Zener Voltage Regulator.

1
Zener Voltage Regulators

• CEC

2
Contents

• Block Diagram of a Power Supply.
• Zener Diode Characteristics.
• Unloaded Zener Voltage Regulator.
• Loaded Zener Voltage Regulator.
• Zener Regulator Design.
• Line Regulation and Load Regulation.

3
Power Supply

4
Zener Diodes

• Special diodes optimized for operation in the
  breakdown region.
• Connected in parallel with the load of the power
  supply.
• Zener voltage remains constant despite load
  current variations.
• Voltage regulation is the most common
  application.

5
Zener Diode V/I Characteristics

• Zener diode acts like an ordinary silicon
  rectifier diode when forward biased.
• Forward voltage drop of about 0.7 V when
  conducting.
• In the reverse-bias region, a small reverse
  leakage current flows until the breakdown voltage
  reached.
• Reverse current (zener current) increases sharply
  beyond breakdown.

6
Zener Diode V/I Characteristics

• Breakdown voltage remains nearly constant as the
  zener current increases.
• Zener Voltage VZ remains constant even though
  zener current IZ varies over a wide range.
• Zener diode can be used in voltage regulation
  circuits.
• Zener voltage VZ specified at a test current IZT.

7
Zener Diode V/I Characteristics

Current rises sharply beyond breakdown voltage
Behaves like an ordinary diode
Very small current
8
Power Rating of a Zener Diode

• Zener power dissipation PZ VZIZ
• PZ - power dissipated by the zener diode,
• VZ - zener voltage, IZ - zener current.
• Power dissipated in a zener diode must always be
  less than its power dissipation rating PZM.
• Maximum current that a zener can safely handle

9
Unloaded Zener Regulator
Vin Vout dropped across Rs
IS
Is Iz
No Load Resistance
10
Loaded Zener Regulator
IS IZ IL
Load Resistance
11
Zener Regulator with Adjustable Load
Variable
12
Zener Voltage Regulator Design

2.4K
13
Zener Voltage Regulator Design

14
Zener Voltage Regulator Design

15
Zener Voltage Regulator Design

16
Zener Voltage Regulator Circuit Diagram

, 0.5 W
17
? indicates change.
VNL No load output voltage. VFL - Output
voltage under full load.
18
Other Regulators

• Transistor Voltage Regulators Series and Shunt.
• Buck, Boost and Buck-Boost Regulators.
• IC Fixed Voltage Regulators - IC 78xx (positive)
  and IC 79xx (negative) (5V to 15 V).
• Adjustable (Variable) Voltage Regulators using
  ICs LM 317.

19
Thank You
