1
RCDsSystem pro M compact
  • ABB SACE LPD

2
RCDs 3 families
RCCBs
RCBOs
Blocks
  • (with MCBs)
  • Overload
  • Short circuit
  • Earth leakage
  • Indirect contact
  • Earth leakage
  • Indirect contact
  • Overload
  • Short circuit
  • Earth leakage
  • Indirect contact

3
Future ABB RCDs range
  • RCCBs
  • F 200 AC / F 200 A RCCBs Type AC/A (ex
    F360/F370)
  • RCBOs
  • DS 200 AC / DS 200 A RCBOs Type AC/A 6kA
    (ex DS650/DS750)
  • DS 200 M AC / DS 200 M A RCBOs Type AC/A
    10kA (ex DS670/F270)
  • RCD-blocks
  • DDA 200 AC / DDA 200 A RCD blocks Type AC/A
    (ex DDA60/DDA70)

4
Future ABB RCCBs commercial designation
F202 A S - 63/0,03
Sensitivity 0,03A, 0,1A
Current 25A 40A 63A
Tripping time S for selective
Type AC A
N of poles 2 4
Family F200 RCCBs
5
Future ABB RCBOs commercial designation
Tripping characteristic B, C
B. cap. 4,5kA, 6kA
DS202 L A S - C10/0,03
Sensitivity0,03A, 0,1A
Current 6A, 10A.63A
Tripping time S for selective
Type AC A
N of poles 1N 2 3 4
Family DS200 RCBOs
6
Future ABB RCD-blocks comm. designation
DDA202 A S - 25/0,03
Sensitivity 0,03A, 0,1A
Current 25A 40 63A
Tripping time S for selective
Type AC A
N of poles 2 3 4
Family DDA200 RCD-blocks
7
Migration old to new series
8
A range of RCDs for all application
RCCBs standard and special ranges
9
A range of RCDs for all application
RCD-blocks standard and special ranges
10
A range of RCDs for all application
11
Against nuisance tripping special ranges
Problem unwanted tripping
  • The causes
  • Atmospheric discharges (lightnings)
  • Operational discharges (switch-off in MV)
  • Consequences in RCDs
  • Sudden and unjustified tripping (out of service)

12
ABB solution RCCB-AR aut. reclosing device
Future F200
Present F3
RCCB
AR unit

Factory fitted
Fitted by customer
  • Advantages
  • Flexibility for wholesalers and LSO
  • Higher number of possible configuration

13
ABB solution RCCB-AP no unwanted tripping
Present F3 and DDA AP
Future F200 and DDA200 AP-R and G type
  • Features
  • 8/20µs surge current test 3000A
  • AC and A type available
  • AP-R and G (Austrian) commercial designation

14
RCCBs design
  • New design
  • Differently from the present F3 series, the new
    F200 series hasnt any projection on the front
    side, thus guaranteeing a better homogeneity
    with MCBs ranges.
  • Moreover the upper and lower shoulders have
    been eliminated.

F 202
F 202
F 362
15
RCCBs new terminal features
  • Tightening
  • The new terminal has two distinct slots which
    can be wired.
  • The front slot of the terminal can be wired
    with cables up to 25 mm2, while the back one is
    suitable for wiring with busbars or cables up to
    10 mm2.
  • In the screwing phase, the closing of the two
    slots is carried out in two opposite directions
    (bi-directional movement), thus guaranteeing a
    maximum tightening torque of 2,8 Nm.

Open terminal
Closed terminal
16
RCCBs new terminal features
  • Wiring
  • The availability of two slots for each
    terminal offers different wiring
    solutions thanks to the possibility of
    deriving independently two cables/each terminal
    from the same RCCB. The back space, in fact,
    can be used for another circuit, for an
    auxiliary circuit or to feed instruments with
    small section cables without having to connect
    them in the same space of the power cables.

17
RCCBs new terminal demo
18
RCCBs new terminal features
  • Safety
  • The structure of the new terminal avoids wrong
    wiring operations once the terminal is closed,
    in fact, the two spaces arent accessible
    anymore.

