Air Bubble Sheet and Roll Manufacturer India

1
WELCOME TO AEROLAM INSULATIONS
2
AEROLAM PACKAGING

• AIR BUBBLE FILM
• UV STABILIZED AIR BUBBLE FILM
• FIRE RETARDENT AIR BUBBLE FILM

3
AIR BUBBLE FILM
Air Bubble Sheet / Rolls are available in 1mtr
and 1.2mtr width .Standard Length of the Roll is
100mtrs and Bubble dia is 10mm X 4mm
Height. Material is available in various
thickness, from 50gsm to 160gsm.
Bubble Diameter 10mm X 4mm H
Water Absorption 0.02 after 24hrs.
Chemical Resistance Excellent
Service Temp. 8 C to 60 C
4
TECHNICAL FOR AIR BUBBLE SHEET
Gauge GSM Weight of 1mtr Roll Weight of 1.2mtr Rol
200 50 5.000Kgs 6.000Kgs
225 55 5.500Kgs 6.600Kgs
250 60 6.000Kgs 7.200Kgs
275 65 6.500Kgs 7.800Kgs
300 70 7.000Kgs 8.400Kgs
325 75 7.500Kgs 9.000Kgs
350 80 8.000Kgs 9.600Kgs
400 90 9.000Kgs 10.800Kgs
435 100 10.000Kgs 12.000Kgs
500 115 11.500Kgs 13.800Kgs
560 130 13.000Kgs 15.600Kgs
600 140 14.000Kgs 16.800Kgs
650 150 15.000Kgs 18.000Kgs
700 160 16.000Kgs 19.200Kgs
5
UV STABILIZED AIR BUBBLE FILM
Air Bubble Sheet / Rolls are available in 1mtr
and 1.2mtr width . Standard Length of the Roll
is 100mtrs and Bubble dia is 10mm X 4mm
Height.Material is available in various
thickness, from 50gsm to 160gsm.
Bubble Diameter 10mm X 4mm H
Water Absorption 0.02 after 24hrs.
Chemical Resistance Excellent
Service Temp. 8 C to 60 C
6
TECHNICAL FOR UV STABILIZED BUBBLE FILM
Gauge GSM Weight of 1mtr Roll Weight of 1.2mtr Rol
200 50 5.000Kgs 6.000Kgs
225 55 5.500Kgs 6.600Kgs
250 60 6.000Kgs 7.200Kgs
275 65 6.500Kgs 7.800Kgs
300 70 7.000Kgs 8.400Kgs
325 75 7.500Kgs 9.000Kgs
350 80 8.000Kgs 9.600Kgs
400 90 9.000Kgs 10.800Kgs
435 100 10.000Kgs 12.000Kgs
500 115 11.500Kgs 13.800Kgs
560 130 13.000Kgs 15.600Kgs
600 140 14.000Kgs 16.800Kgs
650 150 15.000Kgs 18.000Kgs
700 160 16.000Kgs 19.200Kgs
7
FIRE RETARDENT AIR BUBBLE FILM
Air Bubble Sheet / Rolls are available in 1mtr
and 1.2mtr width .Standard Length of the Roll is
100mtrs and Bubble dia is 10mm X 4mm Height.
Material is available in various thickness, from
50gsm to 160gsm.
Bubble Diameter 10mm X 4mm H
Water Absorption 0.02 after 24hrs.
Chemical Resistance Excellent
Service Temp. 8 C to 60 C
8
TECHNICAL FOR FIRE RETARDANT AIR BUBBLE FILMS
Gauge GSM Weight of 1mtr Roll Weight of 1.2mtr Rol
200 50 5.000Kgs 6.000Kgs
225 55 5.500Kgs 6.600Kgs
250 60 6.000Kgs 7.200Kgs
275 65 6.500Kgs 7.800Kgs
300 70 7.000Kgs 8.400Kgs
325 75 7.500Kgs 9.000Kgs
350 80 8.000Kgs 9.600Kgs
400 90 9.000Kgs 10.800Kgs
435 100 10.000Kgs 12.000Kgs
500 115 11.500Kgs 13.800Kgs
560 130 13.000Kgs 15.600Kgs
600 140 14.000Kgs 16.800Kgs
650 150 15.000Kgs 18.000Kgs
700 160 16.000Kgs 19.200Kgs
9
AEROLAM- Air Bubble films offers

• Better Cushioning
• Longer Lasting Protection
• Reduced Packaging Cost
• Reusable/recyclable
• Provides a complete protective enclosure.
• Air bubble construction absorbs heavy impact
• Easily wraps around odd-sized, irregular shaped
  items.
• Flexible and Tenacious

10
Application of AEROLAM-AIR BUBBLE FILM

• Disposable Sleeping sheets
• Padding thermal insulator under carpets
• Application in the medical field in UK due to
  its cushioning thermal insulation properties,
  the film is used to cover the wounded portion of
  persons involved in road accidents. To cover New
  Born babies to regulate their body temperature.
• Excellent sound insulation properties. Ideal in
  creating sound insulated rooms (usually temporary
  locations not for professional applications)

11
Click Here For Aerolam Packaging
12
Thank You For More Information Visit Our Website.
