• Transformer oil is mainly used in the electrical
  industries. Sometimes different types of
  impurities entered into the transformer oil. And
  it is the cause to damage a transformer. So
  testing of transformer oil is important. In this
  slide we can know the top 3 method to test
  transformer oil. These methods can help to detect
  the problem of transformer oil and can find out
  the solution of problem.

3
Methods to Test Transformer Oil

• The top 3 methods to test transformer oil. They
  are oil type test, routine test of transformer
  oil, and special testing of transformer oil.
• 1) Oil type test The first method to test
  transformer oil is oil type test. There are
  different types of test for different types of
  transformer oil. At first we have to know that,
  which type of oil is it in the transformer . It
  may be paraffinic-based transformer oil,
  naphthenic-based transformer oil,or bio-based
  transformer oil etc. Some tests are mentioned in
  below
• Vacuum test Viscosity testing
• Tap charger testing
• Winding resistance testing
• Insulation resistance testing
• Short Circuit Impedance
• Temperature rise test

4

• 2)Routine test in transformer oil Routine test
  of transformer oil in transformer oil is the
  testing in which two component mainly test before
  starting the working. Some routine test of
  transformer are
• Can open circuit test
• Measurement of impedance voltage
• Vector group test
• Testing of specific resistance
• Measure winding resistance
• Oil pressure testing
• Oil leakage testing
• Transformer ratio testing
• Dielectric test

5

• 3)Special Testing of transformer oil Special
  testing of transformer oil is used under the
  physical and chemical industry. This test of
  transformer oil used in a particular gravity and
  in particular whether climates. There are some
  parameters included in the tests
• Testing of the noise level
• The measure of zero sequence impedance
• Testing harmonic current or no load current
• Dielectric strength testing
• Measurements of power level taken by due to a
  lamp
• Test three phase transformer
• Short circuit or open circuit testing
• Component testing
• Temperature indicators
