Data Warehousing and Data Mining Chapter 7

1
Data Warehousing and Data Mining Chapter 7

• MIS 542
• Spring 2004

2
Chapter 7. Classification and Prediction

• What is classification? What is prediction?
• Issues regarding classification and prediction
• Classification by decision tree induction
• Bayesian Classification
• Classification by Neural Networks
• Classification by Support Vector Machines (SVM)
• Classification based on concepts from association
  rule mining
• Other Classification Methods
• Prediction
• Classification accuracy
• Summary

3
Classification vs. Prediction

• Classification
• predicts categorical class labels (discrete or
  nominal)
• classifies data (constructs a model) based on the
  training set and the values (class labels) in a
  classifying attribute and uses it in classifying
  new data
• Prediction
• models continuous-valued functions, i.e.,
  predicts unknown or missing values
• Typical Applications
• credit approval
• target marketing
• medical diagnosis
• treatment effectiveness analysis

4
ClassificationA Two-Step Process

• Model construction describing a set of
  predetermined classes
• Each tuple/sample is assumed to belong to a
  predefined class, as determined by the class
  label attribute
• The set of tuples used for model construction is
  training set
• The model is represented as classification rules,
  decision trees, or mathematical formulae
• Model usage for classifying future or unknown
  objects
• Estimate accuracy of the model
• The known label of test sample is compared with
  the classified result from the model
• Accuracy rate is the percentage of test set
  samples that are correctly classified by the
  model
• Test set is independent of training set,
  otherwise over-fitting will occur
• If the accuracy is acceptable, use the model to
  classify data tuples whose class labels are not
  known

5
Classification Process (1) Model Construction
Classification Algorithms
IF rank professor OR years gt 6 THEN tenured
yes
6
Classification Process (2) Use the Model in
Prediction
(Jeff, Professor, 4)
Tenured?
7
Supervised vs. Unsupervised Learning

• Supervised learning (classification)
• Supervision The training data (observations,
  measurements, etc.) are accompanied by labels
  indicating the class of the observations
• New data is classified based on the training set
• Unsupervised learning (clustering)
• The class labels of training data is unknown
• Given a set of measurements, observations, etc.
  with the aim of establishing the existence of
  classes or clusters in the data

8
Chapter 7. Classification and Prediction

• What is classification? What is prediction?
• Issues regarding classification and prediction
• Classification by decision tree induction
• Bayesian Classification
• Classification by Neural Networks
• Classification by Support Vector Machines (SVM)
• Classification based on concepts from association
  rule mining
• Other Classification Methods
• Prediction
• Classification accuracy
• Summary

9
Issues Regarding Classification and Prediction
(1) Data Preparation

• Data cleaning
• Preprocess data in order to reduce noise and
  handle missing values
• Relevance analysis (feature selection)
• Remove the irrelevant or redundant attributes
• Data transformation
• Generalize and/or normalize data

10
Issues regarding classification and prediction
(2) Evaluating Classification Methods

• Predictive accuracy
• Speed and scalability
• time to construct the model
• time to use the model
• Robustness
• handling noise and missing values
• Scalability
• efficiency in disk-resident databases
• Interpretability
• understanding and insight provided by the model
• Goodness of rules
• decision tree size
• compactness of classification rules

11
Chapter 7. Classification and Prediction

• What is classification? What is prediction?
• Issues regarding classification and prediction
• Classification by decision tree induction
• Bayesian Classification
• Classification by Neural Networks
• Classification by Support Vector Machines (SVM)
• Classification based on concepts from association
  rule mining
• Other Classification Methods
• Prediction
• Classification accuracy
• Summary

12
Classification by Decision Tree Induction

• Decision tree
• A flow-chart-like tree structure
• Internal node denotes a test on an attribute
• Branch represents an outcome of the test
• Leaf nodes represent class labels or class
  distribution
• Decision tree generation consists of two phases
• Tree construction
• At start, all the training examples are at the
  root
• Partition examples recursively based on selected
  attributes
• Tree pruning
• Identify and remove branches that reflect noise
  or outliers
• Use of decision tree Classifying an unknown
  sample
• Test the attribute values of the sample against
  the decision tree

13
Training Dataset
This follows an example from Quinlans ID3
14
Output A Decision Tree for buys_computer
age?
lt30
overcast
gt40
30..40
student?
credit rating?
yes
no
yes
fair
excellent
no
no
yes
yes
15
Algorithm for Decision Tree Induction

