Best Transformer manufacturer and supplier in India

1
Introduction To Transformer
Submitted By Komal Designation Digital
Marketing
2
INDEX

• Introduction to Company
• Introduction to Transformer
• Construction of Transformer
• Types of Transformers
• Maintenance

3
our Muskaan Power Transformer Manufacturer is
One of Leading Brand in India. It was Established
in 2003. We are the best transformer
manufacturer, supplier and exporter in India. Mr
Neeraj Mahajan and Mr. Ravi Mahajan are the
Director of this company. we are achieving the
maximum trust hold of clients.
Introduction To Company
4

• Introduction To Transformer
• A Transformer is a static electrical machine
  which transfers AC electrical power from one
  circuit to the other circuit at the constant
  frequency, but the voltage level can be altered
  that means voltage can be increased or decreased
  according to the requirement.
• Transformer Parts And Construction
• The three main parts of a transformer
• Primary Winding of Transformer
• Magnetic Core of Transformer
• Secondary Winding of Transformer

5

• Construction Of Transformer
• The transformer mainly consists of the Magnetic
  circuit, electric circuit, dielectric circuit,
  tanks, and accessories. The main elements of the
  transformer are the primary and secondary
  windings and the steel core.
• Magnetic circuit
• The magnetic circuit of a transformer consists of
  core and yoke. The circuit provides the path to
  the flow of magnetic flux.
• Electric circuit
• Construction of the electric circuit of the
  transformer consists of primary and secondary
  windings usually made of copper.

6

• Types of Transformer
• Distribution Transformer
• Corrugated type Transformer
• Dry type Transformer
• Power Transformer
• Single Phase Power Transformer
• Oil Immersed Power Transformer

7
Distribution Transformer A
distribution transformer or service transformer is
a transformer that provides the final voltage
transformation in the electric power distribution
system, stepping down the voltage used in the
distribution lines to the level used by the
customer.

www.muskaanpower.com
8
Corrugated Type Transformer Transformer
s with corrugated walls are compact compared
to transformers with radiators, thus reducuting
the space for installation.  ww
w.muskaanpower.com
9
Dry Type Transformer A dry type
transformer is a type of transformer which never
uses any insulating liquid where its winding or
core are immerged in liquid.
www.muskaanpower.com
10
Power Transformer A Power
Transformer is a static machine used for
transforming power from one circuit to another
without changing frequency. This is a very basic
definition of transformer. www.m
uskaanpower.com
11
Single Phase Power
Transformer A single-phase transformer is a type
of power transformer that utilizes single-phase al
ternating current, meaning the transformer relies
on a voltage cycle that operates in a unified
time phase. www.muskaanpower.co
m
12
Oil Immersed Transformer Oil
immersed transformer, also called oil filled trans
former, is a kind of voltage transformation
device utilizing oil cooling method to reduce
the transformer temperature. www
.muskaanpower.com
13

• Maintenance
• Oil level in the oil cap must be checked on a
  monthly basis so that it doesnt drop below a
  fixed limit and hence avoid damage due to it.
• Keep the breathing holes in the silica gel
  breather clean to ensure proper breathing action
  at all times.
• If your electrical transformer has oil filling
  bushing, make sure that the oil is filled up to
  the correct level.

14
