Dedicated Outdoor Air System

1
RTU-FA DOAS
Dedicated Outdoor Air System
2
Proudly Introducing FLOAIRES

• Dedicated Outdoor Air System
• Air Volume 400 12,000 cfm
• Maximum SP 6.5" wg. _at_ standard air density

3
FloAire- Raising the bar in DOAS
4
RTU-FA DOAS

• This DOAS system has a Danfoss variable speed
  inverter scroll compressor with VFD
• Mixed air temperature/humidity sensor measures
  outdoor, return, mixed, discharge and space air
• 2 metal mesh outdoor air filters

5

RTU-FA DOAS

• Low leakage outdoor air damper, includes
  integrated louver and bird screen assembly,
  exceeds AMCA Class 1A leakage standards
• Wide staggered indoor coil design

6
(No Transcript)