• Basic algorithm (a greedy algorithm)
• Tree is constructed in a top-down recursive
  divide-and-conquer manner
• At start, all the training examples are at the
  root
• Attributes are categorical (if continuous-valued,
  they are discretized in advance)
• Examples are partitioned recursively based on
  selected attributes
• Test attributes are selected on the basis of a
  heuristic or statistical measure (e.g.,
  information gain)
• Conditions for stopping partitioning
• All samples for a given node belong to the same
  class
• There are no remaining attributes for further
  partitioning majority voting is employed for
  classifying the leaf
• There are no samples left

16
Attribute Selection Measure Information Gain
(ID3/C4.5)

• Select the attribute with the highest information
  gain
• S contains si tuples of class Ci for i 1, ,
  m
• information measures info required to classify
  any arbitrary tuple
• entropy of attribute A with values a1,a2,,av
• information gained by branching on attribute A

17
Attribute Selection by Information Gain
Computation

• Class P buys_computer yes
• Class N buys_computer no
• I(p, n) I(9, 5) 0.940
• Compute the entropy for age

• means age lt30 has 5 out of 14
  samples, with 2 yeses and 3 nos. Hence
• Similarly,

18
Gain Ratio

• Add another attribute transaction TID
• for each observation TID is different
• E(TID) (1/14)I(1,0)(1/14)I(1,0)
  (1/14)I(1,0)... (1/14)I(1,0)0
• gain(TID) 0.940-00.940
• the highest gain so TID is the test attribute
• which makes no sense
• use gain ratio rather then gain
• Split information measure of the information
  value of split
• without considering class information
• only number and size of child nodes

19

• Split information ?(-Si/S)log2(Si/S)
• information needed to assign an instance to one
  of these branches
• Gain ratio gain(S)/split information(S)
• in the previous example
• split info (1/14)log2(1/14)143.807
• gain ratio (0.940-0.0)/3.8070.246
• Split info for ageI(5,4,5)
• (5/14)log25/14 (4/14)log24/14 (5/14)log25/141.5
  77
• gain ratio gain(age)/split info(age)

• 0.247/1.5770.156

20
Exercise

• Repeat the same exercise of constructing the tree
  by the gain ratio criteria as the attribute
  selection measure
• notice that TID has the highest gain ratio
• do not split by TID

21
Other Attribute Selection Measures

• Gini index (CART, IBM IntelligentMiner)
• All attributes are assumed continuous-valued
• Assume there exist several possible split values
  for each attribute
• May need other tools, such as clustering, to get
  the possible split values
• Can be modified for categorical attributes

22
Gini Index (IBM IntelligentMiner)

• If a data set T contains examples from n classes,
  gini index, gini(T) is defined as
• where pj is the relative frequency of class j
  in T.
• If a data set T is split into two subsets T1 and
  T2 with sizes N1 and N2 respectively, the gini
  index of the split data contains examples from n
  classes, the gini index gini(T) is defined as
• The attribute provides the smallest ginisplit(T)
  is chosen to split the node (need to enumerate
  all possible splitting points for each attribute).

23
Extracting Classification Rules from Trees

• Represent the knowledge in the form of IF-THEN
  rules
• One rule is created for each path from the root
  to a leaf
• Each attribute-value pair along a path forms a
  conjunction
• The leaf node holds the class prediction
• Rules are easier for humans to understand
• Example
• IF age lt30 AND student no THEN
  buys_computer no
• IF age lt30 AND student yes THEN
  buys_computer yes
• IF age 3140 THEN buys_computer yes
• IF age gt40 AND credit_rating excellent
  THEN buys_computer yes
• IF age lt30 AND credit_rating fair THEN
  buys_computer no

24
Approaches to Determine the Final Tree Size

• Separate training (2/3) and testing (1/3) sets
• Use cross validation, e.g., 10-fold cross
  validation
• Use all the data for training
• but apply a statistical test (e.g., chi-square)
  to estimate whether expanding or pruning a node
  may improve the entire distribution
• Use minimum description length (MDL) principle
• halting growth of the tree when the encoding is
  minimized

25
Enhancements to basic decision tree induction

• Allow for continuous-valued attributes
• Dynamically define new discrete-valued attributes
  that partition the continuous attribute value
  into a discrete set of intervals
• Handle missing attribute values
• Assign the most common value of the attribute
• Assign probability to each of the possible values
• Attribute construction
• Create new attributes based on existing ones that
  are sparsely represented
• This reduces fragmentation, repetition, and
  replication

