Title: Creating of Rich Client Applications using NetBeans 6 and Java Swing


1
Creating of Rich Client Applications using
NetBeans 6 and Java Swing
  • Miroslav Nachev

2
Contents
  • SwingX
  • Simple Database Application
  • Another simple Database Application with
    MasterTable and DetailTable
  • Rich Client Application example
  • Swing Application Framework
  • Q A

3
SwingX
  • Contains extensions to the Swing GUI toolkit,
    including new and enhanced components that
    provide functionality commonly required by rich
    client applications.
  • SwingX Demo

4
SwingX highlights include
  • Sorting, filtering, highlighting for tables,
    trees, and lists
  • Date picker component
  • Find/search
  • Auto-completion
  • Login/authentication framework
  • TreeTable component
  • Collapsible panel component
  • Tip-of-the-Day component

5
SwingX links
  • Links
  • http//www.swinglabs.org/
  • https//swingx.dev.java.net/
  • https//swinglabs-demos.dev.java.net/
  • https//swinghelper.dev.java.net/
  • http//wiki.java.net/bin/view/Javadesktop/SwingLab
    sSwingX

6
Simple Database Application
  • Creating a Database car_db
  • Creating the Application CarsApp
  • Transaction type JTA in a JavaEE and
    RESOURCE_LOCAL in a JavaSE
  • Transaction model persists all and commit to
    save or rollback to cancel
  • .properties files containing the labels in the
    user interface

7
Features that are already built into the
application
  • Car.java entity bean
  • Bean to Table relation using annotations
  • Property Change notification
  • Persistence unit META-INF/persistence.xml,
    defines a connection between the database and the
    entity class.
  • Using beans binding (JSR 295) to connect the
    properties of the entity class with the
    properties of the JTable component.
  • The entityManager, query, and list objects,
    which are defined in the CarsView class

8
Adding More Controls
  • Tire Size slider
  • Modernness slider
  • Spoiler checkbox
  • Roof checkbox

9
Binding Controls to Values in the Table
  • In the form, right-click the first slider and
    choose Bind gt value.
  • In the Binding Source drop-down list of the
    Binding dialog box, select masterTable.
  • In the Binding Expression drop-down list, select
    selectedElement gt tiresize.
  • Click the Advanced tab.
  • Select the Unreadable Source Value checkbox.
  • Click the ellipsis (...)button that is next to
    the Unreadable Source Value checkbox.

10
Binding Controls to Values in the Table
  • In the Incomplete Path Value dialog box, select
    Custom Code from the drop-down list. Then type
    the integer 0.
  • Right-click the checkbox and choose Customize
    Code.
  • In white line under the bindingGroup.addBinding(bi
    nding) line, type
  • binding.setSourceUnreadableValue(false)
  • Run application and verify into Databse

11
Setting up a Custom Component
  • Adding Car Preview package
  • Drag the CarPreview.java class (JavaBeans
    component) to the form
  • Bind all the binding properties of the CarPreview
    component to the corresponding selectedElement
    attributes of the masterTable

12
Another simple Database Application with
MasterTable and DetailTable
  • Creating a new Database Connection to Swing_Demo
  • Creating the Application MasterDetailDemo
  • Adding annotation _at_GeneratedValue to Entity beans

13
Changes in detailTable
  • Switch to Binding category in Properties window
  • Select elements property
  • Invoke property customizer (Press ... button)
  • Switch to Advanced tab.
  • Check 'Unreadable Source Value' (ltnonegt should be
    selected in combo next to this check-a1box).

14
Starting of the application with OpenJPA agent
  • Select root node of your project in Projects
    window.
  • Invoke Properties action from contextual menu of
    this node.
  • Select Run node (in the tree on the left).
  • Enter
  • -javaagentltPATH_TO_OPENJPA_JARgt/openjpa-1.0.1.jar
    into VM Options field.

15
Rich Client Application example
  • Creating the Application RichClientApp
  • Creating a Swing Application
  • Separating Business Logic Interfaces from EJB
    Implementation (Module)

16
Swing Application Framework
  • Framework Architecture. Two classes help you
    manage your application (one-to-one
    relationship)
  • ApplicationContext
  • Application
  • ApplicationContext services
  • Localizable resource management
  • Task services and monitoring
  • Event-action management
  • Session-state storage

17
From where to start
  • All Swing Application Framework applications
    must subclass either the Application class or its
    SingleFrameApplication subclass.
  • The SingleFrameApplication adds a default main
    GUI frame, retrieves and injects default
    resources, and uses the ApplicationContext to
    save and restore simple session state. Session
    state includes UI component location, size, and
    configuration.

18
Application Life Cycle
  • launch -- You must call this framework method.
  • initialize -- The framework will invoke this
    optional overridden method.
  • startup -- The framework will invoke this
    overridden method.
  • ready -- The framework will invoke this optional
    overridden method.
  • exit -- You must call this framework method.
  • shutdown -- The framework will invoke this
    optional overridden method.

19
Example subclasses the Application class
  • public class BasicFrameworkApp extends
    Application
  • private JFrame mainFrame private JLabel label
  • protected void startup()
  • mainFrame new JFrame("BasicFrameworkApp")
    mainFrame.setDefaultCloseOperation(JFrame.DO_NOTH
    ING_ON_CLOSE)
  • mainFrame.addWindowListener(new WindowAdapter()
  • public void windowClosing(WindowEvent e)
    mainframe.setVisible(false)
  • exit()
  • )
  • label new JLabel("Hello, world!")
  • mainFrame.add(label)
  • mainFrame.pack()
  • mainFrame.setVisible(true)
  • public static void main(String args)
  • Application.launch(BasicFrameworkApp.class,
    args)

20
Example subclasses the SingleFrameApplication
class
  • public class BasicSingleFrameApp extends
    SingleFrameApplication
  • JLabel label
  • protected void startup()
  • getMainFrame().setTitle("BasicSingleFrameApp")
  • label new JLabel("Hello, world!")
  • label.setFont(new Font("SansSerif", Font.PLAIN,
    22))
  • show(label)
  • public static void main(String args)
  • Application.launch(BasicSingleFrameApp.class,
    args)

21
ExitListener interface
  • The ExitListener interface has two methods
  • public boolean canExit(EventObject e)
  • public void willExit(EventObject e)
