Cellular Level of Organization

1
Cellular Level of Organization

2
Introduction

• Two types of cells
• Sex cells (haploid)
• Somatic cells (diploid)

3
(No Transcript)
4
Cell Membranes

• 4 main functions

5
1. Physcial Isolation

• Separates inside of cell from outside

6
2. Selectively Permeable Membrane

• Regulates exchange with the environment

7
3. Sensitivity

• Contains receptors

8
4. Structural Support

• The cell membrane can connect to other cells or
  extracellular proteins

9
Cell Membrane Structure

• Hydrophilic head
• Hydrophobic tails

10
(No Transcript)
11
Cell Membrane Structure

• Ions and water soluble compounds cannot cross the
  membrane

12
Cell Membrane Structure

• This separates the extracellular fluid from the
  cytosol which is important for homeostasis

13
What are in membranes?

• 1. Cholesterol

14
(No Transcript)
15
What are in membranes?

• Integral proteins

16
(No Transcript)
17
What are in membranes?

• Enzymes
• Catalyzes reactions

18
What are in membranes?

• Receptor proteins
• Protein lock
• Ligand - key

19
What are in membranes?

• 5. Carrier Protein
• Transports things across the membrane

20
What are in membranes?

• Channels
• Allows continuous movements of ions and water
  soluble materials

21
What are outside cell membranes?

1. Peripheral proteins
2. Glycoproteins
3. Glycolipids

22
(No Transcript)
23
Glycoprotiens and glycolipids

• Can tell if certain cells are normal or abnormal
  by their glycoproteins and glycolipids

24
Organelles

• Components of cells

25
1. Cytoskeleton

• Strength and flexibility
• Composed of 3 main structures
• Microfilaments ( actin )
• Intermediate filaments ( collagen )
• Microtubules ( tubulin )

26
(No Transcript)
27
2. Microvilli

• Increase surface area
• Finger-shaped projections of cell membranes

28
3. Centrioles

• Their involved in cell division
• Not found in RBC, skel. muscle cells, cardiac
  muscle cells, and neuron cells

29
(No Transcript)
30
4. Cilia

• Long slim extensions of the cell membrane
• Found in trachea

31
5. Ribosomes

• Synthesize proteins
• Composed of two subunits ( one small and one
  large)
• Free ribosomes
• Fixed ribosomes

32
(No Transcript)
33
(No Transcript)
34
6. Endoplasmic Reticulum

• Network within the cytoplasm attached to the
  nucleus

35
(No Transcript)
36
(No Transcript)
37
6. Endoplasmic Reticulum

• Two types
• SER
• RER

38
(No Transcript)
39
(No Transcript)
40
6. Endoplasmic Reticulum

• SER
• Detoxifies drugs or toxins
• Synthesizes lipids and carbs

41
6. Endoplasmic Reticulum

• RER
• Transports materials and synthesizes proteins

42
7. Golgi Apparatus

• Proteins come from the ER into the golgi for
  modification

43
(No Transcript)
44
(No Transcript)
45
8. Lysosome

• Breaks down and recycles organelles
• Breaks down bacteria and foreign material

46
(No Transcript)
47
(No Transcript)
48
9. Peroxisomes

• Breaks down fatty acids and organic compounds

49
(No Transcript)
50
10. Mitochondria

• Powerhouse of the cell
• Produces ATP energy
• Contains two membranes (outer and inner)

51
(No Transcript)
52
(No Transcript)
53
11. Nucleus

• Chromosomes are stored here
• Composed of DNA

54
Membrane Transport

• Membranes are selectively permeable

55
Membrane Transport

• Passive processes do not require energy

56
Membrane Transport

• Active processes require energy

57
Membrane Transport

• 3 major ways in which materials are transported
• Diffusion
• Carrier-mediated transport
• Vesicular transport

58
Diffusion

• Hypotonic solution less concentrated

59
1. Diffusion

• Hypertonic more concentrated

60
1. Diffusion

• Isotonic solutions equal concentration

61
1. Diffusion

• Solutes move from hypertonic solution to
  hypotonic solution

62
Ions and Water

• Remember ions and water must pass through channels

63
Lipid Soluble Substances

• Alcohol, fatty acids, and steroids are lipid
  soluble

64
O2 and CO2

• O2 and CO2 pass easily

65
Glucose

• Glucose to big to cross cell membrane

66
2. Carrier-Mediated Transport

• Can be passive or active

67
2. Carrier-Mediated Transport

• Proteins carry substances across

68
2. Carrier-Mediated Transport

• Sometimes carries two things at once (cotransport)

69
2. Carrier-Mediated Transport

• Sometimes carries to things in opposite
  directions (countertrasnport)

70
2. Carrier-Mediated Transport

1. Fascilitated Diffusion
2. Active Transport
3. Secondary Active Transport

71
Facilitated Diffusion

• Passive

72
Facilitated Diffusion

• Carries substances such as glucose and amino acids

73
Facilitated Diffusion

• Goes down conc. Gradient but limited to number of
  carrier proteins

74
Active Transport

• Requires energy

75
Active Transport

• Not dependent on concentration gradient

76
Active Transport

• Ion pumps use active transport

77
Active Transport

• Exchange pumps move two kinds of ions in
  different directions
• Example Na/K Pump

78
Na/K Pump

• Na higher in concentration outside cell
• K higher in cell

79
Na/K Pump

• Sometimes Na diffuses into cell and K leaves
  through leaky channels

80
Na/K Pump

• Na/K pump puts things back into order

81
Na/K Pump

• Ejects on average 3Na and bringing in 2K ions

82
(No Transcript)
83
Secondary Active Transport

• Does not require energy

84
Secondary Active Transport

• Goes down a conc. gradient

85
Secondary Active Transport

• It uses the concentration gradient of a molecule
  as the driving force to move another molecule
  against the concentration gradient

86
3. Vesicular Transport

• Requires energy

87
3. Vesicular Transport

1. Endocytosis
2. Exocytosis

88
Endocytosis

• Imports substances into the cell

89
Endocytosis

1. Receptor mediated endocytosis
2. Pinocytosis
3. Phagocytosis

90
Receptor Mediated Endocytosis

• Extremely selective

91
Receptor Mediated Endocytosis

• Plasma membrane proteins bind only with certain
  substances

92
(No Transcript)
93
Pinocytosis

• Cell drinking

94
Pinocytosis

• Dissolved proteins gather on the external surface
  of the plasma membrane, causing the membrane to
  invaginate and to incorporate a droplet of fluid

95
(No Transcript)
96
Phagocytosis

• Cell eating

97
Phagocytosis

• Parts of the plasma membrane flow around a
  relatively large or solid material and engulf it.

98
(No Transcript)
99
Exocytosis

• Expels material out of the cell
