Know All About Flange Mount Bearing

1
Flange Mount Bearing
2
About Flange Mount Bearing
Flange mount bearings are a form of bearing unit
that supports heavy loads when the shaft axis is
perpendicular to the mounting surface.
3
It is a rigid housing which allows the unit to
rotate within a stable and carefully controlled
environment. The housing is bolted to the
foundation of the unit, and allows the outer ring
to stay still while the inner ring is able to
freely rotate.
4
How to Select flange mount bearings
When selecting flange mount bearings, there is
something to consider as following
Maximum speed It is the high speed the flange
mount bearing can safely function at before
failure. Bearing life It is also known as the
rating life L10, a statistical measure of the
life which 90 of a group of apparently identical
ball bearings will achieve or exceed.
5
Bearing load It is a combination of radial loads
and thrust forces. Basic dynamic load rating.
It is a calculated, constant radial load.
Engineering load It describes the effect of
reaction loads on the flange mount bearings.
6
Applications of Flange Mount Bearings
Flange mount bearings can be used for many
applications rotary motor, micro-motor soft
drive, pressure rotor dental drill, hard drive
motor transmission equipment, entertainment
equipment, robotics, medical equipment,
electrical optics, imaging devices, card readers,
precision machinery, power tools, food processing
machinery, textile, baggage systems, and various
other light duty industrial applications.
7
Riccotek  ADD Unit 602, Bldg47, Yindou NanLi,
Jimei District. Xiamen, China 361021 TEL 86
592 5759801 FAX [phone] Website
http//www.riccotek.com/flange-mount-bearing-c-48.
html
