CSE325 Computers and Sculpture

1
CSE325 Computersand Sculpture

• Prof. George Hart

2
Symmetry

• Intuitive notion mirrors, rotations,
• Mathematical concept set of transformations
• Possible 2D and 3D symmetries
• Sculpture examples
• M.C. Escher sculpture
• Carlo Sequins EscherBall program
• Constructions this week based on symmetry

3
Intuitive uses of symmetry

• left side right side
• Human body or face
• n-fold rotation
• Flower petals
• Other ways?

4
Mathematical Definition

• Define geometric transformations
• reflection, rotation, translation (slide),
• glide reflection (slide and reflect), identity,

• A symmetry is a transformation
• The symmetries of an object are the set of
  transformations which leave object looking
  unchanged
• Think of symmetries as axes, mirror lines,

5
Frieze Patterns
Imagine as infinitely long. Each frieze has
translations. A smallest translation generates
all translations by repetition and
inverse. Some have vertical mirror lines. Some
have a horizontal mirror. Some have 2-fold
rotations. Analysis shows there are exactly seven
possibilities for the symmetry.
6
(No Transcript)
7
Wallpaper Groups

• Include 2 directions of translation
• Might have 2-fold, 3-fold, 6-fold rotations,
  mirrors, and glide-reflections
• 17 possibilities
• Several standard notations. The following slides
  show the orbifold notation of John Conway.

8
Wallpaper Groups
o
2222
xx

2222
22
9
Wallpaper Groups
442
x
22x
442
222
42
10
Wallpaper Groups
333
33
333
Images by Xah Lee
632
632
11
3D Symmetry

• Three translation directions give the 230
  crystallographic space groups of infinite
  lattices.
• If no translations, center is fixed, giving the
  14 types of polyhedral groups
• 7 families correspond to a rolled-up frieze
• Symmetry of pyramids and prisms
• Each of the seven can be 2-fold, 3-fold, 4-fold,
• 7 correspond to regular polyhedra

12
Roll up a Frieze into a Cylinder
13
Seven Polyhedra Groups

• Octahedral, with 0 or 9 mirrors
• Icosahedral, with 0 or 15 mirrors
• Tetrahedral, with 0, 3, or 6 mirrors
• Cube and octahedron have same symmetry
• Dodecahedron and icosahedron have same symmetry

14
Symmetries of cube Symmetries of octahedron
In dual position symmetry axes line up
15
Cube Rotational Symmetry

• Axes of rotation
• Three 4-fold through opposite face centers
• four 3-fold through opposite vertices
• six 2-fold through opposite edge midpoints
• Count the Symmetry transformations
• 1, 2, or 3 times 90 degrees on each 4-fold axis
• 1 or 2 times 120 degrees on each 3-fold axis
• 180 degrees on each 2-fold axis
• Identity transformation
• 9 8 6 1 24

16
Cube Rotations may or may not Come with Mirrors
If any mirrors, then 9 mirror planes. If put
squiggles on each face, then 0 mirrors
17
Icosahedral Dodecahedral Symmetry
Six 5-fold axes. Ten 3-fold axes. Fifteen
2-fold axes There are 15 mirror planes. Or
squiggle each face for 0 mirrors.
18
Tetrahedron Rotations
Four 3-fold axes (vertex to opposite face
center). Three 2-fold axes.
19
Tetrahedral Mirrors

• Regular tetrahedron has 6 mirrors (1 per edge)
• Squiggled tetrahedron has 0 mirrors.
• Pyrite symmetry has tetrahedral rotations but 3
  mirrors

20
Symmetry in Sculpture

• People Sculpture (G. Hart)
• Sculpture by M.C. Escher
• Replicas of Escher by Carlo Sequin
• Original designs by Carlo Sequin

21
People
22
Candy BoxM.C. Escher
23
Sphere with FishM.C. Escher, 1940
24
Carlo Sequin, after Escher
25
Polyhedron with FlowersM.C. Escher, 1958
26
Carlo Sequin, after Escher
27
Sphere with Angels and DevilsM.C. Escher, 1942
28
Carlo Sequin, after Escher
29
M.C. Escher
30
Construction this Week

• Wormballs
• Pipe-cleaner constructions
• Based on one line in a 2D tessellation

31

• The following slides are borrowed from
• Carlo Sequin

32
Escher Sphere Construction Kit
Jane YenCarlo SéquinUC BerkeleyI3D 2001
1 M.C. Escher, His Life and Complete Graphic
Work
33
Introduction

• M.C. Escher
• graphic artist print maker
• myriad of famous planar tilings
• why so few 3D designs?

2 M.C. Escher Visions of Symmetry
34
Spherical Tilings

• Spherical Symmetry is difficult
• Hard to understand
• Hard to visualize
• Hard to make the final object

1
35
Our Goal

• Develop a system to easily design and manufacture
  Escher spheres - spherical balls composed of
  tiles
• provide visual feedback
• guarantee that the tiles join properly
• allow for bas-relief
• output for manufacturing of physical models

36
Interface Design

• How can we make the system intuitive and easy to
  use?
• What is the best way to communicate how spherical
  symmetry works?

37
Spherical Symmetry

• The Platonic Solids

38
How the Program Works

• Choose a symmetry based on a Platonic solid
• Choose an initial tiling pattern to edit
• starting place
• Example
• Tetrahedron

R3
R2
Tile 1
Tile 2
39
Initial Tiling Pattern
easier to understand consequences of moving
points guarantees proper tiling requires user
to select the right initial tile - can only
make monohedral tiles
2
Tile 2
Tile 1
Tile 2
40
Modifying the Tile

• Insert and move boundary points
• system automatically updates the tile based on
  symmetry
• Add interior detail points

41
Adding Bas-Relief

• Stereographically projected and triangulated
• Radial offsets can be given to points
• individually or in groups
• separate mode from editing boundary points

42
Creating a Solid

• The surface is extruded radially
• inward or outward extrusion, spherical or
  detailed base
• Output in a format for free-form fabrication
• individual tiles or entire ball

43
Video
44
Fabrication Issues

• Many kinds of manufacturing technology
• we use two types based on a layer-by-layer
  approach

45
FDM Fabrication
moving head
Inside the FDM machine
support material
46
Z-Corp Fabrication
infiltration
de-powdering
47
Results
FDM
48
Results
FDM Z-Corp
49
Results
FDM Z-Corp
50
Results
Z-Corp
51
Conclusions

• Intuitive Conceptual Model
• symmetry groups have little meaning to user
• need to give the user an easy to understand
  starting place
• Editing in Context
• need to see all the tiles together
• need to edit the tile on the sphere
• editing in the plane is not good enough
  (distortions)
• Part Fabrication
• need limitations so that designs can be
  manufactured
• radial manipulation
• Future Work
• predefined color symmetry
• injection molded parts (puzzles)
• tessellating over arbitrary shapes (any genus)