26
Missing Values

• T cases for attribute A
• in F cases value of A is unknown
• gain (1-F/T)(info(T)-entropy(T,A)
• (F/T)0
• split info add another branch for cases whose
  values are unknown

27
Missing Values

• When a case has a known attribute value it s
  assigned to Ti with probability 1
• if the attribute value is missing it is assigned
  to Ti with a probability
• give a weight w that the case belongs to subset
  Ti
• do that for each subset Ti
• Than number of cases in each Ti has fractional
  values

28
Example

• One of the training cases has a missing age
• T(age ?, incmid,stuno,creditex,class buy
  yes)
• gain(age) inf(8,5)-ent(age)
• inf(8,5)-(8/13)log(8/13)-(5/13)log(5/13)0.961
• ent(age)
• (5/13)-(2/5)log(2/5)-(3/5)log(3/5)
• (3/13)-(3/3)log(3/3)0
• (5/13)-(3/5)log(3/5)-(2/5)log(2/5)
• .747
• gain(age) (13/14)(0.961-0.747)199

29

• split info(age) (5/14)log5/14 lt30
• (3/14)log3/14 31..40
• (5/14)log5/14 gt40
• (1/14)log1/14 missing
• 1.809
• gain ratio(age) 0.199/1.8090.156

30

• after splitting by age
• age lt30 branch
• age student
  class weight
• agelt30 y B 1
• agelt30 n N 1
• agelt30 n N 1
• agelt30 n N 1
• agelt30 y B 1
• agelt30 n B 5/13

age
gt40
31..40
lt30
credit
student
3,3/13 B
ext 2N 5/13B
fair 3B
no 3N 5/13 B
yes 2B
31

• What happens if a new case has to be classified
• T agelt30,incomemid,stu?,creditfair,
• classhas to be found
• based on age goes to first subtree
• but student is unknown
• (2.0/5.4) student
• (3.4/5.4) not student
• P(buy) P(stu)P(buystu) P(notst)P(buynostu)
• (2/5.4)1(3.4/5.4)(5/44)0.44
• P(nbuy) P(stu)P(nbuystu) P(notst)P(nbuynostu
  )
• (2/5.4)0(3.4/5.4)(39/44)0.56

32
Continuous variables

• Income is continuous
• make a binary split
• try all possible splitting points
• compute entropy and gain similarly
• but you can use income v as a test variable in
  any subtree
• there is still information in income not used
  perfectly

33
Avoid Overfitting in Classification

• Overfitting An induced tree may overfit the
  training data
• Too many branches, some may reflect anomalies due
  to noise or outliers
• Poor accuracy for unseen samples
• Two approaches to avoid overfitting
• Prepruning Halt tree construction earlydo not
  split a node if this would result in the goodness
  measure falling below a threshold
• Difficult to choose an appropriate threshold
• Postpruning Remove branches from a fully grown
  treeget a sequence of progressively pruned trees
• Use a set of data different from the training
  data to decide which is the best pruned tree

34
Motivation for pruning

• A trivial tree two classes with probability p no
• 1-pyes
• conditioned on a given set of attribute values
• (1) assign each case to majority no
• error(1) 1-p
• (2) assign to no with p and yes with 1-p
• error(2) p(1-p) (1-p)p2p(1-p)gt1-p
• for pgt0.5
• so simple tree has a lower error of
  classification

35

• If the error rate of a subtree is higher then the
  error obtained by replacing the tree with its
  most frequent leaf or branch
• prune the subtree
• How to estimate the prediction error
• do not use training samples
• pruning always increase error of the training
  sample
• estimate error based on test set
• cost complexity or reduced error pruning

36
Pessimistic error estimates

• Based on training set only
• subtree covers N cases E cases missclasified
• error based on training set fE/N
• but this is not error
• resemble it as a sample from population
• estimate a upper bond on the population error
  based on the confidence limit
• Make a normal approximation to the binomial
  distribution

37

• Given a confidence level c default value is 25
  in C4.5
• find confidence limit z such that
• P((f-e)/sqrt(e(1-e)/N)gtz)c
• N number of samples
• f E/N observed error rate
• e true error rate
• the upper confidence limit is used as a
  pesimistic estimate of the true but unknown error
  rate
• first approximation to confidence interval for
  error
• f /-zc/2?f /-zc/2sqrt(f(1-f)/N))

