Enabling Automated Design Space Exploration for Parallel Embedded Systems

1
(No Transcript)
2
Virtual platforms and timing analysis status,
challenges, and future directions

• Marco Di Natale
• GM Research and Development
• ECI/ECSA Lab. Warren, MI USA

3
Outline

• Automotive architecture trends and challenges
• Platform-based system-level design and timing
  evaluation metrics
• Issues with model-based design
• Time predictability and timing isolation
• From analysis to synthesis

4
Evolution of Integrated Functions
Post-2014
function17
function16
function15
function14
to 2012/14
function13
function12
function11
function10
to 2010/12
function9
function8
function7
function6
function5
ACC
Pre-2004
Stabilitrak 2
Onstar emergency notification
Speed-dependant volume
Body
HVAC
Telematics
Transmiss.
Engine
Occupant Information
Exterior lighting
Occ. protection
Infotainm.
Environm. sensing
Object detection
Suspension
Steering
Brake
Subsystem
5
Automotive architecture trends

• Horizontally-integrated functions are becoming
  key differentiators and are gaining increasing
  authority
• An increasing number of functions will be
  distributed on a decreasing number of ECUs and
  enabled through an increasing number of smart
  sensors and actuators
• today gt 5 buses and gt 30 ECUs
• 90 of innovation in cars for the foreseeable
  future will be enabled through the Electronic
  Vehicle Architecture
• Transition from single-ECU Black-box based
  development processes to a system-level
  engineering process
• System-level methodologies for quantitative
  exploration and selection,
• From Hardware Emulation to Model Based
  Verification of the System
• Architectures need to be defined years ahead of
  production time, with incomplete information
  about (future) features
• Multiple non-functional requirements can be
  defined

6
Outline

• Automotive architecture trends and challenges
• Platform-based system-level design and timing
  evaluation metrics
• Issues with model-based design
• Time predictability and timing isolation
• From analysis to synthesis

7
Deployment Design Process
8
Functional model
Input interface
Output interface
signal
s2
s1
s4
f2
f1
f3
period is_trigger precedence
f4
s3
Functional model
function
s5
period activation mode
Jitter constraint
f5
f6
deadline
9
Architecture model
s2
s1
s4
f2
f1
f3
f4
s3
Functional model
s5
f5
f6
ECU2
ECU1
ECU3
Execution architect. model
OSEK1
bus
CAN1
speed (b/s)
ECU
clk speed (Mhz) register width
10
Deployment model
s2
s1
s4
f2
f1
f3
f4
s3
Functional model
s5
f5
f6
System platform model
Execution architect. model
11
Tool integration platform
System-level virtual prototyping and architecture
selection
Requirements
Virtual prototyping (virtual platforms)
Model
Model
Model
Validation
Model
Model
Model
Debugging
Unit Testing
Prototype
Prototype
Prototype
Model
Model
Model
Integr. Testing
Prototype
12
Design Process and Requirement
13
Functional Model An example
Function Example xxx
14
Architecture Model An example
15
Deployment An example
End-to-end latencies ECU and bus utilizations
16
Periodic Activation Model
17
Data Driven Activation Model
18
Case study 1

• By transmitting messages on event, the worst
  case latency can be reduced in most cases
• By properly allocating functions to ECUs the
  end-2-end latency can be improved

19
Outline

• Automotive architecture trends and challenges
• Platform-based system-level design and timing
  evaluation metrics
• Issues with model-based design
• Time predictability and timing isolation
• From analysis to synthesis

20
Issues with model-based development

• Model-based design methodologies
• improve the quality and the reusability of
  software.
• The possibility of defining components
  (subsystems) at higher levels of abstraction and
  with well defined interfaces allows separation of
  concerns and improves modularity and reusability.

• The availability of verification tools (often by
  simulation) gives the possibility of a
  design-time verification of the system
  properties.
• However, most modern tools for model-based design
  have a number of shortcomings

21
Issues with model-based development

• Lack of separation between the functional model
  and the architecture model
• Lack of support for the definition of the task
  and resource model
• Insufficient support for the specification of
  timing constraints and attributes
• Lack of modeling support for the analysis and the
  back-annotation of scheduling-related delays
• Issue of semantics preservation

22
Outline

• Automotive architecture trends and challenges
• Platform-based system-level design and timing
  evaluation metrics
• Issues with model-based design
• Time predictability and timing isolation
• Composability and AUTOSAR
• From analysis to synthesis

23
From priorities to resource reservation

• Tasks from different applications (IPs) may be
  executed in the same ECU
• freedom of relocating code as in AUTOSAR
• Functional protection
• Enabled by processes with protected addressing
  space (as in OSEK revision)
• Temporal protection
• Protect each the temporal behaviour of each task
  from the other tasks
• Each task should execute as if it were on a
  dedicated slower processor

24
Priority-based scheduling

• What is wrong with (OSEK-like) static priorities
  ?

executing too much...
Deadline miss!
Correct behavior
Timing fault
25
Resource reservation

• Class of techniques that provide temporal
  protection
• Each task is assigned a fraction of the resource
• The task is allocated at least the reserved
  fraction of the resource
• The concept has been around for 15 years in
  Communication Networks
• Packet switching (PS, GPS, WFQ, WF2Q, )
• Type of guarantees
• The services actually receivedby the stream will
  be bound between min (lag) and max (lead) of
  the share it should receive

26
Outline

• Automotive architecture trends and challenges
• Platform-based system-level design and timing
  evaluation metrics
• Issues with model-based design
• Time predictability and timing isolation
• Composability and AUTOSAR
• From analysis to synthesis

27
Opportunities for synthesis
Number and type of ECUs and buses System topology
Periods Activation modes
Function to ECU allocation
Task and message priorities
Function to task mapping
28
QA
Thank you!
