Automated Multilevel Car Parking Systems By Wohr Combiparker 555

1
Automated Multilevel Car Parking Systems by Wohr
- Combiparker 555

• Wohr Parking Systems

www.wohrparking.in
2

• Wohr Parking Systems (WPS) is the leading
  manufacturer of Automated Multilevel Car Parking
  Systems.

www.wohrparking.in
3

• Automated Multilevel Car Parking Systems -
  Combiparker 555 With the tried and tested
  principle of stacking and moving closer together,
  Combiparker 555 creates even more space.

www.wohrparking.in
4
Our Products As

• Combiparker 555

www.wohrparking.in
5

• Combiparker 555

www.wohrparking.in
6
Other Combiparker Products

• Combiparker 556

www.wohrparking.in
7

• General Description of the System
• The Combiparker CP555 is Automatic Car Parking
  System with very high level of space saving
  concept. The system comprises of vertical parking
  system with maximum eight levels. The cars are
  parked in parking levels with a specially
  designed adjustable sliding carrier units. The
  transport lift which take the car up and down is
  located in every second grid of the system.
• The system can have minimum three grid with
  eight levels up to maximum seven grids with five
  levels. The appropriate solution can be worked
  out considering the car parking requirements and
  the available foot print area. The transport lift
  grid also serve as the entrance and exit for car
  parking.

www.wohrparking.in
8

• Typical Park In Operation
• Driver has to flash the given RFID card or Chip
  to the sensor to activate the parking process.
  The lift door is opened for park in operation.
  After parking the car in the lift, driver has to
  flash the card again as per the instructions.
• The lift car door gets closed and car is
  transported vertically to the required level. The
  car is transferred from lift platform to parking
  platform in the lift grid. Parking platform moves
  to its original position with the car. The lift
  is moved to its home position and be ready for
  next operation.

www.wohrparking.in
9

• Typical Park Out Operation
• Driver has to flash the given RFID card or Chip
  to the sensor to activate the parking process.
  The platform with the car is moved laterally to
  the lift grid. The car is shifted from parking
  platform to lift.
• The car is lowered down to entry level by
  transport lift. The door is open for driver to
  drive out the car. Once the car is taken out, the
  sensor system is activated for door closure and
  system is ready for next operation.

www.wohrparking.in
10
www.wohrparking.in
11
www.wohrparking.in
12
Highlights

• Variable arrangement of 3-7 grids beside one
  another
• Different car heights are possible at different
  level
• Carrying capacity per platform / per car
  available with 2600kg
• Independent parking systems
• Cost-effective technology using state-of-the-art
  servo drives and laser based guidance systems

www.wohrparking.in
13

• High level of operating and functional safety
  according to EN norms
• Easy operation
• Quick parking and retrieval cycle time
• Modular design to suit the space availability at
  site
• Suitable for residential commercial, Car dealers
  and malls

www.wohrparking.in
14
Contact Us

• Regd. Office
• Vyas Vertex', 1206/41A, J.M. Road, Shivaji Nagar,
  Pune - 411 004. Maharashtra, India
• Tel [phone] / 82 / 66012470Fax
  91-20-2553 6184E-mail info_at_wohrparking.in