38

• Solving the above inequality
• e (fz2/2N zsqrt(f/N-f2/2Nz2/4N2))


• (1z2/N)
• z is number of standard deviations corresponding
  to a confidence level c
• for c0.25 z0.69
• refer to Figure 6.2 on page 166 of

39
Example

• Labour negotiation data
• dependent variable or class to be predicted is
  acceptability of contract good or bad
• independent variables
• duration,
• wage increase 1th year lt2.5, gt2.5
• working hours per week lt36, gt36
• health plan contribution none, half, full
• Figure 6.2 shows a branch of a d.tree

40
wage increase 1th year
gt2.5
lt2.5
working hours per week
gt36
lt36
health plan contribution
1 Bad 1 good
full
none
half
4 bad 2 good
4 bad 2 good
1 bad 1good
a
c
b
41

• for node a
• E2,N6 so f2/60.33
• plugging into the formula upper confidence limit
  e 0.47
• use 0.47 a pessimistic estimate of the error
• rather then the training error of 0.33
• for node b
• E1,N2 so f1/20.50
• plugging into the formula upper confidence limit
  e 0.72
• for node c f2/60.33 but e0.47
• average error(60.4720.7260.47)/140.51
• The error estimate for the parent healt plan is
• f5/14 and e0.46lt0.51
• so prune the node
• now working hour per week node has two branchs

42
working hour per week
1 bad 1 good
bed e0.46
e0.72
average pessimistic error (20.72140.46)/16 th
e pessimistic error of the pruned tree f 6/16
ep Exercise calculate pessimistic error decide
to prune or not based on ep
43
Extracting Classification Rules from Trees

• Represent the knowledge in the form of IF-THEN
  rules
• One rule is created for each path from the root
  to a leaf
• Each attribute-value pair along a path forms a
  conjunction
• The leaf node holds the class prediction
• Rules are easier for humans to understand
• Example
• IF age lt30 AND student no THEN
  buys_computer no
• IF age lt30 AND student yes THEN
  buys_computer yes
• IF age 3140 THEN buys_computer yes
• IF age gt40 AND credit_rating excellent
  THEN buys_computer yes
• IF age gt40 AND credit_rating fair THEN
  buys_computer no

44

• Rule R A then class C
• Rule R-A- then class C
• delete condition X from A to obtain A-
• make a table
• class C not class C
• X Y1 E1
• not X Y2 E2
• Y1E1 satisfies R Y1 correct E1 misclassified
• Y2E2 cases satisfied by R- but not R

45

• The total cases by R- is Y1Y2E1E2
• some satisfies X some not
• use a pessimistic estimate of the true error for
  each rule using the upper limit UppCy(E,N)
• for rule R estimate UppCy(E1,Y1E1)
• and for R- estimate UppCy(E1E2,Y1E1Y2E2)
• if pessimistic error rate of R- lt that of R
• delete condition x

46

• Suppose n conditions for a rule
• delete conditions one by one
• repeat
• compare with the pessimistic error of the
  original rule
• if min(R-)ltR delete condition x
• unit no improvement is in pessimistic error
• Study example on page 49-50 of Quinlan 93

47
AnswerTree

• Variables
• measurement levels
• case weights
• frequency variables
• Growing methods
• Stopping rules
• Tree parameters
• costs, prior probabilities, scores and profits
• Gain summary
• Accuracy of tree
• Cost-complexity pruning

48
Variables

• Categorical Variables
• nominal or ordinal
• Continuous Variables
• All grouping method accept all types of variables
• QUEST requires that tatget variable be nominal
• Target and predictor variables
• target variable (dependent variable)
• predictor (independent variables)
• Case weight and frequency variables

49
case weight variables

• unequal treatment to the cases
• Ex direct marketing
• 10,000 households respond
• and 1,000,000 do not
• all responders but 1 of nonresponders(10,000)
• case weight 1 for responders and
• case weight 100 for nonresponders
• FREQUENCY VARIABLES
• count of a record representing more than one
  individual

50
Tree-Growing Methods

• CHAID
• Chi-squared Automatic Interaction Detector
• Kass (1980)
• Exhaustive CHAID
• Biggs, de Ville, Suen (1991)
• CRT
• Classification and Regression Trees
• Breiman, Friedman, Olshen, and Stone (1984)
• QUEST
• Quick, Unbiased, Efficient Statistical Tree
• Loh, Shih (1997)

