About Us

• Incepted in the year 2015, 4M Automation is a
  distinguished manufacturer and service
  provider offering an enormous consignment of Leak
  Test Machine, Plastic Welding Machine, Product
  Assembly Machine, Quality and Performance Testing
  Machine, Poka Yoke Machine, Validation Test
  Machine and Jigs and Fixture Designing Services.
•  Immensely acclaimed in the industry owing to
  their preciseness, these are presented by us in
  standard and modified forms to our clients. To
  add, only optimum class material is utilized in
  their production. These presented by us in
  various provisions, these are inspected sternly
  to retain their optimum quality.

3
Leak Test Machine

• Leak test machines with Positive pressure,
  Negative pressure or Flow based technologies.
• Our machines are used for testing automobile Air
  Filters, Lights, Tanks, Hoses Pipe lines etc.
• We have developed our own Leak Test Controller,
  thats why we can make low cost machines

4
Infrared Welding Machine Or IR Welding Machine

• With Infrared plastic welding machine, we can
  save Electrical Power Consumables cost.
• We can achieve hi Pull-load strength and leak
  resistance of welded parts.

5
Hotplate Welding Machine

• 4m Automation offered Hotplate Welding Machine.
• Welding table Size Width 400mm X Length 600mm
• Day Light 400mm
• SSR Heater control
• PLC control
• Part sensors for fool proof production
• Light curtain for safety
• MS pipe structure with powder coating
• Air Pressure interlock
• Quick change fixtures
• Servo option with HMI height adjustment

6
Heat Staking Machine

• 4m Automation has developed its own Hot staking
  head
• These work on Hot-Cold principle. As a result, we
  get a perfect Button formation, Material does not
  stick to the Staking head.
• The machine is designed with SMED thought
  process. So the Tool change over takes less than
  5 minutes.
• Heating time 5 Minutes
• Light curtain for safety
• Part presence Poka-Yoke
• Air Pressure Interlock
• Temperature Interlock

7
Hot Insertion SPM

• 4m Automation has made insertion machines with
  Convection heating Induction heating
  technologies.
• The Stud insertion machine, can insert 2 Studs
  simultaneously.
• The CD can be maintained between 0.05mm

8
Special Purpose Machines (SPM)

• 4m Automation offered Special Purpose Machines
  .Punching, Crimping, Pressing, Stamping,
  Shearing, Drilling, Riveting, Screw Driving,
  Staking, Marking, Welding Vending, Dispensing,
  Spraying, Heating, Curing.

9
Vision Inspection Machine Or Sorting Machines

• Vision Based Inspection Machines for following
  activities
• Product sorting
• Dimension, Measurement
• Absence Presence
• Color Identification
• We have made machines with Smart Cameras and PC
  Based Cameras.
• Inspection machine with up to 4 cameras for one
  application

10
Plastic Punching SPM

• 4m Automation offered Plastic Punching SPM.
• Plastic Part Hole Punching and shearing machines
• With a bed size of 2000X1600mm
• Punching with Servo, Hydraulic, Pneumatic
  Hydro-pneumatic Presses
• Safety interlocks of light curtain, Bi-hand
  operation
• Alarms for Low Pressure, Part absent, wrong part
  etc.
• PLC based machine function control
• CNC machined holding fixtures
• Hybrid machine structure with MS Square pipe
  Aluminium extrusion profiles to maintain
  robustness aesthetics

11
UV Curing Oven Or Ultraviolet Curing

• 4m Automation offered UV Curing Oven or
  Ultraviolet Curing.
• UV Curing systems for Adhesives Coatings
• Robotic Dispensing of UV Coating
• Safety shrouds, Light curtains and door
  interlocks
• UV Source Protection facility against physical
  electrical Parameters
• Automatic Loading/Unloading facility of product
• Conveyorised or batch ovens
• Fully automatic PLC based control, HMI for
  parameter settings Display

12
Performance Test Machines Or Endurance Test
Machines

• 4m Automation offered Performance Test Machines
  or Endurance Test Machines.
• Testing of Physical, Electrical parameters
• Machines for checking product Life cycle test or
  100 on-line checking
• Fully automatic PLC based control, HMI for
  parameter settings Display

13
Contact Us

• 4M Automation
• Email ID bharat_at_4mautomation.in
• Mob No 9011963979
• Address SCO-12, Shivraj Industrial Complex,
• Near Vishveshwar Chowk, Sec -7,
• MIDC Bhosari, Pune, India.