19
RCCBs safer wiring with cables demo
20
RCCBs new terminal features
  • Plus of wiring with busbars
  • Differently from the past solution, the busbars
    are fitted in the back terminals slot so that
    the front side of the terminal is completely
    visible during the wiring operation .
  • The wiring is now easier for installers and
    also the accessibility in case of maintenance
    operations is improved.

F 202
F 362
21
RCCBs positive contact indication (PCI)
  • More Information with PCI
  • RCCBs can support, during their life, high
    short circuit currents for a short time
    (until MCBs intervene).
  • Sometimes, owing to repeated short-circuits or
    in presence of MCBs not opportunely coordinated,
    the RCCB might be damaged internally and its
    contacts can result partially welded , and in
    this case the circuit could be live also in the
    open position.
  • The presence of the PCI on all products of
    F200 range guarantees the verification of the
    RCCB efficiency .

22
RCCBs improved short circuit performance
Short circuit performances combination
  • MKTs that dont use RCD-blocks need higher
    coordination performances for RCCBs, in order
    to be used in all industrial application
  • Im and Inc are more and more used in technical
    specification of consultants/engineers
  • ABB product reaches a level of coordination good
    for domestic/civil application but low if
    compared with competitors performances-----?

23
RCCBs improved short circuit performance (2)
Short circuit performances combination
of Imshort-circuit breaking capacity Inccond
itional short-circuit breaking capacity
  • Future F200
  • Im1000 A
  • Inc10000A with 100A gL SCPD
  • Present F3
  • Im1500 A
  • Inc6000A with 63A gL fuse SCPD

24
RCCBs auxiliary elements
  • The range of auxiliary elements include
  • Auxiliary contact S2C-H 6R (H)
  • Universal Auxiliary/Signal contact S2C-S/H
    6R (S/H)
  • Undervoltage release (UR)
  • 6 models for different voltage levels
  • Automatic Reclosing Unit (AR)
  • motor deviceenclosed logic unit only as add
    on to circuit-breaker

25
RCCBs auxiliary elements
Fitting on RCCBs
26
RCCBs auxiliary elements
Present F 3..
RCCB 2P or 4P H
  • H auxiliary contact
  • S/H auxiliary/signal contact
  • UR undervoltage release

27
RCCBs new packaging system
2P
1)
2)
3)
4P
1)
2)
3)
28
RCD-blocks an auxiliary release for MCBs
DDA200 blocks will be fitted on the left side
of S200 MCBs allowing a complete accessoriability
for the MCB
MCD
UR H H H UR S/H H H
S200 2P, 3P or 4P
S/H H H H H H
ST H H H ST S/H H H
DDA200 2P, 3P or 4P
29
RCD-blocks tailored to the necessity
DDA200 blocks are divided in 3 sizes (In) for
2P, 3P and 4P pole configuration with only 2
phisical sizes
Present DDA
Future DDA200
2P - 25-40-63A 3P, 4P - 25A
2P - 25-40-63A 3P, 4P 25-40A
3P, 4P - 40A
3P, 4P - 63A
3P, 4P - 63A
30
RCD- Blocks fitting on MCBs
Also DDA200 have the fitting pins shaped
according to the size of the MCB to assemble.
31
RCD- Blocks fitting on MCBs
In compliance with IEC/EN 61009 standard, DDA200
have a new fitting system withclips in order to
prevent that RCD-Block could be disassembled once
fitted to the MCB.
32
RCD-blocks easier installation
Housing with holes in the upper side
  • assure an easy wiring of MCBs fitted with
    RCD-blocks with standard busbars
  • allow the possibility to fit MCBs fitted with
    RCD-blocks on the ways of Type B distribution
    boarD

33
RCD-blocks additional feature
Additional terminal for remote tripping on 63A
size DDA-blocks
  • add the function of remote tripping to a
    standard DDA200 block
  • allows space and cost saving for the customer
    when an auxiliary emergency circuit is needed
    for an RCBO (MCBRCD-block)?no need for
    additional shunt trip

34