51
CHAID

• evaluate all values of a potential predictor
• merges values that are judged to be statistically
  homogenous
• target variable
• continuous F test
• categorical Chi-square test
• not binary produce more than two categories at
  any particular level
• wider tree than do the binary methods
• works for all types of variables
• case weights and frequency variables
• missing values as a single valid category

52
CHAID Algorithm

• for each predictor X
• find pair of categories of X least significantly
  different (has the largest p value) wrt target
  variable Y
• Y cont use F test
• Y nominal for a two-way cross tabulation with
  categories of X as rows categories of Y a columns
  use the Chi-squared test
• for the pair of categories of X with largest p
  value
• p gt ?merge (pre specified level) than
• merge this pair into a single compound category
• go to step (1)
• p lt ?merge (pre specified level) than
• go to step (3)

53
CHAID Algorithm (cont)

• compute adjusted p values
• select the predictor X that has the smallest
  adjusted p value (most significant)
• compare its p value to a ?split (pre specified
  splitting level)
• Plt ?split split the node based on categories of
  X
• P gt ?split do not split the node (terminal node)
• continue the tree growing process until the
  stopping rules are made

54
Exhaustive CHAID

• CHAID may not find the optimal split for a
  variable as it stop merging categories
• all are statistically different
• continue merging until two super categories are
  left
• examine series of merges for the predictor
• set of categories giving strongest association
  with the target
• computes and adjusted p values for that
  association
• best split for each predictor
• choose predictor based on p values
• otherwise identical to CHAID
• longer to compute
• safer to use

55
CART

• Binary tree growing algorithm
• may not present efficiently
• partitions data into two subsets
• same predictor variable may be used several times
  at different levels
• misclassification costs
• prior probability distribution
• Computation can take a long time with large data
  sets
• Surrogate splitting for missing values

56
Impurity measures (1)

• for categorical targets variables
• Gini, twoing, or (ordinal targets) ordered twoing
• for continuous targets
• least-squared deviation (LSD)
• Gini
• at node t, g(t)
• g(t) ?j?ip(jt)p(it) i and j are categories
• g(t) 1-?jp2(jt)
• when cases are evenly distributed g takes its max
  value of 1-1/k k number of categories

57
Impurity measures (2)

• if costs are specified
• g(t) ?j?iC(ij)p(jt)p(it)
• C(ij) specifies cost of misclassifiying a
  category j case as category i
• gini criterion function for split s at node t
• ?(s,t) g(t) - pLg(tL) - pRg(tR)
• PL proportion of cases in t sent to left child
  node
• PR proportion of cases in t sent to right child
  node
• split s maximizing the value of ?(s,t) is choosen
• improvement in the tree

58
Impurity measures (3)

• Twoing
• splitting into two superclasses
• best split on the predictor based on those two
  superclasses
• ?(s,t) pLpR?jp(jtL)-p(jtR)2
• the split s is chosen that maximizes this
  criterion
• C1 j p(jtL)gtp(jtR)
• C2 C - C1
• costs are not taken into account

59
Impurity measures (4)

• Ordered Twoing
• for ordinal target variables
• contiguous categories can be combined to form
  superclasses
• LSD
• continuous targets
• within node variance for node t
• R(t) (1/Nw(t))?i?twnfn(yi-y_bar(t))2
• where Nw weighted number of cases in t
• wn is value of weighting variable for case i
• fn is frequency variable
• yi target variable
• y_bar(t) weighted mean for t

60

• LSD criterion function
• ?(s,t) R(t) - pLR(tL) - pRR(tR)
• this value weighted by the proportion of all
  cases in t is the value reported as improvement
  in the tree

61
Steps in the CART analysis

• at the root node t1, search for a split s
• giving the largest decrease in impurity
• ?(s,1) max ?s?S(s,1)
• split 1 as t2 and t3 using s
• repeat the split searching process in t2 and t3
• continue until one of the stopping rules is met

62

• all cases have identical values for all
  predictors
• the node becomes pure all cases have the same
  value of the target variable
• the depth of the tree has reached its
  prespecified maximum value
• the number of cases in a node less than a
  prespecified minimum parent node size
• split at node results in producing a child node
  with cases less than a prespecified min child
  node size
• for CART only max decrease in impurity is less
  than a prespecified value

