Welcome to 3FF3! Bio-organic Chemistry

1
Welcome to 3FF3!Bio-organic Chemistry

• Jan. 7, 2008

2

• Instructor Adrienne Pedrech
• ABB 417
• Email adriennepedrech_at_hotmail.com
• -Course website http//www.chemistry.mcmaster.ca/
  courses/3f03/index.html
• Lectures MW 830 F 1030 (CNH/B107)
• Office Hours T 1000-1230 F 100-230 or by
  appointment
• Labs
• 230-530 M (ABB 302,306) Note course
  timetable says ABB217 230-530 F (ABB 306)
• Every week except reading week (Feb. 18-22)
  Good Friday (Mar. 21)
• Labs start Jan. 7, 2008 (TODAY!)

3

• For Monday 7th Friday 11th
• Check-in, meet TA, safety and Lab 1 (Isolation of
  Caffeine from Tea)
• Lab manuals Buy today!
• BEFORE the lab, read lab manual intro, safety and
  exp. 1
• Also need
• Duplicate lab book (20B3 book is ok)
• Goggles (mandatory)
• Lab coats (recommended)
• No shorts or sandals
• Obey safety rules marks will be deducted for
  poor safety
• Work at own pacesome labs are 2 or 3 wk labs.
  In some cases more than 1 exp. can be worked in a
  lab periodyour TA will provide instruction

4

• Evaluation
• Assignments 2 x 5 10
• Labs -write up 15
• - practical mark 5
• Midterm 20
• Final 50
• Midterm test
• Fri. Feb. 29, 2008 at 700 pm
• Make-up test TBD
• Assignments Feb.6 Feb.13
• Mar.7 Mar.14
• Note academic dishonesty statement on outline-NO
  copying on assignments or labs (exception when
  sharing results)

5

• Texts
• Dobson Foundations of Chemical Biology,
  (Optional- bookstore)
• Background Refreshers
• An organic chemistry textbook (e.g. Solomons)
• A biochemistry textbook (e.g. Garrett)
• 2OA3/2OB3 old exam on web
• This course has selected examples from a variety
  of sources, including Dobson
• Buckberry Essentials of Biological Chemistry
• Dugas, H. "Bio-organic Chemistry"
• Waldman, H. Janning, P. Chemical Biology
• Also see my notes on the website

6

• What is bio-organic chemistry? Biological chem?
  Chemical bio?
• Chemical Biology
• Development use of chemistry techniques for
  the study of biological phenomena (Stuart
  Schreiber)
• Biological Chemistry
• Understanding how biological processes are
  controlled by underlying chemical principles
  (Buckberry Teasdale)
• Bio-organic Chemistry
• Application of the tools of chemistry to the
  understanding of biochemical processes (Dugas)
• Whats the difference between these???
• Deal with interface of biology chemistry

7
Simple organics eg HCN, H2CO (mono-functional) C
f 20A3/B3
BIOLOGY
CHEMISTRY
Life large macromolecules cellscontain 100,
000 different compounds interacting
Biologically relevant organics polyfunctional
1 Metabolism present in all cell (focus of
3FF3) 2 Metabolism specific species, eg.
Caffeine (focus of 4DD3)
How different are they?
CHEMISTRY Round-bottom flask
BIOLOGY cell
8

• Exchange of ideas
• Biology Chemistry
• Chemistry explains events of biology mechanisms,
  rationalization
• Biology
• Provides challenges to chemistry synthesis,
  structure determination
• Inspires chemists biomimetics ? improved
  chemistry by understanding of biology (e.g.
  enzymes)

9
Key Processes of 1 Metabolism

• Bases sugars ? nucleosides
  nucleic acids
• Sugars (monosaccharides)
  polysaccharides
• Amino acids
  proteins
• Polymerization reactions cell also needs the
  reverse process
• We will look at each of these 3 parts
• How do chemists synthesize these structures?
• How are they made in vivo?
• Improved chemistry through understanding the
  biology biomimetic synthesis

10
Properties of Biological Molecules that Inspire
Chemists

• Large ? challenges for synthesis
• for structural prediction (e.g. protein
  folding)
• 2) Size ? multiple FGs (active site) ALIGNED to
  achieve a goal
• (e.g. enzyme active site, bases in NAs)
• 3) Multiple non-covalent weak interactions ? sum
  to strong, stable binding non-covalent complexes
• (e.g. substrate, inhibitor, DNA)
• 4) Specificity ? specific interactions between 2
  molecules in an ensemble within the cell

11

• 5) Regulated ? switchable, allows control of cell
  ? activation/inhibiton
• 6) Catalysis ? groups work in concert
• 7) Replication ? turnover
• e.g. an enzyme has many turnovers, nucleic
  acids replicates

12
Evolution of Life

• Life did not suddenly crop up in its element form
  of complex structures (DNA, proteins) in one
  sudden reaction from mono-functional simple
  molecules
• In this course, we will follow some of the ideas
  of how life may have evolved

13
RNA World

• Catalysis by ribozymes occurred before protein
  catalysis
• Explains current central dogma
• Which came first nucleic acids or protein?
• RNA world hypothesis suggests RNA was first
  molecule to act as both template catalyst
• catalysis replication

14

• How did these reactions occur in the pre-RNA
  world? In the RNA world? in modern organisms?
• CATALYSIS SPECIFICITY
• How are these achieved? (Role of NON-COVALENT
  forces BINDING)
• a) in chemical synthesis
• b) in vivo how is the cell CONTROLLED?
• c) in chemical models can we design better
  chemistry through understanding biochemical
  mechanisms?

