What Is Fuel Module?

1
FUEL MODULE(FUEL FILTRATION)
Fleetguard Filters Private Limited
Proprietary Information
2
Fuel Modules

• What is a Module?
• The module is a subsystem integrating filtration
  cartridge, usually for liquid filtration (not
  used for air filtration or CV). It is designed to
  serve multiple functions required in fuel
  filtration system such as fuel water separation,
  water draining, air venting, fuel pumping,
  by-pass filtration etc. It also works as a
  Pressure Temperature sensor device.
• Why opt for Modules?
• Inefficient fuel filtration can lead to wear of
  injector components. Over fueling, deposits,
  elevated nozzle wear, reduced performance and a
  drop in fuel efficiency. With the current
  stringent emission norms and economy, Fleetguard
  fuel filtration provides excellent shield for all
  fuel system components and enhance engine
  performance..
• Advantages with Fuel Modules
• Extended service interval
• Efficiently removes hard particles
• Flexibility for technology upgradation
• Engine Integrity Protection opportunity
• Competitive design for application works in
  severe conditions
• Environment friendly
• Options for integrating additional features

Proprietary Information
3
Proprietary Information
4
FUNCTIONS OF FUEL MODULES

• Resistance from contamination present in the
  surrounding
• Separates drains water out of the system
• Measures fuel pressure fuel temperature
• Measures water content present in fuel
• Connects fuel circuit internal components
• Plugging Indication on dashboard
• Extended service intervals

Proprietary Information
5
FLEETGUARD FUEL MODULES
Proprietary Information
6
FUEL FILTRATION By Fleetguard Filters Private
Limited For more information visit
www.fleetguard-filtrum.com
