Advanced%20Batch%20Files

1
Chapter 11

• Advanced Batch Files

2
Overview

• Quick review of batch file commands learned in
  earlier chapters.

3
Overview

• Advanced features of these commands will be
  explained and used.

4
Overview

• Will explain the purpose and function of
  remaining batch file commands and then will use
  these commands to write sophisticated batch
  files.

5
Overview

• Will refine techniques in working with
  environment.

6
Batch File Commands

• Batch files
• Have file extension .BAT or .CMD
• Are ASCII text files
• Include legitimate commands
• Create generic batch files using replaceable
  parameters
• Are not case sensitive

7
Batch File Commands

• Any command used at the command line can be used
  in a batch file.

8
Batch File CommandsTable 11.1 Batch File
Commands p. 548

9
Batch File CommandsTable 11.1 Batch File
Commands p. 548
10
Batch File Commands

• Batch files have
• Limited vocabulary (commands)
• Syntax
• Programming logic

11
Review of REM, PAUSE, and ECHO Commands

• REM command (remarks)
• Documents batch file
• Not a command that executes
• With ECHO ON displays but does not execute what
  follows REM
• Placed at beginning of a line in batch or
  CONFIG.SYS file, REM disables but does not delete
  line

12
Review of REM, PAUSE, and ECHO Commands

• PAUSE command
• Instructs batch file to stop executing until user
  takes some action
• Does not stop execution of .EXE or COM program
• Will not do any conditional processing

13
Review of REM, PAUSE, and ECHO Commands

• To interrupt a batch file during execution
• Press ltCtrlgt C
• Press ltCtrlgt ltBreakgt

14
Review of REM, PAUSE, and ECHO Commands

• ECHO command
• Used on command line or in batch file
• Controls printing of messages on screen when
  batch file run

15
Review of REM, PAUSE, and ECHO Commands

• ECHO ON -displays all commands to screen along
  with output.
• ECHO OFF - displays only output of commands to
  the screen.
• Precede ECHO OFF with _at_ and ECHO OFF will not
  appear on screen.

16
Advanced Features of ECHO and REM

• For faster processing, use a double colon ()
  instead of REM in front of remark or
  documentation line.

17
Advanced Features of ECHO and REM

• To delete the display of even the message 1
  file(s) copied, redirect output of command to
  NUL device.

18
Advanced Features of ECHO and REM

• Using NUL will not suppress a message such as
  file not found.

19
Advanced Features of ECHO and REM

• There is no such thing as a blank line in batch
  files.
• Pressing ltEntergt does not generate a blank line
  in batch files.

20
Advanced Features of ECHO and REM

• To insert a blank line, key in ECHO followed by a
  period (ECHO.)

21
ActivityUsing ECHO and NUL

• KEY CONCEPTS
• Replaced REM with () for faster processing
• Redirected output to NUL device so no
  messages/remarks shown on screen
• _at_ before ECHO OFF - ECHO OFF does not appear
  on screen
• ECHO. created a blank line in batch file

22
The GOTO Command

• GOTO command
• In conjunction with a label creates a loop
• Processes command following label

23
The GOTO Command

• Loop repeats steps until stopped by . . .
• using an IF statement.
• breaking into the batch file with ltCtrlgt C.

24
The GOTO Command

• Label in a batch file
• Is not a command
• Identifies location in a batch file
• Is preceded by a colon ()
• No longer then 8 characters
• Not case sensitive
• Ignored by OS until called with GOTO command

25
The GOTO Command

• GOTO has one parameter
• GOTO label

26
ActivityUsing the GOTO Command

• KEY CONCEPTS
• Debug - see and repair any errors
• To execute a batch file must be at system prompt
  (not in editor)
• Usefulness of loops
• Redirecting output to NUL device

27
ActivityUsing the GOTO Command

• Example of a Batch file to delete
• all files from many floppy disks
• _at_ECHO OFF
• TOP
• CLS
• ECHO Place disk with files no longer want in ECHO
  Drive A.
• PAUSE
• DEL /Q A.\
• ECHO Press Ctrl C to stop executing this batch
  file.
• ECHO otherwise, press any key to continue
  deleting files.
• PAUSE gt NUL
• GOTOTOP

28
The SHIFT Command

• SHIFT command allows for an unlimited number of
  parameters on the command line.

