Destaco Pneumatic Clamps
www.seimitsu.in
2
Compensating

• Hook Pin Clamps
• Tollerance compensation 0-5 mm
• PNP sensor with M12X1 cable connetctor
• Two fingers perpendicular to standard direction

Destaco Pneumatic Clamps
3
Pin Packages 85D5
Sensors can be mounted on either side of unit
40 MM stroke
NAAMS Standard Rotated 180
Hand lever side can be attached on either side
of unit
Inductive Sensing System with 90 Connector
sales_at_seimitsu.in
4
82M Series Enclosed Power Clamp
optional U-Arms and Cylinders with Internal Hold
Open Device Front Mount available for 82M and TCC
size 40mm Front Mount available for 82M and TCC
size 40mm Using Allen wrench, release mechanism
Tighten to 20 Nm.
Your Solution Partner..!!
5
Pneumatic Swing Clamps 8000 Series
SEIMITSU Factory Automation Pvt Ltd
Threaded body may be mounted in a tapped hole or
a clearance hole with optional mounting
flange. Sensor ready for use with round style
sensors Clamp arm and spindle included
6
Pneumatic Swing Clamps
89E series
89B Series

• Lightweight and robust, designed for several
  million cycles
• Can be mounted from the side or the top
• Sensor ready for T-slot style sensors
• Metric design, Clamp arm sold separately

Lightweight and robust, designed for several
million cycles. Threaded body may be mounted in
a tapped hole or a clearance hole with an
optional mounting flange Metric design, Clamp
arm sold separately