63
QUEST

• variable selection and split point selection
  separately
• computationally efficient than CART

64
Classification in Large Databases

• Classificationa classical problem extensively
  studied by statisticians and machine learning
  researchers
• Scalability Classifying data sets with millions
  of examples and hundreds of attributes with
  reasonable speed
• Why decision tree induction in data mining?
• relatively faster learning speed (than other
  classification methods)
• convertible to simple and easy to understand
  classification rules
• can use SQL queries for accessing databases
• comparable classification accuracy with other
  methods

65
Scalable Decision Tree Induction Methods in Data
Mining Studies

• SLIQ (EDBT96 Mehta et al.)
• builds an index for each attribute and only class
  list and the current attribute list reside in
  memory
• SPRINT (VLDB96 J. Shafer et al.)
• constructs an attribute list data structure
• PUBLIC (VLDB98 Rastogi Shim)
• integrates tree splitting and tree pruning stop
  growing the tree earlier
• RainForest (VLDB98 Gehrke, Ramakrishnan
  Ganti)
• separates the scalability aspects from the
  criteria that determine the quality of the tree
• builds an AVC-list (attribute, value, class label)

66
Data Cube-Based Decision-Tree Induction

• Integration of generalization with decision-tree
  induction (Kamber et al97).
• Classification at primitive concept levels
• E.g., precise temperature, humidity, outlook,
  etc.
• Low-level concepts, scattered classes, bushy
  classification-trees
• Semantic interpretation problems.
• Cube-based multi-level classification
• Relevance analysis at multi-levels.
• Information-gain analysis with dimension level.

67
Chapter 7. Classification and Prediction

• What is classification? What is prediction?
• Issues regarding classification and prediction
• Classification by decision tree induction
• Bayesian Classification
• Classification by Neural Networks
• Classification by Support Vector Machines (SVM)
• Classification based on concepts from association
  rule mining
• Other Classification Methods
• Prediction
• Classification accuracy
• Summary

68
Bayesian Classification Why?

• Probabilistic learning Calculate explicit
  probabilities for hypothesis, among the most
  practical approaches to certain types of learning
  problems
• Incremental Each training example can
  incrementally increase/decrease the probability
  that a hypothesis is correct. Prior knowledge
  can be combined with observed data.
• Probabilistic prediction Predict multiple
  hypotheses, weighted by their probabilities
• Standard Even when Bayesian methods are
  computationally intractable, they can provide a
  standard of optimal decision making against which
  other methods can be measured

69
Bayesian Theorem Basics

• Let X be a data sample whose class label is
  unknown
• Let H be a hypothesis that X belongs to class C
• For classification problems, determine P(H/X)
  the probability that the hypothesis holds given
  the observed data sample X
• P(H) prior probability of hypothesis H (i.e. the
  initial probability before we observe any data,
  reflects the background knowledge)
• P(X) probability that sample data is observed
• P(XH) probability of observing the sample X,
  given that the hypothesis holds

70
Bayesian Theorem

• Given training data X, posteriori probability of
  a hypothesis H, P(HX) follows the Bayes theorem
• Informally, this can be written as
• posterior likelihood x prior / evidence
• MAP (maximum posteriori) hypothesis
• Practical difficulty require initial knowledge
  of many probabilities, significant computational
  cost

71
Naïve Bayes Classifier

• A simplified assumption attributes are
  conditionally independent
• The product of occurrence of say 2 elements x1
  and x2, given the current class is C, is the
  product of the probabilities of each element
  taken separately, given the same class
  P(y1,y2,C) P(y1,C) P(y2,C)
• No dependence relation between attributes
• Greatly reduces the computation cost, only count
  the class distribution.
• Once the probability P(XCi) is known, assign X
  to the class with maximum P(XCi)P(Ci)

72
Example

• H X is an apple
• P(H) priori probability that X is an apple
• X observed data round and red
• P(H/x) probability that X is an apple given that
  we observe that it is red and round
• P(X/H) posteriori probability that a data is red
  and round given that it is an apple
• P(X) priori probablility that it is red and round

73

• P(H/X) P(H,X)/P(X) P(X/H)P(H)/P(X)
• calculate P(H/X) from
• P(X/H),P(H),P(X)

74
Naïve Bayes Classifier (I)

• A simplified assumption attributes are
  conditionally independent
• Greatly reduces the computation cost, only count
  the class distribution.