15
Relevance of Labs to the Course

• Labs illustrate
• Biologically relevant small molecules (e.g.
  caffeine Exp 1)
• Structural principles characterization (e.g.
  anomers of glucose, anomeric effect,
  diastereomers, NMR, Exp 2)
• Cofactor chemistry pyridinium ions (e.g. NADH,
  Exp 3 4)
• Biomimetic chemistry (e.g. simplified model of
  NADH, Exp 3)
• Chemical mechanisms relevant to catalysis (e.g.
  NADH, Exp 3)

16

• Application of biology to stereoselective
  chemical synthesis (e.g. yeast, Exp 4)
• Synthesis of small molecules (e.g. drugs,
  dilantin, tylenol, Exp 5,7)
• Chemical catalysis (e.g. protection activation
  strategies relevant to peptide synthesis in vivo
  and in vitro, Exp 6)
• All of these demonstrate inter-disciplinary area
  between chemistry biology

17

• Two Views of DNA
• Biochemists view shows overall shape,
  ignores atoms bonds
• chemists view atom-by-atom structure,
  functional groups illustrates concepts from
  2OA3/2OB3

18
Biochemists View of the DNA Double Helix
Minor groove
Major groove
19
Chemists View
20
BASES

• Aromatic structures
• all sp2 hybridized atoms (6 p orbitals, 6 p e-)
• planar (like benzene)
• N has lone pair in both pyridine pyrrole ?
  basic (H acceptor or e- donor)

21
6 p electrons, stable cation ? weaker acid,
higher pKa ( 5) strong conj. base
sp3 hybridized N, NOT aromatic ? strong acid, low
pKa ( -4) weak conj. base

• Pyrrole uses lone pair in aromatic sextet ?
  protonation means loss of aromaticity
  (BAD!)
• Pyridines N has free lone pair to accept H
• ? pyridine is often used as a base in organic
  chemistry, since it is soluble in many common
  organic solvents

22

• The lone pair also makes pyridine a H-bond
  acceptor e.g. benzene is insoluble in H2O but
  pyridine is soluble
• This is a NON-specific interaction, i.e., any
  H-bond donor will suffice

23
Contrast with Nucleic Acid Bases (A, T, C, G, U)
Specific!

• Evidence for specificity?
• Why are these interactions specific? e.g. G-C
  A-T

24

• Evidence?
• If mix G C together ? exothermic reaction
  occurs change in 1H chemical shift in NMR other
  changes ? reaction occurring
• Also occurs with A T
• Other combinations ? no change!

e.g. Guanine-Cytosine

• Why?
• In G-C duplex, 3 complementary H-bonds can form
  donors acceptors molecular recognition

25

• Can use NMR to do a titration curve
• Favorable reaction because ?H for complex
  formation -3 x H-bond energy
• ?S is unfavorable ? complex is organized ?
  3 H-bonds overcome the entropy of complex
  formation
• Note In synthetic DNAs other interactions can
  occur

26

• Molecular recognition not limited to natural
  bases

Forms supramolecular structure 6 molecules in a
ring
? Create new architecture by thinking about
biology i.e., biologically inspired chemistry!
27
Synthesis of Bases (Nucleic)

• Thousands of methods in heterocyclic chemistry
  well do 1 example
• May be the first step in the origin of life
• Interesting because H-CN/CN- is probably the
  simplest molecule that can be both a nucleophile
  electrophile, and also form C-C bonds

28
Mechanism?
29
Other Bases?
Try these mechanisms!
30
Properties of Pyridine

• Weve seen it as an acid an H-bond acceptor
• Lone pair can act as a nucleophile

31

• Balance between aromaticity charged vs
  non-aromatic neutral!
• ? can undergo REDOX reaction reversibly

32

• Interestingly, nicotinamide may have been present
  in the pre-biotic world
• NAD or related structure may have controlled
  redox chemistry long before enzymes involved!

