Porsche 997 turbo upgrade

• Contact Information https//markskituning.com
• Mail id- info_at_markskituning.com,
• Address-7139 N. SIOUX CT.CHICAGO, ILLINOIS
  60646, USA
• The Porsche 997 turbo is an exceptional piece in
  the field of automotive engineering and it is
  proved by its years of success in the market
  place and its history of winning and dominating
  in the many racing series and competitions around
  the world.
• As such upgrades to this wonderful car must be
  approached a bit differently than other vehicles.
  The way the several components and systems of the
  car are well designed and its function is a
  little bit different than the particular every
  day car and as a result it needs some expert
  knowledge and understanding to perform Porsche
  997 turbo upgrade and to do proper maintenance on
  these vehicles. Here we'll talk about the Porsche
  997 clutch and related repairs.

2

• For instance the 997 clutch system in this car is
  not similar to other vehicles on the market. The
  clutch on the Porsche 997 turbo is assisted
  hydraulically so that the pedal effort does not
  change even when high clamping load pressures
  plates are installed. The prime difference in
  this system in comparison to other types of cars
  is in the slave cylinder design. The hydraulic
  assist system in this car works by using the
  high-pressure circuit of the power steering
  system to charge an accumulator that's a
  significant part of the slave cylinder assembly
  in order to lower the effort needed to operate
  it.
• A good and complete understanding of this system
  is necessary in order to perform work such as
  clutch component replacement correctly and
  according to factory specs.
• Another main difference in the way the clutch
  system works in the 997 turbo in comparison to
  other types of cars is the pressure plate release
  mechanism. The prime and most common way of
  pressure plate release operation is the mechanism
  of push-type while on the Porsche 996 turbo it is
  a pull-type.

3

• While this may sound like a very small and minor
  detail, it isn't so as the method required to
  detach the gearbox from the engine is very
  different. The most difficult and the biggest
  aspect of the job become removing and
  reinstalling the pivot pin that the release lever
  attached to the throw-out bearing operates on.
  This pin must be removed before the gearbox could
  be detached, and must be put in during the
  assembly after the engine and gearbox have been
  mated.
• If you have ever seen this assembly you would
  understand how difficult is it to line up the
  holes on the release lever with the ones on the
  bell-housing as there is no way to actually see
  them and must be done by feel. Furthermore the
  pin has roller bearings on both ends which house
  small steel rollers inside and can slide off the
  shaft if it is pulled back during insertion. If
  this happens the gearbox will need to be removed
  again in order to retrieve the rollers and
  assemble the bearings.

4

• Here at Markskituning.com we have expert
  knowledge of these systems along with the needed
  and indispensible experience to carry out work of
  this nature and as the premier performance shop
  we exactly know what to do and how to do it in
  the right way. We assure you that your Porsche
  will be in the best possible care with us. Get
  your Porsche 997 turbo upgrade done here.