29
ActivityUsing the Shift Command
30
ActivityUsing the Shift Command
31
ActivityUsing the Shift Command
32
ActivityUsing the Shift Command
33
ActivityUsing the Shift Command

• KEY CONCEPTS
• Can keep date log not dependent on file
  modification date
• Usefulness of SHIFT command
• Displays 5 or more parameters and places echoing
  parameters in batch file
• Moves each parameter over by one position
• ECHO - echoes what is keyed in

34
ActivityUsing the Shift Command

• KEY CONCEPTS
• sign tells OS to concatenate files
• Contents of file ended when see EOF
• Typically ltCtrlgt Z
• COPY command places second ltCtrlgt Z at end of
  file creates problem
• Solve by copying file in binary mode

35
ActivityUsing the Shift Command

• KEY CONCEPTS
• /B switch - tells OS to copy file in binary
  mode
• Concatenated files with no switches - files
  copied in text mode
• gtgt used to see both name of directory and bytes
  in directory.
• ltCtrlgt C used to break out

36
The IF Command

• IF command allows for conditional processing of
  parts of a batch file.
• Conditional processing compares two items to
  determine if they are identical.

37
The IF Command

• Results of comparison testing
• True
• Items are identical
• Command executed
• False
• Items are not identical
• Command not executed
• Goes to next command line in batch file

38
The IF Command

• IF command checks to see
• If two sets of characters are/are not identical
• If a file exists
• The value of the variable in ERRORLEVEL

39
The IF Command

• IF command syntax
• IF ltconditiongt ltcommandgt
• IF NOT ERRORLEVEL number command
• IF NOT string1string2 command
• IF NOT EXIST filename command
• Note complete syntax in Appendix H

40
The IF Command Using Strings

• IF can be used to compare strings.
• Two equal signs ( ) separate items to be
  compared.

41
The IF Command Using Strings

• Can tell IF statement to GOTO a label or to
  perform an operation whether the condition is
  true or false.

42
ActivityUsing the IF Command with Strings

• KEY CONCEPTS
• No more lines - return to system prompt
• Batch file replaceable parameters get value from
  position on command line
• Case matters
• To ignore case add the /I parameter immediately
  following the IF statement

43
Testing for NULL Values

• If SHIFT used in a batch file will be caught in
  endless loop when all parameters are used.

44
Testing for NULL Values

• A null value (value equal to nothing) must be
  placed in a batch file to indicate end of data.

45
Testing for NULL Values

• Can test for a NULL value using IF with quotation
  marks.
• IF 1 GOTO LABEL

46
Testing for NULL Values

• Can test for a NULL value using
• IF with any word.
• IF 1word word GOTO LABEL
• wordword

47
Testing for NULL Values

• Can test for a NULL value using
• IF with backslash.
• IF \1\ \\ GOTO LABEL
• \\\\

48
ActivityUsing NULL Values

• KEY CONCEPTS
• Test for a null value using quotation marks
• Test for null value using a user designated word

49
The IF EXIST/IF NOT EXIST Command

• IF EXIST/IF NOT EXIST command
• Checks for the existence or non-existence of a
  file
• Works only with file names - not directory names

50
The IF EXIST/IF NOT EXIST Command

• Using IF EXIST command
• If file does exist
• Condition - true
• Processing passes to specified GOTO location
• If file does not exist
• Condition - false
• Batch file reads next line in file

51
The IF EXIST/IF NOT EXIST Command

• Using IF NOT EXIST command
• If file does not exist
• Condition - true
• Processing passes to specified GOTO location
• If file does exist
• Condition -false
• Batch file reads next line in file

52
ActivityUsing IF EXIST to Test for a File

• 1. IF \1\ \\ GOTO end
• 2. IF NOT \2\ \\ GOTO next
• 3. ECHO You must include a destination name
• 4. ECHO for the new directory name.
• 5. GOTO end
• 6. next

53
ActivityUsing IF EXIST to Test for a File

• 7. IF EXIST 1 GOTO message
• 8. REN 1 2
• 9. GOTO end
• 10. message
• 11. ECHO This is a file, not a directory.
• 12. end

54
ActivityUsing IF EXIST to Test for a File

• KEY CONCEPTS
• IF command testing for true condition
• True condition - command processed
• False condition - command ignored - next line in
  batch file processed
• IF NOT command testing for truth in reverse
• False condition - command processed
• True condition - command ignored - next line in
  batch file processed

55
ActivityUsing IF EXIST to Test for a File

• KEY CONCEPTS
• IF EXIST
• Used to check for existence of a file
• Can not be used to check for existence of a
  directory
• Use NUL to fool IF EXIST/IF NOT EXIST to check
  for existence of directory

56
The IF ERRORLEVEL Command Testing

• Program can set an exit code when it finishes
  executing.
• Batch file tests exit code with IF ERRORLEVEL
  statement.

