HOW DO YOU DO MECHANICAL SEAL SETTING COMPRESSION?

1

• Leak Pack - https//leakpack.com/

2
HOW DO YOU DO MECHANICAL SEAL SETTING COMPRESSION?

• The compression set test is the rubbers ability
  to come back to its original thickness or shape.
• It is tested after squeezing it for a long time.
• These tests are conducted at high temperatures
  because they want to simulate real working
  conditions.
• Performance of the end rubber part is recorded
  after the test.
• Each rubber type has to be tested under a
  specific temperature and for a particular time.
• There could be a variation if it is a specific
  need.

3
HOW DO YOU DO MECHANICAL SEAL SETTING COMPRESSION?

• Due to constant compression load, physical change
  happens in elastomeric material.
• It cannot return to its original size after
  release.
• The amount of material that cannot return to its
  original size is called a compression set.

4
HOW DO YOU DO MECHANICAL SEAL SETTING COMPRESSION?

• Both static and dynamic seals find this kind of
  failure.
• Due to the compression set failure flat surfaces
  produce on both sides of the O-rings
  cross-section.
• It reduces the sealing potential and efficiency.

5
What is the reason behind compression set
failure?  Here are some of the causes.

• The choice of elastomer is incorrect. It has poor
  compression set properties.
• The material shows low heat resistance.
• There is excessive swelling of material in the
  system fluid
• Excessive squeeze is needed to achieve the seal
• Vulcanization or incomplete curing of O-ring
  material during production

6
What could be the solutions if you experience a
compression set. Here are some solutions.

• Use of low set elastomer
• Use of O-ring material that resists heat
  generated due to operation and friction
• Check the compatibility of the material with
  system fluid and chemicals
• Reduction in O-ring squeeze as much as possible
• Checking O-rings for right physical properties

7
What could be the solutions if you experience a
compression set. Here are some solutions.

• It is essential to set formulas for calculating
  the minimum and maximum O-ring compression.
• When you are stuck somewhere, the best thing is
  to ask some expert.
• Nowadays, it is easy to get help online.
• Enroll into some authentic site and get the
  desired information.

8
Choosing the right material is the key for seal
setting

• You should understand how the elastomeric
  material will behave when you select the
  material.
• There are several elastomers in cellular and
  solid formats.
• You can pick one by picking the most appropriate
  methods and by knowing the fundamental properties
  of the material.

9
What could be the solutions if you experience a
compression set. Here are some solutions.

• The process of selection can be made easy by
  reducing the choices based on the above research.
• Once it happens then a solution development
  process can be initiated around the particular
  application.
• It involves mating surfaces that are supposed to
  be sealed.
• Other parameters are airflow, pressurized air,
  gases, fluids, and so on.
• The surfaces will affect the choices.

10
What could be the solutions if you experience a
compression set. Here are some solutions.

• Leak-Pack is ISO 90012008 certified
  company and leading mechanical seals manufacturer
  supplier in India, providing solutions to all
  types of leakages by manufacturing Mechanical
  Seals and Sealing Components as per customers
  drawings, samples or requirements.
