In-Place Strength Without Testing Cores
The Pullout Test
Prepared By
Nicholas J. Carino, PhD Consultant, Chagrin
Falls, OH, USA
www.sigmatest.org
1
2
Current Practice for Acceptance Testing of
Concrete

• Standardized testing of specimens made from
  concrete delivered to the project
• Standard consolidation
• Standard curing
• Provides assurance that correct concrete was
  delivered
• Indicates potential strength
• Does not account for actual consolidation and
  curing

www.sigmatest.org
2
3
Future Performance-Based Specifications

• Measure in-place properties of concrete to
  ensure structure will perform as intended
• Methods for estimating in-place strength

• Testing drilled cores

High cost

• Rebound number method
• Probe penetration test
• Ultrasonic pulse velocity

Requires correlation testing for each concrete
mixture Reliable estimates

• Pullout test

www.sigmatest.org
3
4
Outline

• Explain pullout test
• Strength correlation and failure mechanism
• Describe CAPO-Test
• Case study
• Summary

www.sigmatest.org
4
5
Pullout Test
ASTM C 900

• Measure force to pullout an insert anchored in
  concrete.
• Cast-in-place (CIP) LOK-Test
• Post-installed (PI) CAPO-Test

www.sigmatest.org
5
6
CIP-Pullout Test

• 25 mm
• Insert
• 25 mm
• Formwork

Insert
www.sigmatest.org
6
7
CIP-Pullout Test
Insert
ternsI
55 mm
Pullout Force
Reaction Ring
www.sigmatest.org
7
8
CIP-Pullout Test
Insert
Insert
Pullout Force
Reaction Ring
www.sigmatest.org
8
9
Pullout Test
COMA-meter
Apply Pullout Load Conical Fragment
www.sigmatest.org
9
10
Estimate Concrete Strength
100 80 60 40 20 0
Compressive Strength, MPa
10 20 30 40 50 60 70 80 Pullout Load, kN
0
www.sigmatest.org
10
11
Correlation Testing ACI 228.1R

• Prepare cylinders (or cubes) for standard
  compressive strength testing
• Prepare 200-mm cubes with inserts
• Cure all specimens under same conditions

www.sigmatest.org
11
12
Correlation Testing

• At ages of 1, 2, 3, 7, 14 and 28 days
• Test 2 cylinders (or cubes) for compressive
  strength
• Perform 8 pullout tests (2 cubes)

200 mm
200 mm
www.sigmatest.org
12
13
Example of Correlation
35 30 25 20 15 10 5
Cylinder Strength, MPa
10
15
25
30
20 Pullout Force, kN
www.sigmatest.org
13
14
Why is there a correlation?

• Analytical studies of pullout test have been
  done
• Plasticity theory
• Compression-strut theory
• Aggregate-interlock theory
• Pullout strength is related fundamentally to
  concrete strength

www.sigmatest.org
14
15
Pullout Failure Mechanism
Compression strut theory
www.sigmatest.org
15
16
Pullout Failure Mechanism
Compression strut theory
www.sigmatest.org
16
17
Compression Strut
www.sigmatest.org
17
18
Robust Correlation

• Not affected by
• Type of cementitious materials
• Water-cement ratio
• Age
• Air entrainment
• Types of admixtures
• Shape or size of normal density aggregate up to
  40 mm
• Lightweight aggregate, however, produces
  significantly different correlation

www.sigmatest.org
18
19
Cube Strength Correlations
120
Johansen - LOK core Gerhard - LOK Winden - LOK
Winden - LOK Bellander - CAPO core Bellander -
LOK core Bellander - CAPO Bellander - LOK
Worthers - CAPO Moczko - CAPO core
1.16
f 0.76 F
cube
Cube or Core Strength, MPa
100
80
Price - LOK
60
Price - LOK General Correlation
40 20 0
0
10
20
60
70
80
30 40 50 Pullout Force, kN
www.sigmatest.org
19
20
Cylinder Strength Correlations
120 100
f 0.69 F1.12
Cylinder Strength, MPa
cyl
Gay - LOK Bick ley - LOK Krenchel - LOK
Krenchel - CAPO Krenchel - LOK Jensen - LOK
Drake - LOK Drake - LOK Poulsen - LOK
Kierkegaard - LOK Lekso - LOK Lekso - LOK
Krenchel - LOK Krenchel - CAPO McGee - LOK
Bickley - LOK AEC - LOK CAPO Obla - LOK
General Correlation
80 60 40 20
0
0
20
80
100
40 60 Pullout Force, kN
www.sigmatest.org
20
21
Manufacturers General Correlations
100
Compressive Strength, MPa
f 0.76 F1.16 cube
80
60
f 0.69 F1.12
cyl
40
General Correlations for Cylinder and Cube
Strength
20
0
0
10 20 30 40 50 60 70 80 Pullout Load, kN
www.sigmatest.org
22
Post-Installed Pullout Test CAPO-Test