33
Another example of N-Alkylation of Pyridines
This is an SN2 reaction with stereospecificity
34
References

• Solomons
• Amines basicity ch.20
• Pyridine pyrrole pp 644-5
• NAD/NADH pp 645-6, 537-8, 544-6
• Bases in nucleic acids ch. 25
• Also see Dobson, ch.9
• Topics in Current Chemistry, v 259, p 29-68

35
Sugar Chemistry Glycobiology

• In Solomons, ch.22 (pp 1073-1084, 1095-1100)
• Sugars are poly-hydroxy aldehydes or ketones
• Examples of simple sugars that may have existed
  in the pre-biotic world

36

• Most sugars, i.e., glyceraldehyde are chiral sp3
  hybridized C with 4 different substituents
• The last structure is the Fischer projection
• CHO at the top
• Carbon chain runs downward
• Bonds that are vertical point down from chiral
  centre
• Bonds that are horizontal point up
• H is not shown line to LHS is not a methyl group

37

• In (R) glyceraldehyde, H is to the left, OH to
  the right ? D configuration if OH is on the
  left, then it is L
• D/L does NOT correlate with R/S
• Most naturally occurring sugars are D, e.g.
  D-glucose
• (R)-glyceraldehyde is optically active rotates
  plane polarized light (def. of chirality)
• (R)-D-glyceraldehyde rotates clockwise, ? it is
  the () enantiomer, and also d-, dextro-rotatory
  (rotates to the right-dexter)
• ? (R)-D-()-d-glyceraldehyde
• its enantiomer is (S)-L-(-)-l-glyderald
  ehyde
• ()/d (-)/l do NOT correlate

38

• Glyceraldehyde is an aldo-triose (3 carbons)
• Tetroses ? 4 Cs have 2 chiral centres
• 4 stereoisomers
• D/L erythrose pair of enantiomers
• D/L threose - pair of enantiomers
• Erythrose threose are diastereomers
  stereoisomers that are NOT enantiomers
• D-threose D-erythrose
• D refers to the chiral centre furthest down the
  chain (penultimate carbon)
• Both are (-) even though glyceraldehyde is () ?
  they differ in stereochemistry at top chiral
  centre
• Pentoses D-ribose in DNA
• Hexoses D-glucose (most common sugar)

39
(No Transcript)
40
Reactions of Sugars

• The aldehyde group
• Aldehydes can be oxidized
• reducing sugars those that have a free
  aldehyde (most aldehydes) give a positive
  Tollens test (silver mirror)
• Aldehydes can be reduced

41

• Reaction with a Nucleophile
• Combination of these ideas ? Killiani-Fischer
  synthesis used by Fischer to correate
  D/L-glyceraldehyde with threose/erythrose
  configurations

42
(No Transcript)
43
Reactions (of aldehydes) with Internal
Nucleophiles

• Glucose forms 6-membered ring b/c all
  substituents are equatorial, thus avoiding
  1,3-diaxial interactions

44

• Can also get furanoses, e.g., ribose

• Ribose prefers 5-membered ring (as opposed to
  6) otherwise there would be an axial OH in the
  6-membered ring

45

• Why do we get cyclic acetals of sugars? (Glucose
  in open form is ltlt 1)
• Rearrangement reaction we exchange a CO bond
  for a stronger C-O s bond ? ?H is favored
• There is little ring strain in 5- or 6- membered
  rings
• ?S there is some loss of rotational entropy in
  making a ring, but less than in an intermolecular
  reaction1 in, 1 out.

significant ve ?S! ??G ?H -
T?S
Favored for hemiacetal
Not too bad for cyclic acetal
46
Anomers

• Generate a new chiral centre during hemiacetal
  formation (see overhead)
• These are called ANOMERS
• ß-OH up
• a-OH down
• Stereoisomers at C1 ?diastereomers
• a- and ß- anomers of glucose can be crystallized
  in both pure forms
• In solution, MUTAROTATION occurs

47
Mutatrotation
48
In solution, with acid present (catalytic), get
MUTAROTATION not via the aldehyde, but oxonium
ion

• At equilibrium, 3862 aß despite a having an
  AXIAL OHWHY? ANOMERIC EFFECT

49
Anomeric Effect
oxonium ion
O lone pair is antiperiplanar to C-O s bond ?
GOOD orbital overlap (not the case with the
ß-anomer)
50
Projections
51
More Reactions of Sugars

• Reactions of OH group(s)
• Esterification
• Ethers

52
b) Ethers (cont)

1. Acetals

53
c) Acetals (cont)
54

• These reactions are used for selective protection
  of one alcohol activation of another
  (protecting group chemistry)

1 alcohol is most reactive ?protect first
AZT
55
e.g, synthesis of sucrose (Lemieux, Alberta)

• Can only couple one wayif we dont protect, get
  all different coupling patterns
• Yet nature does this all of the time enzymes
  hold molecules together in the correct
  orientation, BUT the mechanism still goes through
  an oxonium ion (more on this later)

56
Selectivity of Anomer Formation in Glycosides

• Oxonium ion can often be attacked from both Re
  Si faces to give a mixture of anomers.
• How do we control this?

57
This reaction provides a clue to how an enzyme
might stabilize an oxonium ion (see later)