75
Naive Bayesian Classifier (II)

• Given a training set, we can compute the
  probabilities

76
Bayesian classification

• The classification problem may be formalized
  using a-posteriori probabilities
• P(CiX) prob. that the sample tuple
  Xltx1,,xkgt is of class Ci.
• There are m classes Ci i 1 to m
• E.g. P(classN outlooksunny,windytrue,)
• Idea assign to sample X the class label Ci such
  that P(CiX) is maximal
• P(CiX)gt P(CjX) 1ltjltm j?i

77
Estimating a-posteriori probabilities

• Bayes theorem
• P(CiX) P(XCi)P(Ci) / P(X)
• P(X) is constant for all classes
• P(Ci) relative freq of class Ci samples
• Ci such that P(CiX) is maximum Ci such that
  P(XCi)P(Ci) is maximum
• Problem computing P(XCi) is unfeasible!

78
Naïve Bayesian Classification

• Naïve assumption attribute independence
• P(x1,,xkCi) P(x1Ci)P(xkCi)
• If i-th attribute is categoricalP(xiCi) is
  estimated as the relative freq of samples having
  value xi as i-th attribute in class Ci sik/si .
• If i-th attribute is continuousP(xiCi) is
  estimated thru a Gaussian density function
• Computationally easy in both cases

79
Training dataset
Class C1buys_computer yes C2buys_computer
no Data sample X (agelt30, Incomemedium, Stud
entyes Credit_rating Fair)
80
Naïve Bayesian Classifier Example

• Compute P(X/Ci) for each class
• P(agelt30 buys_computeryes)
  2/90.222
• P(agelt30 buys_computerno) 3/5 0.6
• P(incomemedium buys_computeryes)
  4/9 0.444
• P(incomemedium buys_computerno)
  2/5 0.4
• P(studentyes buys_computeryes) 6/9
  0.667
• P(studentyes buys_computerno)
  1/50.2
• P(credit_ratingfair buys_computeryes)
  6/90.667
• P(credit_ratingfair buys_computerno)
  2/50.4
• X(agelt30 ,income medium, studentyes,credit_
  ratingfair)
• P(XCi) P(Xbuys_computeryes) 0.222 x
  0.444 x 0.667 x 0.0.667 0.044
• P(Xbuys_computerno) 0.6 x
  0.4 x 0.2 x 0.4 0.019
• P(XCi)P(Ci ) P(Xbuys_computeryes)
  P(buys_computeryes)0.028
• P(Xbuys_computeryes)
  P(buys_computeryes)0.007
• X belongs to class buys_computeryes

81
Naïve Bayesian Classifier Comments

• Advantages
• Easy to implement
• Good results obtained in most of the cases
• Disadvantages
• Assumption class conditional independence ,
  therefore loss of accuracy
• Practically, dependencies exist among variables
• E.g., hospitals patients Profile age, family
  history etc
• Symptoms fever, cough etc., Disease lung
  cancer, diabetes etc
• Dependencies among these cannot be modeled by
  Naïve Bayesian Classifier
• How to deal with these dependencies?
• Bayesian Belief Networks

82
Bayesian Networks

• Bayesian belief network allows a subset of the
  variables conditionally independent
• A graphical model of causal relationships
• Represents dependency among the variables
• Gives a specification of joint probability
  distribution

• Nodes random variables
• Links dependency
• X,Y are the parents of Z, and Y is the parent of
  P
• No dependency between Z and P
• Has no loops or cycles

X
83
Bayesian Belief Network An Example
Family History
Smoker
(FH, S)
(FH, S)
(FH, S)
(FH, S)
LC
0.7
0.8
0.5
0.1
LungCancer
Emphysema
LC
0.3
0.2
0.5
0.9
The conditional probability table for the
variable LungCancer Shows the conditional
probability for each possible combination of its
parents
PositiveXRay
Dyspnea
Bayesian Belief Networks
84
Learning Bayesian Networks

• Several cases
• Given both the network structure and all
  variables observable learn only the CPTs
• Network structure known, some hidden variables
  method of gradient descent, analogous to neural
  network learning
• Network structure unknown, all variables
  observable search through the model space to
  reconstruct graph topology
• Unknown structure, all hidden variables no good
  algorithms known for this purpose
• D. Heckerman, Bayesian networks for data mining