• Does not require pre-planning test locations
• Can perform test at any accessible location
• Permits testing of existing structures
• Immediate test results compared with cores

www.sigmatest.org
23
Prepare Concrete
Plane surface Drill hole
18 mm
25 mm
Cut slot
25 mm
www.sigmatest.org
24
Surface Planing
www.sigmatest.org
25
www.sigmatest.org
26
Cut Slot
3.5 mm
25 mm
www.sigmatest.org
27
Cut Slot
www.sigmatest.org
28
Cut Slot
www.sigmatest.org
29
Insert Expansion Cone and Coiled Split-Ring
Coiled ring
Cone
www.sigmatest.org
30
Ring Expansion Hardware
Bevel
www.sigmatest.org
31
Expand Ring
Nut
www.sigmatest.org
32
Pullout the Expanded Ring
www.sigmatest.org
33
www.sigmatest.org
34
CAPO-Test vs LOK-Test
70
CAPO bLOK
60 50 40 30
Value Error
b 1.0038 0.0051703
Chisq 112.19 1.3 kN
R 0.99593
CAPO-Test Load, kN
Krenchel Bellander Best-fit line
20
10
0
30 40 LOK-Test Load, kN
0
10
20
50
60
70
www.sigmatest.org
35
Case Study
November/December 2016
www.sigmatest.org
36
Polish Bridge Study

• Tested 15 bridges ages 25 to 52 years
• Measured depth of carbonation (2 to 35 mm)
• Tested drilled cores with L/D 1 to represent
  cube strength
• Conducted companion CAPO tests
• Used manufacturers correlation to estimate
• cube strength from CAPO-Test
• Investigated effect of carbonation depth

www.sigmatest.org
37
Correlation
60 Core Strength
Best fit curve f 0.77F1.15
50
core Upper Confidence Limit Lower Confidence
Limit General Correlation f 0.76F1.16 cube
Core Strength, MPa
40
30 20 10
15 20 25 CAPO-TEST, kN
0 0
5
10
30
35
40
www.sigmatest.org
38
Relative Error
? Estimated Cube Strength ? Core Strength ?100
Core Strength
?
CT
www.sigmatest.org
39
Summary for 15 Bridges
Bridge No. Carbonation depth, mm Average core strength, MPa Average CAPO-TEST, kN Estimated compressive strength, MPa Relative error, aCT,
1 2 34.2 28.1 36.4 6.4
2 4 24.7 21.4 26.6 7.7
3 5 46.4 37.3 50.6 9.1
4 5 34.2 28.7 37.3 9.1
5 7 37.1 27.5 35.5 -4.3
6 7 42.0 30.1 39.4 -6.2
7 7 37.5 29.2 38.1 1.6
8 8 35.4 28.3 36.7 3.7
9 10 42.4 30.6 40.2 -5.2
10 19 33.3 24.9 31.7 -4.8
11 20 29.7 24.6 31.2 5.1
12 20 28.5 24.3 30.8 8.1
13 22 31.7 26.1 33.4 5.4
14 26 31.7 26.5 34.0 7.3
15 35 19.6 16.4 19.5 -0.5
39
www.sigmatest.org
40
Error vs. Carbonation Depth
20 15 10 5 0 -5
Relative Error,
Linear Fit
-10
Error
Value
3.2683 2.5763
Intercept
0.15923
-0.033116
Slope
-15
NA
441.56
Sq. Error
NA
R 0.057588
-20
15 20 25 Carbonation Depth, mm
0
5
10
30
35
40
www.sigmatest.org
40
41
Summary

• Pullout test offers the possibility of estimating
  in-place concrete with acceptable reliability
• Stress state created by reaction ring leads to a
  compression strut that explains the good
  correlation with compressive strength
• CAPO-Test allows testing without pre-placing
  inserts
• Polish bridge study
• On average, CAPO-Test estimate was 3 greater
  than core strength
• Carbonation did not appear to affect CAPO-Test
  results