57
The IF ERRORLEVEL Command Testing

• An exit code is tested with ERRORLEVEL to
  determine if it is greater than or equal to it.

58
The IF ERRORLEVEL Command Testing

• Exit codes listed in descending order when using
  IF ERROR LEVEL.
• Exit codes listed in ascending order when using
  IF NOT ERORLEVEL.

59
ActivityUsing IF ERRORLEVEL with COPY

• KEY CONCEPT
• User exit codes successfully in a batch file

60
Writing Programs to Test for Key Codes

• Exit codes
• Set by an operating system program
• Created by writing small program based upon an
  activity

61
Writing Programs to Test for Key Codes

• Every time a key is pressed, it is identified by
  a scan code.

62
Writing Programs to Test for Key Codes

• Can write programs by using
• Programming language
• DEBUG (operating system utility program)

63
Writing Programs to Test for Key Codes

• Easiest way to use DEBUG
• is to create a script file.

64
Writing Programs to Test for Key Codes

• A script file is set of instructions that can be
  written in any text editor.

65
Writing Programs to Test for Key Codes

• Feed script file via redirection into DEBUG
  program.
• DEBUG program converts script file to executable
  program with .com file extension.

66
Writing Programs to Test for Key Codes

• Summary of command available
• within BUG program (p. 576)
• assemble A (Address)
• compare C range address
• dump D (range)
• enter E address (list)
• fill F range list
• go G address addresses
• hex H value1 value2
• input I port
• load L address drive firstsector number
• move M range address
• name N pathname arglist
• output O port byte

67
Writing Programs to Test for Key Codes

• Summary of command available
• within BUG program (p. 576)
• proceed P addressnumber
• quit Q
• register R register
• search S range list
• trace T address value
• unassemble U range
• write W address drive firstsector
  number
• allocate expanded memory XA pages
• deallocate expanded memory XD handle
• map expanded memory pages XM Lpage Ppage
  handle
• display expanded memory status XS

68
Writing Programs to Test for Key Codes

• .COM Program Written with DEBUG
• to return scan code of Pressed Key
• A\gtDEBUG
• -a 100 ltEntergt
• 158E0100 mov ah,8 ltEntergt
• 158E0102 int 21 ltEntergt
• 158E0104 cmp al,0 ltEntergt
• 158E0106 jnz 10a ltEntergt
• 158E0108 mov ah,8int21 ltEntergt
• 158E010A mov ah,4c ltEntergt
• 158E010C int 21 ltEntergt
• 158E010E mov ah,8 ltEntergt
• -r cx ltEntergt
• CX 0000
• e ltEntergt
• -n reply.com ltEntergt
• -w ltEntergt
• Writing 000E bytes

69
Writing Programs to Test for Key Codes

• Easier way to create reply.com is to create
  script file with any text editor
• Script file - text file containing series of
  commands that can be redirected into DEBUG to
  create a .COM file
• Script file is not the program

70
ActivityWriting a Script File

• KEY CONCEPTS
• Convert script file into a program by redirecting
  it to DEBUG
• Error codes tested for equal to or greater than
  value specified
• IF ERRORLEVEL - descending order
• IF NOT ERROR LEVEL - ascending order

71
The Environment

• The environment is an area in memory where data
  can be stored.

72
The Environment

• Data
• Constant/fixed values - never change
• Variables that do change - depends on conditions
  or information passed to program

73
The Environment

• In programming, an expression is any legal
  combination of symbols that represent a value.

74
The Environment

• The operating system stores data in form of two
  strings
• Name of variable
• Value of variable

75
The Environment

• Environmental variable is name assigned to string
  (value) of data.

76
The Environment

• User can set environmental variables.
• Some common variables set when Windows started.

77
The Environment

• User can leave messages in environment using SET
  command.

78
The Environment

• Environmental variables set in Command Prompt
  window or batch files executed in Command Prompt
  window remain in effect only during that command
  prompt session.

79
The Environment

• SET syntax
• SET variable string

80
The Environment

• SET without parameters displays current
  environmental variables.

