10. Conclusion Spelling is related to grade
  level in this school district.

31
Hypothesis testing with two or more means

• Why a new statistical test? To maintain p(Type I
  error) lt .05 when testing more than two means?
• Analysis of variance theory
• F ratio BGvar/WGvar when HA is true, numerator
  goes up, denominator stays the same.
• Breakdown of sums of squares and degrees of
  freedom
• Hypothesis testing with ANOVA
• Independent samples ANOVA table
• Dependent samples ANOVA table
• Which means are different from which Tukeys
  HSD.

32
Breakdown of SS and df for dependent ANOVA
Generally
SST
dfT
SSBS
SSWS
dfBS
dfWS
SSTreat
SSerror
dfTreat
dferror
Same subjects in different conditions.
33
Breakdown of SS and df for dependent ANOVA
Generally
SST
dfT kn-1
SSBS
SSWS
dfBS n-1
dfWS n(k-1)
SSTreat
SSerror
dfTreat k-1
dferror (n-1)(k-1)
Observed F ratio TREATvar/ERRORvar
(SSTreat/dfTreat)/(SSerror/dferror)
Same subjects in different conditions.
34
Sample test problem dependent ANOVA

• A psychologist is interested in the effects that
  observers have in an individuals problem solving
  ability. He recruits 10 subjects and asks them
  to solve some problems under three different
  conditions alone, with one observer, and with 10
  observers. The problems to be solved were of
  equal difficulty and the order of conditions was
  randomized across subjects. The DV was the
  percent of correctly solved problems. Help this
  psychologist determine if the number of observers
  influences problem solving ability.

Source SS df s2 Fobt p Between
subjects 1036.67 9 Within
subjects 4250.00 20 Treatment 2381.67
2 1190.83 11.47 error 1868.33
18 103.80 Total 5286.67 29
Xalone 89, Xone 81.5, Xten 67.5
35
Decision-making steps

• 1. Define Does the number of observers
  influence prob. solving?
• 2. Define hypotheses
• H0
• HA
• 3. Define experiment 10 subjects solve
  problems,3 conditions alone,
• with one observer, and with ten
  observers.
• 4. Define statistic
• 5. Define acceptable probability of Type I error
  a lt .05.
• 6. Define value of statistic upon which decision
  hinges
• 7. Perform experiment/collect data Xalone 89,
  Xone 81.5, Xten 67.5
• 8. Compare observed to critical value.
• 9. Decide
• 10. Conclusion

36
Decision-making steps

• 1. Define Does the number of observers influence
  prob. solving?
• 2. Define hypotheses
• H0 malone mone mten
• HA malone mone mten
• 3. Define experiment 10 subjects solve
  problems,3 conditions alone,
• with one observer, and with ten
  observers.
• 4. Define statistic F test One factor,
  dependent samples ANOVA.
• 5. Define acceptable probability of Type I error
  a lt .05.
• 6. Define value of statistic upon which decision
  hinges F(2,18) 3.55 6.01
• 7. Perform experiment/collect data Xalone 89,
  Xone 81.5, Xten 67.5
• 8. Compare observed to critical value.
• 9. Decide
• 10. Conclusion

37
Decision-making steps

• 1. Define Does the number of observers influence
  prob. solving?
• 2. Define hypotheses
• H0 malone mone mten
• HA malone mone mten
• 3. Define experiment 10 subjects solve problems,
  3 conditions alone,
• with one observer, and with ten
  observers.
• 4. Define statistic F test One factor,
  dependent samples ANOVA.
• 5. Define acceptable probability of Type I error
  a lt .05.
• 6. Define value of statistic upon which decision
  hinges F(2,18) 3.55 6.01
• 7. Perform experiment/collect data Xalone 89,
  Xone 81.5, Xten 67.5
• 8. Compare observed to critical value. Fobs gt
  Fcrit at p lt .05 and p lt.01
• 9. Decide Reject H0
• 10. Conclusion The number of observers does
  influence problem solving.

38
Hypothesis testing with two or more means

• Why a new statistical test? To maintain p(Type I
  error) lt .05 when testing more than two means?
• Analysis of variance theory
• F ratio BGvar/WGvar when HA is true, numerator
  goes up, denominator stays the same.
• Breakdown of sums of squares and degrees of
  freedom
• Hypothesis testing with ANOVA
• Independent samples ANOVA table
• Dependent samples ANOVA table
• Which means are different from which Tukeys
  HSD.

39
Which means are different from which?

• A significant ANOVA (reject H0) tells you that
  there at least one mean differs from at least one
  other mean.
• Does NOT tell you which mean is different from
  which.
• Tukeys HSD A method of determining where the
  differences are while maintaining p(Type I) lt .05
• Tukeys HSD requires
• Denominator of F ratio (either sW2 or s2error,
  aka MSW or MSerror )
• n (number of subjects in each group/condition)
• Qobt for each pair of means
• Xlarge Xsmall or Xlarge Xsmall
• sW2 /n s2error /n
• Qcrit from Table G using dfW (or dferror), a, and
  k ( grps or conditions)

40
Procedure for Problem solving/Observer example.

• Denominator of F ratio (s2error, aka MSerror )
  103.80
• n (number of subjects in each group/condition)
  10
• Qobt for each pair of means Xalone 89, Xone
  81.5, Xten 67.5
• Xlarge Xsmall
• s2error /n
• 89 81.5 89 67.5 81.5 67.5
• 103.80/10 103.80/10 103.80/10
• 2.33 6.67 4.35
• Qcrit from Table G using dferror(18), a (.05),
  and k (3)

and
and
Qobt
and
Qobt
and
41
Procedure for Problem solving/Observer example.

• Qobt for each pair of means Xalone 89, Xone
  81.5, Xten 67.5
• 89 81.5 89 67.5 81.5 67.5
• 103.80/10 103.80/10 103.80/10
• 2.33 6.67 4.35
• Qcrit from Table G 2.97
• Qobt must be greater than Qcrit
• Thus the condition where there were 10 observers
  differed from the condition when subjects were
  alone and had only one observer, but the
  condition where subjects were alone did not
  differ from that where there was only one
  observer.

and
Qobt
and
and
and
Qobt
42
Procedure for spelling/Grade example.

• Denominator of F ratio (sW2, aka MSW ) 3.75
• n (number of subjects in each group/condition)
  6
• Qobt for each pair of means
• X2 12.17, X4 10.00, X6 7.33, X8 8.17
• Xlarge Xsmall
• s2error /n
• 12.17 10.00 12.17 7.33 12.17 8.17
• 3.75/6 3.75/6 3.75/6
• 10.00 7.33 10.00 8.17 8.17 7.33
• 3.75/6 3.75/6 3.75/6
• Qcrit from Table G using dferror(20), a (.05),
  and k (4) 3.96

and
and
Qobt
Qobt
and
and
