Introduction
If you operate in a factory, distribution centre,
or warehouse using an automated storage system,
vertical lift module, or vertical carousel and
aren't familiar with the different components of
vertical storage systems, consult this glossary
of terms.
www.verticalcarouselsaustralia.com.au
3
Automated Storage and Retrieval System (ASRS)
The Automated Storage and Retrieval System (ASRS)
is a collection of software-controlled devices
that store and retrieve inventory automatically.
www.verticalcarouselsaustralia.com.au
4
Clear Height
The area above a building's ceiling that is free
of HVAC pipes and equipment, lighting fixtures,
and other things.
www.verticalcarouselsaustralia.com.au
5
Carrier
A system's one-of-a-kind storage unit. It's
occasionally used instead of a tray or a shelf
when neither is available.
www.verticalcarouselsaustralia.com.au
6
Ergonomics

• In vertical storage systems, ergonomics refers
  to the process of getting all parts to the
  "golden zone" (the area between the shoulders and
  the waist) for picking.
• As a result of improved ergonomics, employees
  who utilise the vertical storage system on a
  daily basis will suffer fewer workplace accidents
  and have higher job satisfaction.
• Vertical carousels and storage systems keep
  supplies at workable height, eliminating the need
  for users to bend over, reach for a high shelf,
  or climb ladders to retrieve what they need.

www.verticalcarouselsaustralia.com.au
7
Cube
The volume of storage space can be calculated in
three dimensions, rather than only by looking at
the square footage of a facility.
www.verticalcarouselsaustralia.com.au
8
Heavy Duty

• Medium- and heavy-duty operations require more
  than one shift throughout the course of a
  five-day workweek.
• If you're working three shifts seven days a
  week, it's better to buy new equipment than to
  use old equipment.
• Purchasing new equipment is usually the greatest
  solution for lowering the chance of failures and
  downtime.
• If you're working on a light or medium-duty
  schedule, buying used equipment and materials
  makes more sense.

www.verticalcarouselsaustralia.com.au
9
Kardex
Kardex Remstar is a vertical storage system
manufacturer in Europe. The Kardex Remstar
Shuttle and the Kardex Remstar Megamat are the
two models available.
www.verticalcarouselsaustralia.com.au
10
Hanel
Hanel is a European vertical storage system
manufacturer. The Hanel Rotomat and the Hanel
Lean Lift are two options.
www.verticalcarouselsaustralia.com.au
11
Modula
Modula is a manufacturer of vertical storage
systems situated in the United States and Europe.
The Modula Lift and the Modula Sintes1 are the
two variations available.
www.verticalcarouselsaustralia.com.au
12
Remstar
Please consult Kardex for Remstar.
www.verticalcarouselsaustralia.com.au
13
Tray

• A system's one-of-a-kind storage space.
  Occasionally used in place of a carrier or a
  shelf.
• A vertical carousel is a storage device with a
  fixed shelf height that rotates vertically. Take
  a peek at this enclosed small Ferris wheel.

www.verticalcarouselsaustralia.com.au
14
Shelf
In a system, a shelf is a separate storage place.
It's sometimes used instead of a tray or a
carrier when neither is available.
www.verticalcarouselsaustralia.com.au
15
Vertical Lift Module / VLM
Vertical Lift Module is an automated storage
system with adjustable shelf heights that
functions similarly to a tall storage system with
an elevator in the centre of two storage zones.
www.verticalcarouselsaustralia.com.au
16
Vertical Lift Sequencer / VLS

• For activities involving a high number of goods
  or parts SKUs, a vertical lift sequencer (VLS)
  can deliver the speed, efficiency, and precision
  required.
• VLS units act as a buffer between production and
  order fulfilment in distribution centres and
  warehouses.
• The VLS employs buffer sequencers to
  automatically separate fast-moving SKUs from
  palletizing station packages, allowing for the
  most efficient split-case picking.

www.verticalcarouselsaustralia.com.au
17
Vertical Storage System
A vertical lift module and a vertical carousel
are two automated storage devices that utilise
the cube.
www.verticalcarouselsaustralia.com.au
18
Warehouse Control System (WCS)

• A warehouse control system (WCS) receives
  real-time data from material processing equipment
  and devices, as well as warehouse management
  system (WMS) software, in order to appropriately
  direct and supervise automated material handling
  and operations within the storage facility..
• WCS integrates with WMS/ERP systems to manage
  automation equipment in warehouses and
  distribution centres. The software is used to
  connect the equipment to the client's WMS/ERP
  system.

www.verticalcarouselsaustralia.com.au
19
Warehouse Management System (WMS)

• A WMS (Warehouse Management System) is software
  that aids in the management of storage
  facilities.
•
• A warehouse management system manages the
  transportation and storage of goods within a
  warehouse (WMS).
• Picking and storage, as well as shipping and
  receiving, are all handled by the WMS.

www.verticalcarouselsaustralia.com.au
20
Warranty

• All new installations are backed by a
  manufacturer's warranty and are maintained by
  factory-trained technicians.
• Select pre-owned material handling equipment
  from Outsource Equipment Company comes with an
  extended warranty (some restrictions apply).

www.verticalcarouselsaustralia.com.au