81
ActivityUsing SET and the Environmental Variables

• KEY CONCEPTS
• Command processor must be in memory when keying
  in command
• Using MORE
• Pressing ltEntergt - moves one line at a time
• Pressing ltSpaceBargt - goes to end of file
• SET with letter of alphabet - environmental
  variables beginning with letter displayed

82
ActivityUsing SET and the Environmental Variables

• KEY CONCEPTS
• To see value of environmental variable - use
  ECHO and enclose environmental variable name you
  are seeking with percent signs
• Environmental variable
• Can be used with commands
• Can be used to change directories

83
Using SET and the Environment in Batch Files

• Can use built-in environmental variables that
  Windows sets and uses.
• Can set own environmental variables.

84
Using SET and the Environment in Batch Files

• Setting environmental variables
• Can give them name and value in batch
  file/command line
• Only good for that session of Command Prompt
  Window

85
ActivityUsing SET and the Environment in Batch
Files

• KEY CONCEPTS
• Can set environmental value and use it in batch
  file
• Environmental variables set - deleted when
  Command Prompt window closed
• Environmental variables - not case sensitive
• To eliminate value - must set it at nothing
• Can add directory to PATH statement

86
The DIRCMD Environmental Variable

• DIRCMD environmental variable with
• SET to preset DIR command parameters or switches.
• ERRORLEVEL to change the way DIR displays
  information for current MS-DOS work session.

87
ActivityUsing DIRCMD

• KEY CONCEPTS
• Can determine how to display batch files
• Files displayed this way until change values or
  close Command Prompt session

88
FORINDO Command

• FOR..IN..DO command
• Allows repetitive processing
• Can be
• issued at the command line
• placed in a batch file

89
FORINDO Command

• FOR allows the use of a single command to issue
  several commands at once.
• Command can DO something FOR every value IN a
  specified set.

90
FORINDO Command

• Syntax at command line
• FOR variable IN (set) DO
• command command-parameters

91
FORINDO Command

• Syntax in a batch program
• FOR variable IN (set) DO
• command command-parameters

92
FORINDO Command

• GOTO loop is vertical.
• FORINDO loop is horizontal.

93
FORINDO Command

• There is a difference between
• a variable and a parameter.

94
ActivityUsing the FORINDO Command

• KEY CONCEPTS
• Space and comma between items in a set work same
  way
• Advantages of using space and comma between items
  in a set
• Command line is case sensitive
• Variable letter chosen is not important
• - used at command line
• used in batch file

95
ActivityUsing the FORINDO Command

• KEY CONCEPTS
• Items in set is a horizontal not vertical loop
• Moved all batch files to BATCH subdirectory and
  set path to include BATCH directory
• Caution If close Command Prompt window, have
  to issue following command to include the
  A\BATCH directory in your path
  A\BATCHgtA\BATCH\ADD A\BATCH
• Changed dates of files

96
More Features of the FORINDO Command

• New features of FORINDO command
• May list environmental variables so they are
  divided and appear on separate lines
• Use /R parameter (recursive parameter)

97
More Features of the FORINDO Command

• New features of FORINDO command
• Use tilde operator () to
• Strip a file name of quotation marks
• Expand variable
• Select specific text from ASCII files

98

ActivityUsing Additional Features of FORINDO
Command

• KEY CONCEPTS
• Use FORINDO to display list one line at a time
  (list easier to read)
• Tilde () strips file name of quotation marks
• Use quotation marks to add prefix or suffix to
  long file name
• REN only needs file name

99
ActivityUsing Additional Features of FORINDO
Command

• KEY CONCEPTS
• Use n and x to precede any file name with prefix
• Can strip out specific fields in a text file -
  use /F parameter
• Can delimit data

100
The CALL Command

• CALL command
• Allows you to run one batch file from within
  another
• Returns control to original batch file when
  second batch file is finished executing

101
ActivityUsing CALL

• KEY CONCEPTS
• Use ltCtrlgt L - to eject a page
• Use ltCtrlgt G - to create a noise
• Create series of batch files that return to
  directory you were previously in
• When executing a program within a batch file -
  not returned to batch file unless you use CALL

102
ActivityUsing CALL

• KEY CONCEPTS
• Creating and Saving batch file called HOMETO.BAT
  in BATCH directory
• Line 1 COPY A\BATCH\HOME.DAT
  A\BATCH\HOMESAVE.BAT ltEntergt
• Line 2 CD gtgt A\BATCH\HOMESAVE.BAT ltEntergt
• Line 3CALL HOMNESAVE.BAT ltEntergt
• Line 4 DEL A\BATCH\HOMESAVE.BAT ltEntergt
